Contents
Power tilt/sliding sunroof* ................ 251
Opening and closing ..................... 251
Synchronizing ............................... 253
Driving systems ................................. 255
Cruise control............................... 255
Distronic* (Canada only) .............. 260
Distance warning function*
(Canada only) ............................... 272
Downhill Speed Regulation
(DSR) ............................................ 273
Off-road driving program
(Vehicles without
enhanced off-road package*) ....... 277
Air suspension program ............... 278
Adaptive Damping System
(ADS)* .......................................... 278
Vehicle level control ..................... 279
Parktronic system* ...................... 288
Rear view camera* ....................... 293Loading .............................................. 295
Carriers* ...................................... 295
Loading instructions..................... 301
Cargo tie-down rings .................... 302
Hooks........................................... 304
Expanding cargo compartment .... 304
Cargo compartment cover blind... 310
Cargo net* ................................... 312
Useful features .................................. 315
Storage compartments ................ 315
Parcel nets ................................... 319
Cup holders.................................. 320
Ashtrays ....................................... 321
Cigarette lighter ........................... 323
Power outlets ............................... 324
Floormats ..................................... 325
Seat cover under third-row seats . 326
Heated steering wheel* ............... 327
Telephone* .................................. 328
Tele Aid ........................................ 331
Garage door opener ..................... 338
Compass ...................................... 344
Infrared reflecting windshield* ..... 344
Operation......................................... 345
The first 1000 miles (1500 km) ......... 346
Driving instructions ........................... 347
Drive sensibly – save fuel............. 347
Drinking and driving ..................... 347
Pedals .......................................... 347
Power assistance ......................... 348
Brakes.......................................... 348
Driving off .................................... 350
Parking......................................... 350
Tires ............................................. 351
Hydroplaning................................ 352
Tire traction ................................. 352
Tire speed rating .......................... 353
Winter driving instructions ........... 353
Standing water............................. 355
Off-road driving ............................ 355
Trailer towing ............................... 364
Passenger compartment .............. 370
Driving abroad ............................. 370
Control and operation of radio
transmitters ................................. 370
Catalytic converter
(gasoline engine).......................... 371
164.boo Seite 6 Freitag, 30. März 2007 12:54 12

Contents
Oxidation catalyst
(diesel engine).............................. 371
Emission control .......................... 372
Coolant temperature .................... 372
At the gas station .............................. 374
Refueling ...................................... 374
Check regularly and
before a long trip.......................... 376
Engine compartment ......................... 378
Hood ............................................ 378
Engine oil ..................................... 380
Transmission fluid level ................ 381
Coolant level ................................ 381
Windshield/rear window
washer system and
headlamp cleaning system* ........ 383
Tires and wheels ................................ 384
Important guidelines .................... 384
Tire care and maintenance........... 385
Direction of rotation ..................... 387
Loading the vehicle ...................... 387
Recommended tire
inflation pressure ......................... 393
Checking tire inflation pressure ... 395
Tire labeling.................................. 406
Load identification ....................... 410DOT, Tire Identification
Number (TIN) ................................ 410
Maximum tire load ........................ 412
Maximum tire inflation pressure ... 412
Uniform Tire Quality Grading
Standards (U.S. vehicles) .............. 413
Tire ply material ............................ 415
Tire and loading terminology......... 415
Rotating tires ................................ 418
Winter driving ..................................... 420
Winter tires ................................... 420
Snow chains.................................. 421
Maintenance....................................... 422
Maintenance service indicator
message ....................................... 422
Calling up the maintenance
service indicator display ............... 424
Resetting the maintenance
service indicator ........................... 424
Vehicle care........................................ 425
Cleaning and care of the vehicle ... 425
Practical hints.................................. 435
What to do if … ................................... 436
Lamps in instrument cluster ......... 436
Lamp in center console ................ 447
Vehicle status messages in
the multifunction display .............. 449
Where will I find ...? ............................ 490
First aid kit.................................... 490
Vehicle tool kit.............................. 490
Spare wheel .................................. 494
Unlocking/locking in an emergency .. 496
Unlocking the vehicle ................... 496
Locking the vehicle ....................... 497
Fuel filler flap ................................ 497
Resetting activated head restraints.... 499
Vehicles without Rear seat
entertainment system*................. 499
Vehicles with Rear seat
entertainment system*................. 500
Replacing SmartKey batteries ............ 502
Replacing bulbs .................................. 504
Bulbs............................................. 504
Replacing bulbs for front lamps .... 507
Replacing bulbs for rear lamps ..... 511
Adjusting headlamp aim ............... 514
164.boo Seite 7 Freitag, 30. März 2007 12:54 12

