garage door opener MERCEDES-BENZ ML320CDI 2007 W163 Comand Manual

ContentsDriving systems ................................. 245
Cruise control............................... 245
Distronic*..................................... 250
Distance warning function*.......... 263
Downhill Speed Regulation
(DSR) ............................................ 264
Off-road driving program .............. 268
Air suspension package* ............. 269
Adaptive Damping System
(ADS)* .......................................... 269
Vehicle level control* ................... 270
Parktronic system* ...................... 274
Rear view camera* ....................... 279
Loading .............................................. 281
Carriers* ...................................... 281
Loading instructions ..................... 281
Cargo tie-down rings .................... 283
Hooks ........................................... 284
Expanding cargo compartment .... 284
Cargo compartment cover blind ... 286
Partition net* ............................... 287
Cargo management system*........ 290Useful features .................................. 294
Storage compartments ................ 294
Parcel nets ................................... 297
Cup holders.................................. 298
Ashtrays* ..................................... 300
Cigarette lighter* ......................... 301
Power outlets ............................... 302
Floormats* ................................... 303
Heated steering wheel* ............... 304
Telephone* .................................. 305
Tele Aid* ...................................... 308
Garage door opener* ................... 316
Compass ...................................... 321
Infrared reflecting windshield* ..... 322
Operation......................................... 323
The first 1000 miles (1500 km) ......... 324
Driving instructions ........................... 325
Drive sensibly – save fuel............. 325
Drinking and driving ..................... 325
Pedals .......................................... 325
Power assistance ......................... 326
Brakes.......................................... 326
Driving off .................................... 329
Parking......................................... 329
Tires ............................................. 329
Hydroplaning................................ 330
Tire traction ................................. 330
Tire speed rating .......................... 331
Winter driving instructions ........... 332
Standing water............................. 333
Off-road driving ............................ 333
Trailer towing ............................... 342
Passenger compartment .............. 348
Driving abroad ............................. 348
Control and operation
of radio transmitters .................... 348
Catalytic converter
(gasoline engine).......................... 349

33 At a glance
Overhead control panel
Overhead control panel
Item
Page
1
Left reading lamp switch
142
2
Rear interior lighting switch
142
3
Automatic interior lighting
switch
142
4
Front interior lighting switch
142
5
Right reading lamp switch
142
6
Front right interior lamp
142
7
Tilt/sliding sunroof* switch
241
8
Tele Aid* (emergency call
system) button
311
9
Interior rear view mirror
200
a
Front right reading lamp
142
Item
Page
b
Front left reading lamp
142
c
Garage door opener*
316
d
Vehicles without
telephone* installed:
Hands-free microphone for
Tele Aid* (emergency call
system)
308
e
Vehicles with telephone*
installed:
Hands-free microphone for
Tele Aid* (emergency call
system) and telephone*
308
f
Front left interior lamp
142

316 Controls in detailUseful featuresGarage door opener*
The integrated remote control is capable of
operating up to three separately controlled
devices. It provides a convenient way to re-
place up to three hand-held remote con-
trols used to operate devices such as
garage door openers, gate openers, or oth-
er devices compatible with HomeLink
® or
some other systems.
Before the integrated remote control can
be used, it must be programmed to the ga-
rage door opener, gate operator or other
device you wish to operate. See the follow-
ing instructions for programming informa-
tion.
Interior rear view mirror with integrated
remote control1Indicator lamp
2 3 4Signal transmitter button
Needed for programming (not part of vehi-
cle equipment):
5Hand-held remote control of ga-
rage door opener, gate operator
or other device
6Hand-held remote control but-
ton
i
When the anti-theft alarm stays on for more
than 30 seconds, a call is initiated automatically
to the Response Center. See anti-theft alarm
system (
page 103).
Warning!
G
Before programming the integrated remote
control to a garage door opener or gate
operator, make sure people and objects are
out of the way of the device to prevent po-
tential harm or damage. When programming
a garage door opener, the door moves up or
down. When programming a gate operator,
the gate opens or closes.
Do not use the integrated remote control
with any garage door opener that lacks
safety stop and reverse features as required
by U.S. federal safety standards (this
includes any garage door opener model
manufactured before April 1, 1982).
A garage door that cannot detect an object
– signaling the door to stop and reverse –
does not meet current U.S. federal safety
standards.

