wtheTPMS tocontinu eto function prop‐
er ly. The
system checks thetir epr essur eand thetir e
te mp eratur eof thetir es installed ontheve hicle
by means ofatir epr essu resensor .
Ne wtirepr essur esensor s,e.g. inwint ertires,
ar eaut omaticall yta ught -indur ing thefirs tjou r‐
ne yth ey areused.
The tirepr essur eand thetir ete mp eratur e
appear inthemultifunc tiondispla y
(/ page51 9).
If th er eis asubs tantia lpr ess ureloss orifth e
tir ete mp eratur eis exc essiv e,youwill bewarned
in thefo llo wing ways:
R Viadispla ymes sages(/ page61 4)
R Viath e0077 warning lam pin theins trument
clus ter(/ page634)
The tirepr essu remonit oring system isonl yan
aid. Itis thedr iver's responsibili tyto setth etir e
pr essur eto there comme ndedcoldtirepr ess ure
su itab leforth eoper ating situation .Se tth etir e
pr essur efo rcold tires using atir epr essu re ga
ug e. No tethat thecor rect tirepr ess urefo rth e
cur rent operati ng situa tionmu stfirs tbe taught -
in to thetir epr essur emonit oring system.
In mos tcases, thetir epr essur emonit oring sys‐
te m wil lau tomatical lyupd ateth ene wrefere nce
va lues afte ryo uha ve chang edthetir epr essur e.
Yo ucan ,ho we ver,also updat eth ere fere nce val‐
ues byrestar tin gth etir epr essur emonit oring
sy stem manuall y(/ page520).
Sy stem limit s
The system maybe impair edorma yno tfunc tion
in thefo llo wing situat ions:
R The tirepr essur ehas been setinc orrectl y
R The reisasudden pressur eloss caused, for
ex am ple, byafo re ign obje ctpene trating the
tir e
R Thereis ama lfunctio ncau sedby ano ther
ra dio signal source
Be sureto also payatt ent ion tothefo llo wing
re lat ed topic:
R Noteson tirepr essur e(/ page51 5) Ch
ecking thetir epr essur ewit hth etir epr es‐
sur emoni toring system
Re quirement s:
R The ignit ionisswitc hedon.
On- boar dcom puter:
4 Service 5
Tires
One ofthefo llo wing displa ysappear s:
R Cur rent tirepr ess ureand tirete mp eratur eof
th eindividual wheels: R
Tire pressure willbedisplayed afterdriving a
few minutes
R Tire Pressure MonitorAct ive: thete ac h-in
pr oce ssofthesy stem isno tye tcomple te. Wheels
andtires 51
9
Page 522 of 682

The
tirepr essur esarealr eady being moni‐
to re d. #
Com pareth etir epr essur ewit hth ere com‐
mend edtirepr ess urefo rth ecur rent operat‐
ing cond ition (/ page 516). Observeth e
no teson tirete mp eratur e(/ page51 5).
% Theva lues displa yedin themultifunc tiondis‐
pla yma yde viat efrom those ofthetir epr es‐
sur ega ug eas they referto sea leve l.At high
altitudes, thetir epr essur eva lue indic ated by
a pr essur ega ug ear ehigh erthan those
sho wnbytheon- boar dcom puter.In this
case, donotre duce thetir epr essur e.
Mak esur eto obser vethefo llo wing further rela‐
te dsubjec t:
R Noteson tirepr essur e(/ page51 5)
Re star ting thetir epr essur emoni toring sys‐
te m
Re quirement s:
R The recomme ndedtirepr ess ureis cor rectl y
se tfo rth ere spectiv eoper ating status on
eac hof thefo ur wheel s(/ page51 5). Re
star tth etir epr essur emonit oring system in
th efo llo wing situat ions:
R The tirepr essur ehas chang ed.
R The wheels ortires have been chang edor
ne wlyins talled.
On- boar dcom puter:
4 Service 5
Tires #
Swipe down wardson Touc hCon trol on the
lef t-hand sideofthesteer ing wheel.
The Use Current Pressures asNew Refer-
ence Values messag eis sho wninthemulti‐
func tion displa y. #
Tobegin restar t,pr ess Touc hCon trol on the
lef t-hand sideofthesteer ing wheel.
The Tire Press. MonitorRestart edmessag eis
sho wninthemultifunc tiondispla y.
Cur rent wa rning mess ages aredele tedand
th eye llo w0077 warning lam pgoes out.
Af teryo uha ve been driving fora fe w
minut es,thesy stem checks whe ther thecur‐
re nt tirepr ess ures arewi thin thespecif ied
ra ng e. The current tirepr ess ures areth en
accep tedas refere nce values andmon itor ed. Mak
esur eto obser vethefo llo wing further rela‐
te dsubjec t:
R Noteson tirepr essur e(/ page51 5)
Ra dio -equipme ntappr oval of thetir epr es‐
sur emoni toring system
Ra dio equipme ntappr oval number s Co
untr yR adiotype approval number
US AF CCID:YG OTSSRE4A
Ca nad aI C:4008C-TS SRE4A Fu
rther information onthedeclar ationofcon ‐
fo rm ity forwir eles sve hicle component s
(/ page27 ). Ti
re pres sur elo ss wa rning system Fu
nction ofthetir epr essur eloss warning
sy stem
The tirepr essur eloss warning system warnsth e
dr iver by means ofdisp lay messa geswhen ther e
is ase vere tirepr es su re loss. 520
Wheels andtires
Page 523 of 682

