240 Controls in detailPower windows
Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle
(page 239).
The SmartKey or SmartKey with
KEYLESS-GO* must be in close proxim-
ity to the driver’s outside door handle.

Press and hold button‹ on the
SmartKey or SmartKey with
KEYLESS-GO* until the windows and
the tilt/sliding sunroof* are completely
closed.

Release button‹ on the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the closing procedure.
Vehicles with KEYLESS-GO*:

Press and hold the lock button on an
outside door handle (
page 68) until
the windows and the tilt/sliding sun-
roof* are completely closed.

Release the lock button on the outside
door handle to interrupt the closing
procedure.
Vehicles with KEYLESS-GO*:

Release the lock button (
page 68) on
the driver’s outside door handle to stop
the closing procedure.


Immediately pull on the same outside
door handle and hold firmly. The win-
dows and the tilt/sliding sunroof* will
open for as long as the door handle is
held but the door is not opened.

ProCarManuals.com

241 Controls in detail
Power tilt/sliding sunroof*
Power tilt/sliding sunroof*
Opening and closing
The tilt/sliding sunroof is opened and
closed electrically. The switch for the
tilt/sliding sunroof is located on the
overhead control panel.
Sunroof switch1Push back to slide sunroof open
2Push forward to slide sunroof closed
3Push up to raise sunroof at rear
4Pull down to lower sunroof at rearWith the sunroof closed or tilted open, a
screen can be slid into the roof opening to
guard against sun rays. When sliding the
sunroof open, the screen will also retract.
ProCarManuals.com

242 Controls in detailPower tilt/sliding sunroof*Warning!
G
When closing the tilt/sliding sunroof, make
sure that there is no danger of anyone being
harmed by the closing procedure.
If the tilt/sliding sunroof encounters an ob-
struction that blocks its path in a circum-
stance where you are closing the tilt/sliding
sunroof by moving the tilt/sliding sunroof
switch past the resistance point, or by
pressing and holding button‹ on the
SmartKey, by pressing and holding the lock
button (vehicles with KEYLESS-GO*) on the
door handle, the automatic reversal function
will not operate.
The opening/closing procedure of the
tilt/sliding sunroof can be immediately halt-
ed by releasing the switch or, if the switch
was moved past the resistance point and re-
leased, by moving the switch in any direc-
tion.
The tilt/sliding sunroof is made out of glass.
In the event of an accident, the glass may
shatter. This may result in an opening in the
roof.
In a vehicle rollover, occupants not wearing
their seat belts or not wearing them properly
may be thrown out of the opening. Such an
opening also presents a potential for injury
for occupants wearing their seat belts prop-
erly as entire body parts or portions of them
may protrude from the passenger compart-
ment.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock your vehicle. Do not leave children un-
attended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment can cause an accident
and/or serious personal injury.!
To avoid damaging the seals, do not trans-
port any objects with sharp edges which can
stick out of the tilt/sliding sunroof.Do not open the tilt/sliding sunroof if there is
snow or ice on the roof, as this could result in
malfunctions.
The tilt/sliding sunroof can be opened or closed
manually should an electrical malfunction occur
(
page 478).
i
When the tilt/sliding sunroof is open, reso-
nance noises may result in addition to the usual
wind noises. They are caused by minimal pres-
sure changes in the passenger compartment. To
reduce or eliminate these noises, change the po-
sition of the tilt/sliding sunroof or open a side
window slightly.
i
You can also open or close the tilt/sliding
sunroof using the SmartKey or the
KEYLESS-GO* function, see “Summer opening
feature” (
page 239) and see “Convenience
closing feature” (
page 239).
i
Depending on the current position, the
tilt/sliding sunroof may also open or close when
the air recirculation button: on the control
panel of the climate control (
page 208) or
automatic climate control* (
page 222) is
pressed and held.
ProCarManuals.com

243 Controls in detail
Power tilt/sliding sunroof*

Switch on the ignition (
page 40).
Opening and closing

To open, close, raise, or lower the
tilt/sliding sunroof, move the sunroof
switch to the resistance point in the
required direction of arrows1to4
(page 241).

Release the sunroof switch when the
tilt/sliding sunroof has reached the de-
sired position.Fully opening (Express-open) and
closing (Express-close)

To fully open or close the tilt/sliding
sunroof, move the sunroof switch past
the resistance point in the required
direction of arrows1to2
(page 241) and release.
The tilt/sliding sunroof opens or closes
completely.
Stopping the power tilt/sliding sunroof
during Express-open

