191 Controls in detail
Automatic transmission
Driving tips
Accelerator position
Your driving style influences the
transmission’s shifting behavior:
Less throttle Earlier upshifting
More throttle Later upshifting
Kickdown
Use kickdown when you want maximum
acceleration.
Press the accelerator past the point of
resistance.
Depending on the engine speed the
transmission shifts into a lower gear.

Ease on the accelerator when you have
reached the desired speed.
The transmission shifts up again.Stopping
When you stop briefly, e.g. at traffic lights:

Leave the transmission in gear.

Hold the vehicle with the brake.
When you stop for a longer period of time
with the engine idling and/or on a hill:

Set the parking brake.

Shift into park positionP.
Maneuvering
When you maneuver in tight areas,
e.g. when pulling into a parking space:

Control the vehicle speed by gradually
releasing the brakes.

Accelerate gently.

Never abruptly step on the accelerator.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Children could shift the
automatic transmission out of park
positionP, which could result in an accident
and/or serious personal injury.

199 Controls in detail
Transfer case
Transfer case
!
Operational or performance test must only
be conducted on a two-axle dynanometer. If
such tests are necessary, contact an authorized
Mercedes-Benz Light Truck Center. You could
otherwise seriously damage the brake system or
the transfer case which is not covered by the
Mercedes-Benz Limited Warranty.
!
Because the ESP
® operates automatically,
the engine and ignition must be shut off
(SmartKey in starter switch position0 or1 or
KEYLESS-GO* start/stop button in
position0or1) when testing the brakes on a
brake test dynamometer and such testing should
be no longer than 10 seconds.
Active braking action through the ESP
® may
otherwise seriously damage the brake system
which is not covered by the Mercedes-Benz
Limited Warranty.
i
The vehicle is equipped with full-time
four-wheel drive. Both the front and rear axles
are powered at all times when the vehicle is
being operated.

237 Controls in detail
Power windows
Opening the door windows
Press switch1, 2, 3, or4
(page 236) to the resistance point.
The corresponding door window moves
downwards until you release the
switch.
Closing the door windows

Pull switch1, 2, 3, or4
(page 236) to the resistance point.
The corresponding door window moves
upwards until you release the switch.
If a door window encounters an obstruction
that blocks its path in a circumstance where
you are closing a door window by pulling and
holding the switch, or by pressing and hold-
ing button‹on the SmartKey, by press-
ing and holding the lock button (vehicles
with KEYLESS-GO*) on a door handle, the
automatic reversal function will not operate.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment can cause an accident
and/or serious personal injury.
i
You can also open or close the windows
using the SmartKey, see “Summer opening fea-
ture” (page 239) and see “Convenience clos-
ing feature” (
page 239).
Depending on the current position, the power
windows may also open or close when the air
recirculation button: on the control panel of
the climate control (
page 208) or automatic
climate control* (
page 222) is pressed and
held.
i
With the SmartKey in starter switch
position0 or removed from the starter switch,
the windows can be operated


until you open the driver’s or front passenger
door


for at least 5 minutes
Warning!
G
If you pull and hold the switch up when clos-
ing the door window, and upward movement
of the door window is blocked by some ob-
struction including but not limited to arms,
hands, fingers, etc., the automatic reversal
will not operate.

239 Controls in detail
Power windows
Summer opening feature
If the weather is warm, you can ventilate
the vehicle before driving off by simulta-
neously:

opening the door windows


opening the tilt/sliding sunroof*


switching on the seat ventilation* for
the driver’s seat

Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle.
The SmartKey or SmartKey with
KEYLESS-GO* must be in close proxim-
ity to the driver’s outside door handle.

Press and hold buttonΠon the
SmartKey or SmartKey with
KEYLESS-GO* until the windows and
the tilt/sliding sunroof* have reached
the desired position.

Release buttonΠon the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the opening procedure.
Convenience closing feature
When locking the vehicle, you can close
the windows and the tilt/sliding sunroof*
simultaneously.Warning!
G
When closing the windows and the
tilt/sliding sunroof*, make sure that there is
no danger of anyone being harmed by the
closing procedure.
If potential danger exists, proceed as fol-
lows:

Release button‹ to stop the closing
procedure. To open, press and hold
buttonŒ. To continue the closing
procedure after making sure that there
is no danger of anyone being harmed by
the closing procedure, press and hold
button‹.