Af
tera ch ang ein tirepr essur e,awheel rotatio n
or atir ech ang e,or ifyo uha ve re-ins talled
wheels ortires, thetir epr essur eloss warning
sy stem has tobe restar ted(/ page52 1).
The tirepr essur eloss warning system does not
re place theneed toregular lych eckth etir epr es‐
sur e.
Sy stem limita tions
The system maybe impair edorma yno tfunc tion
par ticular lyin thefo llo wing situat ions:
R Incorrectly settir epr ess ure
R Sud den press urelos scau sed,fo rex am ple,
by afo re ign obje ctpene trating thetir e
R Steady pressur eloss inseveraltir es
The system has are strict ed ordel ayed func tion
par ticular lyin thefo llo wing situat ions:
R Poor ground condit ions,e.g.snowor grave l
R Driving with sno wch ains
R When adoptingave ry spor tydriving style
wit hhigh corner ing speeds orsudden accel‐
er ation
R Drivin gwit have ry hea vyorlarge trai le r R
Driving with ahigh load
Be sureto also obse rveth efo llo wing further
re lat ed subje cts:
R Noteson tirepr essur e(/ page51 5)
R Display messa gesabout thetir es
(/ page61 4)
Re star ting thetir epr essur eloss warning
sy stem
Re quirement s:
R The recomme ndedtirepr ess ureis cor rectly
se tfo rth ere spectiv eoper ating status on
eac hof thefo ur wheel s(/ page51 5).
Re star tth etir epr essur eloss warning system in
th efo llo wing situat ions:
R The tirepr essur ehas chang ed.
R The wheels ortires have been chang edor
ne wlyins talled. On-
boar dcom puter:
4 Service 5
Tires #
Swipe down wardson Touc hCon trol on the
lef t-hand sideofthesteer ing wheel.
The Tire Pressure ControlSystem Active
Restart messageis sho wninthemultifunc ‐
tion displa y. #
Tobegin restar t,pr ess Touc hCon trol on the
lef t-hand sideofthesteer ing wheel.
The Tire Pressure NowOK?messag eis
sho wninthemultifunc tiondispla y. #
Select Yes. #
Toconf irm restar t,pr ess Touc hCon trol on
th elef t-hand sideofthesteer ing wheel.
The Run FlatIndic atorRestart edmessag eis
sho wninthemultifunc tiondispla y.
Af teryo uha ve driven fora fe w min utes, the
tir epr es su re loss warning system monit ors
th ese ttir epr essur esofall thetir es.
Be sureto also obse rveth efo llo wing further
re lat ed subje cts:
R Noteson tirepr essur e(/ page51 5) Wh
eelsan dtir es 52
1
Page 524 of 682

