546 Practical hints
Fuses
Fuse box in passenger compartment
The fuse box is located behind a cover in
the dashboard on the front passenger side.
1CoverOpening
Open the front passenger door.
Open the glove box (page 316).
Insert flat, blunt object as a lever into
the edge of the cover1 at the position
indicated by the arrow.
Loosen cover1 from dashboard using
lever.
Using your hands, pull cover1 out
and remove.
Closing
Hook cover1 into the opening at the
front.
Press cover1 back on until it engag-
es.
Emergency engine shut-down
If the engine cannot be turned off as de-
scribed in the “Getting started” section
(
page 69), you may use the following
emergency procedure.
Take the fuse chart from the vehicle
tool kit (
page 496).
Open the fuse box in engine compart-
ment (
page 545).
Use the fuse extractor to remove
fuse 120. Find its location in the fuse
chart.
!Do not use sharp objects such as a screw-
driver to open the fuse box cover1 in the dash-
board, as this could damage the fuse box cover
or the dashboard.