240 Controls in detailPower windows
Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle
(page 239).
The SmartKey or SmartKey with
KEYLESS-GO* must be in close proxim-
ity to the driver’s outside door handle.

Press and hold button‹ on the
SmartKey or SmartKey with
KEYLESS-GO* until the windows and
the tilt/sliding sunroof* are completely
closed.

Release button‹ on the SmartKey
or SmartKey with KEYLESS-GO* to
interrupt the closing procedure.
Vehicles with KEYLESS-GO*:

Press and hold the lock button on an
outside door handle (
page 68) until
the windows and the tilt/sliding sun-
roof* are completely closed.

Release the lock button on the outside
door handle to interrupt the closing
procedure.
Vehicles with KEYLESS-GO*:

Release the lock button (
page 68) on
the driver’s outside door handle to stop
the closing procedure.


Immediately pull on the same outside
door handle and hold firmly. The win-
dows and the tilt/sliding sunroof* will
open for as long as the door handle is
held but the door is not opened.


242 Controls in detailPower tilt/sliding sunroof*Warning!
G
When closing the tilt/sliding sunroof, make
sure that there is no danger of anyone being
harmed by the closing procedure.
If the tilt/sliding sunroof encounters an ob-
struction that blocks its path in a circum-
stance where you are closing the tilt/sliding
sunroof by moving the tilt/sliding sunroof
switch past the resistance point, or by
pressing and holding button‹ on the
SmartKey, by pressing and holding the lock
button (vehicles with KEYLESS-GO*) on the
door handle, the automatic reversal function
will not operate.
The opening/closing procedure of the
tilt/sliding sunroof can be immediately halt-
ed by releasing the switch or, if the switch
was moved past the resistance point and re-
leased, by moving the switch in any direc-
tion.
The tilt/sliding sunroof is made out of glass.
In the event of an accident, the glass may
shatter. This may result in an opening in the
roof.
In a vehicle rollover, occupants not wearing
their seat belts or not wearing them properly
may be thrown out of the opening. Such an
opening also presents a potential for injury
for occupants wearing their seat belts prop-
erly as entire body parts or portions of them
may protrude from the passenger compart-
ment.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock your vehicle. Do not leave children un-
attended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment can cause an accident
and/or serious personal injury.!
To avoid damaging the seals, do not trans-
port any objects with sharp edges which can
stick out of the tilt/sliding sunroof.Do not open the tilt/sliding sunroof if there is
snow or ice on the roof, as this could result in
malfunctions.
The tilt/sliding sunroof can be opened or closed
manually should an electrical malfunction occur
(
page 478).
i
When the tilt/sliding sunroof is open, reso-
nance noises may result in addition to the usual
wind noises. They are caused by minimal pres-
sure changes in the passenger compartment. To
reduce or eliminate these noises, change the po-
sition of the tilt/sliding sunroof or open a side
window slightly.
i
You can also open or close the tilt/sliding
sunroof using the SmartKey or the
KEYLESS-GO* function, see “Summer opening
feature” (
page 239) and see “Convenience
closing feature” (
page 239).
i
Depending on the current position, the
tilt/sliding sunroof may also open or close when
the air recirculation button: on the control
panel of the climate control (
page 208) or
automatic climate control* (
page 222) is
pressed and held.

243 Controls in detail
Power tilt/sliding sunroof*

Switch on the ignition (
page 40).
Opening and closing

To open, close, raise, or lower the
tilt/sliding sunroof, move the sunroof
switch to the resistance point in the
required direction of arrows1to4
(page 241).

