sunroof MERCEDES-BENZ R-Class 2012 W251 Owner's Manual

Convenience submenu ..................209
Displaying a service message ........287
Displaying the coolant
temperature ................................... 202
Displaying the outside
temperature ................................... 202
Display messages ..........................213
DISTRONIC menu .......................... 178
Factory settings ............................. 205
Important safety notes ..................198
Instrument cluster submenu ..........205
Lighting submenu .......................... 206
Menu overview .............................. 201
Message memory menu ................. 213
Navigation menu ............................ 204
Operating video DVD .....................204
Operation ....................................... 199
Selecting the language ..................206
Settings menu ............................... 205
Standard display ............................ 202
Status bar ...................................... 206
Telephone menu ............................ 211
Time/Date submenu .....................206
Trip computer menu ......................210
Vehicle submenu ........................... 208
Opening and closing the side trim
panels ................................................. 123
Operating system see On-board computer
Outside temperature
Calling up (on-board computer) .....202
Display ........................................... 198
Overhead control panel ...................... 34
Override feature Rear side windows ...........................63
P
Paint code number ............................ 353
Paintwork (cleaning instructions) ... 290
Panic alarm .......................................... 64
Panorama roof with power tilt/
sliding panel Opening/closing .............................. 91
Opening/closing the roller
sunblind ........................................... 91
Problem (malfunction) .....................92
Resetting ......................................... 92
Panorama sliding sunroof
Important safety notes ....................89
Parking
Important safety notes ..................163
Parking brake ................................ 164
Position of exterior mirror, front-
passenger side ............................... 111
Rear view camera .......................... 187
see Parking
see PARKTRONIC
Parking aid
see Exterior mirrors
see PARKTRONIC
Parking brake
Display message ............................ 217
Notes/function .............................. 164
see Parking brake
Parking lamps (changing bulbs) ...... 122
PARKTRONIC Deactivating/activating .................186
Driving system ............................... 184
Function/notes ............................. 184
Problem (malfunction) ...................187
Range of the sensors .....................184
Trailer towing ................................. 186
Warning display ............................. 185
Pedals ................................................. 165
Permanent four-wheel drive see 4MATIC (permanent four-
wheel drive)
Plastic trim (cleaning instructions) . 292
Power washers .................................. 289
Power windows see Side windows
PRE-SAFE ®
(Preventive occupant
safety system) Display message ............................ 218
Operation ......................................... 49
PRE-SAFE ®
Brake (vehicles with
DISTRONIC PLUS) Warning lamp ................................. 245
Preventive occupant safety
system
see PRE-SAFE ®
(Preventive
occupant safety system)
Product information ............................ 21
Program selector button .................. 153Index13

SeatFolding down the 2nd row of
seats .............................................. 254
Important safety notes ....................97
Resetting the 2nd row of seats ......256
Resetting the 3rd row of seats ....... 256
Seat belts
Adjusting the driver's and front-
passenger seat belt .........................54
Adjusting the height ......................... 54
Belt force limiters ............................ 55
Cleaning ......................................... 293
Correct usage .................................. 52
Emergency Tensioning Devices ........ 55
Fastening ......................................... 53
Important safety guidelines .............51
Releasing ......................................... 54
Safety guidelines ............................. 39
Special seat belt retractor ...............58
Switching belt adjustment on/off
(on-board computer) ......................209
Warning lamp ................................. 238
Warning lamp (function) ................... 54
Seats
Adjusting (electrically) .....................98
Adjusting (second and third rows) . 101
Adjusting the 4-way lumbar
support .......................................... 105
Adjusting the head restraint ............99
Cleaning the cover .........................293
Correct driver's seat position ........... 96
Folding down the 3rd row of seats . 255
Folding the rear bench seat
forwards/back ............................... 253
Multicontour seat .......................... 105
Seat heating problem ....................106
Seat ventilation problem ................107
Storing settings (memory
function) ........................................ 112
Switching seat heating on/off .......106
Switching the seat ventilation on/
off .................................................. 106
Securing hooks .................................. 258
Sensors (cleaning instructions) ....... 291
Service see ASSYST PLUS service interval
display Service interval display
Displaying service messages .........287
Hiding service messages ...............287
Notes ............................................. 287
Service messages ..........................287
Service products
Brake fluid ..................................... 359
Capacities ...................................... 355
Coolant (engine) ............................ 359
DEF special additives .....................357
Engine oil ....................................... 358
Fuel ................................................ 356
Important safety notes ..................354
Refrigerant (air-conditioning
system) .......................................... 359
Washer fluid ................................... 360
Settings
Factory (on-board computer) .........205
On-board computer .......................205
Setting the air distribution ............... 138
Setting the airflow ............................ 138
Side impact air bag ............................. 42
Side marker lamp (display
message) ............................................ 224
Side marker lamps (changing
bulbs) ................................................. 123
Side windows Convenience closing feature ............88
Convenience opening feature ..........87
Hinged side windows .......................87
Important safety information ...........86
Opening/closing .............................. 86
Problem (malfunction) .....................89
Resetting ......................................... 89
Sliding sunroof
Important safety notes ....................89
Opening/closing .............................. 90
Problem (malfunction) .....................92
Resetting ......................................... 90
see Panorama roof with power
tilt/sliding panel
SmartKey
Changing the battery .......................76
Changing the programming .............75
Checking the battery .......................76
Convenience closing feature ............88
Convenience opening feature ..........87
Display message ............................ 236Index15

