60 Getting started
Driving
Driving off
Depress the brake pedal.
The gear selector lever can now be
used.
Shift automatic transmission toD orR
(
page 191).
Release the brake pedal.
Carefully depress the accelerator
pedal.After a cold start, the automatic transmis-
sion shifts at a higher engine revolution.
This allows the catalytic converter (gaso-
line engine) or the oxidation catalyst (die-
sel engine) to reach its operating
temperature earlier.
iWait for the gear selection process to com-
plete before setting the vehicle in motion.
iShifting from gear positionP to positionR,
N, orD is only possible with the brake pedal
depressed. Without the brake pedal depressed,
the gear selector lever can be moved, but the
parking pawl remains engaged, not allowing
shifting to occur.
!If you hear a warning signal and the
message
Release Parking Brake appears in
the multifunction display when driving off, you
have forgotten to release the parking brake.
Release the parking brake (
page 59).
iOnce the vehicle is in motion, the automatic
central locking system engages and the locking
knobs drop down.
The automatic door lock feature can be
deactivated (
page 180).
You can open a locked door from the inside.
Open door only when conditions are safe to do
so.
Warning!G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced vehi-
cle control. Your vehicle’s ABS will not pre-
vent this type of loss of control.
Warning!G
It is dangerous to shift the automatic trans-
mission out ofP orN if the engine speed is
higher than idle speed. If your foot is not
firmly on the brake pedal, the vehicle could
accelerate quickly forward or in reverse. You
could lose control of the vehicle and hit
someone or something. Only shift into gear
when the engine is idling normally and when
your right foot is firmly on the brake pedal.
164.boo Seite 60 Freitag, 30. März 2007 12:54 12

61 Getting started
Driving
For more information, see “Driving instruc-
tions” (
page 347).
For information on off-road driving, see
“Off-road driving” (
page 355).
Switching on headlamps
Low beam headlamps
The exterior lamp switch is located on the
dashboard to the left of the steering wheel.
Exterior lamp switch
1Off
2Low beam headlamps on
Switch on the ignition (page 41).
Turn the exterior lamp switch to
positionB.
The low beam headlamps come on.High beam
The combination switch is located on the
left of the steering column.
Combination switch
1High beam
2High beam flasher
Push the combination switch in
direction of arrow1.
The high beam headlamp indicator
lampA in the instrument cluster
comes on (
page 26).
For more information on headlamps, see
“Lighting” (
page 143).
!Shift the automatic transmission to
positionPorR only when the vehicle is stopped
in order to avoid damaging the transmission.
!Do not run cold engine at high engine
speeds. Running a cold engine at high engine
speeds may shorten the service life of the
engine.
!Simultaneously depressing the accelerator
pedal and applying the brakes reduces engine
performance and causes premature brake and
drivetrain wear.
164.boo Seite 61 Freitag, 30. März 2007 12:54 12

62 Getting started
Driving
Turn signals
The combination switch is located on the
left of the steering column.
Combination switch
1Turn signals, right
2Turn signals, left
Press the combination switch in
direction of arrow1 or2.
The corresponding turn signal indicator
lampL orK in the instrument
cluster flashes (
page 26).The combination switch resets automati-
cally after major steering wheel move-
ment.
Windshield wipers
The combination switch is located on the
left of the steering column.
Combination switch
1Single wipe
Wiping with windshield washer fluid
2Switching on windshield wipers
Switch on the ignition (page 42).
iTo signal minor directional changes such as
changing lanes, press combination switch only
to point of resistance and release. The corre-
sponding turn signal will flash three times.
!Do not operate the windshield wipers when
the windshield is dry. Dust that accumulates on
a windshield might scratch the glass and/or
damage the wiper blades when wiping occurs on
a dry windshield. If it is necessary to operate the
windshield wipers in dry weather conditions,
always operate the windshield wipers with wind-
shield washer fluid (
page 64).
!If anything blocks the windshield wipers
(leaves, snow, etc.), switch them off immediate-
ly.

For safety reasons, stop the vehicle in a safe
location and

remove SmartKey from starter switch
or

turn off the engine by pressing the
KEYLESS-GO* start/stop button and
open the driver’s door (with the driver’s
door open, starter switch is in
position0, same as with SmartKey
removed from starter switch)
before attempting to remove any blockage.

Remove blockage.

