CD changer MERCEDES-BENZ M-Class 2003 W163 Comand Manual

Contents
Introduction . . . . . . . . . . . . . . . . . . . . . 5
Where to find it . . . . . . . . . . . . . . . . . . . 5
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operating safety. . . . . . . . . . . . . . . . . . . 7
At a glance . . . . . . . . . . . . . . . . . . . . . . 9
MCS control unit . . . . . . . . . . . . . . . . . 10
Display screen . . . . . . . . . . . . . . . . 12
Quick reference MCS . . . . . . . . . . . . . . 14
Switching the MCS operating
unit on and off . . . . . . . . . . . . . . . . 14
Adjusting the volume . . . . . . . . . . . 16
Radio operation . . . . . . . . . . . . . . . 16
Tape operation . . . . . . . . . . . . . . . . 17
CD operation* . . . . . . . . . . . . . . . . 18
Telephone operation* . . . . . . . . . . . 19
Navigation system, entering a
destination and calculating
a route . . . . . . . . . . . . . . . . . . . . . . 20
Audio. . . . . . . . . . . . . . . . . . . . . . . . . . 25
Radio operation . . . . . . . . . . . . . . . . . . 26
Quick reference . . . . . . . . . . . . . . . 26
Menu overview . . . . . . . . . . . . . . . . 28Switching radio operation on . . . . . 30
Switching another system on . . . . . 30
Changing the Radio band . . . . . . . . 31
Selecting a station . . . . . . . . . . . . . 32
Memory functions . . . . . . . . . . . . . . 36
Tape operation . . . . . . . . . . . . . . . . . . . 38
Quick reference . . . . . . . . . . . . . . . 38
Inserting or ejecting a tape. . . . . . . 40
Menu overview . . . . . . . . . . . . . . . . 42
Listening to a cassette . . . . . . . . . . 44
Error messages . . . . . . . . . . . . . . . . 44
Changing sides . . . . . . . . . . . . . . . . 44
Fast forward and rewind . . . . . . . . . 45
Music search . . . . . . . . . . . . . . . . . 45
Tape scan . . . . . . . . . . . . . . . . . . . . 46
Blank skip . . . . . . . . . . . . . . . . . . . . 46
Dolby B (noise reduction) . . . . . . . . 47
Pause . . . . . . . . . . . . . . . . . . . . . . . 47
CD operation . . . . . . . . . . . . . . . . . . . . 48
Quick reference . . . . . . . . . . . . . . . 48
General information on CD
mode. . . . . . . . . . . . . . . . . . . . . . . . 50
Inserting or ejecting a CD . . . . . . . . 51
Menu overview . . . . . . . . . . . . . . . . 54
Switching CD operation on
and off . . . . . . . . . . . . . . . . . . . . . . 56Error messages . . . . . . . . . . . . . . . . 57
Selecting a CD
MCS with CD changer. . . . . . . . . . . 58
Track select . . . . . . . . . . . . . . . . . . 59
Music seek . . . . . . . . . . . . . . . . . . . 60
CD track scan . . . . . . . . . . . . . . . . . 60
CD track repeat . . . . . . . . . . . . . . . 61
CD track random play . . . . . . . . . . . 61
Pause . . . . . . . . . . . . . . . . . . . . . . . 62
Elasped time display . . . . . . . . . . . . 62
Audio Adjustment . . . . . . . . . . . . . . . . . 63
Audio Adjustment . . . . . . . . . . . . . . 63
Telephone. . . . . . . . . . . . . . . . . . . . . . 65
Important notes . . . . . . . . . . . . . . . . . . 66
Telephone mode . . . . . . . . . . . . . . . . . . 68
Quick reference . . . . . . . . . . . . . . . 68
Menu overview . . . . . . . . . . . . . . . . 70
Switching telephone
operation on . . . . . . . . . . . . . . . . . . 72
Switching telephone
operation off . . . . . . . . . . . . . . . . . . 72
Incoming call. . . . . . . . . . . . . . . . . . 73
Outgoing call . . . . . . . . . . . . . . . . . . 74
Emergency call . . . . . . . . . . . . . . . . . . . 80