Move the sunroof switch in any direc-
tion.
The movement of the tilt/sliding sun-
roof stops.
i
If the movement of the tilt/sliding sunroof is
blocked during the closing procedure, the
tilt/sliding sunroof will stop and reopen slightly.
Warning!
G
If the tilt/sliding sunroof encounters an ob-
struction that blocks its path in a circum-
stance where you are closing the tilt/sliding
sunroof by moving the tilt/sliding sunroof
switch past the resistance point, or by
pressing and holding button‹ on the
SmartKey, by pressing and holding the lock
button (vehicles with KEYLESS-GO*) on the
door handle, the automatic reversal function
will not operate.
The opening/closing procedure of the
tilt/sliding sunroof can be immediately halt-
ed by releasing the switch or, if the switch
was moved past the resistance point and re-
leased, by moving the switch in any direc-
tion.
ProCarManuals.com

244 Controls in detailPower tilt/sliding sunroof*Synchronizing
The tilt/sliding sunroof must be
synchronized

after the battery has been
disconnected or discharged


after the tilt/sliding sunroof has been
closed manually (
page 478)


after a malfunction


if the tilt/sliding sunroof does not open
smoothly

Remove the fuse for the tilt/sliding
sunroof from the fuse box
(page 522).

Reinsert the fuse in the main box.

Switch on the ignition (
page 40).

Press and hold the sunroof switch in
the direction of arrow3 (
page 241)
until the tilt/sliding sunroof is fully
raised at the rear.

Hold the sunroof switch in the direction
of arrow3 for approximately
1 second.

Open the tilt/sliding sunroof using the
Express-open feature (
page 243).
If the tilt/sliding sunroof opens
completely, it is synchronized.
If the tilt/sliding sunroof does not open
completely:

Repeat the above steps.
i
For information on which fuse box contains
the fuse for the power tilt/sliding sunroof, see
the fuse chart provided with the vehicle tool kit
(
page 469).
ProCarManuals.com

245 Controls in detail
Driving systems
Driving systems
The driving systems of your vehicle are
described on the following pages:

Cruise control (
page 245) and
Distronic* (
page 250), with which
the vehicle can maintain a preset
speed.


Distance warning function*
(page 263) is only available with
Distronic*, which warns of stationary
obstacle or slower moving vehicles that
you are closing in on too quickly.


Downhill Speed Regulation (DSR)
(page 264), which supports you
when you are driving downhill.


Off-road driving program (
page 268),
which supports you when you are driv-
ing off-road.


Air suspension package*
The system consists of two compo-
nents.

Adaptive Damping System (ADS)*
(page 269), which adjusts the
vehicle suspension characteristics.


Vehicle level control*
(page 270), which controls the
vehicle level.


Parktronic* (
page 274) and rear view
camera* (
page 279), which serve as
a parking aid.
For information on the ABS, BAS, EBP,
ESP
®, and 4-ETS, see “Driving safety sys-
tems” (page 96).
Cruise control
The cruise control automatically maintains
the speed you set for your vehicle.
The use of cruise control is recommended
for driving at a constant speed for extend-
ed periods of time. You can set or resume
cruise control at any speed above
20 mph (30 km/h).
The cruise control function is operated by
means of the cruise control lever.
The cruise control lever is the uppermost
lever on the left-hand side of the steering
column (
page 24).
i
The cruise control should not be activated
during off-road driving.
ProCarManuals.com

246 Controls in detailDriving systems
1Setting current or higher speed
Adjustment in 1 mph increments (to
the resistance point) or 5 mph
increments (past the resistance point)
(Canada: 1 km/h or 10 km/h)
2Setting current or lower speed
Adjustment in 1 mph increments (to
the resistance point) or 5 mph
increments (past the resistance point)
(Canada: 1 km/h or 10 km/h)
3Canceling cruise control
4Resume to last set speed
Warning!
G
The cruise control is a convenience system
designed to assist the driver during vehicle
operation. The driver is and must always
remain responsible for the vehicle’s speed
and for safe brake operation.
Only use the cruise control if the road, traffic
and weather conditions make it advisable to
travel at a constant speed.

The use of the cruise control can be
dangerous on winding roads or in heavy
traffic because conditions do not allow
safe driving at a constant speed.


The use of the cruise control can be
dangerous on slippery roads. Rapid
changes in tire traction can result in
wheel spin and loss of control.


Deactivate the cruise control when
driving in fog.
The “Resume” function should only be
operated if the driver is fully aware of the
previously set speed and wishes to resume
this particular preset speed.
Warning!
G
The cruise control brakes automatically so
that the set speed is not exceeded. The
brake pedal depresses when the cruise con-
trol engages the brakes.
Keep driver’s foot area clear at all times,
including the area under the brake pedal.
Objects stored in this area may impair pedal
movement which could interfere with the
braking ability of the cruise control system.
Do not place your foot under the brake pedal
– your foot could become caught.
Keep in mind that the cruise control is a
convenience system designed to assist the
driver during vehicle operation. The driver is
and must always remain responsible for the
vehicle’s speed and for safe brake
operation.
ProCarManuals.com

247 Controls in detail
Driving systems
Activating cruise control
You can activate the cruise control when
the vehicle speed is above
20 mph (30 km/h).
In the following cases you cannot activate
the cruise control:

when you brake


when you have set the parking brake


when the automatic transmission is set
to positionP, R, or N


if the ESP
® is switched off


if the ESP
® has switched off due to a
malfunctionSetting current speed

Accelerate or decelerate to the desired
speed.

