MERCEDES-BENZ R350 2007 R171 Owner's Manual

180 Controls in detail
Control system
Available languages:

German

English

French

Italian

Spanish

Dutch

Danish

Swedish

Portuguese

Turkish

Russian (Canada only)Selecting display (digital speedometer
or outside temperature) for status
indicator
Move the selection marker with
buttonæ orç to the
Instr.
cluster
submenu.
Press buttonj ork repeatedly
until the message
Status line
display
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to select
the desired setting.
The selected display is then shown
continuously in the status indicator
(lower display).
The other display now appears in the
menu of the standard display
(
page 167):

Digital speedometer
or

Outside temperature

181 Controls in detail
Control system
Time/Date submenu
Access the
Time/Date submenu via the
Settings menu. Use the Time/Date
submenu to change the time and date
settings.
The following functions are available:Setting the time (hour)
This function is not available if your vehicle
is equipped with the COMAND system and
navigation module*.
Move the selection marker with
buttonæ orçto the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Clock Set hour
appears in the multifunction display.
The selection marker is on the hour
setting.
Press buttonæ orç to set the
hour.Setting the time (minutes)
This function is not available if your vehicle
is equipped with the COMAND system and
navigation module*.
Move the selection marker with
buttonæ orçto the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Clock Set minute(s) appears in the
multifunction display.
The selection marker is on the minute
setting.
Press buttonæ orç to set the
minutes.
FunctionPage
Setting the time (hours)181
Setting the time (minutes)181
Setting the date (month)182
Setting the date (day)182
Setting the date (year)182
iIf your vehicle is equipped with the
COMAND system and navigation module*, see
separate COMAND operating instructions for
information on how to set the date and time.

182 Controls in detail
Control system
Setting the date (month)
This function is not available if your vehicle
is equipped with the COMAND system and
navigation module*.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Date Set month
appears in the multifunction display.
The selection marker is on the month
setting.
Press buttonæ orç to set the
month.Setting the date (day)
This function is not available if your vehicle
is equipped with the COMAND system and
navigation module*.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Date Set day
appears in the multifunction display.
The selection marker is on the day
setting.
Press buttonæ orç to set the
day.Setting the date (year)
This function is not available if your vehicle
is equipped with the COMAND system and
navigation module*.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Date Set year
appears in the multifunction display.
The selection marker is on the year
setting.
Press buttonæ orç to set the
year.

183 Controls in detail
Control system
Lighting submenu
Access the
Lighting submenu via the
Settings menu. Use the Lighting
submenu to change the lamp and lighting
settings on your vehicle.
The following functions are available:Setting daytime running lamp mode
(USA only)
Move the selection marker with
buttonæ orç to the
Lighting
submenu.
Press buttonj ork repeatedly
until the message
Lamp circuit
headlamp
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to select
manual operation (
Manual) or daytime
running lamp mode (
Constant).
With daytime running lamp mode activated
and the exterior lamp switch in
positionM orU, the low beam
headlamps are switched on when the
engine is running.
FunctionPage
Setting daytime running lamp
mode (USA only)183
Setting locator lighting184
Setting night security
illumination185
Setting interior lighting delayed
shut-off186
iThis function is not available in countries
where the daytime running lamp mode is manda-
tory and therefore in a constant mode.

184 Controls in detail
Control system
In low ambient light conditions the
following lamps will switch on additionally:

Parking lamps

Tail lamps

License plate lamps

Side marker lamps
For more information on the daytime
running lamp mode, see “Lighting”
(
page 146).Setting locator lighting
With the locator lighting feature activated,
the exterior lamp switch in positionU
(
page 147) and the interior lighting in
automatic mode (
page 153), the
following lamps will switch on during dark-
ness when the vehicle is unlocked using
button Πon the SmartKey or SmartKey
with KEYLESS-GO*:

Parking lamps

Tail lamps

License plate lamps

Side marker lamps

Front fog lamps*
The locator lighting switches off when the
driver’s door is opened.
If you do not open a door after unlocking
the vehicle with the SmartKey, the lamps
will switch off automatically after approxi-
mately 40 seconds.
Move the selection marker with
buttonæ orç to the
Lighting
submenu.
Press buttonj ork repeatedly
until the message
Function Surround
lighting
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the locator lighting function
On or Off.
Turn the exterior lamp switch to
positionU when exiting the vehicle.
The locator lighting feature is
activated.
iFor safety reasons, changing the setting for
the daytime running lamp mode is not possible
while the vehicle is in motion. The following
message appears in the multifunction display:
Settings
only possible
at standstill
For safety reasons, resetting to factory settings
(
page 176) while driving will not deactivate the
daytime running lamp mode.