5
Where to find it
Introduction
Where to find it
This Operator's Manual is designed to pro-
vide support information for you, the MCS
operator. Each chapter has its own guide
color to provide fast access to information.
At a glance
This chapter will give you an overview of all
MCS control elements and system compo-
nents. If you are operating MCS for the first
time or if you have rented or borrowed the
vehicle, this is the chapter you should read
first.
Audio
Here you will find detailed information on
how to use the radio, cassette player, sin-
gle CD player*, CD changer* and adjust
the audio system settings.
Telephone*
Here you can learn in detail about the
many functions of the telephone, how to
initiate an emergency call and use service
numbers.
Navigation*
This chapter provides detailed information
on the following topics:

Destination input

Route selection and calculation

Route guidance

Destination memory
Info Services* and system settings
This chapter provides information on how
to:

Request and display info services such
as news, weather, stocks and sports

Adjust MCS system settings.
Directories
The table of contents and index will help
you to quickly locate the information you
need.

11 At a glance
MCS control unit
FunctionPage
1Switches the radio oper-
ation on30
2Color display
3Delete the last input, re-
turn to previous screen
4Press to:
Open and close the con-
trol panel
Cassette compartment
and CD/DVD slot are lo-
cated behind control
panel
40,
51
5Press to:
Switch the MCS on and
off
Turn to:
Adjust the volume of an
audio source, or naviga-
tion voice prompt during
active route guidance
announcement.
14
16
FunctionPage
6Radio operation:
Selecting a station
Saving stations manually
CD operation:
Selecting a track or CDs
Telephone:
Entering the unlock code
Entering the telephone
number
34
36
58, 59
72
74
7Joystick:
Activates equipment
functions and submenus
via menu fields
Pressing :
Confirms a selection
8Switches the navigation*
system on
Activates the navigation
menu90
FunctionPage
9Repeats current (last)
voice instruction
10Softkeys
11Ending a call73
12Accepting an incoming
call
Sending a call73
13Switches telephone* op-
eration on72
14Switches info service*
operation on138
15Switches CD operation
on (single CD player*,
CD changer*)56
16Switches tape operation
on44

12 At a glance
MCS control unit
Main menu structure
Main radio display
1Active system/function display field
2Inserted cassette icon
3Inserted navigation DVD or audio CD
icon
4Inserted CD changer icon
5Telephone roaming indicator
6Telephone signal strength meter
7Selected station preset / CD
8Softkey menu Active system / function display field Display screen
System
Display
FM
AM, WB
CD
CHANGER
INFO SER-
VICE
PHONE
TAPE
Roaming in-
dicator
S
R
R (highlight-
ed)Meaning
FM radio band selected
AM radio band or Weather
Band WB selected
Single CD player selected
CD changer selected
Info service selected
Telephone selected
Tape selected
Signal in home network
Roaming
Roaming on non-home
type system

16 At a glance
Quick reference MCS
Turn the rotary/push-button.
For the audio sources

Radio

Tape

CD* (single CD and CD changer)
you can set the volume jointly.
For the service source

Telephone*
you can alter the listening volume for the
telephone only.For the service sources

Voice output during route guidance
(navigation system)
and

Voice Control System (refer to sepa-
rate operating instruction)
you can set the volume jointly.
Switching on
Press .
The radio is switched on. The station
last tuned to will begin to play.
Changing the radio band
Press the softkey “AM”, “FM” or
“WB”.
Adjusting the volume
i
The volume of the navigation voice
prompt can only be adjusted during
active route guidance. Turn the rotary
push button during an announcement,
or press Navi Voice to repeat the
current/last voice instruction and turn
the rotary push button during the
announcement.
During an announcement, the volume is
lowered automatically.
Radio Operation

18 At a glance
Quick reference MCS
Switching on
Press .
The main CD menu will be displayed.
CD playback will begin automatically
depending on the CD player selected.

