navigation system MERCEDES-BENZ M-Class 2003 W163 Comand Manual

Contents
Introduction . . . . . . . . . . . . . . . . . . . . . 5
Where to find it . . . . . . . . . . . . . . . . . . . 5
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operating safety. . . . . . . . . . . . . . . . . . . 7
At a glance . . . . . . . . . . . . . . . . . . . . . . 9
MCS control unit . . . . . . . . . . . . . . . . . 10
Display screen . . . . . . . . . . . . . . . . 12
Quick reference MCS . . . . . . . . . . . . . . 14
Switching the MCS operating
unit on and off . . . . . . . . . . . . . . . . 14
Adjusting the volume . . . . . . . . . . . 16
Radio operation . . . . . . . . . . . . . . . 16
Tape operation . . . . . . . . . . . . . . . . 17
CD operation* . . . . . . . . . . . . . . . . 18
Telephone operation* . . . . . . . . . . . 19
Navigation system, entering a
destination and calculating
a route . . . . . . . . . . . . . . . . . . . . . . 20
Audio. . . . . . . . . . . . . . . . . . . . . . . . . . 25
Radio operation . . . . . . . . . . . . . . . . . . 26
Quick reference . . . . . . . . . . . . . . . 26
Menu overview . . . . . . . . . . . . . . . . 28Switching radio operation on . . . . . 30
Switching another system on . . . . . 30
Changing the Radio band . . . . . . . . 31
Selecting a station . . . . . . . . . . . . . 32
Memory functions . . . . . . . . . . . . . . 36
Tape operation . . . . . . . . . . . . . . . . . . . 38
Quick reference . . . . . . . . . . . . . . . 38
Inserting or ejecting a tape. . . . . . . 40
Menu overview . . . . . . . . . . . . . . . . 42
Listening to a cassette . . . . . . . . . . 44
Error messages . . . . . . . . . . . . . . . . 44
Changing sides . . . . . . . . . . . . . . . . 44
Fast forward and rewind . . . . . . . . . 45
Music search . . . . . . . . . . . . . . . . . 45
Tape scan . . . . . . . . . . . . . . . . . . . . 46
Blank skip . . . . . . . . . . . . . . . . . . . . 46
Dolby B (noise reduction) . . . . . . . . 47
Pause . . . . . . . . . . . . . . . . . . . . . . . 47
CD operation . . . . . . . . . . . . . . . . . . . . 48
Quick reference . . . . . . . . . . . . . . . 48
General information on CD
mode. . . . . . . . . . . . . . . . . . . . . . . . 50
Inserting or ejecting a CD . . . . . . . . 51
Menu overview . . . . . . . . . . . . . . . . 54
Switching CD operation on
and off . . . . . . . . . . . . . . . . . . . . . . 56Error messages . . . . . . . . . . . . . . . . 57
Selecting a CD
MCS with CD changer. . . . . . . . . . . 58
Track select . . . . . . . . . . . . . . . . . . 59
Music seek . . . . . . . . . . . . . . . . . . . 60
CD track scan . . . . . . . . . . . . . . . . . 60
CD track repeat . . . . . . . . . . . . . . . 61
CD track random play . . . . . . . . . . . 61
Pause . . . . . . . . . . . . . . . . . . . . . . . 62
Elasped time display . . . . . . . . . . . . 62
Audio Adjustment . . . . . . . . . . . . . . . . . 63
Audio Adjustment . . . . . . . . . . . . . . 63
Telephone. . . . . . . . . . . . . . . . . . . . . . 65
Important notes . . . . . . . . . . . . . . . . . . 66
Telephone mode . . . . . . . . . . . . . . . . . . 68
Quick reference . . . . . . . . . . . . . . . 68
Menu overview . . . . . . . . . . . . . . . . 70
Switching telephone
operation on . . . . . . . . . . . . . . . . . . 72
Switching telephone
operation off . . . . . . . . . . . . . . . . . . 72
Incoming call. . . . . . . . . . . . . . . . . . 73
Outgoing call . . . . . . . . . . . . . . . . . . 74
Emergency call . . . . . . . . . . . . . . . . . . . 80

