flat tire MERCEDES-BENZ GL450 2007 X164 Owner's Manual

Contents
Emission control .......................... 373
Coolant temperature .................... 374
At the gas station .............................. 375
Refueling ...................................... 375
Check regularly and
before a long trip.......................... 377
Engine compartment ......................... 379
Hood ............................................ 379
Engine oil ..................................... 381
Transmission fluid level ................ 382
Coolant level ................................ 382
Windshield/rear window
washer system and
headlamp cleaning system* ........ 384
Tires and wheels ................................ 385
Important guidelines .................... 385
Tire care and maintenance........... 386
Direction of rotation ..................... 388
Loading the vehicle ...................... 388
Recommended tire
inflation pressure ......................... 394
Checking tire inflation pressure ... 396
Tire labeling.................................. 406
Load identification ....................... 410
DOT, Tire Identification
Number (TIN) ............................... 410Maximum tire load ........................ 412
Maximum tire inflation pressure ... 412
Uniform Tire Quality Grading
Standards (U.S. vehicles) .............. 413
Tire ply material ............................ 415
Tire and loading terminology......... 415
Rotating tires ................................ 418
Winter driving ..................................... 420
Winter tires ................................... 420
Snow chains.................................. 421
Maintenance....................................... 422
Maintenance service indicator
message ....................................... 422
Calling up the maintenance
service indicator display ............... 424
Resetting the maintenance
service indicator ........................... 424
Vehicle care........................................ 425
Cleaning and care of the vehicle ... 425
Practical hints.................................. 435
What to do if … ................................... 436
Lamps in instrument cluster ......... 436
Lamp in center console ................ 448
Vehicle status messages in
the multifunction display .............. 451
Where will I find ...? ............................ 495
First aid kit.................................... 495
Vehicle tool kit.............................. 495
Spare wheel .................................. 499
Unlocking/locking in an emergency .. 500
Unlocking the vehicle ................... 500
Locking the vehicle ....................... 501
Fuel filler flap ................................ 501
Opening/closing in an emergency ..... 503
Power tilt/sliding sunroof* ........... 503
Resetting activated head restraints.... 504
Replacing SmartKey batteries ............ 506
Replacing bulbs .................................. 508
Bulbs............................................. 508
Replacing bulbs for front lamps .... 511
Replacing bulbs for rear lamps ..... 515
Adjusting headlamp aim ............... 518

Contents
Replacing wiper blades ...................... 520
Front wiper blades ....................... 520
Rear wiper blade .......................... 521
Flat tire .............................................. 523
Preparing the vehicle.................... 523
Mounting the spare wheel ............ 524
Bleeding the fuel system
(diesel engine only) ............................ 529
Battery ............................................... 530
Disconnecting, removing,
reinstalling and
reconnecting the battery .............. 532
Charging the battery .................... 537
Jump starting ..................................... 538
Towing the vehicle ............................. 540
Installing towing eye bolt.............. 542
Stranded vehicle .......................... 543
Fuses ................................................. 544
Fuse box in engine compartment . 545
Fuse box in cargo compartment ... 545
Fuse box in
passenger compartment .............. 546
Emergency engine shut-down ...... 546
Technical data................................. 547
Parts service ...................................... 548
Warranty coverage............................. 549
Loss of Service and Warranty
Information Booklet ..................... 549
Identification labels ........................... 550
Layout of poly-V-belt drive ................. 552
GL 320 CDI .................................. 552
GL 450 ......................................... 552
Engine................................................ 553
Rims and tires.................................... 554
Same size tires ............................. 555
Minispare wheel ........................... 556
Electrical system ............................... 557
Main Dimensions ............................... 558
Weights.............................................. 559Fuels, coolants, lubricants ................. 560
Capacities .................................... 560
Engine oils ................................... 562
Engine oil additives ...................... 562
Air conditioning refrigerant .......... 562
Brake fluid.................................... 562
Premium unleaded gasoline
(gasoline engine) .......................... 563
Fuel requirements ........................ 563
Gasoline additives
(gasoline engine) .......................... 564
Coolants ...................................... 565
Windshield washer system and
headlamp cleaning system*......... 567
Index................................................. 569

23 At a glance
Exterior view
ItemPage
1Tailgate124
Power tailgate*125
Cargo compartment

Loading instructions303

Cargo tie-down rings304

Hooks306

Expanding306

Cover blind312

Cargo net*313
Vehicle tool kit495
Spare wheel499
2Rear window defroster215
3Rear lamps509
4Fuel filler flap375
Refueling375
Fuel376,
563
ItemPage
5Exterior rear view mirrors
Adjusting52
Auto-dimming rear view
mirrors*211
Power folding*211
6Towing
Installing towing eye bolt542
7Tires and wheels385,
554
Checking tire inflation
pressure396
General information385
Flat tire523
Spare wheel499
8Hood379
Opening379
Engine oil381
Coolant382
ItemPage
9Windshield wipers63
Wiper blades, replacing520
Wiper blades, cleaning431
aWindshield
Cleaning with wiper fluid65
Cleaning431
bRoof rails297
Carriers*298
cPower tilt/sliding sunroof*253
dDoors
Locking and unlocking114
Opening and closing122
Locking/unlocking in an
emergency500
eFront lamps509
fHeadlamp cleaning system*210

