110 Navigation
Navigation main menu
The COMAND calculates the route as
Fastest route.
Minimizing traffic routes
Press the Mode soft key
in the Navigation main menu
(
page 108)
in the Start route guidance menu
(
page 129)
in the Info menu (page 141).
The
Edit routing mode menu will
appear.
Selectable traffic routes
Minimize freeways:
The system calculates the route with/
without minimizing freeways.
Minimize toll roads:
The system calculates the route with/
without minimizing toll roads.
Minimize ferries:
The system calculates the route with/
without minimizing ferry connections.
Minimize tunnels:
The system calculates the route with/
without minimizing tunnels.
Push the joystick to g or G to
select a routing mode.
Press E.
Switches the option on or off. You can
switch on more than one option.
Press the Back soft key to confirm.
The setting is saved. The previous
navigation screen will appear.
Setting the routing mode
OptionSymbol
OnQ
Off q

111 Navigation
Navigation main menu
Press c.
The full view of the map appears. You
will see the vehicle’s current position.
Press any soft key.
The soft key displays will appear.
Press the Memory soft key.
The system saves the current position
as a destination in the
Last
destinations
memory
(
page 153).
Saving current locationi
Such destinations are marked in
the
Last destinations memory
with
_.
For permanent storage you can save
the destination in the regular
Destination memory (
page 154).

113 Navigation
Destination input
Press the State soft key
in the Enter street menu
(
page 112)
in the Enter city menu (page 119).
The Select state/province menu will
appear.
Select state/province menu
Push the joystick to g or G to
select a state.
Press E.
The Enter street menu will reappear
and shows the new state code in the
middle of the screen.
Toggling between State and Province
list
You can toggle between states in the USA
and provinces in Canada.
Push the joystick to H or h.
State of Hawaii
When on the mainland, you cannot choose
destinations in Hawaii, because these are
in a database separate from the USA/
Canada. Similarly, when in Hawaii, you cannot choose mainland destinations. The
message
You must change the state
or province in order to use that
destination
will appear in this case, if
such a destination is selected from the last
destinations memory (
page 153), the
destination memory (
page 155) or as
home address (
page 125).
Choose another state or province.
The warning message
This selec-
tion will restart the system.
Last destinations may not be
available, and today’s plan
will be erased. Do you wish to
continue?
will appear.
Push the joystick to H to select Yes.
Press E to restart.
Selecting the state/province
i
Use the State list for selecting states in
the USA and the Province list for
selecting provinces in Canada.
i
If you have already calculated a route,
you can toggle to the Last list, which
contains up to 5 last selected states or
provinces.
i
After such a restart, Today’s Plan
entries are all deleted. Destinations in
the previous area (for example in Last
Destinations) are kept so that you can
access and delete them.

114 Navigation
Destination input
Entering a street
In the Enter street menu (page 112)
push the joystick to
h, H, g or
G to select the characters. After each
selection, press
E.
Push the joystick to F or f to
select characters diagonally.
or
Press one of the number keys 1 to
9 and 0 to enter digits.
Press the Delete soft key if
necessary.
The character last entered by the
system is deleted.
Back to the previous menu
Press the Back soft key.
Confirming a street (menu)
Press E longer than 2 seconds.
or
Select the ( symbol. Push the
joystick to
h, H, g or G to do
so.
Press E.
Entering destination address
i
If you enter the first character, the
State and City soft keys disappear.
The status bar shows the number of
current matches.
i
For quicker input, COMAND offers
available characters from the character
set based on your selections and the
names of the streets stored on the
navigation DVD. The character
selected appears magnified.
Greyed out characters are not available
and cannot be selected.
i
If there is only one match for the
entered street name, the
( symbol is
highlighted automatically.

119 Navigation
Destination input
Confirming a cross street (list)
Press E to confirm.
The Start route guidance menu
(
page 129) will appear.
Entering a city
Press the City soft key in the Enter
street menu (
page 112).
Enter city menu
The most recently entered destination is
shown in the upper area.You can now
enter a city name or
accept the city name shown
Available soft keys:
Map soft key:
Brings you to the destination input
directly above the map (
page 123).
State soft key:
Brings you to the state/province
selection (
page 113).
List soft key:
Brings you to a list of cities with the
previously input street.
Delete soft key:
The character last entered or the
character last accepted by the system
is deleted.
Back soft key:
Returns you to the previous menu.
i
The currently set state is identifed by
the state code in the middle of the
screen.
If the vehicle location is in Canada, this
soft key appears as
Province.