Load
ingtheve hicl e No
teson Tire and Loading Information plac‐
ar d &
WARNIN GRisk ofacci dent from overloa‐
ded tires
Ov erloaded tires ma yove rheat and burstas a
con sequenc e.Ov erloaded tires can also
im pair thesteer ing and handling charact eris‐
tic sand lead tobrak efa ilur e. #
Obser vetheload-bear ingcapacity of
th etir es. #
The load-bear ingcapacity mustbe at
leas thalf thegr oss axle weight rating of
th eve hicle. #
Neverove rload thetir es by exc eeding
th emaximum load. The
Tire and Loadi ngInfo rm atio nplacar dis on
th eB-pillar onthedr iver's side oftheve hicle. 1
Tire and Loadi ngInfo rm atio nplacar d %
The datasho wnintheillus tration isexam ple
dat a.
The Tire and Loadi ngInfo rm atio nplacar dsho ws:
R Maximum numberofseats 2accor dingto
th emaximum numberofpeople permitt edto
tr ave lin theve hicle.
R Maximum permissible load3com prises the
gr os swe ight ofall vehicle occupants, load
and luggage. 522
Wheels andtires
Page 525 of 682

R
Recomme ndedtirepr ess ures 1 forcold
tir es. The recomme ndedtirepr ess ures are
va lid forth emaximum permissible loadand
up tothemaximum permissible vehicle
speed.
Please alsonote:
R Information onper missib lewe ight sand loads
on theve hicle identif ication plate
(/ page552).
R Information ontirepr essur ein thetir epr es‐
sur eta ble (/ page51 6).
Fu rther relat ed subje cts:
R Determ inin gth emaximum permissible load
(/ page523)
R Noteson tirepr essur e(/ page51 5). Ste
psforDe term ining Correct Load Limit The
follo wing steps have been developed as
re qu ired ofall manuf acturersunder Title 49,
Co de ofU.S. Feder alRe gulations, Part57 5, pur‐
sua nttothe"N ational Traf fic and MotorVe hicle
Saf etyAc tof 1966". #
(1):Locat eth est at emen t"The combined
we ight ofocc upant sand cargoshould never
exc eed XXX kgorXXX lbs." onyour vehicle's
placar d. #
(2): Determ ine thecombin edweight ofthe
dr iver and passeng ersth at will beriding in
yo ur vehicle. #
(3): Subtr actthecombin edweight ofthe
dr iver and passeng ersfrom XXX kgor
XXX lbs. #
(4): The resulting figur eeq uals theav ailable
amoun tof car goand luggageload capac ity.
Fo rex am ple, ifth e"XXX" amount equals
14 00 lbs. and ther ewill befive 150lb pas ‐
seng ersin your vehicle, theamount ofavaila‐
ble cargoand luggageload capac ityis
65 0lbs. (140 0-75 0(5 x15 0) =650 lbs.) #
(5):De term ine thecombin edweight oflug‐
ga ge and cargobein gloaded ontheve hicle.
The weight mayno tsaf elyexc eed theav aila‐
ble cargoand luggageload capac itycalc ula‐
te din Step 4. #
(6): Ifyo ur vehicle willbetowing atrailer ,
load from your trailer willbetrans ferred to yo
ur vehicle. Consult this manual todeter‐
mine howthis reduces theav ailable cargo
and luggageload capac ityofyour vehicle.
% Notall vehicles areper mitt edtotow a
trailer .To wing atrailer isonl yper mittedifa
tra iler -hit chisins talled. Please consult an
aut hor ized Mercedes -Benz dealer ifyo uha ve
an yqu estion sabout towing atrailer with
yo ur vehicle.
Ev en ifyo uha ve cal cul ated thetot alload care‐
full y,yo usho uld still mak esur eth at themaxi‐
mum permissible gross weight andthemaxi‐
mum gross axle weight rating ofyour vehicle are
no texc eeded. Details can befound ontheve hi‐
cle identif ication plate. #
Have your loaded vehicle –including driver ,
occupants andload –we ighed onave hicle
we ighbr idge.
The measur edvalues mayno texc eed the
maximu mper missi blevalues stat ed on the
ve hicle identif ication plate.
Fu rther relat ed subje cts:
R Calculation exam ple forde term inin gth emax‐
imum load(/page52 4) Wheels
andtires 523
Page 526 of 682