Release the sunroof switch when the
tilt/sliding sunroof has reached the de-
sired position.Fully opening (Express-open) and
closing (Express-close)

To fully open or close the tilt/sliding
sunroof, move the sunroof switch past
the resistance point in the required
direction of arrows1to2
(page 241) and release.
The tilt/sliding sunroof opens or closes
completely.
Stopping the power tilt/sliding sunroof
during Express-open

Move the sunroof switch in any direc-
tion.
The movement of the tilt/sliding sun-
roof stops.
i
If the movement of the tilt/sliding sunroof is
blocked during the closing procedure, the
tilt/sliding sunroof will stop and reopen slightly.
Warning!
G
If the tilt/sliding sunroof encounters an ob-
struction that blocks its path in a circum-
stance where you are closing the tilt/sliding
sunroof by moving the tilt/sliding sunroof
switch past the resistance point, or by
pressing and holding button‹ on the
SmartKey, by pressing and holding the lock
button (vehicles with KEYLESS-GO*) on the
door handle, the automatic reversal function
will not operate.
The opening/closing procedure of the
tilt/sliding sunroof can be immediately halt-
ed by releasing the switch or, if the switch
was moved past the resistance point and re-
leased, by moving the switch in any direc-
tion.

295 Controls in detail
Useful features
Closing CD changer*
1CD changer
Gent ly push CD c ha ng er1 up in direc-
tion of arrow until it engages.
For information on CD changer operation,
see separate COMAND system operating
instructions.Locking and unlocking the glove box
separately
You can lock the glove box separately, e.g.
when the vehicle is in the shop for service.

Take the mechanical key out of the
SmartKey or SmartKey with
KEYLESS-GO* (
page 475).
1Unlocking glove box
2Locking glove box

Insert mechanical key into glove box
lock.

Turn mechanical key to position2 to
lock the glove box.

Turn mechanical key to position1 to
unlock the glove box.
i
The glove box can only be locked or
unlocked with the mechanical key.

301 Controls in detail
Useful features
Opening rear ashtray
Briefly press ashtray cover2.
The ashtray1 opens automatically.
Removing rear ashtray insert

Grip the insert on the sides and pull it
out upwards.
Reinstalling rear ashtray insert

Install ashtray insert.

Close the ashtray.
Cigarette lighter

Switch on the ignition (
page 40).

Push in cigarette lighter.
The cigarette lighter will pop out auto-
matically when hot.
Cigarette lighter*
Switch on the ignition (
page 40).1Cigarette lighter

Open the ashtray (
page 300).

Push in cigarette lighter1.
The cigarette lighter will pop out auto-
matically when hot.
Warning!
G
Never touch the heating element or sides of
the cigarette lighter; they are extremely hot.
Hold the knob only.
Make sure that any children traveling with
you do not injure themselves or start a fire
with the hot cigarette lighter.
When leaving the vehicle always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.

305 Controls in detail
Useful features
Switching off
Turn switch at the tip of stalk in the
direction of arrow3.
The heated steering wheel is switched
off. Indicator lamp2 goes out.
For information on the steering wheel, see
“Multifunction steering wheel”
(
page 148).
Telephone*
Radio transmitters, such as a portable tele-
phone or a citizens band unit, should only
be used inside the vehicle if they are con-
nected to an antenna that is installed on
the outside of the vehicle.
The external antenna must be approved by
Mercedes-Benz. Please contact an autho-
rized Mercedes-Benz Light Truck Center
for information on the installation of an ap-
proved external antenna. Refer to the radio
transmitter operation instructions regard-
ing use of an external antenna.
i
Indicator lamp2 flashes or goes out


in case of power surge or undervoltage


in case of a steering wheel heating malfunc-
tion
i
The steering wheel heating switches off
automatically when you remove the SmartKey
from the starter switch or, on vehicles with
KEYLESS-GO*, when you switch off the ignition
(
page 39) and open the driver’s door.
Warning!
G
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system, pos-
sibly resulting in an accident and/or serious
personal injury.
Warning!
G
Please do not forget that your primary re-
sponsibility is to drive the vehicle. A driver’s
attention to the road must always be
his /her primary focus when driving. For
your safety and the safety of others, we rec-
ommend that you pull over to a safe location
and stop before placing or taking a tele-
phone call.
If you choose to use the telephone
1 while
driving, please use the hands-free device
and only use the telephone when road,
weather and traffic conditions permit. Some
jurisdictions prohibit the driver from using a
cellular telephone while driving a vehicle.
Only operate the COMAND system1 if road,
weather and traffic conditions permit.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.
1Observe all legal requirements