Opening/closing (automatically
from outside) ................................... 83
Opening/closing (from outside) .......82
Tail lamps
Display message ............................ 224
see Lights
Tank
see Fuel tank
Tank content
Fuel gauge ....................................... 29
Technical data
R 350 ............................................. 361
R 350 BlueTEC ............................... 360
Tires/wheels ................................. 347
TELEAID
Call priority .................................... 273
Display message ............................ 218
Downloading destinations
(COMAND) ..................................... 273
Emergency call .............................. 270
Important safety notes ..................269
Locating a stolen vehicle ...............275
MB info call button ........................272
Roadside Assistance button ..........272
Search & Send ............................... 274
Self-test ......................................... 270
System .......................................... 270
Vehicle remote unlocking ..............274
Telephone
Accepting a call ............................. 211
Display message ............................ 235
Menu (on-board computer) ............211
Number from the phone book ........ 212
Redialing ........................................ 212
Rejecting/ending a call .................212
Temperature
Coolant (on-board computer) ......... 202
Displaying the outside
temperature ................................... 202
Outside temperature ...................... 198
Setting (climate control) ................137
Theft deterrent locking system
Immobilizer ...................................... 68
Tilt/sliding sunroof
see Sliding sunroof
Time (on-board computer) ................ 206
TIREFIT kit .......................................... 299Tire pressure
Calling up (on-board computer) .....331
Checking manually ........................329
Display message ............................ 231
Maximum ....................................... 328
Notes ............................................. 327
Not reached (TIREFIT) ....................302
Pressure loss warning ....................329
Reached (TIREFIT) ..........................302
Recommended ............................... 325
Tire pressure monitoring system
Function/notes ............................. 331
Restarting ...................................... 333
Warning lamp ................................. 245
Tires
Aspect ratio (definition) .................345
Average weight of the vehicle
occupants (definition) ....................343
Bar (definition) ............................... 343
Characteristics .............................. 343
Checking ........................................ 323
Definition of terms .........................343
Direction of rotation ......................346
Display message ............................ 231
Distribution of the vehicle
occupants (definition) ....................346
DOT, Tire Identification Number
(TIN) ............................................... 342
DOT (Department of
Transportation) (definition) ............343
GAWR (Gross Axle Weight Rating)
(definition) ..................................... 344
GTW (Gross Trailer Weight)
(definition) ..................................... 344
GVW (Gross Vehicle Weight)
(definition) ..................................... 344
GVWR (Gross Vehicle Weight
Rating) (definition) .........................344
Important safety notes ..................322
Increased vehicle weight due to
optional equipment (definition) ......343
Kilopascal (kPa) (definition) ...........344
Labeling (overview) ........................339
Load bearing index (definition) ......345
Load index ..................................... 342
Load index (definition) ...................344
Maximum loaded vehicle weight
(definition) ..................................... 344Index17

