stop start MERCEDES-BENZ M-Class 2004 W163 Comand Manual

46 AudioTape operationWhen this function is activated, you can
play back the first 8 seconds of each track
in succession.
Activating scan
Press the softkey SCAN.Scan begins. SCAN is highlighted in the
softkey menu and SCANNING is dis-
played in the tape menu.
Cancelling scan

Press the highlighted softkey
SCAN.
or

Push the joystick in any direction.
Playback resumes with the desired
track.When this function is activated, the unit
skips blank segments longer than 15 sec-
onds. The unit fast forwards to the next
track or side and starts playing it.
Starting blank skip

Press the softkey SKIP.
Blank skip begins. SKIP is highlighted
in the softkey menu. If a blank section
is detected SKIPPING BLANK SECTION
is displayed in the tape menu.
Tape scaniThe scan function does not work prop-
erly unless there is enough blank tape
(approx. 2 seconds) separating the indi-
vidual tracks.
iAt the end of the tape, the tape auto-
matically switches to the other side and
scan stops.
Blank skip

56 AudioCD operation
MCS with single CD player*
CD operation begins:
Automatically, by inserting a CD
(page 51)
The playback starts at Track 1.

By pressing when a CD is already
inserted in the CD slot, playback starts
at Track 1.
The telephone functions can be used while
a CD is playing.
To stop CD playback

Eject the CD, switch to the radio or
tape mode, or switch off the MCS.MCS with CD changer*
CD changer operation begins:

Press when CDs are inserted in
the CD changer (
page 52).
The playback starts at Track 1 of the
first CD.
The telephone and navigation functions
can be used while a CD is playing.
To stop CD playback

Switch to the radio or tape mode or
switch off the MCS.
Switching CD operation on and offiThe navigation functions can be used
while a CD is playing in the CD-changer.
MCS with navigation system:
Navigation is only possible when a navi-
gation DVD is inserted in the single CD
player.

57 Audio
CD operation
MCS with single CD player* and CD
changer*
If you press , the MCS starts the CD
m o d e t h a t w a s l a s t a c t i v a t e d . T o s w i t c h b e -
tween CD modes, press again.
Single CD player playback
Single CD player playback begins:
Automatically, by inserting a CD,
(page 51) The playback starts at
Track 1.

By pressing when a CD is already
inserted in the CD slot, playback starts
at Track 1.
To stop CD playback

Eject the CD
or

Switch to the radio, tape or CD changer
or

Switch off the MCSCD changer playback
CD changer operation begins:

By pressing when CDs are insert-
ed in the CD changer, (
page 52).
Playback starts at Track 1.
To stop CD playback

Switch to the radio
or

Switch to tape or single CD player
mode
or

Switch off the MCSThe following error messages can appear
after is pressed:

NO CD - there is no CD inserted. Insert
a CD.

CD ERROR - the inserted CD can not
be read. The CD may be inserted incor-
rectly, be damaged, or is not an audio
CD. The CD may be copy protected. If it
is a recorded CD (instead of a stamped
CD), the quality may be poor or the for-
matting incorrect.

Single CD mode: NAVIGATION
DISC INSERTED... - a navigation
DVD is inserted in the CD slot. Replace
the DVD with an audio CD.Error messages

72 Satellite radio*Satellite radio* operationIn this example:
SAT (on the left) = the selected system

SAT5 = location in the program memo-
ry, if the current channel is pre-stored

POP = selected category (
page 74)

US-1 = name of the selected station

CH:1 = number of the current channel

Silva Reyna = Current Artist

You Can Change Your M..=
Current title
Possible soft keys:

FM, AM or WB
starts the radio operation (
page 30).

LIST
shows channels pre-stored in the pro-
gram memory (up to 10 channels). You
can store stations (
page 75) and re-
quest stored stations (page 72).

PTY
is used to select the program category
(page 75).

ADJ
displays the audio adjust screen. You
can adjust the sound settings for the
audio sources (
page 63).

SCAN
is used to start and stop the scan
search (
page 75).

NUM
displays the telephone number of the
SIRIUS Service Center and your per-
sonal twelve-digit electronic serial
number (ESN).The following options are available:

Selecting a station using the selected
category (
page 74),

Tuning via station presets (
page 72),

Tuning via scan search (
page 75).

Tuning via manual channel input
(page 73).

Tuning via the program category list
(page 74).
Tuning via station presets
Ten Satellite radio station presets are
available.
Access to the presets via number keys or
via the Presets menu.
Soft key functions
Selecting a station

75 Satellite radio*
Satellite radio* operation
Tuning via Scan search
Scan Search is characterized as follows:
Scan search plays a channel for
approx. 8 seconds and then skips to
the next channel within the current cat-
egory.

Scan search can be terminated manu-
ally.

Press the softkey SCAN.
The search starts.

