MERCEDES-BENZ GL320CDI 2007 X164 Owner's Manual

110 Safety and Security
Driving safety systems
For more information, see the “Practical
hints” section (
page 436) and
(
page 451).
Off-road - 4-ETS
With the off-road driving program switched
on (
page 279), or with the transmission
in LOW RANGE* mode (
page 203), the
4-ETS designed for off-road use is auto-
matically activated.
!Operational or performance test must only
be conducted on a two-axle dynamometer. If
such tests are necessary, contact an authorized
Mercedes-Benz Light Truck Center. You could
otherwise seriously damage the brake system or
the transfer case which is not covered by the
Mercedes-Benz Limited Warranty.
!Because the ESP® operates automatically,
the engine and ignition must be shut off
(SmartKey in starter switch position0 or1 or
KEYLESS-GO* start/stop button in
position0or1) when testing the parking brake
on a brake test dynamometer and such testing
should be no longer than 10 seconds.
Active braking action through the ESP
® may
otherwise seriously damage the brake system
which is not covered by the Mercedes-Benz
Limited Warranty.
iIf the yellow ESP® warning lampv
comes on while driving, the 4-ETS is being
switched off temporarily to prevent overheating
of the drive wheel brakes. In addition, the
message
ESP inoperative See Operator’s
Manual
appears in the multifunction display.

111 Safety and Security
Anti-theft systems
Anti-theft systems
Immobilizer
The immobilizer prevents unauthorized
persons from starting your vehicle.
Activating
With the SmartKey
Remove the SmartKey from the starter
switch.
With KEYLESS-GO*
Press the KEYLESS-GO start/stop
button (
page 43) on the starter
switch once.
The engine is turned off.
Open the driver’s door.
Deactivating
With the SmartKey
Turn the SmartKey in the starter switch
to position2 (
page 41).With KEYLESS-GO*
Switch on the ignition (page 42).
Anti-theft alarm system
Once the alarm system has been armed, a
visual and audible alarm is triggered when
someone opens

a door

the tailgate

the hood
The alarm will stay on, even if the activat-
ing element (a door, for example) is imme-
diately closed.The alarm system will also be triggered
when

the vehicle is opened with the mechan-
ical key, see “Unlocking the vehicle”
(
page 500)

a door is opened from the inside, see
“Opening the doors from the inside”
(
page 122)
iStarting the engine will also deactivate the
immobilizer.
In case the engine cannot be started (yet the
vehicle’s battery is charged), the system is not
operational. Contact an authorized
Mercedes-Benz Light Truck Center or call
1-800-FOR-MERCedes (in the USA), or
1-800-387-0100 (in Canada).
iIf the alarm stays on for more than
30 seconds, a call to the Response Center is
initiated automatically by the Tele Aid system
(
page 332) provided that the Tele Aid service
was subscribed to and properly activated, and
that necessary cellular service and GPS cover-
age are available.

112 Safety and Security
Anti-theft systems
Arming the alarm system
The alarm system indicator lamp is located
to the lower left of the hazard warning
flasher.
1Alarm system indicator lamp
Lock the vehicle with the SmartKey or
with KEYLESS-GO* (
page 71).
The turn signal lamps flash three times
to indicate that the vehicle is locked.
The alarm system is armed within ap-
proximately 10 seconds. Alarm system
indicator lamp1 flashes.Disarming the alarm system
Unlock the vehicle with the SmartKey
or with KEYLESS-GO* (
page 40).
The turn signal lamps flash once to
indicate that the alarm system is
disarmed. Indicator lamp1 goes out.Canceling the alarm
To cancel the alarm:
With the SmartKey
Insert the SmartKey in the starter
switch.
or
Press theŒ or ‹button on the
SmartKey.
With KEYLESS-GO*
Grasp an outside door handle.
The SmartKey with KEYLESS-GO must
be within 3 ft (1 m) of the vehicle.
or
Press the KEYLESS-GO start/stop
button (
page 43).
The SmartKey with KEYLESS-GO must
be inside the vehicle.
iIf the turn signal lamps do not flash three
times, one of the following elements may not be
properly closed:

a door

the tailgate
Close the respective element and lock the
vehicle again.
iThe alarm system will rearm automatically
again after approximately 40 seconds if neither a
door nor the tailgate is opened.