Contents
Replacing wiper blades ...................... 516
Front wiper blades ....................... 516
Rear wiper blade .......................... 517
Flat tire .............................................. 519
Preparing the vehicle.................... 519
Mounting the spare wheel ............ 520
Bleeding the fuel system
(diesel engine only) ............................ 527
Battery ............................................... 528
Disconnecting, removing,
reinstalling and
reconnecting the battery .............. 530
Charging the battery .................... 535
Jump starting ..................................... 536
Towing the vehicle ............................. 538
Installing towing eye bolt.............. 540
Stranded vehicle .......................... 542
Fuses ................................................. 543
Fuse box in engine compartment . 544
Fuse box in cargo compartment ... 544
Fuse box in
passenger compartment .............. 545
Emergency engine shut-down ...... 545
Technical data................................. 547
Parts service ...................................... 548
Warranty coverage............................. 549
Loss of Service and Warranty
Information Booklet ..................... 549
Identification labels ........................... 550
Layout of poly-V-belt drive ................. 552
GL 320 CDI .................................. 552
GL 450, GL 550............................ 552
Engine................................................ 553
Rims and tires.................................... 555
Same size tires ............................. 556
Minispare wheel ........................... 558
Electrical system ............................... 559
Main Dimensions ............................... 560
Weights.............................................. 561Fuels, coolants, lubricants ................. 562
Capacities .................................... 562
Engine oils ................................... 564
Engine oil additives ...................... 564
Air conditioning refrigerant .......... 564
Brake fluid.................................... 564
Premium unleaded gasoline
(gasoline engine).......................... 565
Fuel requirements ........................ 565
Gasoline additives
(gasoline engine).......................... 566
Coolants ...................................... 567
Windshield washer system and
headlamp cleaning system*......... 569
Index................................................. 571
164.boo Seite 8 Freitag, 30. März 2007 12:54 12

17 Introduction
Operating safety
Operating safety
Proper use of the vehicle
Proper use of the vehicle requires that you
are familiar with the following information
and rules:

the safety precautions in this manual

the “Technical data” section in this
manual

traffic rules and regulations

motor vehicle laws and safety stan-
dards
Warning!G
Work improperly carried out on electronic
components and associated software could
cause them to cease functioning. Because
the vehicle’s electronic components are in-
terconnected, any modifications made may
produce an undesired effect on other sys-
tems. Electronic malfunctions could
seriously impair the operating safety of your
vehicle.
See an authorized Mercedes-Benz Light
Truck Center for repairs or modifications to
electronic components.
Other improper work or modifications on the
vehicle could also have a negative impact on
the operating safety of the vehicle.
Some safety systems only function while the
engine is running. You should therefore nev-
er turn off the engine while driving.
Warning!G
Heavy blows against the vehicle underbody
or tires/wheels, for example when running
over an obstacle, road debris or a pothole,
may cause serious damage and impair the
operating safety of your vehicle. If you feel a
sudden significant vibration or ride distur-
bance, or you suspect that damage to your
vehicle has occurred, you should turn on
your hazard warning flashers, carefully slow
down, and drive with caution to an area
which is a safe distance from the road.
Inspect the vehicle underbody and
tires/wheels for possible damage. If the ve-
hicle appears unsafe, have it towed to the
nearest authorized Mercedes-Benz Light
Truck Center or other qualified maintenance
or repair facility for further inspection or re-
pairs.
Warning!G
Various warning labels are attached to your
vehicle. These warning labels are intended
to make you and others aware of various
risks. You should not remove any of these
warning labels unless explicitly instructed to
do so by information on the label itself. Re-
moval of any of these labels may cause you
and others to be unaware of certain risks
which may result in an accident and/or per-
sonal injury.
164.boo Seite 17 Freitag, 30. März 2007 12:54 12