Turn the windshield wipers on again.
164.boo Seite 62 Freitag, 30. März 2007 12:54 12

63 Getting started
Driving
Switching on windshield wipers
Turn the combination switch to the
desired position depending on the
intensity of the rain.
MWindshield wipers off
USlow intermittent wiping
Rain sensor operation with low
sensitivity.
VFast intermittent wiping
Rain sensor operation with high
sensitivity.
uSlow continuous wiping
tFast continuous wipingIntermittent wiping
Only switch on intermittent wiping under
wet weather conditions or in the presence
of precipitation.
When you select intermittent wiping, the
rain sensor is activated. The rain sensor
automatically sets a suitable wiping
interval depending on the wetness of the
sensor surface.
Turn the combination switch to
positionU orV.After the initial wipe, pauses between
wipes are automatically controlled by the
rain sensor.
Single wipe
Press the combination switch briefly in
direction of arrow1 to the resistance
point.
The windshield wipers wipe one time
without washer fluid.
If windshield wipers fail to function at all in the
combination switch positionU orV,

set the combination switch to the next
higher wiper speed

have the windshield wipers checked at the
nearest authorized Mercedes-Benz Light
Truck Center
!Do not leave windshield wipers on an inter-
mittent setting when the vehicle is taken to an
automatic car wash or during windshield clean-
ing. Wipers will operate in the presence of water
sprayed on the windshield, and windshield
wipers may be damaged as a result.
!If you have set intermittent wiping, dirt on
the surface of the rain sensor or optical effects
may cause the windshield wipers to wipe in an
undesired fashion. This could then damage the
windshield wiper blades or scratch the windows.
You should therefore switch off the windshield
wipers when weather conditions are dry.
iIntermittent wiping is interrupted when the
vehicle is at a standstill and a front door is
opened. This protects persons getting into or out
of the vehicle from being sprayed.
Intermittent wiping will be continued when all
doors are closed and

the automatic transmission is set to
positionD orR
or

the wiper setting is changed using the
combination switch
164.boo Seite 63 Freitag, 30. März 2007 12:54 12

64 Getting started
Driving
Wiping with windshield washer fluid
Press the combination switch in direc-
tion of arrow1 past the resistance
point.
The windshield wipers operate with
washer fluid.
For information on cleaning the headlamps
with washer fluid, see “Headlamp cleaning
system*” (
page 208).
For information on filling up the washer
reservoir, see “Windshield/rear window
washer system and headlamp cleaning
system*” (
page 383).
Rear window wiper/washer
The combination switch is located on the
left of the steering column.
Combination switch
1Rear window wiper switch
2Wiping rear window with washer fluid
3Intermittent wiping
4Rear window wiper off
5Wiping rear window with washer fluid6Rear window wiper indicator
Switch on the ignition (page 42).
Activating intermittent wipe
Turn rear window wiper switch1 to
position3 (
page 64).
In the lower multifunction display you
will see indicator6, indicating that
the rear window wiper is activated.
iTo prevent smears on the windshield or
noisy/chattering wiper blades, wipe with
windshield washer fluid every now and then even
when it is raining.
iThe rear window wiper engages automatical-
ly when the automatic transmission is shifted to
positionR with the windshield wipers switched
on.
164.boo Seite 64 Freitag, 30. März 2007 12:54 12

65 Getting started
Driving
Deactivating intermittent wipe
Turn rear window wiper switch1 to
position4 (
page 64).
Indicator6 (
page 64) for the rear
window wiper is cleared from the lower
multifunction display, indicating that
the rear window wiper is deactivated.
Wiping with windshield washer fluid
Turn and hold rear window wiper
switch1 in position2 or5
(
page 64) until the rear window is
clean.
The rear window wiper operates with
washer fluid.
For information on filling up the washer
reservoir, see “Windshield/rear window
washer system and headlamp cleaning
system*” (
page 383).
Problems while driving
The engine runs erratically and misfires

An ignition cable may be damaged
(gasoline engine only).

The engine electronics may not be
operating properly.

Unburned gasoline may have entered
the catalytic converter and damaged it
(gasoline engine only).
Give very little gas.
Have the problem repaired by an
authorized Mercedes-Benz Light Truck
Center as soon as possible.The coolant temperature is above
248°F (120°C)
The coolant is too hot and is no longer
cooling the engine.
Stop the vehicle in a safe location as
soon as possible and turn off the en-
gine. Allow engine and coolant to cool
off.
Check the coolant level and add cool-
ant if necessary (
page 381).
164.boo Seite 65 Freitag, 30. März 2007 12:54 12

66 Getting started
Driving
In case of accident
If the vehicle is leaking fuel:
Do not start the engine under any
circumstances.
Notify local fire and/or police authori-
ties.
If the extent of the damage cannot be de-
termined:
Contact an authorized Mercedes-Benz
Light Truck Center or call Roadside
Assistance.
If no damage can be determined on the

major assemblies

fuel system

engine mount:
Start the engine in the usual manner.
164.boo Seite 66 Freitag, 30. März 2007 12:54 12

