MERCEDES-BENZ ML320 2008 W164 Owner's Manual

190 Controls in detail
Automatic transmission
Driving tips
Accelerator position
Your driving style influences the
transmission’s shifting behavior:
Less throttle Earlier upshifting
More throttle Later upshifting
Kickdown
Use kickdown when you want maximum
acceleration.
Press the accelerator past the point of
resistance.
Depending on the engine speed the
transmission shifts into a lower gear.
Ease on the accelerator when you have
reached the desired speed.
The transmission shifts up again.Stopping
When you stop briefly, e.g. at traffic lights:
Leave the transmission in gear.
Hold the vehicle with the brake.
When you stop for a longer period of time
with the engine idling and/or on a hill:
Set the parking brake.
Shift into park positionP.
Maneuvering
When you maneuver in tight areas,
e.g. when pulling into a parking space:
Control the vehicle speed by gradually
releasing the brakes.
Accelerate gently.
Never abruptly step on the accelerator.
Warning!G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Children could shift the
automatic transmission out of park
positionP, which could result in an accident
and/or serious personal injury.

191 Controls in detail
Automatic transmission
Rocking the vehicle
Rocking the vehicle by shifting between
drive positionD and reverse gearR can
help free a vehicle stuck in mud or snow.
The engine control system of this vehicle
electronically limits shifting between
drive positionD and reverse gearR to
very low speeds, i.e. approximately
5 mph (9 km/h). To shift between drive
positionD and reverse gearR, move the
gear selector lever past the resistance
point up or down.
Working on the vehicleHill start assist system
On uphill grades with a gradient angle of
more than 5°, the hill start assist system
maintains the pressure in the brake sys-
tem for approximately 1 second after you
have released the brake pedal. Therefore,
you can start off smoothly without the
vehicle moving immediately after releasing
the brake pedal.The hill start assist system is inactive

when starting off on a level road or
downhill grades

with the transmission in neutral
positionN

with the parking brake set

if the ESP® has switched off due to a
malfunction
Towing a trailer
If you tow a trailer, note the following
points:

Manually shift to a lower gear range
(
page 192) if the transmission hunts
between gears on inclines.
A lower gear range and reduction of
speed reduces the chance to overload
or overheat the engine.
For more information on trailer towing, see
the “Operation” section (
page 328).
Warning!G
When working on the vehicle, set the
parking brake and shift to park positionP.
Otherwise the vehicle could roll away.
Warning!G
The hill start assist system is not designed
to function as a parking brake and does not
prevent the vehicle from moving when
parked on an incline.
Always set the parking brake in addition to
shifting to park positionP.

192 Controls in detail
Automatic transmission
Gear ranges
With the automatic transmission in drive
positionD, you can select a gear range for
the automatic transmission to operate
within.
You can limit the gear range by pressing
the left gearshift button on the steering
wheel gearshift control, and reverse the
gear range limit by pressing the right gear-
shift button on the steering wheel gearshift
control (
page 193).
The selected gear range appears in the
multifunction display.
1Current gear range
Effect
ïThe transmission shifts through
sixth gear only.
îThe transmission shifts through
fifth gear only.
éThe transmission shifts through
fourth gear only.
èThe transmission shifts through
third gear only.
With this selection you can use
the braking effect of the engine.
Effect
çThe transmission shifts through
second gear only.
Allows the use of engine’s
braking power when driving:

on steep downgrades

in mountainous regions

under extreme operating
conditions
æThe transmission operates in
first gear only.
For maximum use of engine’s
braking effect on very steep or
lengthy downgrades.