Press the softkey SCAN again.
The search stops.Additional text information (artist, title) re-
lated to the current channel can be dis-
played.

Press one of the number keys, e.g.
, longer than 2 seconds.
You will hear a confirmation beep.
The radio saves the current station at
the memory preset selected. The mem-
ory preset selected appears in the sta-
tus line, e.g. SAT3.

Press the softkey NUM.
The telephone number of the SIRIUS
Service Center and the twelve-digit
electronic serial number (ESN) of your
SAT tuner are displayed.
Obtaining additional text
informationStoring stationsiThere are 10 presets available.
An existing entry is overwritten in the
memory list when a new input is given.
Calling up the SIRIUS information
menu

127 Navigation*
Route guidance
Adding a stopover to the route
Whenever a destination is set and calculat-
ed, the system allows you to create a stop-
over along the way.
Start route guidance.

Enter a desired stopover destination.

In the Confirm Destination menu, se-
lect Add as Stopover to Route
and press .
The desired destination is added to the
route.Cancelling the current destination

To activate the softkeys, press any
softkey.

Press the softkey STOP.
A window appears confirming the stop
request.

If you wish to delete the current desti-
nation, use the joystick to select YES
and press .
The current destination is cancelled.
or

If you don’t wish to continue:
Use the joystick to select NO and
press .

Press .

Wait 10 seconds
The stop request is cancelled.Changing the route calculation mode
during guidance

Press .

Use the joystick to select ROUTE
FUNCTIONS and press .
The Route Select menu appears.









160 Indexentering . . . . . . . . . . . . . . . . . . . . . . . 20
address . . . . . . . . . . . . . . . . . 21, 103
saving . . . . . . . . . . . . . . . . . . . . . . . 140
in the address book . . . . . . . . . . . 132
searching
by address . . . . . . . . . . . . . . . . . . 104
by intersection . . . . . . . . . . . . . . . 108
by phone number. . . . . . . . . . . . . 116
by Point of Interest . . . . . . . . . . . 112
from Previous Destination . . . . . . 119
in the address book . . . . . . . . . . . 118
selecting
via the map . . . . . . . . . . . . . . . . . 120
Destination input. . . . . . . . . . . . . . . 100
menu overview . . . . . . . . . . . . . . . . 100
Destination list
previous
delete entries. . . . . . . . . . . . . . . . 141
editing . . . . . . . . . . . . . . . . . . . . . 141
Destination memory . . . . . . . . . . . . 132
Detour function . . . . . . . . . . . . . . . . 131
Dialing
a number from the
telephone book . . . . . . . . . . . . . . . . . 88
begin . . . . . . . . . . . . . . . . . . . . . . . . . 87
interrupt . . . . . . . . . . . . . . . . . . . . . . 87quick-dialing . . . . . . . . . . . . . . . . . . . 91
redial . . . . . . . . . . . . . . . . . . . . . . . . . 90
speed-dialing . . . . . . . . . . . . . . . . . . . 90
subsequent . . . . . . . . . . . . . . . . . . . . 88
tetelephone number . . . . . . . . . . . . . 86
Display screen . . . . . . . . . . . . . . . . . . 12
setting dimming
characteristics. . . . . . . . . . . . . . . . . 151
Dolby B
tape operation . . . . . . . . . . . . . . . . . . 47
DVD-ROM version information . . . . 155
E
Editing
address book. . . . . . . . . . . . . . . . . . 134
previous Destination list . . . . . . . . . 141
Today’s Plan . . . . . . . . . . . . . . . . . . 139
Ejecting
a CD . . . . . . . . . . . . . . . . . . . . . . . . . 51
a tape . . . . . . . . . . . . . . . . . . . . . . . . 40
the navigation DVD . . . . . . . . . . . . . . 98
Emergency call. . . . . . . . . . . . . . 92, 157
ending/stopping . . . . . . . . . . . . . . . . 92
initiating . . . . . . . . . . . . . . . . . . . . . . 92
Ending a call . . . . . . . . . . . . . . . . . . . . 85Entering
address
navigation system . . . . . . . . . . . . 104
destination address . . . . . . . . . 21, 103
telephone number . . . . . . . . . . . . 20, 86
time zone. . . . . . . . . . . . . . . . . . . . . 153
unlock code . . . . . . . . . . . . . . . . . 20, 84
Error messages
CD operation . . . . . . . . . . . . . . . . . . . 57
tape operation . . . . . . . . . . . . . . . . . . 44
F
Fault messages
during preparation of
navigation startup . . . . . . . . . . . . . . 103G
Global Positioning
System (GPS) . . . . . . . . . . . . . . 95, 157
Guidance display . . . . . . . . . . . . . . . 143
selecting . . . . . . . . . . . . . . . . . . . . . 143H
Hands-free operation
telephone mode . . . . . . . . . . . . . . . . 85
Heading-up . . . . . . . . . . . . . . . . . . . . 157