Contents
Navigation. . . . . . . . . . . . . . . . . . . . . . 81
Important notes . . . . . . . . . . . . . . . . . . 82
Quick reference . . . . . . . . . . . . . . . . . . 84
Inserting or ejecting the
navigation DVD . . . . . . . . . . . . . . . . 86
Destination input . . . . . . . . . . . . . . . . . 88
Menu overview . . . . . . . . . . . . . . . . 88
Switching the navigation
system on . . . . . . . . . . . . . . . . . . . . 90
Entering destination address . . . . . 91
Route guidance. . . . . . . . . . . . . . . . . . 110
Route guidance principles . . . . . . 110
Destination memory . . . . . . . . . . . . . . 120
Address book . . . . . . . . . . . . . . . . 120
Today’s plan . . . . . . . . . . . . . . . . . 125
Saving the current
vehicle position . . . . . . . . . . . . . . . 128
Editing the Previous
Destination list . . . . . . . . . . . . . . . 129Settings . . . . . . . . . . . . . . . . . . . . . . . 130
Voice prompt frequency . . . . . . . . 130
Selecting the guidance display . . . 131
Selecting the estimated
time displayed. . . . . . . . . . . . . . . . 133
Selecting which Point of
Interest icons are displayed . . . . . 134
Setting map and
screen orientation . . . . . . . . . . . . . 135
Info Services/System settings. . . . 137
Info Services . . . . . . . . . . . . . . . . . . . . 138
Requesting and displaying
Info Services* . . . . . . . . . . . . . . . . 138
System settings . . . . . . . . . . . . . . . . . 140
Switching between the light
and the dark mode . . . . . . . . . . . . 140
Setting the display dimming
characteristics . . . . . . . . . . . . . . . 141Selecting the language and
unit of measure . . . . . . . . . . . . . . . 142
Integrated clock adjustment . . . . . 143
System information . . . . . . . . . . . . 145
Index . . . . . . . . . . . . . . . . . . . . . . . . . 147

5
Where to find it
Introduction
Where to find it
This Operator's Manual is designed to pro-
vide support information for you, the MCS
operator. Each chapter has its own guide
color to provide fast access to information.
At a glance
This chapter will give you an overview of all
MCS control elements and system compo-
nents. If you are operating MCS for the first
time or if you have rented or borrowed the
vehicle, this is the chapter you should read
first.
Audio
Here you will find detailed information on
how to use the radio, cassette player, sin-
gle CD player*, CD changer* and adjust
the audio system settings.
Telephone*
Here you can learn in detail about the
many functions of the telephone, how to
initiate an emergency call and use service
numbers.
Navigation*
This chapter provides detailed information
on the following topics:

Destination input

Route selection and calculation

Route guidance

Destination memory
Info Services* and system settings
This chapter provides information on how
to:

Request and display info services such
as news, weather, stocks and sports

Adjust MCS system settings.
Directories
The table of contents and index will help
you to quickly locate the information you
need.

7 Introduction
Operating safety
Operating safety
WarningG
Any alterations made to electronic compo-
nents and the software can cause malfunc-
tions.
The radio, amplifier, CD player*, CD chang-
er*, and telephone* are interconnected.
When one of the components is not opera-
tional or has not been removed/replaced
properly, the function of other components
may be impaired.
This condition might seriously impair the op-
erating safety of your vehicle.
We recommend that you have any service
work on electronic components carried out
by an authorized Mercedes-Benz Center.
WarningG
In order to avoid distraction, which could
lead to an accident, system settings should
be entered with the vehicle at a standstill.
The driver should only operate the system
when traffic conditions permit.
Bear in mind that at a speed of just
30 mph (approximately 50 km/h), your car
is covering a distance of 50 feet (approxi-
mately 14 m) every second.
MCS supplies you with the information to
help you select your route more easily and
guide you conveniently and safely to your
destination. For safety reasons, we encour-
age the driver to stop the vehicle in a safe
place before answering or placing a call, or
consulting the MCS screen to read naviga-
tional maps, instructions, or downloaded in-
formation.
While the navigation system* provides di-
rectional assistance, the driver must remain
focused on safe driving behavior, including
attention to traffic and street signs, and
should utilize the system's audio cues while
driving.
The navigation system* does not supply any
information on stop signs, yield signs, traffic
regulations or traffic safety rules. This al-
ways remains your personal responsibility
when you drive.DVD maps do not cover all ar-
eas nor all routes within an area.

