navigation MERCEDES-BENZ G-Class 2008 W463 Comand Manual

103 Navigation
Important notes
Navigation main menu
Destination input
Route guidance
During route guidance
Last destinations and destination memory
POIs
Today’s plan
Software updates

104 Navigation
Important notes

Important notes
WarningG
For safety reasons, you should only enter a
destination when the vehicle is stationary.
When the vehicle is in motion, a passenger
should enter the destination. Study manual
and select route before driving.
Do not watch display screen or operate but-
tons while the vehicle is in motion - let voice
instructions guide you. Stop at a safe locati-
on before using buttons or making correc-
tions.
Traffic regulations always have priority over
any route recommendations given.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your car is co-
vering a distance of 44 feet (approximately
14 m) every second.
The route calculated by COMAND is a re-
commendation on how to best reach your
selected destination.
During route guidance, you will not receive
any information on
Traffic lights
Stop and yield signs
Parking or stopping zones
One-way streets
Narrow bridges
Similar traffic regulation data
You should therefore always strictly observe
traffic regulations while driving. Drive care-
fully and always obey traffic laws and road
signs even if they contradict COMAND in-
structions.
WarningG
The Navigation DVD module contains a
Class 1 laser product. There is a danger of
invisible laser radiation if the cover is ope-
ned or damaged.
Do not remove the cover. The Navigation
DVD module does not contain any parts ser-
viceable by the user. For safety reasons,
have any necessary service work performed
by qualified personnel.
The display unit can cause injury if contac-
ted when open. Return the display unit after
inserting a Navigation DVD to its closed
position (
page 166).

105 Navigation
Important notes
COMAND calculates the route with the
help of data that is stored on the navigati-
on DVD.
Only use Mercedes-Benz navigation DVDs.
Using other navigation DVDs or CDs will
cause malfunctions and/or damage.
Because of changes in local traffic patterns
(e.g. road works) and/or incomplete data,
errors in calculation may occur.
As a result, the recommended route may
deviate from the ideal route. The data
stored on the DVD only reflects local con-
ditions at the time of DVD production. DVD
maps do not cover all areas nor all routes
within an area.
Loading/ejecting a DVD
DVDs are loaded and ejected at the DVD
Navigation slot. The DVD Navigation slot is
located behind the display unit.
Open the display unit to get access to
the DVD Navigation slot as described in
“Starting an update” (
page 167).
Navigation DVD!
GPS (Global Positioning System) sig-
nals received make it possible to deter-
mine the current vehicle position.
Deviations from the actual position
may occur
if the reception of GPS signals is
disturbed e.g. in parking garages
and tunnels
if road conditions are bad
depending on the vehicle’s conditi-
on
i
There are two l buttons. One is on
the display unit. The other is located
left of the DVD NAVIGATION slot
behind the display (
page 166).

106 Navigation
Important notes
If your vehicle has been transported (e.g.
by a car, train or ferry) the system may
make navigation announcements which do
not correspond to the vehicle’s position.
The system needs to redetermine its
position.
Determining the location after the
vehicle has been transported
The system will need some time to
determine its location after the car has
been transported. The time required for
the system to do so varies from case to
case.
Switch the COMAND on.
Activate the Navigation main menu
(
page 108).
The navigation DVD needs to be in the
DVD NAVIGATION slot (
page 166).
Drive and press c.
Drive until the position or the road
indicated correspond to the real
circumstances. The system is now
correctly adjusted.
Route guidance after the vehicle has
been transported

107 Navigation
Important notes
The following applies if you interrupt your
trip and continue later on:
Trip is continued within 2 hours:
The system will automatically resume
route guidance.
Trip is continued after more than
2 hours:
Press E and confirm Continue
route guidance
in the
Navigation main menu
(
page 108).
Trip interruption during route
guidance
i
Trip interruption means the vehicle is
parked and COMAND is switched off.
Trip continuation means the vehicle is
moving and COMAND is switched on
again.