113 Controls in detail
Locking and unlocking
Seats
Memory function*
Lighting
Instrument cluster
Control system
Automatic transmission
Transfer case
Differential locks*
Good visibility
Climate control
3-zone automatic climate control*
Power windows
Power tilt/sliding sunroof*
Driving systems
Loading
Useful features

114 Controls in detail
In the “Controls in detail” section you will
find detailed information on how to oper-
ate the equipment installed in your vehicle.
If you are already familiar with the basic
functions of your vehicle, this section will
be of particular interest to you.
To quickly familiarize yourself with the ba-
sic functions of the vehicle, refer to the
“Getting started” section of this manual.
The corresponding page numbers are
given at the beginning of each segment.
Locking and unlocking
For more information on locking and un-
locking, see the “Getting started” section
(
page 40) and (page 71).
SmartKey
Your vehicle comes supplied with two
SmartKeys, each with remote control and a
removable mechanical key.
The locking tabs for the mechanical key
portion of the two SmartKeys are a differ-
ent color to help distinguish each
SmartKey unit.
The SmartKey provides an extended oper-
ating range. To prevent theft, however, it is
advisable to only unlock the vehicle when
you are in close proximity to it.
The SmartKey centrally locks and unlocks:

the doors

the tailgate

the fuel filler flap
SmartKey with remote control
1‹ Lock button
2Š Unlock button* for tailgate
3Locking tab for mechanical key
4ΠUnlock button
5Battery check lamp
6Â Panic button (
page 102)

115 Controls in detail
Locking and unlocking
Warning!G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. It is possible
for children to open a locked door from the
inside, which could result in an accident
and/or serious personal injury.
!To prevent possible malfunction, avoid
exposing the SmartKey to high levels of electro-
magnetic radiation.
iUSA only:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
iCanada only:
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation of the device.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
iYou can also open and close

the door windows

the hinged quarter windows*

the tilt/sliding sunroof*
using the SmartKey, see “Summer opening fea-
ture” (
page 251) and see “Convenience clos-
ing feature” (
page 252).
!If you cannot lock or unlock the vehicle with
the SmartKey, the batteries in the SmartKey are
discharged, the SmartKey is malfunctioning, or
the vehicle battery is drained.

Check the batteries in the SmartKey and
replace them if necessary (
page 506).

Use the mechanical key to unlock the
driver’s door (
page 500).

Lock the vehicle as described in the
“Practical hints” section (
page 501).

Have the vehicle battery and the vehicle
battery connections checked (
page 530).
If the SmartKey is malfunctioning, contact
Roadside Assistance or an authorized
Mercedes-Benz Light Truck Center.

116 Controls in detail
Locking and unlocking
Factory setting
Global unlocking
Press buttonŒ.
All turn signal lamps flash once. The
locking knobs in the doors move up.
The anti-theft alarm system is
disarmed.
The vehicle will lock again automatically
and rearm the anti-theft alarm system
within approximately 40 seconds of un-
locking if

neither door nor tailgate is opened

the SmartKey is not inserted in the
starter switch

the central locking switch is not
activatedGlobal locking
Press button‹.
With the tailgate and all doors closed,
the turn signal lamps flash three times.
The locking knobs in the doors move
down. The anti-theft alarm system is
armed.
Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey so that
pressing buttonΠonly unlocks the
driver’s door and the fuel filler flap.
Press and hold buttonsŒ and‹
simultaneously for about 5 seconds
until battery check lamp5
(
page 114) flashes twice.
The SmartKey will then function as
follows:Unlocking driver’s door and fuel filler
flap
Press buttonΠonce.
All turn signal lamps flash once. The
locking knob in the driver’s door moves
up. The anti-theft alarm system is
disarmed.
Global unlocking
Press buttonΠtwice.
All turn signal lamps flash once. The
locking knobs in the doors move up.
The anti-theft alarm system is
disarmed.

