Automatic transmission
Emergency operation (Limp-Home
Mode)
If vehicle acceleration becomes less re-
sponsive or sluggish or the transmission
no longer shifts, the transmission is most
likely operating in limp-home (emergency
operation) mode. In this mode only second
gear and reverse gear can be activated.
Stop the vehicle in a safe location.
Shift to park positionP.
Turn off the engine.
Wait at least 10 seconds before
restarting.
Restart the engine.
Shift to drive positionD (for second
gear) or reverse gearR.
Have the transmission checked at an
authorized Mercedes-Benz Light Truck
Center as soon as possible.
164.boo Seite 200 Freitag, 30. März 2007 12:54 12

201 Controls in detail
Transfer case
Transfer case
LOW RANGE mode*
The LOW RANGE mode is available on vehi-
cles with enhanced off-road package*.
In the following situations you should
switch to LOW RANGE mode:

during off-road driving (page 355)

when crossing water (page 360)

when towing up or down on steep
gradients
With the LOW RANGE selected, the
engine’s power delivery and the shifting
behavior of the automatic transmission are
adjusted. Furthermore, the ABS, ESP
® and
4-ETS functions especially adapted to
off-road travel are activated.
For information on driving safety systems
during LOW RANGE mode, see “Driving
safety systems” (
page 101).
For more information on Off-road driving,
see “Off-road driving” (
page 355).Gear Ranges
There are two possible settings.
!Operational or performance test must only
be conducted on a two-axle dynamometer. If
such tests are necessary, contact an authorized
Mercedes-Benz Light Truck Center. You could
otherwise seriously damage the brake system or
the transfer case which is not covered by the
Mercedes-Benz Limited Warranty.
!Because the ESP® operates automatically,
the engine and ignition must be shut off
(SmartKey in starter switch position0 or1 or
KEYLESS-GO* start/stop button in
position0or1) when testing the parking brake
on a brake test dynamometer and such testing
should be no longer than 10 seconds.
Active braking action through the ESP
® may
otherwise seriously damage the brake system
which is not covered by the Mercedes-Benz
Limited Warranty.
iThe vehicle is equipped with permanent
four-wheel drive. Both the front and rear axles
are powered at all times when the vehicle is
being operated.
HIGH
RANGERoad position for all normal
driving situations.
(LOW RANGE mode off)
LOW
RANGEOff-road position for traveling
on rough terrain.
(LOW RANGE mode on)
Also use the off-road position
when driving on-road on steep
gradients, especially when
towing a trailer.
LOW RANGE acts by raising
the engine’s gear ratio. The ve-
hicle travels at roughly third
the speed compared to when
in the HIGH RANGE position,
leading to an increase in the
engine’s drive power.
164.boo Seite 201 Freitag, 30. März 2007 12:54 12

202 Controls in detail
Transfer case
Switching LOW RANGE mode
The switch is located on the upper part of
the center console.
1LOW RANGE switch
2Indicator lamp
3LOW RANGE displaySwitching LOW RANGE mode on
(switching from HIGH RANGE to LOW
RANGE)
Press LOW RANGE switch1.
Indicator lamp2 flashes.
If the system senses that all conditions
are met, it will switch to LOW RANGE
mode. A chime sounds and the LOW
RANGE display3 appears in the multi-
function display.
The indicator lamp2 on the
LOW RANGE switch comes on continu-
ously, indicating that the LOW RANGE
mode has been activated.
Warning!G
Always wait until the procedure of shifting
from HIGH RANGE to LOW RANGE – and
from LOW RANGE to HIGH RANGE – has
been entirely completed. During this proce-
dure do not:

switch off the engine

shift the automatic transmission into
another gear
If you do not wait until the shifting proce-
dure has been entirely completed then it
might not be correctly performed. The trans-
fer case might be in neutral, thus interrupt-
ing the transfer of power between the
engine and the drive axle.
The vehicle is then freely movable, even if a
gear has been selected, and could uninten-
tionally be set into motion – particularly on
up – or downhill grades. This could lead to
an accident and cause injury to yourself and
others.
Please observe related messages appearing
in the multifunction display (
page 488).
!The shift procedure can only be performed
when the following conditions are met:

The engine is running (page 41).

The automatic transmission is in positionN
(
page 190).

The vehicle speed does not exceed 25 mph
(40 km/h).
iThere is no reset to HIGH after the ignition
has been switched off.
164.boo Seite 202 Freitag, 30. März 2007 12:54 12

203 Controls in detail
Transfer case
Switching LOW RANGE mode off
(switching from LOW RANGE to HIGH
RANGE)
Press LOW RANGE switch1
(
page 202).
Indicator lamp2 flashes.
If the system senses that all conditions
are met, it will switch to back to
HIGH RANGE mode. A chime sounds
and the LOW RANGE display3 ap-
pears in the multifunction display.
The indicator lamp2 on the
LOW RANGE switch goes out, indicat-
ing that the LOW RANGE mode has
been deactivated.
For messages in the multifunction display,
see “Practical hints” section (
page 488).
iYou can cancel the procedure by pressing
the LOW RANGE switch again while the indicator
lamp is flashing.
!The shift procedure can only be performed
when the following conditions are met:

The engine is running (page 41).