Single CD player. The first track on
the CD is played.

CD changer. The first track on the
first CD detected in the magazine is
played.Inserting a CD into the CD drive and insert-
ing CDs in the CD changer (
page 51).
Track select
 Push the joystick to / .
The beginning of the current track, the
previous track, or the next track will be
played.
Selecting a CD from the CD changer
Activate the CD changer.
Press one of the number keys.
Keys - select the corre-
sponding magazine slot of the
CD changer.
The message “Loading CD...” appears
on the display. Playback begins with
track 1.CD track scan
Press the softkey “SCAN”.
The tracks on the CD are played one af-
ter the other for 8 seconds each.
Press the highlighted softkey
“SCAN” to cancel the function.
Refer to (
page 48) “CD operation” for
additional information.
CD operation*

49 Audio
CD operation
FunctionPage
1Switches CD operation
on (single CD player*,
CD changer*)56
2Color screen
3Press to:
Open and close the con-
trol panel
The CD slot is located
behind the control panel.
51
4Press to:
Switch the MCS on and
off
Turn to:
Adjust the volume
14
16
5Playing a CD (CD chang-
er)
Selecting a track58
5 9
6Joystick
: Track select for-
ward
: Track select re-
verse
: Music seek for-
ward
: Music seek re-
verse
59
59
60
60
7Softkeys
“II”: Pause
“RDM”: Random play
“RPT”: Repeat
“TIME”: Select time dis-
play
“ADJ”: Audio adjust-
ment
“SCAN”: Scan
62
61
61
62
63
60
FunctionPage

50 Audio
CD operation
CD player locations

The single CD player* is located behind
the MCS control panel
You can play audio CDs or read data
from the navigation DVD.

The 6 disc CD changer*.
The status line in the main CD menu indi-
cates which component is being used for
CD playback.Tips on caring for your CDs

Only touch the CD on the sides.

Avoid touching the CD recording sur-
face with your fingers.

Clean the CD with a dry, lint-free cloth.
Wipe the CD in a straight line from the
center. Never wipe the CD in a circular
motion.

Do not use rubbing alcohol or solvents
to clean the CDs.

Do not expose the CDs to heat or direct
sunlight.

Do not write or put stickers on CD’s.
General information on CD mode
WarningG
The single CD player and CD changer are
Class 1 laser products. There is a danger of
invisible laser radiation if the cover is
opened or damaged.
Do not remove the cover. The single CD
player and the CD changer do not contain
any parts which can be serviced by the user.
For safety reasons, have any necessary ser-
vice work performed by an authorized Mer-
cedes-Benz center.
!
Use only CDs with a diameter of 12 cm;
do not use 8-cm CDs.
An 8-cm CD adapter may cause damage
to the CD changer and s
should not be
used.

52 Audio
CD operation
Loading CDs in the changer
The CD changer is located behind the trim
panel on the right side of the cargo area. It
can accommodate up to 6 CDs.
Open the sliding door by pushing in the
direction of the arrow above. Push the
door completely open until it locks in
the open position.1Eject button
Press the eject button.
The magazine will slide upwards.
Pull the disk tray forward until it stops.
i
The magazine can be ejected even if the
MCS is switched off.
The eject button does not function if the
battery is drained or disconnected.
i
Do not attempt to remove the tray from
the magazine.

53 Audio
CD operation
Place a CD in the tray. The CD should
be inserted with the label side up.2Arrow tip on the rack wall
Push the CD tray into the magazine
completely.
Slide the magazine into the CD changer
until it clicks into place (listen for the
click).
Close the sliding door.
i
Make sure that 22 is pointing in the di-
rection of the arrow 3
3.
Do not force the magazine into the
changer. If the magazine does not enter
smoothly, please check for proper ori-
entation of the magazine.