117 Controls in detail
Locking and unlocking
Global locking
Press button‹.
With the tailgate and all doors closed,
the turn signal lamps flash three times.
The locking knobs in the doors move
down. The anti-theft alarm system is
armed.
Restoring to factory setting
Press and hold buttonsŒ and‹
simultaneously for about 5 seconds
until battery check lamp5
(
page 114) flashes twice.
SmartKey with KEYLESS-GO*
Vehicles equipped with KEYLESS-GO come
with two SmartKeys with KEYLESS-GO,
each with remote control and a removable
mechanical key.
The locking tabs for the mechanical key
portion of the two SmartKeys with
KEYLESS-GO are a different color to help
distinguish each SmartKey with
KEYLESS-GO unit.
The KEYLESS-GO function is integrated
into the SmartKey. On these vehicles, the
validity of the SmartKey with KEYLESS-GO
is checked when you grasp an outside door
handle.
If the SmartKey with KEYLESS-GO is valid,
your vehicle unlocks

the doors

the tailgate

the fuel filler flap
SmartKey with KEYLESS-GO*
1‹ Lock button
2Š Unlock button* for tailgate
3Locking tab for mechanical key
4ΠUnlock button
5Battery check lamp
6Â Panic button (
page 102)

118 Controls in detail
Locking and unlocking
Warning!G
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO* with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. A child’s unsupervised
access to a vehicle could result in an
accident and/or serious personal injury.
!To prevent possible malfunction, avoid
exposing the SmartKey with KEYLESS-GO to high
levels of electromagnetic radiation.
iUSA only:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interfer-
ence, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
iCanada only:
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation of the device.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
iYou can also open and close

the door windows

the hinged quarter windows*

the tilt/sliding sunroof*
using the SmartKey with KEYLESS-GO, see
“Summer opening feature” (
page 251) and
see “Convenience closing feature”
(
page 252).
!If you cannot lock or unlock the vehicle with
the SmartKey with KEYLESS-GO, the batteries in
the SmartKey with KEYLESS-GO are discharged,
the SmartKey with KEYLESS-GO is malfunction-
ing or the vehicle battery is drained.

Check the batteries in the SmartKey with
KEYLESS-GO (
page 122) and replace
them if necessary (
page 506).

Use the mechanical key to unlock the
driver’s door (
page 500).

Lock the vehicle as described in the
“Practical hints” section (
page 501).

Have the vehicle battery and the vehicle
battery connections checked (
page 530).
If the SmartKey with KEYLESS-GO is malfunc-
tioning, contact Roadside Assistance or an
authorized Mercedes-Benz Light Truck Center.

119 Controls in detail
Locking and unlocking
Important notes on using KEYLESS-GO*

You can also use the SmartKey with
KEYLESS-GO like a normal SmartKey
(
page 114).
The starter switch is located under the
KEYLESS-GO button. Pull the
KEYLESS-GO button out in order to ac-
cess the starter switch (
page 43).

You can combine KEYLESS-GO func-
tions with normal SmartKey functions
(e.g. unlocking with KEYLESS-GO and
locking with the ‹button).

Always carry the SmartKey with
KEYLESS-GO with you.

Never store the SmartKey with
KEYLESS-GO together with:

electronic items such as a cellular
phone or another SmartKey with
KEYLESS-GO

metallic objects such as coins or
metal foil
Doing so could impair the function of
the KEYLESS-GO system.

To lock or unlock the vehicle, the
SmartKey with KEYLESS-GO must be
located outside the vehicle within ap-
proximately 3 ft (1 m) of the respective
door or the tailgate.

If the vehicle has been parked for more
than 72 hours, you must pull an outside
door handle in order to activate the
KEYLESS-GO function.

In order to start the engine with the
SmartKey with KEYLESS-GO:

The SmartKey with KEYLESS-GO
must be located in the vehicle.

The KEYLESS-GO start/stop button
must be inserted in the starter
switch (
page 43).

The brake pedal must be firmly
depressed. Do not depress the
accelerator.

If the SmartKey with KEYLESS-GO is
positioned farther away from the vehi-
cle, the system may no longer recog-
nize the SmartKey with KEYLESS-GO.
The vehicle then cannot be locked or
the engine started via the KEYLESS-GO
system.

If you have started the engine with the
KEYLESS-GO start/stop button
(
page 59), you can turn it off again by

pressing the KEYLESS-GO
start/stop button (
page 70)

inserting the SmartKey into the
starter switch when the vehicle is at
a standstill and the automatic
transmission is in positionP
(
page 70)