317 Controls in detail
Useful features
Programming the integrated remote
control
Step 1:
Switch on the ignition (
page 40).Step 2:

If you have previously programmed a
signal transmitter button and wish to
retain its programming, proceed to
step 3.
If you are programming the integrated
remote control for the first time, press
and hold the two outer signal transmit-
ter buttons2 and4 and release
them only when indicator lamp1
begins to flash after approximately
20 seconds (do not hold the button for
longer than 30 seconds). This proce-
dure erases any previous settings for
all three channels and initializes the
memory.
If you later wish to program a second
and/or third hand-held transmitter to
the remaining two signal transmitter
buttons, do not repeat this step and be-
gin directly with step 3.Step 3:

Hold end of the hand-held remote
control5 of the device you wish to
train approximately 2 to 5 in
(5 to 12 cm) away from the signal
transmitter button (2, 3 or4) to be
programmed, while keeping the indica-
tor lamp1 in view.
Step 4:

Using both hands, simultaneously
press hand-held remote control
button6 and the desired signal trans-
mitter button (2, 3 or4). Do not
release the buttons until step 5 is com-
pleted.
Indicator lamp1 will flash, first slowly
and then rapidly.
When programming a garage door opener,
park the vehicle outside the garage.
Do not run the engine while programming
the integrated remote control. Inhalation of
exhaust gas is hazardous to your health.
All exhaust gas contains carbon monoxide
(CO), and inhaling it can cause unconscious-
ness and possible death.
i
Indicator lamp1 flashes immediately the
first time the signal transmitter button is
programmed. If this button has already been
programmed, the indicator lamp will only start
flashing after 20 seconds.


318 Controls in detailUseful featuresStep 5:
After indicator lamp1 changes from a
slow to a rapidly flashing light, release
the hand-held remote control button
and the signal transmitter button.
Step 6:

Press and hold the just-trained signal
transmitter button (2, 3 or4) and
observe indicator lamp1.
If indicator lamp1 stays on
constantly, programming is complete
and your device should activate when
the respective signal transmitter
button (2, 3 or4) is pressed and re-
leased.Step 7:

To program the remaining two signal
transmitter buttons, repeat the steps
above starting with step 3.
Rolling code programming
To train a garage door opener (or other
rolling code devices) with the rolling code
feature, follow these instructions after
completing the “Programming” portion
(steps 1 through 6) of this text. (A second
person may make the following training
procedures quicker and easier.)
Step 8:

Locate “training” button on the garage
door opener motor head unit.
Exact location and color of the button
may vary by garage door opener brand.
Depending on manufacturer, the
“training” button may also be referred
to as “learn” or “smart” button. If there
is difficulty locating the transmitting
button, refer to the garage door opener
Operator’s Manual.Step 9:

Press the “training” button on the ga-
rage door opener motor head unit.
The “training light” is activated.
You have 30 seconds to initiate the follow-
ing two steps.
Step 10:

Return to the vehicle and firmly press,
hold for 2 seconds and release the pro-
grammed signal transmitter button
(2, 3 or4).
Step 11:

Press, hold for 2 seconds and release
same signal transmitter button a sec-
ond time to complete the training pro-
cess.
i
If indicator lamp1 flashes rapidly for about
2 seconds and then turns to a constant light,
continue with programming steps 8 through 12
as your garage door opener may be equipped
with the “rolling code” feature.
i
Some garage door openers (or other rolling
code equipped devices) may require you to
press, hold for 2 seconds and release the same
signal transmitter button a third time to
complete the training process.


319 Controls in detail
Useful features
Step 12:
Confirm the garage door operation by
pressing the programmed signal trans-
mitter button (2, 3 or4).
Step 13:

To program the remaining two signal
transmitter buttons, repeat the steps
above starting with step 3.
Gate operator/Canadian programming
Canadian radio-frequency laws require
transmitter signals to “time-out” (or quit)
after several seconds of transmission
which may not be long enough for the
integrated signal transmitter to pick up the
signal during programming. Similar to this
Canadian law, some U.S. gate operators
are designed to “time-out” in the same
manner.
If you live in Canada or if you are having
difficulties programming a gate operator
(regardless of where you live) by using the
programming procedures, replace step 4
with the following:Step 4:

Press and hold the signal transmitter
button (2, 3 or4). Do not release
this button until it has been successful-
ly trained.

While still holding down the signal
transmitter button (2, 3 or4),
“cycle” your hand-held remote control
button6 as follows: Press and hold
button6 for 2 seconds, then release
it for 2 seconds, and again press and
hold it for 2 seconds. Repeat this se-
quence on the hand-held remote con-
trol until the frequency signal has been
learned. Upon successful training,
indicator lamp1 will flash slowly and
then rapidly after several seconds.