Overhead control panelFunctionPage:p Switches the left-
hand reading lamp on/off
118
;| Switches the
automatic interior lighting
control on/off
119
=u Switches the rear
interior lighting on/off
119
?c Switches the front
interior lighting on/off
119
Ap Switches the right-
hand reading lamp on/off
118
BInterior lighting, right119C2 Opens/closes the
sliding sunroof
90
2 Opens/closes the
panorama roof with power
tilt/sliding panel and roller
sunblinds
91
FunctionPageDG SOS button (mbrace
system)
270
ERear-view mirror109FReading lamps118GButtons for the garage door
opener
276
HMicrophone for mbrace
(emergency call system),
telephone and the Voice
Control System 4IInterior lighting, left1194
Observe the additional operating instructions.34Overhead control panelAt a glance

GWARNING
If the 42 indicator lamp does not illuminate or remains out with the weight of a
typical 12-month-old child in a standard child restraint or less, or is unoccupied, on the front-
passenger seat, do not transport a child on the front-passenger seat until the system has been
repaired.
PRE-SAFE ®
(preventative occupant
protection)GWARNING
The PRE-SAFE ®
system reduces the impact of
an accident on vehicle occupants, as long as
their seat belts have been fastened correctly.
Although your vehicle is equipped with a PRE-
SAFE ®
system, the possibility of injury in the
event of an accident cannot be ruled out. You
should therefore always drive carefully and
adapt your driving style to the prevailing road,
weather and traffic conditions.
PRE-SAFE ®
takes preemptive measures to
protect occupants in certain hazardous
situations.
PRE-SAFE ®
intervenes:
R in emergency braking situations when BAS
intervenes
R in critical driving situations, e.g. when
physical limits are exceed and the vehicle
understeers or oversteers severely
PRE-SAFE ®
takes the following measures
depending on the hazardous situation
detected:
R the front seat belts are pre-tensioned.
R on vehicles with memory function for the
front-passenger seat: the front-passenger
seat is adjusted if it is in an unfavorable
position.
R if the vehicle skids, the side windows are
closed so that only a small gap remains.
R on vehicles with a sliding sunroof: if the
vehicle skids, the sliding sunroof closes so
that only a small gap remains.
If the hazardous situation passes without
resulting in an accident, PRE-SAFE ®
slackens
the belt pretensioning. All settings made by
PRE-SAFE ®
can then be reversed.
If the seat belts are not released:XMove the backrest or seat back slightly, but
only when the vehicle is stationary.
The belt pretensioning is reduced and the
locking mechanism is released.GWARNING
Make sure that nobody can become trapped
as you adjust the seat.
! Make sure that there are no objects in the
footwell or behind the seats when resetting
the seats. There is a risk that the seats
and/or the objects could be damaged.
More information about seat-belt
adjustment, a convenience function
integrated into PRE-SAFE ®
, can be found in
the "Seat-belt adjustment" section
( Y page 54).
NECK-PRO head restraints/NECK-
PRO luxury head restraints
NECK-PRO head restraints/NECK-PRO luxury
head restraints increase protection of the
driver's and front-passenger's head and
neck. In the event of a rear collision of a
certain severity, the NECK-PRO head
restraints/NECK-PRO luxury head restraints
on the driver's and front-passenger seats are
moved forwards and upwards. This provides
better head support.
GWARNING
Do not attach any objects (e.g. a coat hanger)
to the NECK-PRO head restraints/NECK-PRO
luxury head restraints. Otherwise, the NECK-
Occupant safety49SafetyZ

Useful information ..............................72
SmartKey ............................................. 72
Doors .................................................... 79
Cargo compartment ............................81
Side windows ...................................... 86
Sliding sunroof .................................... 8971Opening/closing