108 Navigation
Navigation main menu

Navigation main menu
Press b.
The Navigation main menu or the
current navigation screen (e.g. map
screen) will appear.
Navigation main menu
Push the joystick to g or G to
select a menu item.
Press E.
or
Press one of the soft keys.
The selected menu or the function of
the selected soft key appears.
Selectable Menu Items
Continue route guidance:
Resumes interrupted or aborted route
guidance.
Activating the Navigation main
menu i
If route guidance is active, a message
appears instead asking you whether
you wish to cancel route guidance
(
page 139).
If route guidance has been interrupted
for more than 2 hours, the entry
Continue route guidance will be
on top of the list.
i
This menu item appears if you:
have aborted route guidance
(
page 139)
have interrupted your journey and
continue it after more than 2 hours

109 Navigation
Navigation main menu
Destination memory
You can select destinations from the
Destination Memory (page 155).
Enter destination
Activates the Enter street menu
(
page 112).
Last destinations
You can select last destinations from
the
Last destinations memory
(
page 153).
Points of interest:
Brings you to the
Select point
category
menu (page 157).
POIs are e.g. gas stations, parking
facilities or airports.
Phone number:
You can select a POI by phone number.
Brings you to the
Enter POI phone
number
menu (page 161).
Today’s Plan:
You can select destinations from the
Today’s Plan list one after the other or
sort destinations as Bestway or Round
trip (
page 163).Available soft keys
Home soft key:
You can edit the home address and
start route guidance (
page 125).
Mode soft key:
You can edit the routing mode for the
next route guidance (
page 110).
Compass soft key:
You can display direction of travel,
altitude and steering angle of the
vehicle
(page 127).

110 Navigation
Navigation main menu
The COMAND calculates the route as
Fastest route.
Minimizing traffic routes
Press the Mode soft key
in the Navigation main menu
(
page 108)
in the Start route guidance menu
(
page 129)
in the Info menu (page 141).
The
Edit routing mode menu will
appear.
Selectable traffic routes
Minimize freeways:
The system calculates the route with/
without minimizing freeways.
Minimize toll roads:
The system calculates the route with/
without minimizing toll roads.
Minimize ferries:
The system calculates the route with/
without minimizing ferry connections.
Minimize tunnels:
The system calculates the route with/
without minimizing tunnels.
Push the joystick to g or G to
select a routing mode.
Press E.
Switches the option on or off. You can
switch on more than one option.
Press the Back soft key to confirm.
The setting is saved. The previous
navigation screen will appear.
Setting the routing mode
OptionSymbol
OnQ
Off q

111 Navigation
Navigation main menu
Press c.
The full view of the map appears. You
will see the vehicle’s current position.
Press any soft key.
The soft key displays will appear.
Press the Memory soft key.
The system saves the current position
as a destination in the
Last
destinations
memory
(
page 153).
Saving current locationi
Such destinations are marked in
the
Last destinations memory
with
_.
For permanent storage you can save
the destination in the regular
Destination memory (
page 154).

112 Navigation
Destination input

Destination input
Activating the Navigation main menu
(
page 108).
Push the joystick to g or G to
select the menu item
Enter
destination
.
Press E.
The Enter street menu will appear.
Enter street menu
You can use the following functions
entering a street name or accepting a
street name if already available
(
page 114).
changing the state/province
(
page 113).
or
entering a city (page 119).Available soft keys:
State soft key:
Brings you to the Select state/province
menu (
page 113).
City soft key:
Brings you to the Enter city menu
(
page 119).
List soft key:
Brings you to a list of streets beginning
with the previously input letters.
Delete soft key:
The character last entered is deleted.
Back soft key:
Returns you to the previous menu.
Activating the Enter street menu
i
The currently set state is identifed by
the state code in the middle of the
screen.
If the vehicle location is in Canada, this
soft key appears as
Province.