The automatic transmission is in positionN
(
page 190).

The vehicle speed does not exceed 43 mph
(70 km/h).
iThere is no reset to LOW after the ignition
has been switched off.
iYou can cancel the procedure by pressing
the LOW RANGE switch again while the indicator
lamp is flashing.
164.boo Seite 203 Freitag, 30. März 2007 12:54 12

204 Controls in detail
Differential locks*
For more information on Off-road driving,
see “Off-road driving” (
page 355).
Vehicles with enhanced off-road package*
are equipped with automatic locks for the
center and rear axle differential to improve
vehicle traction.

The center differential compensates
for differences in wheel rotation be-
tween the front and rear axle.

The rear axle differential compensates
differences between the rear wheels.A few words about differentials and
differential locks*
When a vehicle negotiates a turn, wheels
on the outside of the curve must travel far-
ther and rotate faster than the inside
wheels. The differential, the operation of a
set of gears that allows the powered
wheels in a vehicle to turn at different
speeds, makes this essential function pos-
sible.
The drawback is that the differential also
sends most of the engine’s power to the
wheel with the least load or strain on it. For
example, if one of a vehicle’s powered
wheels sits on a patch of snow and spins
because there is no traction, all of the en-
gine’s power will go to that wheel because
the power will take the path of least resis-
tance. Meanwhile, the opposite wheel, sit-
ting on dry pavement where it could get
enough grip to start the vehicle moving,
sits idle because it receives no power.The Electronic Traction System (ETS) ad-
dresses this problem and provides for
good control and steering ability by auto-
matically slowing the slipping wheel and
thus increasing the power to the other
non-slipping drive wheels to get the vehicle
moving. The ESP
® and ETS in this vehicle
feature such intelligent limited-slip differ-
ential technology, ideally suited for
on-road and light off-road driving. Transfer
case position LOW (
page 201) also en-
hances off-road driving capabilities
(
page 355).
More extreme off-road conditions may call
for another solution, engaging a differen-
tial lock or preventing the differential from
operating altogether. This vehicle comes
with two differential locks: transfer case
(center) and rear. Each can be engaged
simply by operating a rotary switch located
on the center console (
page 205). When
the transfer case (center) differential is
locked, the combined (or average) speed
of the front wheels is identical to the com-
bined rear wheel speed. When the rear
differential is locked, both rear wheels turn
iAt the front axles, the 4-ETS system
(
page 107) compensates for any traction
problems.
164.boo Seite 204 Freitag, 30. März 2007 12:54 12

205 Controls in detail
Differential locks*
at the same speed, independent of the in-
dividual torque. Please be aware that en-
gaging the differential locks will
significantly reduce the steering ability of
the vehicle.
For your safety and the safety of others
and to prevent damage to the vehicle, the
differential locks must not be engaged
when driving on paved roads. It is impor-
tant to understand that during
on-road/paved driving, differentials are
absolutely necessary for providing the es-
sential control and steering ability of the
vehicle. The differential locks, therefore,
must not be engaged when driving on
paved roads and should only be used to
the extent necessary to negotiate off-road
conditions which cannot be handled by the
systems (automatic 4-ETS, the ESP
®, man-
ual switch position “LOW” of transfer case)
this vehicle comes equipped with.
Switching differential locks*The rotary switch for the differential locks
is located on the upper part of the center
console.
You can select between three locking
modes.
1Rotatable outer adjustment ring with
indicator lamp
2AUTO mode: center differential is auto-
matically locked
3Center differential is completely locked
4Center and rear axle differential are
completely locked
!If the differential locks are engaged, accel-
erate gently when setting the vehicle in motion.
To avoid damage to the transmission, the vehicle
may only be operated on a dynamometer (single
axle dynamometer) if

the axle not being driven is jacked up
or

the associated propeller shaft is disconnect-
ed.
164.boo Seite 205 Freitag, 30. März 2007 12:54 12