automatic operation by operating the
switch again.
i You can continue to operate the side
windows after you switch off the engine or
remove the SmartKey. This function is
available for up to five minutes or until the
driver's or front-passenger door is opened.
Opening and closing the hinged side
windows
The hinged side windows are operated
electrically from the from the driver's seat.
GWARNING
Make sure that nobody can become trapped
as you close the hinged side windows. If there
is a risk of somebody becoming trapped,
release the switch or push the switch again to
reopen the side window.
Door control panel
XMake sure that the SmartKey is in position
1 or 2 in the ignition lock.XTo open fully: press switch : and release.XTo close fully: pull switch : and release.XTo stop the closing procedure: press
switch : again.
Both hinged side windows open fully.
i If the hinged side windows are blocked
when closing, the closing procedure is
terminated and the hinged side windows
open again slightly.
i For safety reasons, the hinged side
windows can only be opened again after
four seconds.
Convenience opening feature
You can ventilate the vehicle before you start
driving. To do this, the key is used to carry out
the following functions simultaneously:
R unlock the vehicle
R open the side windows
R open the hinged side windows
R open the sliding sunroof or the panorama
roof with power tilt/sliding panel and the
roller sunblinds
i The convenience opening feature can
only be operated using the SmartKey. The
SmartKey must be close to the driver's
door handle.
XPoint the tip of the SmartKey at the driver's
door handle.XPress and hold the % button until the
side windows and the sliding sunroof or the
panorama roof with power tilt/sliding
panel are in the desired position.
If the roller sunblinds of the panorama roof
with power tilt/sliding panel are closed, the
roller sunblinds are opened first.
XPress and hold the % button again until
the panorama roof with power tilt/sliding
panel is in the desired position.XTo interrupt convenience opening:
release the % button.Side windows87Opening/closingZ

Convenience closing
General information
When you lock the vehicle, you can
simultaneously:
R close the side windows
R close the hinged side windows
R close the sliding sunroof or the panorama
roof with power tilt/sliding panel
On vehicles with a panorama roof with power
tilt/sliding panel, you can then close the
roller sunblinds.
GWARNING
When closing the door windows and the
sliding sunroof or panorama roof with power
tilt/sliding panel, make sure that there is no
danger of anyone being harmed by the closing
procedure.
If potential danger exists, proceed as follows:
R Release the & button to stop the closing
procedure. To open, press and hold the
% button. To continue the closing
procedure after making sure that there is
no danger of anyone being harmed by the
closing procedure, press and hold the
& button.
Vehicles with KEYLESS-GO:
R Release the lock button on the outside door
handle to stop the closing procedure.
R Immediately pull on the same outside door
handle and hold firmly. The door windows
and the sliding sunroof or panorama roof
with power tilt/sliding panel will open for
as long as the door handle is held but the
door is not opened.
Using the SmartKey
i The SmartKey must be close to the
driver's door handle.
XPoint the tip of the SmartKey at the driver's
door handle.XPress and hold the & button until the
side windows and the sliding sunroof or thepanorama roof with power tilt/sliding
panel are fully closed.XMake sure that all the side windows and the
sliding sunroof or panorama roof with
power tilt/sliding panel are closed.
On vehicles with a panorama roof with power
tilt/sliding panel:
XPress and hold the & button again until
the roller sunblinds of the panorama roof
with power tilt/sliding panel close.XTo interrupt convenience closing:
release the & button.
Using KEYLESS-GO
The KEYLESS-GO key must be outside the
vehicle. All the doors must be closed.
XKeep locking button : on the door handle
pressed until the side windows and the
sliding sunroof or panorama roof with
power tilt/sliding panel are fully closed.XMake sure that all the side windows and the
sliding sunroof or panorama roof with
power tilt/sliding panel are closed.
On vehicles with a panorama roof with power
tilt/sliding panel:
XPress and hold locking button : again
until the roller sunblinds of the panorama
roof with power tilt/sliding panel close.XTo interrupt convenience closing:
release locking button : on the door
handle.88Side windowsOpening/closing