23 At a glance
Exterior view
ItemPage
1Tailgate122
Power tailgate*123
Cargo compartment

Loading instructions301

Cargo tie-down rings302

Hooks304

Expanding304

Cover blind310

Cargo net*312
Vehicle tool kit490
Spare wheel494
2Rear window defroster212
3Rear lamps505
4Fuel filler flap374
Refueling374
Fuel375,
565
ItemPage
5Exterior rear view mirrors
Adjusting51
Auto-dimming rear view
mirrors*208
Power folding*209
6Towing eye bolt
Installing towing eye bolt540
7Tires and wheels384,
555
Checking tire inflation
pressure395
General information384
Flat tire519
Spare wheel494
8Hood378
Opening378
Engine oil380
Coolant381
ItemPage
9Windshield wipers62
Wiper blades, replacing516
Wiper blades, cleaning431
aWindshield
Cleaning with wiper fluid64
Cleaning431
bRoof rails295
Carriers*296
cPower tilt/sliding sunroof*251
dDoors
Locking and unlocking112
Opening120
Unlocking/locking in an
emergency496
eFront lamps505
fHeadlamp cleaning system*208
164.boo Seite 23 Freitag, 30. März 2007 12:54 12

101 Safety and Security
Driving safety systems
Driving safety systems
In this section you will find information on
the following driving safety systems:

ABS (Antilock Brake System)

BAS (Brake Assist System)

ESP® (Electronic Stability Program)

EBP (Electronic Brake Proportioning)

4-ETS (Electronic Traction System)
ABS
The Antilock Brake System (ABS) regulates
the brake pressure so that the wheels do
not lock during braking. This allows you to
maintain the ability to steer your vehicle.
The ABS is functional above a speed of ap-
proximately 5 mph (8 km/h) independent
of road surface conditions.
On slippery road surfaces, the ABS will
respond even to light brake pressure.
The -indicator lamp in the instrument
cluster (
page 26) comes on when you
switch on the ignition. It goes out when the
engine is running.
Warning!G
The following factors increase the risk of
accidents:

Excessive speed, especially in turns

Wet and slippery road surfaces

Following another vehicle too closely
The driving safety systems described in this
section cannot reduce these risks or pre-
vent the natural laws of physics from acting
on the vehicle.
Always adapt your driving style to the pre-
vailing road and weather conditions and
keep a safe distance to other road users and
objects in the street.
iIn winter operation, the maximum effective-
ness of the ABS, the BAS, the ESP®, the EBP, and
the 4-ETS is only achieved with winter tires
(
page 420) or snow chains as required.
Warning!G
Do not pump the brake pedal. Use firm,
steady brake pedal pressure instead. Pump-
ing the brake pedal defeats the purpose of
the ABS and significantly reduces braking
effectiveness.
164.boo Seite 101 Freitag, 30. März 2007 12:54 12