161 Controls in detail
Control system
Menus, submenus and functions
Menu1Menu2Menu3Menu4Menu5
Standard displayAudioNAV*Off-roadDISTRONIC*
(page 164)(page 166)(page 168)(page 168)(page 169)
Commands/submenus
Trip- and main odometerSelecting radio stationRoute guidance
instructions, current
direction traveledCompassCalling up settings
Checking tire inflation pressureSelecting satellite radio
station* (USA only)Vehicle level
Checking coolant temperatureOperating CD playerDifferential locks*
Calling up digital speedometer
or outside temperature
Calling up maintenance service
indicator
iThe headings used in the menus table are
designed to facilitate navigation within the sys-
tem and are not necessarily identical to those
shown in the control system displays.The first function displayed in each menu will
automatically show you which part of the system
you are in.

164 Controls in detail
Control system
Standard display menu
In the standard display, the main odometer
and the trip odometer appear in the multi-
function display.
1Trip odometer
2Main odometer
If you see another display, press
buttonè orÿ repeatedly until
the standard display appears.
Press buttonk orj to select
the functions in the standard display
menu.The following functions are available:Checking coolant temperature
FunctionPage
Checking tire inflation pressure396
Checking coolant temperature164
Calling up digital speedometer
or outside temperature165
Calling up maintenance service
indicator424
Warning!G

Driving when your engine is overheated
can cause some fluids which may have
leaked into the engine compartment to
catch fire. You could be seriously
burned.

Steam from an overheated engine can
cause serious burns which can occur
just by opening the hood. Stay away
from the engine if you see or hear steam
coming from it.
Stop the vehicle in a safe location away from
other traffic. Turn off the engine, get out of
the vehicle and do not stand near the vehicle
until the engine has cooled down.

336 Controls in detail
Useful features
Roadside Assistance button•
The Roadside Assistance button• is
located below the center armrest cover.
1Roadside Assistance button•
Open the storage tray (page 319).
Press and hold button1 (for longer
than 2 seconds).
A call to a Mercedes-Benz Roadside
Assistance dispatcher will be initiated.
The button will flash while the call is in
progress. The message
Connecting call will appear in the
multifunction display.When the connection is established, the
message
Call connected appears in the
multifunction display. The Tele Aid system
will transmit data generating the vehicle
identification number, model, color and
location (subject to availability of cellular
and GPS signals).
A voice connection between the Roadside
Assistance dispatcher and the occupants
of the vehicle will be established.
Describe the nature of the need for as-
sistance.The Mercedes-Benz Roadside Assistance
dispatcher will either dispatch a qualified
Mercedes-Benz technician or arrange to
tow your vehicle to the nearest
Mercedes-Benz Light Truck Center. For
services such as labor and/or towing,
charges may apply. Refer to the Roadside
Assistance Manual for more information.
The following is only available in the USA:

Sign and Drive services: Services such
as jump start, a few gallons of fuel or
the replacement of a flat tire with the
vehicle spare tire are obtainable.
iWhile the call is connected you can change
to the navigation menu by pressing the NAV
button on the COMAND system unit.

353 Operation
Driving instructions
TiresTreadwear indicators (TWI) are required by
law. These indicators are located in six
places on the tread circumference and
become visible at a tread depth of
approximately
1/16in (1.6 mm), at which
point the tire is considered worn and
should be replaced.
The treadwear indicator appears as a solid
band across the tread.Specified tire inflation pressures must be
maintained. This applies particularly if the
tires are subjected to high loads (e.g. high
speeds, heavy loads, high ambient temper-
atures).
For more information, see “Tires and
wheels” (
page 385).

Turn the SmartKey or the SmartKey with
KEYLESS-GO* to starter switch
position0 and remove, or press
KEYLESS-GO* start/stop button.

Take the SmartKey or the SmartKey with
KEYLESS-GO* with you and lock vehicle
when leaving.
Warning!G
If you feel a sudden significant vibration or
ride disturbance, or you suspect that possi-
ble damage to your vehicle has occurred,
you should turn on the hazard warning flash-
ers, carefully slow down, and drive with cau-
tion to an area which is a safe distance from
the road.
Inspect the tires and the vehicle underbody
for possible damage. If the vehicle or tires
appear unsafe, have the vehicle towed to
the nearest Mercedes-Benz Light Truck
Center or tire dealer for repairs.
Warning!G
Although the applicable federal motor
vehicle safety laws consider a tire to be
worn when the treadwear indicators (TWI)
become visible at approximately
1/16in
(1.6 mm), we recommend that you do not
allow your tires to wear down to that level.
As tread depth approaches
1/8in (3 mm),
the adhesion properties on a wet road are
sharply reduced.
Depending upon the weather and/or road
surface (conditions), the tire traction varies
widely.
Warning!G
Do not drive with a flat tire. A flat tire affects
the ability to steer or brake the vehicle. You
may lose control of the vehicle. Continued
driving with a flat tire or driving at high
speed with a flat tire will cause excessive
heat build-up and possibly a fire.