Resetting the side windows
You must reset each side window if:
R the battery has been disconnected or has
become discharged.
R the side window opens again slightly after
being closed fully.
R the side window can no longer be fully
opened or closed.XClose all the doors.XTurn the SmartKey to position 1 or 2 in the
ignition lock.XPull the corresponding switch on the door
control panel until the side window is
completely closed. ( Y page 86)XHold the switch for an additional second.
If the side window opens again slightly:
XImmediately pull the corresponding switch
on the door control panel until the side
window is completely closed ( Y page 86).XHold the switch for an additional second.XIf the corresponding side window remains
closed after the button has been released,
the side window has been reset correctly.
If this is not the case, repeat the steps
above again.
Problems with the side windows
Problem: a side window cannot be closed
because it is blocked by objects, e.g.
leaves in the window guide.
XRemove the objects.XClose the side window.
Problem: a side window cannot be closed
and you cannot see the cause.
GWARNING
Closing the side windows with increased force
or without the anti-entrapment feature could
lead to serious or even fatal injury. Make sure
that nobody can become trapped when
closing the side windows.
If a side window is obstructed during closing
and reopens again slightly:XImmediately after the window blocks, pull
the corresponding switch again until the
side window has closed.
The side window is closed with increased
force.
If a side window is obstructed again during
closing and reopens again slightly:
XImmediately after the window blocks, pull
the corresponding switch again until the
side window has closed.
The side window is closed without the anti-
entrapment feature.GWARNING
Pulling and holding the switch to close the
door window immediately after it had been
blocked two times will cause the door window
to close without the anti-entrapment feature
for as long as you hold the switch.
Sliding sunroof
Important safety notes
Your vehicle may be equipped with a sliding
sunroof or a panorama roof with power tilt/
sliding panel. In the following section, the
term "sliding sunroof" refers to both types of
sliding sunroof.
GWARNING
When opening or closing the sliding sunroof,
make sure that there is no danger of anyone
being harmed by the opening/closing
procedure.
The sliding sunroof is equipped with
automatic operation and the anti-entrapment
feature. If the movement of the sliding sunroof
is blocked during the closing procedure, the
sliding sunroof will stop and open slightly.
The sliding sunroof operates differently when
the sliding sunroof switch is pressed and held.
See the "Problems with the sliding sunroof"
section for more details.
Sliding sunroof89Opening/closingZ

The opening/closing procedure of the sliding
sunroof can be immediately halted by
releasing the sliding sunroof switch or, if the
sliding sunroof switch was moved past the
resistance point and released, by moving the
sliding sunroof switch in any direction.GWARNING
The sliding sunroof is made out of glass. In the
event of an accident, the glass may shatter.
This may result in an opening in the roof.
In a vehicle rollover, occupants not wearing
their seat belts or not wearing them properly
may be thrown out of the opening. Such an
opening also presents a potential for injury for
occupants wearing their seat belts properly,
as entire body parts or portions of them may
protrude from the passenger compartment.
! Only open the sliding sunroof if it is free
of snow and ice. Otherwise, malfunctions
may occur.
Do not allow anything to protrude from the
sliding sunroof. Otherwise, the seals could
be damaged.
! The weather can change abruptly. It could
start to rain or snow. Make sure that the
sliding sunroof is closed when you leave the
vehicle. The vehicle electronics can be
damaged if water enters the vehicle
interior.
i Resonance noises can occur in addition
to the usual airflow noises when the sliding
sunroof is open. They are caused by minor
pressure fluctuations in the vehicle interior.
Change the position of the sliding sunroof
or open a side window slightly to reduce or
eliminate these noises.
Operating the sliding sunroof
Opening and closing
i You can continue to operate the sliding
sunroof after switching off the engine or
removing the SmartKey from the ignition
lock. This function is available for up to five
minutes or until the driver's or front-
passenger door is opened.
Overhead control panel
:To raise;To open=To close/lowerXTurn the SmartKey to position 1 or 2 in the
ignition lock.XPress or pull the 2 switch in the
corresponding direction.
i If you press the 2 switch beyond the
point of resistance, an automatic opening/
closing process is started in the
corresponding direction. You can stop
automatic operation by operating the
switch again.
The sun protection cover automatically opens
along with the sliding sunroof. You can open
or close the sun protection cover manually
when the sliding sunroof is raised or closed.
Resetting
Reset the sliding sunroof if it does not move
smoothly, or if the battery has been
disconnected or has become discharged.
XRemove the SmartKey from the ignition
lock or select position 0 (KEYLESS-GO).XRemove the fuse for the sliding sunroof
from the fuse box. To find out where the
fuse is located, refer to the fuse allocation
chart in the vehicle tool kit ( Y page 296).XReinsert the fuse.90Sliding sunroofOpening/closing