206 Controls in detail
Differential locks*
AUTO mode
The AUTO mode is adequate for most driv-
ing situations since the center differential
is locked and released as required.
Start the engine (page 42).
The center differential locks is in AUTO
mode. The indicator lamp on the
adjustment ring1 above
symbolU2 is on.Center and rear axle differential locksThe differential locks should only be
engaged manually if traction is insufficient
in AUTO mode.
The differential locks can be engaged in
the sequence3, 4 (
page 205) up to a
speed of 19 mph (30 km/h).
Engaging differential locks:

for off-road driving

for driving through water

when driving on deep snow and icy or
fouled surfaces
iAt speeds up to 19 mph (30 km/h), it is
possible to manually lock the differential locks
for driving on rough terrain.
Warning!G
Never drive on a paved surface with the
center and rear axle differential locks
manually engaged. Ability to steer the
vehicle is greatly reduced when the differen-
tial locks are manually engaged, increasing
the risk of an accident.
For safety reasons, the locks are automati-
cally released at a vehicle speed above
31 mph (50 km/h). Nevertheless, you
should only manually lock the differential if
absolutely necessary because engaged
locks will restrict the vehicle drive train
while cornering and cause the vehicle to
chatter. This could cause you to lose control
of the vehicle and cause an accident.
!The differential locks must not be engaged
manually when towing the vehicle or spinning the
wheels.
164.boo Seite 206 Freitag, 30. März 2007 12:54 12

207 Controls in detail
Differential locks*
Start the engine (page 42).
To select the required locking mode,
rotate adjustment ring2 to the
desired position3 or4
(
page 205).
The indicator lamp on the adjustment
ring1 at the respective symbol
comes on.
Example illustration
5Center differential is completely locked
!If the differential locks have been manually
engaged, the tires will scuff on the road surface
when cornering because the differences be-
tween the individual wheel rotation speeds will
not be compensated for.
iThe differential locks are reset to AUTO
mode after the ignition has been switched off for
longer than 10 seconds.
164.boo Seite 207 Freitag, 30. März 2007 12:54 12

208 Controls in detail
Good visibility
For information on windshield wipers, see
“Windshield wipers” (
page 62).
Headlamp cleaning system*
The headlamps will automatically be
cleaned with a high-pressure water jet
when you have

switched on the headlamps
and

operated the windshield wipers with
windshield washer fluid five times
When you switch off the headlamps, the
counter resets.
For information on filling up the washer
reservoir, see “Windshield/rear window
washer system and headlamp cleaning
system*” (
page 383).
Rear view mirrors
For more information on setting the rear
view mirrors, see “Mirrors” (
page 51).
Interior rear view mirror, antiglare
position
1Lever
Tilt the mirror to the antiglare position
by moving lever1 towards the wind-
shield.
The interior rear view mirror is dimmed.Auto-dimming rear view mirrors*
The reflection brightness of the exterior
rear view mirror on the driver’s side and
the interior rear view mirror will respond
automatically to glare when

the ignition is switched on
and

incoming light from headlamps falls on
the sensor in the interior rear view
mirror
The rear view mirror will not react if

the automatic transmission is set to
positionR

the interior lighting is turned on
164.boo Seite 208 Freitag, 30. März 2007 12:54 12

209 Controls in detail
Good visibility
Power folding exterior rear view
mirrors*
Folding the exterior rear view mirrors
in and out automatically
When the corresponding function in the
control system is activated (
page 182):

The exterior rear view mirrors automat-
ically fold in as soon as the vehicle is
locked from the outside.

The exterior rear view mirrors automat-
ically fold out as soon as the vehicle is
unlocked and the driver’s or front pas-
senger door are subsequently opened.Synchronizing exterior rear view
mirrors
The power folding rear view mirrors may
have to be synchronized after the vehicle
battery has been disconnected or dis-
charged. If the exterior rear view mirrors
do not fold properly upon locking or un-
locking the vehicle although the corre-
sponding function in the control system is
activated (
page 182), do the following:
Fold each exterior rear view mirror in
completely (
page 210).
Fold each exterior rear view mirror out
completely (
page 210).
When the exterior rear view mirrors fold
properly upon locking the vehicle, the exte-
rior mirrors are synchronized. Otherwise
repeat the above steps.
Warning!G
The auto-dimming function does not react if
incoming light is not aimed directly at sen-
sors in the interior rear view mirror.
The interior rear view mirror and the exterior
rear view mirror on the driver’s side do not
react, for example, when transporting cargo
which covers the rear window.
Light hitting the mirror(s) at certain angles
(incident light) could blind you. As a result,
you may not be able to observe traffic con-
ditions and could cause an accident.
Warning!G
Exercise care when using the passen-
ger-side exterior rear view mirror. The mirror
surface is convex (outwardly curved surface
for a wider field of view). Objects in mirror
are closer than they appear. Check your
interior rear view mirror or glance over your
shoulder before changing lanes.
!Before you drive the vehicle through an
automatic car wash, fold the exterior rear view
mirrors in. Otherwise they may get damaged.
164.boo Seite 209 Freitag, 30. März 2007 12:54 12