67 Getting started
Parking and locking
Parking and locking
You have now completed your first drive.
You have properly stopped and parked
your vehicle. End your drive as follows.Parking brake
1Parking brake pedal
Warning!G
With the engine not running, there is no
power assistance for the brake and the
steering system. In this case, it is important
to keep in mind that a considerably higher
degree of effort is necessary to brake and
steer the vehicle.
Warning!G
Do not park this vehicle in areas where com-
bustible materials such as grass, hay or
leaves can come into contact with the hot
exhaust system, as these materials could be
ignited and cause a vehicle fire.
To reduce the risk of personal injury, or
damage to the vehicle drivetrain, as a result
of vehicle movement, before turning off the
engine and leaving the vehicle always:

Keep right foot on brake pedal.

Firmly depress parking brake pedal.

Shift the automatic transmission to
positionP.

Slowly release brake pedal.

When parked on an incline, turn front
wheel towards the road curb.

Turn the SmartKey in the starter switch
to position0 and remove the SmartKey
from the starter switch, or press the
start/stop button (vehicles with
KEYLESS-GO*).

Take the SmartKey or the SmartKey with
KEYLESS-GO* with you and lock vehicle
when leaving.
Warning!G
Engaging the parking brake while the vehicle
is in motion can cause the rear wheels to
lock up. You could lose control of the vehicle
and cause an accident. In addition, the vehi-
cle’s brake lights do not light up when the
parking brake is engaged.
164.boo Seite 67 Freitag, 30. März 2007 12:54 12

68 Getting started
Parking and locking
Step firmly on parking brake pedal1.
When the engine is running, the
warning lamp; (USA only) or3
(Canada only) in the instrument cluster
comes on.
Switching off headlamps
Turn the exterior lamp switch toM
(
page 61).
For more information, see “Lighting”
(
page 143).
Turning off the engine
Shift the automatic transmission to
positionP (
page 191).
Apply the parking brake (page 67).
Warning!G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Children could release the
parking brake and/or shift the automatic
transmission out of positionP, either of
which could result in an accident and/or
serious personal injury.
Warning!G
Getting out of your vehicle with the
automatic transmission not fully engaged in
positionP is dangerous. Also, when parked
on an incline, positionP alone may not
prevent your vehicle from moving, possibly
hitting people or objects.
Always set the parking brake in addition to
shifting to positionP (
page 191).
When parked on an incline, also turn front
wheel towards the road curb.
iIf the engine cannot be turned off as
described, see “Emergency engine shut-down”
(
page 545).
Warning!G
Do not turn off the engine before the vehicle
has come to a complete stop. With the en-
gine not running, there is no power assis-
tance for the brake and steering systems. In
this case, it is important to keep in mind that
a considerably higher degree of effort is nec-
essary to brake and steer the vehicle.
iAlways set the parking brake in addition to
shifting the automatic transmission to positionP
(
page 191).
When parked on an incline, also turn front wheel
towards the road curb.
164.boo Seite 68 Freitag, 30. März 2007 12:54 12

69 Getting started
Parking and locking
Turning off with the SmartKey
Turn the SmartKey in the starter switch
to position0 (
page 41).
Remove the SmartKey from the starter
switch.
The immobilizer is activated.Turning off with KEYLESS-GO*
Press the KEYLESS-GO start/stop
button (
page 43) to turn off the
engine.
With the driver’s door closed, the start-
er switch is now in position1. With the
driver’s door opened, the starter switch
is set to position0, same as SmartKey
removed from starter switch
(
page 41).If you have started the engine with the
KEYLESS-GO start/stop button and can-
not turn it off as described above:
Remove the KEYLESS-GO start/stop
button from the starter switch.
Insert the SmartKey with KEYLESS-GO
into the starter switch.
The engine turns off. The starter switch
is in position0 (
page 41).
!Observe instructions when taking the
vehicle through an automatic conveyor type
car wash (
page 428).
!If you turn off the engine using the
SmartKey and

remove the SmartKey from the starter
switch
or

open a front door
the automatic transmission will shift to park
positionP automatically.
Keep in mind that turning off the engine with the
SmartKey alone only will automatically shift the
automatic transmission to neutral positionN.
iIn an emergency you can turn off the engine
while driving by pressing and holding the
KEYLESS-GO start/stop button for
approximately 3 seconds.
!If you turn off the engine using the
KEYLESS-GO start/stop button and open a front
door, the automatic transmission will shift to
park positionP automatically.
Keep in mind that turning off the engine using
the KEYLESS-GO start/stop button alone only
will automatically shift the automatic transmis-
sion to neutral positionN.
164.boo Seite 69 Freitag, 30. März 2007 12:54 12