193 Controls in detail
Automatic transmission
Steering wheel gearshift control
With drive positionD selected, you can
limit or extend the gear range.
If your vehicle is equipped with manual
shift program M, you can use the steering
wheel gearshift control to manually shift
the gears.
1Left shift button: limiting gear range or
downshift (in program modeM)
2Right shift button: extending gear
range or upshift (in program modeM)Limiting gear range
Briefly press left shift button1.
The transmission will shift to the next
lower gear as permitted by the shift
program. This action simultaneously
limits the gear range of the automatic
transmission (
page 192).
iML 63 AMG:
For information on using the steering wheel gear-
shift control in program mode M, see “Shift pro-
gram (ML 63 AMG only)” (
page 194).
!Allow engine to warm up under low load use.
Do not place full load on the engine until the
operating temperature has been reached.
Shift into reverse gearR or park positionP only
when the vehicle is stopped.
Avoid spinning of a drive wheel for an extended
period when driving off on slippery road
surfaces. This may cause serious damage to the
drivetrain which is not covered by the
Mercedes-Benz Limited Warranty.
iYou cannot shift with the steering wheel
gearshift control buttons when the transmission
is in positionP,N orR.
Warning!G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced
vehicle control. Your vehicle’s ABS will not
prevent this type of loss of control.
iTo avoid overrevving the engine when down-
shifting, the transmission will not shift to a lower
gear if the engine’s max. speed would be ex-
ceeded.

194 Controls in detail
Automatic transmission
Extending gear range
Briefly press right shift button2.
The transmission will shift to the next
higher gear as permitted by the shift
program. This action simultaneously
extends the gear range of the automat-
ic transmission (
page 192).
Canceling gear range limit
Press and hold right shift button2
until the cipher for the current gear
range disappears from the multifunc-
tion display (
page 192).
The transmission will shift from the
current gear range directly to gear
rangeD.Shifting into optimal gear range
Press and hold left shift button1.
The transmission will automatically
select the gear range suited for optimal
acceleration and deceleration. This will
involve shifting down one or more
gears.
Shift program (ML 63 AMG only)You can choose between automatic shift
program C or S and manual shift
programM.
1Program mode selector switch
M Manual For manual gear shifting
C Comfort For standard driving
S Sport For sporty drivingiIf you press on the accelerator when the
engine has reached its rpm limit, the transmis-
sion will upshift beyond any gear range limit
selected.
!Allow engine to warm up under low load use.
Do not place full load on the engine until the
operating temperature has been reached.
Shift into reverse gearR or park positionP only
when the vehicle is stopped.
Avoid spinning of a drive wheel for an extended
period when driving off on slippery road
surfaces. This may cause serious damage to the
drivetrain which is not covered by the
Mercedes-Benz Limited Warranty.
!Never change the program mode when the
automatic transmission is out of park positionP.
This could result in a change of driving character-
istics for which you may not be prepared.

195 Controls in detail
Automatic transmission
The selected program mode appears in the
multifunction display.
1Current program mode
Automatic shift program
You can choose between automatic shift
program C or S.
Press program mode selector switch
repeatedly until the letter of the
desired program mode appears in the
multifunction display.
SelectCfor standard driving:

The vehicle starts out in second
gear (both forward and reverse) for
gentler starts. This does not apply if
full throttle is applied or gear
range1 is selected.

Traction and driving stability are
improved on icy roads.

Upshifts occur earlier even when
you give more gas. The engine then
operates at lower rpms and the
wheels are less likely to spin.
SelectSfor sporty driving:

The vehicle starts out in first gear.

Upshifts occur later.
Manual shift program
In the manual program mode M,
system-controlled automatic gearshifting
is switched off and you need to change the
the gears by manually upshifting or down-
shifting using the steering wheel gearshift
control buttons to the left and right of the
steering wheel (
page 193).Activating manual shift program
Press program mode selector switch
repeatedly until the
M for the manual
program modeM appears in the multi-
function display.
The transmission switches to the
manual program modeM. Automatic
shifting is switched off. The gear range
is not limited.
You can change the gears manually with
drive positionD selected. You can upshift
or downshift through the gears in succes-
sion.
iThe last selected program mode (C or S) is
switched on when the engine is restarted.
iThe manual program modeM will not be
stored. When the engine is turned off with the
manual program modeM selected, the transmis-
sion will go to the automatic program mode
(CorS) when the engine is restarted.