185 Controls in detail
Control system
Setting night security illumination
(Headlamps delayed shut-off feature)
Use this function to set whether you would
like the exterior lamps to remain on for
15 seconds during darkness after exiting
the vehicle and closing all doors.
With the headlamps delayed shut-off
feature activated and the exterior lamp
switch in positionU before the engine
is turned off, the following lamps will
switch on when the engine is turned off:

Parking lamps

Tail lamps

License plate lamps

Side marker lamps

Front fog lamps*
If after turning off the engine you do not
open a door or do not close an opened
door, the lamps will automatically switch
off after 60 seconds.
Move the selection marker with
buttonæ orç to the
Lighting
submenu.
Press buttonj ork repeatedly
until the message
Headlamp delayed
shut-off
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the headlamps delayed shut-off feature
On or Off.
Turn the exterior lamp switch to
positionU before turning off the
engine.
The headlamps delayed shut-off
feature is activated.You can temporarily deactivate the head-
lamps delayed shut-off feature:
Before exiting the vehicle, turn the
SmartKey in the starter switch to
position0.
Then turn it to position2 and back to
position0.
The headlamps delayed shut-off
feature is deactivated. It will reactivate
as soon as you reinsert the SmartKey in
the starter switch.
Vehicles with KEYLESS-GO*:
Press the KEYLESS-GO* start/stop
button (
page 41).

186 Controls in detail
Control system
Setting interior lighting delayed shut-off
Use this function to set whether you would
like the interior lighting to remain on for
10 seconds during darkness after you have
removed the SmartKey from the starter
switch.
Move the selection marker with
buttonæ orç to the
Lighting
submenu.
Press buttonj ork repeatedly
until the message
Int. light.
delayed shut-off
appears in the
multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the interior lighting delayed shut-off
feature
On or Off.Vehicle submenu
Access the
Vehicle submenu via the
Settings menu. Use the Vehicle submenu
to make general vehicle settings.
The following functions are available:Compass adjustment
This function is not available if your vehicle
is equipped with the COMAND system with
navigation module*.
Determine your location on the basis of the
following zone maps.
Zone map North America
FunctionPage
Compass adjustment186
Compass calibration187
Audio search function188
Setting automatic locking189
Limiting opening height of
tailgate*189

187 Controls in detail
Control system
Zone map South America
Press buttonæ orç to move
the selection marker to the
Vehicle
submenu.
Press buttonj ork repeatedly
until the message
Compass setting
appears in the multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç to set the
respective compass zone.
For information on how to call up the
compass, see “Compass” (
page 342).Compass calibration
This function is not available if your vehicle
is equipped with the COMAND system with
navigation module*.
In order to calibrate the compass properly,
mind the following:

Calibrate the compass in open terrain.
Nearby buildings, bridges, power lines
and large antenna masts, for example,
could impair compass calibration.

Switch off electrical consumers (e.g.
climate control, windshield wipers, or
rear window defroster).

Close all doors and the tailgate.
Start the engine (page 54).
Press buttonæ orç to move
the selection marker to the
Vehicle
submenu.
iMake sure you are in an area where you can
drive a full circle with your vehicle without dis-
turbing traffic in order to calibrate your compass.


188 Controls in detail
Control system
Press buttonj ork repeatedly
until the message
Compass Calibra-
tion
appears in the multifunction
display.
The selection marker is on setting
switched off.
Press buttonæ to set the selection
marker to
Start.
The following message appears in the
multifunction display:
Compass Calibration active
Please drive in a full circle
Drive a full circle at a vehicle speed
of between 3 mph and 6 mph
(5 km/h and 10 km/h).
When calibration was successful, the
following message appears in the
multifunction display:
Compass calibration
Completed successfully
Audio search function
Use of the Audio search function to
select a radio station (
page 171) will
enable you to start a frequency scan
(
Freq.) or select a radio station stored in
memory (
Memory).
Move the selection marker with
buttonæ orç to the
Vehicle
submenu.
Press buttonj ork repeatedly
until the message
Audio Search
function
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to select
Freq. or Memory.
iIf the message Compass calibration
Completed successfully
does not appear in
the multifunction display, drive another full
circle.
If calibration does not succeed within 3 minutes,
the message
Compass Calibration appears
in the multifunction display again. Calibrating the
compass has failed due to outside influences.
Repeat compass calibration in a different
location.


189 Controls in detail
Control system
Setting automatic locking
Use this function to activate or deactivate
the automatic central locking. With the
automatic central locking system
activated, the vehicle is centrally locked
at vehicle speeds of approximately
9mph(15km/h).
Move the selection marker with
buttonæ orç to the
Vehicle
submenu.
Press buttonj ork repeatedly
until the message
Automatic door
lock
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the automatic central locking
On or Off.Limiting opening height of tailgate*
Use this function to activate or deactivate
the limiting opening height of the tailgate.
Move the selection marker with
buttonæ orç to the
Vehicle
submenu.
Press buttonj ork repeatedly
until the message
Opening limiter
Tailgate
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the limiting opening height of the
tailgate
On or Off.Comfort submenu*
Access the
Comfort submenu via the
Settings menu. Use the Comfort submenu
to change the settings for a number of con-
venience features.
The following functions are available:
FunctionPage
Activating easy-entry/exit
feature*190
Setting fold-in function for
exterior rear view mirrors*190