R
Tire and Loadi ngInfo rm atio nplacar d
(/ page52 2)
R Tire pressur eta ble (/ page51 6)
R Vehicle identif ication plate Calculation
exam ple forde term ining the
ma ximum load The
follo wing table showsexam ples ofhowto
cal cul ateto ta land load capac itieswithva rying
seatin gcon figur ations anddiffere nt num bers
and sizes ofocc upant s.The follo wing exam ples
use amax imum loadof1500 lbs (680 kg).This is
forillus tratio npur pos esonly.Mak esur e
yo uar eusin gth eactual loadlimit foryo ur vehi‐
cle stat ed on your vehicle's Tire and Loadi ng
In fo rm atio nplacar d(/ page52 2).
The high erthewe ight ofall theoccupant s,the
smaller themaximum loadforlug gage .
Ste p1 Ex
am ple 1E xamp le2
Combine dmaxim umweight ofocc upant sand
load (datafrom theTire and Loadi ngInfo rm atio n
placar d) 15
00 lbs (680 kg)1 500lbs(680 kg) Ste
p2 Ex
am ple 1E xamp le2
Nu mb erofpeople intheve hicle (driver and
occupants) 51
Dis trib uti on oftheoccupant sF ront:2
Re ar:3 Fr
ont :1 52
4
Wheels andtires
Page 527 of 682

Ex
am ple 1E xamp le2
We ight ofocc upant sO ccupant1:150lbs (68 kg)
Occupant 2:180lbs (82 kg)
Occupant 3:160lbs (73 kg )
Occupant 4:140lbs (63 kg)
Occupant 5:120lbs (54kg ) Occupant
1:200 lbs(91 kg )
To talwe ight ofall occ upant s7 50lbs (340 kg)2 00lbs (91 kg ) Ste
p3 Ex
am ple 1E xamp le2
Pe rm issible load(maxim umgros sve hicle weight
ra ting from theTire and Loadi ngInfo rm atio n
placar dmin usthegr oss weight ofall occ upant s)15
00 lbs (680 kg)00F8 75 0lbs (340 kg)= 75 0lbs
(340 kg) 15
00 lbs (680 kg)00F8 200 lbs(91 kg )= 13 00 lbs
(589 kg) Wheels
andtires 525
Page 528 of 682

Ti
re labeling Ov
ervie wof tirelabeling 1
Uniform Tire Qua lityGradi ng Standar d
(/ page52 6)
2 DOT,Tire Identif ication Number
(/ page52 7)
3 Maximu mtireloa d(/ page528)
4 Maximu mtirepr essu re(/ pag e528 ) 5
Manuf acturer
6 Char acteristics ofthetir e(/ page529)
7 Tire size designation, load-bearing cap acity,
spe edrating andload index(/ pag e529)
8 Tire nam e
% The data sho wnintheimag eis exam ple
dat a. Ti
re Quality Grading In
accor dance withth eUS Depar tmentof Trans ‐
por tatio n's "Uni form Tire Qua lityGradi ng Stand‐
ar ds", tireman ufact urersar ere qu ired tograde
th eir tires on thebasis ofthefo llo wing thre eper‐
fo rm anc efa ct or s: 1
Tread weargrade
2 Tract ion grade
3 Temp eratur egr ade
% The datasho wnintheillus tration isexam ple
dat a.
% The classificat ion isno tleg allyst ipulat edfor
Canad a,but itis ge ner ally stat ed.
Tr ead weargrade
The tread weargrade isacom parativ era ting
ba sedon thewe arrate of thetir ewhen tested
under controlled conditions onaspecif iedtest
tr ac kof theUS Depar tmentof Trans portatio n.
Fo rex am ple, atir egr aded 150wo uld wearone 526
Wheelsand tires
Page 529 of 682