102 Safety and Security
Driving safety systems
Braking
At the instant one of the wheels is about to
lock up, a slight pulsation can be felt in the
brake pedal, indicating that the ABS is in
the regulating mode.
Keep firm and steady pressure on the
brake pedal while experiencing the pul-
sation.
Continuous, steady brake pedal pressure
yields the advantages provided by the ABS,
namely braking power and ability to steer
the vehicle.
The pulsating brake pedal can be an
indication of hazardous road conditions
and functions as a reminder to take extra
care while driving.Emergency brake maneuver
Keep continuous full pressure on the
brake pedal.
Off-road – ABS
With the off-road driving program switched
on (
page 277), or with the transmission
in LOW RANGE* mode (
page 201), the
ABS designed for off-road use is automati-
cally activated.
When applying the brakes at speeds below
approximately 18 mph (30 km/h), the
front wheels are locked cyclically to short-
en the braking distance (dig-in effect). This
affects steering the vehicle.
For more information, see “Practical hints”
(
page 435).
Warning!G
When the ABS is malfunctioning, the BAS,
the ESP®, and the 4-ETS are also switched
off. The basic driving and braking functions
are still available.
When the ABS is malfunctioning, the wheels
may lock during hard braking, reducing
steering capability and extending the brak-
ing distance.
Warning!G
The ABS cannot prevent the natural laws of
physics from acting on the vehicle, nor can
it increase braking or steering efficiency be-
yond that afforded by the condition of the
vehicle brakes and tires or the traction
afforded. The ABS cannot prevent acci-
dents, including those resulting from
excessive speed in turns, following another
vehicle too closely, or hydroplaning. Only a
safe, attentive, and skillful driver can pre-
vent accidents. The capabilities of an ABS
equipped vehicle must never be exploited in
a reckless or dangerous manner which
could jeopardize the user’s safety or the
safety of others.
164.boo Seite 102 Freitag, 30. März 2007 12:54 12

103 Safety and Security
Driving safety systems
BAS
The Brake Assist System (BAS) operates in
emergency situations. If you apply the
brakes very quickly, the BAS automatically
provides full brake boost, thereby poten-
tially reducing braking distance.
Apply continuous full braking pressure
until the emergency braking situation is
over.
The ABS will prevent the wheels from
locking.
When you release the brake pedal, the
brakes function again as normal. The BAS
is then deactivated.
ESP®
The Electronic Stability Program (ESP®) is
operational as soon as the engine is run-
ning. It monitors the vehicle’s traction
(force of adhesive friction between the
tires and the road surface) and handling.
The ESP
® recognizes when a wheel is
spinning or if the vehicle starts to skid. By
applying brakes to the appropriate wheel
and by limiting engine output, the ESP
®
works to stabilize the vehicle. The ESP® is
especially useful while driving off and on
wet or slippery road surfaces. The ESP
®
also helps stabilize the vehicle during
braking and steering maneuvers.
The ESP
® warning lampv in the instru-
ment cluster (
page 26) flashes when the
ESP® is engaged.
The ESP
® warning lampv in the instru-
ment cluster comes on when you switch on
the ignition. It goes out when the engine is
running.
Warning!G
If the BAS is malfunctioning, the brake sys-
tem is still functioning, but without the addi-
tional brake boost available that BAS would
normally provide in an emergency braking
maneuver. Therefore, the braking distance
may increase.
Warning!G
The BAS cannot prevent the natural laws of
physics from acting on the vehicle, nor can
it increase braking efficiency beyond that
afforded by the condition of the vehicle
brakes and tires or the traction afforded.
The BAS cannot prevent accidents, includ-
ing those resulting from excessive speed in
turns, following another vehicle too closely,
or hydroplaning. Only a safe, attentive, and
skillful driver can prevent accidents. The
capabilities of a BAS equipped vehicle must
never be exploited in a reckless or danger-
ous manner which could jeopardize the
user’s safety or the safety of others.
164.boo Seite 103 Freitag, 30. März 2007 12:54 12

207 Controls in detail
Differential locks*
Start the engine (page 42).
To select the required locking mode,
rotate adjustment ring2 to the
desired position3 or4
(
page 205).
The indicator lamp on the adjustment
ring1 at the respective symbol
comes on.
Example illustration
5Center differential is completely locked
!If the differential locks have been manually
engaged, the tires will scuff on the road surface
when cornering because the differences be-
tween the individual wheel rotation speeds will
not be compensated for.
iThe differential locks are reset to AUTO
mode after the ignition has been switched off for
longer than 10 seconds.
164.boo Seite 207 Freitag, 30. März 2007 12:54 12

345 Operation
The first 1000 miles (1500 km)
Driving instructions
At the gas station
Engine compartment
Tires and wheels
Winter driving
Maintenance
Vehicle care
164.boo Seite 345 Freitag, 30. März 2007 12:54 12