Proceed with programming step 5 and
step 6 to complete.Reprogramming a single signal trans-
mitter button
To program a device using a signal trans-
mitter button previously trained, follow
these steps:

Switch on the ignition (
page 40).

Press and hold the desired signal
transmitter button (2, 3 or4).
Do not release the button.

Indicator lamp1 will begin to flash af-
ter 20 seconds. Without releasing the
signal transmitter button, proceed with
programming starting with step 3.
i
Upon completion of programming the inte-
grated remote control, make sure you retain the
hand-held remote control that came with the ga-
rage door opener, gate operator or other device.
You may need it for use in other vehicles, for fu-
ture programming of an integrated remote con-
trol, or simply for continued use as a hand-held
remote control to operate the respective device
in other situations.

320 Controls in detailUseful featuresOperation of integrated remote control
Switch on the ignition (
page 40).

Select and press the appropriate inte-
grated signal transmitter button (2,
3 or4) to activate the remote con-
trolled device.
The integrated remote control trans-
mitter continues to send the signal as
long as the button is pressed – up to
20 seconds.
Erasing the integrated remote control
memory

Switch on the ignition (
page 40).

Simultaneously press and hold outer
signal transmitter buttons2 and 4,
for approximately 20 seconds, until
indicator lamp1 flashes rapidly. Do
not hold for longer than 30 seconds.
The codes of all three channels are
erased.Programming tips
If you are having difficulty programming
the integrated remote control, here are
some helpful tips:


Check the frequency of hand-held
remote control5 (typically located on
the reverse side of the remote). The in-
tegrated remote control is compatible
with radio-frequency devices operating
between 280-390 MHz.


Put a new battery in hand-held remote
control5. This will increase the likeli-
hood of the hand-held remote control
sending a faster and more accurate sig-
nal to the integrated remote control.


While performing step 3, hold
hand-held remote control5 at differ-
ent lengths and angles from the signal
transmitter button (2, 3 or4) you
are programming. Attempt varying an-
gles at the distance of 2 to 5 inches
(5 to 12 cm) away or the same angle at
varying distances.


If another hand-held remote control is
available for the same device, try the
programming steps again using that
other hand-held remote control. Make
sure new batteries are in the hand-held
remote control before beginning the
procedure.


Straighten the antenna wire from the
garage door opener assembly. This
may help improve transmitting and/or
receiving signals.
i
If you sell your vehicle, erase the codes of all
three channels.
i
Certain types of garage door openers are in-
compatible with the integrated remote control. If
you should experience further difficulties with
programming the integrated remote control,
contact an authorized Mercedes-Benz Center, or
call Mercedes-Benz Customer Assistance
Center (in the USA only) at 1-800-FOR-MER-
Cedes, or Customer Service (in Canada) at
1-800-387-0100.

561 Index
Fuel cap
Messages in the multifunction
display 455
Fuel consumption statistics
After start 180
Since last reset 181
Fuel filler flap 352
Locking/unlocking 352
Opening 352
Opening in an emergency 477
Fuel tank
Capacity 545
Filler flap 352
Fuel, Premium unleaded gasoline 545
Fuels, coolants, lubricants etc. 543
Fuses 522
Fuse box in cargo compartment 523
Fuse box in engine compartment 523
Fuse box in passenger
compartment 524
Fuse chart 469, 522
Fuse extractor 469, 522
Replacing 522
Spare fuses 469, 522G
Garage door opener* 316
Gasoline see Fuel
GAWR 395
Gear range
Automatic transmission 193
Limiting 193
Shifting into optimal 195
Gear selector lever 25, 54, 185
Cleaning 411
Gearshift pattern 185
Messages in the
multifunction display 438
Position 188
Shifting procedure 188
Transmission position 189
Global locking/unlocking see Key,
SmartKey
Glove box 294
Good visibility 200
Gross Axle Weight Rating see GAWR
Gross Trailer Weight see GTW
Gross Vehicle Weight Rating see GVWRGross Vehicle Weight see GVW
GTW 395
GVW 395
GVWR 395
H
Halogen headlamp see Headlamps
Hands-free microphone 33
Hard plastic trim items, cleaning 411
Hazard warning flasher 142
Head restraints 44, 128
Active head restraint 80, 128
Front seats, Adjusting 44
Rear seats 81
Rear seats, Adjusting 129
Rear seats, Removing and
installing 129
Headlamp aim
Adjusting 492
Headlamp cleaning system* 200, 363
Headlamp shut-off delay see Delayed
shut-off, Exterior lamps