11 At a glance
MCS control unit
FunctionPage
1Switches the radio oper-
ation on30
2Color display
3Delete the last input, re-
turn to previous screen
4Press to:
Open and close the con-
trol panel
Cassette compartment
and CD/DVD slot are lo-
cated behind control
panel
40,
51
5Press to:
Switch the MCS on and
off
Turn to:
Adjust the volume of an
audio source, or naviga-
tion voice prompt during
active route guidance
announcement.
14
16
FunctionPage
6Radio operation:
Selecting a station
Saving stations manually
CD operation:
Selecting a track or CDs
Telephone:
Entering the unlock code
Entering the telephone
number
34
36
58, 59
72
74
7Joystick:
Activates equipment
functions and submenus
via menu fields
Pressing :
Confirms a selection
8Switches the navigation*
system on
Activates the navigation
menu90
FunctionPage
9Repeats current (last)
voice instruction
10Softkeys
11Ending a call73
12Accepting an incoming
call
Sending a call73
13Switches telephone* op-
eration on72
14Switches info service*
operation on138
15Switches CD operation
on (single CD player*,
CD changer*)56
16Switches tape operation
on44

12 At a glance
MCS control unit
Main menu structure
Main radio display
1Active system/function display field
2Inserted cassette icon
3Inserted navigation DVD or audio CD
icon
4Inserted CD changer icon
5Telephone roaming indicator
6Telephone signal strength meter
7Selected station preset / CD
8Softkey menu Active system / function display field Display screen
System
Display
FM
AM, WB
CD
CHANGER
INFO SER-
VICE
PHONE
TAPE
Roaming in-
dicator
S
R
R (highlight-
ed)Meaning
FM radio band selected
AM radio band or Weather
Band WB selected
Single CD player selected
CD changer selected
Info service selected
Telephone selected
Tape selected
Signal in home network
Roaming
Roaming on non-home
type system

15 At a glance
Quick reference MCS
The navigation system* was the last system
used
The menu displayed will vary according to
the last navigation function used.
If route guidance was active, you will see:

the basic guidance display or

the mapIf destination input was active, the main
destination input menu appears.Switching another system on
Press a system key, e.g. .
The main radio menu will appear.
i
If the MCS is switched off for more than
30 minutes during active route guid-
ance, all manually entered traffic jams
and detours are deleted. Selecting a de-
tour (
page 119).

16 At a glance
Quick reference MCS
Turn the rotary/push-button.
For the audio sources

Radio

Tape

CD* (single CD and CD changer)
you can set the volume jointly.
For the service source

Telephone*
you can alter the listening volume for the
telephone only.For the service sources

Voice output during route guidance
(navigation system)
and

Voice Control System (refer to sepa-
rate operating instruction)
you can set the volume jointly.
Switching on
Press .
The radio is switched on. The station
last tuned to will begin to play.
Changing the radio band
Press the softkey “AM”, “FM” or
“WB”.
Adjusting the volume
i
The volume of the navigation voice
prompt can only be adjusted during
active route guidance. Turn the rotary
push button during an announcement,
or press Navi Voice to repeat the
current/last voice instruction and turn
the rotary push button during the
announcement.
During an announcement, the volume is
lowered automatically.
Radio Operation

20 At a glance
Quick reference MCS
Switching the navigation system on
Main destination input menu
Press .
If the navigation system has not been
booted, the navigation startup screen
appears during the software loading
process.
The navigation menu displayed will vary
according to the last navigation func-
tion used.
If route guidance was switched off, the
main navigation menu is displayed.Entering destination address

Press .

Use the joystick to select “INPUT
DESTINATION” and press .
Navigation system*, entering a destina-
tion and calculating a route
P82.85-9566-31
P82.85-9566-31

30 Audio
Radio operation
This chapter will provide detailed informa-
tion on:

Radio operation

Tape operation

CD operation* and

Sound adjustments
If you have not done so already, please
familiarize yourself with these functions by
reading the “At a glance” chapter.
Main FM radio menu
Press .
The radio is switched on and the sta-
tion last tuned to will begin to play.
Press any system key, e.g. .
MCS will switch to the tape mode.
Switching radio operation on
i
You can operate the telephone and the
navigation system while the radio is on.
Switching another system on