Briefly lift the cruise control lever in
direction of arrow1 or depress in
direction of arrow2.
The current speed is set.

Remove your foot from the accelerator
pedal.
The cruise control is activated.
The current set speed appears in the
multifunction display for approximately
5 seconds.Canceling cruise control
There are several ways to cancel the cruise
control:

Step on the brake pedal.
The cruise control is canceled. The last
speed set is stored for later use.
or

Briefly push the cruise control lever in
direction of arrow3 (
page 246).
The cruise control is canceled. The last
speed set is stored for later use.
i
The vehicle speed displayed in the speedom-
eter can briefly vary from the speed setting for
the cruise control system.
i
On uphill grades, the cruise control may not
be able to maintain the set speed. Once the
grade eases, the set speed will be resumed.
On downhill grades, the cruise control maintains
the set speed by braking with the vehicle’s
braking system. In addition, on longer downhill
grades the automatic transmission will down-
shift automatically.
i
The last stored set speed is canceled when
the engine is turned off.
ProCarManuals.com

248 Controls in detailDriving systems
Setting a higher speed
You can increase the speed in two ways.
Adjustment in 1 mph (Canada: 1 km/h)
increments
Briefly lift the cruise control lever up to
the resistance point in direction of
arrow1 (
page 246).

Release the cruise control lever.
The vehicle speed increases in incre-
ments of 1 mph (Canada: 1km/h).Adjustment in 5 mph
(Canada: 10 km/h) increments
i
The cruise control switches off
automatically when


you step on the brake pedal


you depress the parking brake pedal
The cruise control switches off automatically and
an acoustic warning will sound when


the vehicle speed is below 20 mph
(30 km/h)


the ESP
® is in operation


the ESP
® is switched off with the ESP
®
switch (
page 99)


the ESP
® has switched off due to a
malfunction (
page 419)


you set the automatic transmission toN
while driving
Observe additional messages in the
multifunction display that may appear.
!
Setting the automatic transmission toN
while driving cancels the cruise control.
However, the automatic transmission should not
be set toN while driving except to coast when
the vehicle is in danger of skidding (e.g. on icy
roads).
i
Depressing the accelerator pedal does not
deactivate the cruise control. After a brief accel-
eration (e.g. for passing), the cruise control will
resume the last set speed.
i
The set value is increased in 1 mph
(Canada: 1 km/h) increments each time you lift
the cruise control lever up to the resistance
point.
Warning!
G
You can increase the vehicle speed in
5 mph (Canada 10 km/h) increments.
When using this feature, keep in mind that it
may take a brief moment until the vehicle
has reached the set speed.
Increase the vehicle speed to a value that
the prevailing road conditions permit. Other-
wise, sudden and unexpected acceleration
of the vehicle could cause an accident
and/or serious injury to you and others.i
The set value is increased in
5 mph (Canada: 10 km/h) increments each time
you lift the cruise control lever past the
resistance point.
ProCarManuals.com

249 Controls in detail
Driving systems

Briefly lift the cruise control lever up
past the resistance point in direction of
arrow1 (
page 246).

Release the cruise control lever.
The vehicle speed increases in incre-
ments of 5 mph (Canada: 10 km/h).
Setting a lower speed
You can reduce the speed in two ways.Adjustment in 1 mph (Canada: 1 km/h)
increments

Briefly press the cruise control lever
down to the resistance point in direc-
tion of arrow2 (
page 246).

Release the cruise control lever.
The vehicle speed decreases in incre-
ments of 1 mph (Canada: 1 km/h).Adjustment in 5 mph
(Canada: 10 km/h) increments
i
The new speed is set and the vehicle will
accelerate. Keep in mind that it may take a brief
moment until the vehicle has reached the set
speed.
i
When you use the cruise control lever to
decelerate, the brake system will automatically
brake the vehicle if the engine’s braking power
does not brake the vehicle sufficiently.
i
The set value is decreased in 1 mph
(Canada: 1 km/h) increments each time you
press the cruise control lever down to the resis-
tance point.
Warning!
G
You can decrease the vehicle speed in
5 mph (Canada 10 km/h) increments. When
using this feature, keep in mind that it may
take a brief moment until the vehicle has
reached the set speed.
Decelerate the vehicle speed to a value that
the prevailing road conditions permit. Other-
wise, sudden and unexpected deceleration
of the vehicle could cause an accident
and/or serious injury to you and others.i
The set value is decreased in 5 mph
(Canada: 10 km/h) increments each time you
press the cruise control lever down past the
resistance point.
ProCarManuals.com