and
one-h alftim esaswellon thego vernment
te st trac kas atir egr ad ed 100.
The relativ eper form anc eof tires depen dsupon
th eactual conditions oftheir use, howe ver,and
ma ydepar tsign ifican tly from thenor mdue to
va riatio nsindrivin ghabit s,ser vicepr act icesand
dif fere nces inroad charact eristic sand climate
con dition s.
Tr actio ngr ade &
DANG ER Risk ofacc iden tdue toinade‐
qu atetract ion
The tract ion grade assig nedtothis tireis
based onstra ight -ahead brakin gtract ion
te sts, and does notinclude either acceler a‐
tion, corner ing, hydroplaning orpeak traction
ch aract eristic s. #
Alw aysadap tyo ur drivin gst yle and
dr ive at aspeed tosuit thepr ev ailin g
traf fic and weather condition s. *
NO
TEDama getothedr ivet ra in from
wheelspin #
Avoid wheelspin. The
traction classes, from highes tto lowe st,ar e
AA ,A, Band C.Tho segrad es repr esent thetir e's
ability tostop onwetpa vement asmeasu red
und ercontro lled condition son spec ified govern‐
ment test sur faces ofasp haltand concr ete. A
tir emar kedC ma yha ve poor traction perform ‐
anc e.
Te mp eratur egr ade &
WARNIN GRisk ofacci dent from tire
ove rheating andtirefa ilur e
The temp eratur egr ade forth is tireis es tab‐
lished fora tir eth at isproper lyinflat ed and
no tove rloaded. Excessiv espeed, underinfla‐
tion, orexc essiv eloading, either separ ately
or incombin ation,cancause excessiv eheat
build-up andpossible tirefa ilur e. #
Obser vethere comme ndedtirepr es‐
su resand regular lych eckth etir epr es‐ sur
eof all tires including thespar e
wheel. #
Adjus tth etir epr essur eas neces sary. The
temp eratur egr ades areA (the highes t),B
and C.The yre pr esent thetir e's resis tance tothe
ge ner ation ofhea tand itsability todissipat e
heat when tested under controlled conditions on
a specif iedindoor laborator yte st wheel. Sus‐
ta ined hightemp eratur ecan cause themat erial
of thetir eto deg ener ateand reduce tirelife, and
exc essiv ete mp eratur ecan lead tosudden tire
fa ilur e.Grade Ccor responds toaleve lof per‐
fo rm anc ewhic hall passe nger car tires mus t
mee tunde rth eFe der alMo torSaf etySt andar d
No. 109. Grade sB and Arepr esent higher leve ls
of per form anc eon thelabor ator yte st wheel
th an theminimum requ ired bylaw. DO
T,Tire Iden tificat ionNumbe r(TI N) US
tirere gulations stipulat eth at eve rytire man‐
uf actu reror retrea de rmu stimprint aTIN inor
on theside wallof eac htir epr oduced. Wheels
andtires 52
7
Page 530 of 682

%
The datasho wnintheimag eis exam ple
dat a.
The TINisauniq ueiden tificat ion num berto
ident ifytires and comprises thefo llo wing:
R DOT(Depar tment ofTranspo rtation ):tir e
symb olmar ks1 indic atingth at thetir e
com plies withth ere qu iremen tsof theUS
Depar tmentof Trans portatio n.
R Man ufac tur eride ntificat ion code: manu‐
fa ctur eridentif ication code 2cont ains
de tails ofthetir emanuf acturer.Ne wtires
ha ve acod ewit htw osymbo ls.Retrea de d
tir es have acod ewit hfo ur symb ols.Further
inf ormation onretrea de dtir es (/ page 534). R
Tire size: identif ier3 descr ibesthetir e
size.
R Tire type code: tiretyp ecod e4 can be
us ed bythemanuf actureras acode to
descr ibespecif icch aract eristic sof thetir e.
R Manuf acturingdate:manuf acturingdate
5 prov ides informatio nabout theag eof a
tir e. The 1stand 2nd position sre pr esent the
cal enda rwe ek and the3r dand 4thposition s
st at eth eye ar ofman ufact ure(e. g."32 08"
re pr esent sth e32n dwe ek of2008 ). Inf
ormat iononthema xim um tireload %
The datasho wnintheimag eis exam ple
dat a.
Max imum tireload 1isthemaximum permissi‐
ble weight forwhi chthetir eis appr oved.
Do notove rload thetir es by exceed ingthespeci‐
fi ed load limit. Themaximum permissible load
can befound ontheve hicle's Tire and Loadi ng
In fo rm atio nplacar don theB-pillar onthedr iv‐
er's side (/page522). Specif
ications formaxi mum tirepr es sur e %
The data sho wnintheimag eis exam ple
dat a. 528
Wheelsand tires