196 Controls in detail
Automatic transmission
Upshifting
Briefly press right shift button2
(
page 193).
The transmission shifts to the next
higher gear.
If you have selected the AMG menu in the
control system and you are driving in the
manual program modeM, upshift
indicator2 in the multifunction display
advises you to upshift before the engine
reaches the overspeed range. Thus you
can drive at the maximum engine speed for
each gear without overrevving the engine.1Gear indicator
2Upshift indicator
Shift to the next higher gear.
The fuel supply will otherwise be inter-
rupted to prevent the engine from over-
revving.
Downshifting
Briefly press left shift button1
(
page 193).
The transmission shifts to the next
lower gear.
Kickdown
Using the kickdown when driving in the
manual program modeM is not possible.
Deactivating manual shift program
Press the program mode selector
switch (
page 194) repeatedly until
CorS appears in the multifunction
display.
or
Restart the engine.
The transmission will go to the
automatic program mode (C orS).
The manual program modeM is not
stored.
!In the manual program modeM, the trans-
mission will not upshift, even if the engine has
reached its overrewing range. Shift up to the
next gear before the engine has reached its over-
rewing range. Make absolutely certain that the
engine speed does not reach the red marking on
the tachometer (
page 28). Otherwise the en-
gine could be damaged which is not covered by
the Mercedes-Benz Limited Warranty.
Warning!G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced
vehicle control. Your vehicle’s ABS will not
prevent this type of loss of control.
iWhen you brake or stop, the transmission
shifts down to a gear from which you can easily
accelerate or drive off.

197 Controls in detail
Automatic transmission
Emergency operation (Limp-Home
Mode)
If vehicle acceleration becomes less re-
sponsive or sluggish or the transmission
no longer shifts, the transmission is most
likely operating in limp-home (emergency
operation) mode. In this mode only second
gear and reverse gear can be activated.
Stop the vehicle in a safe location.
Shift to park positionP.
Turn off the engine.
Wait at least 10 seconds before
restarting.
Restart the engine.
Shift to drive positionD (for second
gear) or reverse gearR.
Have the transmission checked at an
authorized Mercedes-Benz Light Truck
Center as soon as possible.

198 Controls in detail
Transfer case
!Operational or performance test must only
be conducted on a two-axle dynamometer. If
such tests are necessary, contact an authorized
Mercedes-Benz Light Truck Center. You could
otherwise seriously damage the brake system or
the transfer case which is not covered by the
Mercedes-Benz Limited Warranty.
!Because the ESP® operates automatically,
the engine and ignition must be shut off
(SmartKey in starter switch position0 or1 or
KEYLESS-GO* start/stop button in
position0or1) when testing the parking brake
on a brake test dynamometer and such testing
should be no longer than 10 seconds.
Active braking action through the ESP
® may
otherwise seriously damage the brake system
which is not covered by the Mercedes-Benz
Limited Warranty.
iThe vehicle is equipped with permanent
four-wheel drive. Both the front and rear axles
are powered at all times when the vehicle is
being operated.

199 Controls in detail
Good visibility
Good visibility
For information on windshield wipers, see
“Windshield wipers” (
page 60).
Headlamp cleaning system*
The headlamps will automatically be
cleaned with a high-pressure water jet
when you have

switched on the headlamps
and

operated the windshield wipers with
windshield washer fluid five times
When you switch off the headlamps, the
counter resets.
For information on filling up the washer
reservoir, see “Windshield/rear window
washer system and headlamp cleaning
system*” (
page 346).
Rear view mirrors
For more information on setting the rear
view mirrors, see “Mirrors” (
page 49).
Interior rear view mirror, antiglare
position
1Lever
Tilt the mirror to the antiglare position
by moving lever1 towards the wind-
shield.
The interior rear view mirror is dimmed.Auto-dimming rear view mirrors*
The reflection brightness of the exterior
rear view mirror on the driver’s side and
the interior rear view mirror will respond
automatically to glare when

the ignition is switched on
and

incoming light from headlamps falls on
the sensor in the interior rear view
mirror
The rear view mirror will not react if

the automatic transmission is set to
positionR

the interior lighting is turned on