123 Navigation
Destination input
Selecting a destination using the map
Press c.
Push the joystick to H, h, g, G,
F, f.
or
Press the Map soft key, e.g. in the Start
route guidance menu (
page 129).
The map is shown in full view and
cross-hairs appear.If soft key displays are hidden:
Press any soft key.
The soft key displays will appear.Available soft keys
POIs soft key:
Spotlight a POI if POIs are on the map
(
page 160).
Memory soft key:
Set a memory point and saved it in the
Last destinations memory
(
page 111).
i
Select a destination using the map
when vehicle is stationary. If you
choose to confirm a selected
destination by pressing
E while the
vehicle is in motion, the message
It
is not possible to set a
destination via map during
driving
will appear in the display.
i
The system automatically places the
cross-hairs on the current destination
address.
i
c was pressed:
If no soft key is selected within approx.
8 seconds, the soft key display will
disappear again.
i
The POIs, Memory and Display soft
keys are available if the
Map soft key
was pressed.

124 Navigation
Destination input
Display soft key:
The Map view display will appear.
(
page 147).
Soft key +:
Enlarge visible map section.
Soft key ):
Reduce visible map section.
Back soft key:
Returns you to the previous menu.
Push the joystick to H, h, g, G
to move the cross-hairs.
Push the joystick to F or f to move
the cross-hairs diagonally.This allows you to select your destination.
Release the button.
If the system is able to assign a street
name to the selected location, it is
displayed on the status bar.
If a street name can not be assigned,
COMAND increases the zoom by one
increment each time
E is pressed
until a street name can be selected.
Press E.
The system uses the point at the center
of the cross-hairs as destination.
The Start route guidance menu will
appear (
page 129).
i
If you press the Back soft key, your
selection will be discarded. The system
then uses the data of the previous
destination.
i
If a POI is close to the center of the
cross-hairs, a selection list will appear.
You can now select between a POI and
the address destination.

128 Navigation
Destination input
Additional information for 1, 3 and 4
IndicationRemarks and
value range
1 Steering angle Pointer shows to the
left
-35° to 0°
Pointer shows to the
right
0° to +35°
3 Dynamic
compass card 0° to 360°
4 Height above
the sea level i
The white indicator
is fixed, the scale
scrolls as vehicle
altitude changes
Scale range:
The display unit is
set to miles
-328 ft to 19680 ft
The display unit is
set to km
-100 m to 6000 m
IndicationRemarks and
value rangei
Using the control system, the display
unit can be changed between km or
miles (see your vehicle’s Operator’s
Manual).
When the instrument cluster
multifunction display is set to miles,
the COMAND will indicate
distances in miles (mi) or feet (ft)
When the instrument cluster
multifunction display is set to
kilometers, the COMAND will
indicate distances in kilometers
(km) or meters (m)

129 Navigation
Route guidance

Route guidance
Route guidance can be started if the
destination input is complete and
Start
route guidance
is displayed at the
bottom of the main area.
Start route guidance menu
1Destination address
2Arrow indicates the direction to the
destination and the distance to the
destination (as the crow flies)
Press E.
Route calculation and route guidance
begins.
1Routing mode
Setting the routing mode (
page 110)
2Arrow indicates the direction of the
destination, the distance to destination
and
CALC RTE indication
3The road you are currently driving onRoute calculation can take some time,
depending on the distance to the
destination and the routing mode.
During route calculation, an arrow pointing
towards the destination, the distance to
the destination (as the crow flies) and
CALC RTE are displayed.
Route guidance begins when route
calculation is complete.
The system will calculate a new route
during active route guidance if the driver
does not follow the route guidance.
Starting route guidance
Route calculation
Recalculating an existing route

130 Navigation
Route guidance
After route calculation, the system assists
route guidance using pictorial displays
(
page 131) and voice instructions.
Repeating current voice instructions
If you have not understood a navigation
announcement, you can at any time have a
current announcement repeated.
Press j.
The current navigation announcement
is repeated.
Switching voice instructions On/Off
Switching off
Press J during a navigation
announcement.
The message
Voice announcements
muted
will appear briefly. Further route guidance takes place
using only the symbols in the display.
If a new route guidance cycle is started,
the announcements are automatically
switched on again.
Switching on again
Press j.
Voice instructions
WarningG
Voice instructions are intended to direct you
while driving without diverting your attenti-
on from the road and driving.
Always use this feature instead of consulting
the map display for directions. Consulting
the map displays for directions may cause
you to divert your attention from driving and
increase the risk of an accident.
