light MERCEDES-BENZ S-Class 2001 W220 Comand Manual

Telephone
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings Telephone119Begin dialing:
Press the rotary/pushbutton
to confirm the “Send”
button. The “End” button will now be highlighted. The
message “Dialing” will appear.
Note:
If the list is empty, the message “No entry in list” will
appear.
Ending a call, use one of the three ways:
• Press the rotary/pushbutton
to confirm the
“End” button
• Press
• Press
. The main telephone menu is activated and the phone
number or name selected will appear.
P82.85-6073-26

120 Telephone
Introduction AudioTelephone
Navigation
Index Info Services and
system settings
Dialing from calls list
Use the rotary/pushbutton
to highlight and confirm
the “Calls” menu field in the main telephone menu.
The incoming calls memory will be activated.Turn the rotary/pushbutton
to select the desired
phone number.
Begin dialing:
Press the rotary/pushbutton (to confirm the “Send”
button). The “End” button is highlighted.
Ending a call, use one of the three ways:
• Press the rotary/pushbutton
to confirm the
“End” button
• Press
• Press
.
P82.85-6074-26

Telephone
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings Telephone121 Speed-dialing (only with COMAND)
For all memory locations
When the main telephone menu is on display enter the
memory location desired with the number keys, e.g.
. You can enter up to 2 digits.Begin dialing, use one of the two ways:
• Press the rotary/pushbutton
to confirm the
“Send” button. The “End” button will now be
highlighted.
• Press the last number key longer than
2 seconds.
Important!
If you enter “1” and press the rotary/pushbutton
,
the number stored in memory location 1 (default is
9-1-1) will be dialed.
Pressing or holding “1” longer than 2 seconds will also
initiate the call.
The 9-1-1 emergency call system is a public service.
Using it without due cause is a criminal offense.
P82.85-6075-26

124 Telephone
Introduction AudioTelephone
Navigation
Index Info Services and
system settings
Notebook
During a conversation you can enter a telephone
number in the notebook or edit an existing one.
To open the notebook:
Use the rotary/pushbutton
to highlight the “
”
symbol and press to confirm.
Then use the rotary/pushbutton
to highlight the
“Notebook” menu field and press to confirm.To enter the telephone number:
Use the number keys
through
, or press
and
.
To correct input:
• Press
briefly or use the rotary/pushbutton
to highlight the back arrow and confirm by press-
ing – the last digit will be corrected
• Press
longer than 2 seconds – the whole entry
will be corrected.
To close the notebook and store input:
Press
.
Dialing a telephone number from the notebook
To open the notebook, see information on the left.
When the telephone number in the notebook appears,
press the rotary/pushbutton
and the
symbol to
confirm.
Note:
The telephone number in the notebook can be trans-
ferred to the phone book, page 115.
P82.85-6078-26

Telephone
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings Telephone125Changing entries in the phone book
Use the rotary/pushbutton
to highlight menu field
(1) and press to confirm.
The phone book will either display the list of names
sorted alphabetically or the list of telephone numbers
sorted according to memory location.
To activate the input menu:
Use the rotary/pushbutton to highlight the desired
entry and press to confirm. Editing the phone book
Use the rotary/pushbutton
to highlight the “Phone
book” menu field in the main telephone menu and
press to confirm.
The “Phone book” selection menu will be activated.
1To change entries in the phone book, page 125
2To add an entry in the phone book, page 130
3To transfer a telephone number from the notebook,
page 131
P82.85-6079-26
3
2
1
P82.85-6067-26
3

126 Telephone
Introduction AudioTelephone
Navigation
Index Info Services and
system settings
To change a name:
4Phone book entry selected,
enter up to 20 characters
5Character list,
selection of letters, digits and special characters
6Zoom, character selected appears magnified
7Confirm the changed entry
8Deletes the entry in the phone book, page 129To correct input:
• Press
briefly or use the rotary/pushbutton
to highlight the back arropw and confirm by
pressing – the last digit will be corrected
• Press
longer than 2 seconds – the whole entry
will be corrected.
Use the rotary/pushbutton
to highlight the desired
character one after the other and press to confirm. A
character selected will be displayed magnified (6).
The name will be entered in the input line (4). The
input cursor indicates the current input position.
P82.85-6080-268
7
4
5
6

Telephone
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings Telephone127To adopt the character selected and to enter it in the
input line:
• press
or turn the rotary/pushbutton
• automatically after 2 seconds.
Select one of the options to store a name changed in the
phone book:
• Use the rotary/pushbutton
highlight the “OK”
menu field and press it to confirm.
• Press and hold down the rotary/pushbutton
to
confirm the last letter of the name.
The menu for entering telephone numbers (page 128)
will appear.
If you do not wish to save the changes:
Press
. Note:
The characters can also be selected using the numerical
keys. Each numerical key has more than one assign-
ment.
Select a character by pressing the key as listed below the
corresponding number of times. The character selected
(6) will appear magnified.
Button 1: , . – 1 : ‘ /
Button 2: A B C 2 Ä Å Æ Ç
Button 3: D E F 3 É È
Button 4: G H I 4 IJ
Button 5: J K L 5
Button 6: M N O 6 Ñ Ö Ø Œ
Button 7: P Q R S 7
Button 8: T U V 8 Ü
Button 9: W X Y Z 9
Button 0: Blank 0

128 Telephone
Introduction AudioTelephone
Navigation
Index Info Services and
system settings
Changing a telephone number:
9Current name or name previously changed (brown)
will not be displayed if there is no name entry in
the phone book for the telephone number con-
cerned.
10Input line, marked when activated
11Telephone number will be stored in the phone book
Enter the telephone number using the numerical keys
through
, or press
and
.To correct input:
• Press
briefly or use the rotary/pushbutton
to highlight the back arrow and confirm by
pressing – the last digit will be corrected
• Press
longer than 2 seconds – the whole entry
will be corrected.
To store the telephone number in the phone book:
Use the rotary/pushbutton
to highlight menu field
(11) and press to confirm.
The main telephone menu will be activated.
P82.85-6081-26
9
11
10

Telephone
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings Telephone129 Deleting an entry in the phone book
The query will appear after confirmation of the
“Delete” menu field in the input menu, page 126.12Name and telephone number of the entry to be
deleted
13Query
Note:
Positions (12) and (13) are highlighted in brown.
Use the rotary/pushbutton
to highlight the menu
field and press to confirm:
14Entry is deleted,
the main telephone menu will appear.
15The entry is not deleted,
the menu previously activated will appear.
P82.85-6082-26
1412
1513

130 Telephone
Introduction AudioTelephone
Navigation
Index Info Services and
system settings
Adding an entry to the phone book
To enter the name:
Use the rotary/pushbutton
to highlight the “Add
entry” menu field in the selection menu
(page 125) and press to confirm.
An input menu will appear.16Input line
17Confirm the name
Note:
The name will also be stored if the last letter of
name was confirmed by pressing and holding the
rotary/pushbutton
.
The menu for entering the telephone number will
be activated, page 126.
To change a name, page 126.
To correct input, page 126.
P82.85-6083-26
17
16