359 Operation
Driving instructions
Checklist before off-road driving
Engine oil level

Check the engine oil level with the oil
dipstick (
page 381).
Only with a proper oil level can the
vehicle obtain a trouble-free oil supply,
even on steep gradients.Tires

Check the tread depth and maintain
specified tire inflation pressure
(a placard with the recommended tire
inflation pressures is located on the
driver’s door B-pillar (
page 389)).

Check tires for possible damage and
remove foreign objects.

Replace missing valve caps.
Rims

Dented or bent rims can cause tire in-
flation pressure loss and damage the
tire beads. For this reason, check and,
if necessary, change rims before driv-
ing off-road.
Vehicle tool kit

Check if the vehicle jack (page 497)
is functional.

In all cases take the vehicle tool kit, a
strong tow rope, a shovel and a small
plank (to put under the vehicle jack on
sandy soil) with you.

In sandy soil, drive at a steady speed as al-
lowed by conditions. This helps overcome
the vehicle rolling resistance and reduces
the likelihood of the vehicle sinking into the
ground.

Do not initiate jumps with the vehicle. It
interrupts the forward momentum of the
vehicle.

Always drive onto slopes with the engine
running and the vehicle in gear.

Do not shift automatic transmission to
positionN.
Warning!G
Do not reduce the tire inflation pressure
before driving through sand. However, if you
do so, remember to correct the tire inflation
pressure (
page 396) before continuing
your trip. Driving with reduced tire inflation
pressure increases the risk of losing control
of the vehicle and rolling over.
!If the engine oil level warning lamp
(
page 476) comes on while driving, stop the
vehicle in a safe location or as soon at is safe to
do so. Check the engine oil level (
page 381).
The engine oil level warnings should not be
ignored. Extended driving with the symbol
displayed could result in serious engine damage
that is not covered by the Mercedes-Benz
Limited Warranty.

364 Operation
Driving instructions
Driving on sand
When driving on sand, observe the follow-
ing rules:

Set the raised level (page 281).

Avoid high engine speeds.

Shift automatic transmission into a
gear range that is appropriate for the
terrain.

In sandy soil, drive at a steady speed as
conditions permit. This helps overcome
the vehicle rolling resistance and re-
duce the likelihood of the vehicle sink-
ing into the ground.

Drive in tracks of other vehicles if they
are not too deep and you have suffi-
cient clearance.
Ruts
A number of off-road tracks or other by-
ways have deep ruts which can cause the
underbody to come in contact with the
ground.

Make sure the off-road driving program
(
page 279), or if equipped, the LOW
RANGE mode* (
page 203) is
switched on.

Set the raised level (page 281).

Avoid high engine speeds.

Shift automatic transmission to
position1 (
page 200).

Drive next to the ruts rather than
through them if at all possible.

If the ruts are too deep to drive in, drive
with one side of the vehicle on the
grassy center strip if the route permits.
Warning!G
Do not reduce the tire inflation pressure
before driving through sand. However, if you
do so, remember to correct the tire inflation
pressure (
page 396) before continuing
your trip. Driving with reduced tire inflation
pressure increases the risk of losing control
of the vehicle and rolling over.
!Check that the ruts are not too deep and
your vehicle’s clearance is sufficient. Otherwise:

your vehicle may be damaged

the underbody of the vehicle may come in
contact with the ground and you may get
stuck

378 Operation
At the gas station
Brake fluid
Coolant
For normal replenishing, use water (pota-
ble water quality).
For more information, see “Coolant level”
(
page 382) and see “Fuels, coolants, lu-
bricants” (
page 560).Windshield/rear window washer
system and headlamp cleaning
system*
For more information on refilling the wash-
er reservoir, see “Windshield/rear window
washer system and headlamp cleaning
system*” (
page 384).
Vehicle lighting
Check function and cleanliness. For infor-
mation on replacing light bulbs, see “Re-
placing bulbs” (
page 508).
For more information, see “Exterior lamp
switch” (
page 145).
Tire inflation pressure
For more information, see “Checking tire
inflation pressure” (
page 396).
!If you find that the brake fluid in the brake
fluid reservoir has fallen to the minimum mark or
below, have the brake system checked for brake
pad thickness and leaks immediately. Notify an
authorized Mercedes-Benz Light Truck Center
immediately. Do not add brake fluid as this will
not solve the problem. For more information, see
“Brake fluid” (
page 562).
