Page 351 of 561

MERCEDES-BENZ R500 2006 W251 Owners Manual 350 OperationEngine compartmentR3501Filler capR5001Filler cap

Unscrew filler cap1 from filler neck.

Add engine oil as required. Never over-
fill with oil.
Be careful not to spill any oil when addi

Page 352 of 561

MERCEDES-BENZ R500 2006 W251 Owners Manual 351 Operation
Engine compartment
Coolant level
The engine coolant is a mixture of water
and anticorrosion / antifreeze. To check
the coolant level, the vehicle must be
parked on level ground and th

Page 353 of 561

MERCEDES-BENZ R500 2006 W251 Owners Manual 352 OperationEngine compartmentWindshield / rear window washer
system and headlamp cleaning system*
The windshield washer reservoir is located
in the engine compartment.
1Cap
2Windshield washer rese

Page 354 of 561

MERCEDES-BENZ R500 2006 W251 Owners Manual 353 Operation
Tires and wheels
Tires and wheels
See an authorized Mercedes-Benz Light
Truck Center for information on tested and
recommended rims and tires for summer
and winter operation. They ca

Page 355 of 561

MERCEDES-BENZ R500 2006 W251 Owners Manual 354 OperationTires and wheelsTire care and maintenance
Regularly check your tire inflation pressure
at least once a month. For more informa-
tion on checking tire inflation pressure,
see “Recommen

Page 356 of 561

MERCEDES-BENZ R500 2006 W251 Owners Manual 355 Operation
Tires and wheels
Tread depth
Do not allow your tires to wear down too
far. Adhesion properties on wet roads are
sharply reduced at tread depths under 1/8in (3 mm).
Treadwear indicator

Page 357 of 561

MERCEDES-BENZ R500 2006 W251 Owners Manual 356 OperationTires and wheelsDirection of rotation
Unidirectional tires offer added advan-
tages, such as better hydroplaning perfor-
mance. To benefit, however, you must
make sure the tires rotate i

Page 358 of 561

MERCEDES-BENZ R500 2006 W251 Owners Manual 357 Operation
Tires and wheels
1Driver’s door B-pillar
Following is a discussion on how to work
with the information contained on the two
placards with regards to loading your vehi-
cle.Tire and L

Page 359 of 561

MERCEDES-BENZ R500 2006 W251 Owners Manual 358 OperationTires and wheelsThe placard showing the load limit informa-
tion is located on the driver’s door B-pillar.
If your vehicle is equipped with the Tire and
Loading Information placard (E

Page 360 of 561

MERCEDES-BENZ R500 2006 W251 Owners Manual 359 Operation
Tires and wheels
Placard (Example A)1Seating capacityPlacard (Example B)1Seating capacitySteps for determining correct load limit
The following steps have been developed
as required of
