440 Controls in detailTrunkClosing trunk and locking vehicle from
outside (vehicles with KEYLESS-GO*)
In vehicles with trunk opening/closing sys-
tem* and KEYLESS-GO*, you can close the
trunk and lock the vehicle simultaneously
from the outside using the KEYLESS-GO
locking/closing switch.
1KEYLESS-GO locking/closing switch
Make sure you have the SmartKey with
KEYLESS-GO with you.

Press switch1 briefly.
The vehicle is locked and the trunk
closes automatically. With the hood and all doors closed, all
turn signal lamps flash three times to
confirm locking. The locking knobs in
the doors move down. The anti-theft
alarm system is activated.
Trunk emergency release
With the emergency release button, the
trunk can be opened from inside the trunk.
1Emergency release button

Briefly press emergency release
button1.
The trunk opens.
Illumination of the emergency release but-
ton:


The button will flash for 30 minutes af-
ter opening the trunk.


The button will flash for 60 minutes af-
ter closing the trunk.
i
If the trunk lid comes into contact with an
object while closing (e.g. luggage that has been
piled too high) in the upper motion sequence, the
closing procedure is stopped and the trunk re-
opens slightly.
i
The emergency release button unlocks and
opens the trunk while the vehicle is standing still
or in motion.
i
The emergency release button does not
open the trunk if the vehicle battery is dis-
charged or disconnected.

441 Controls in detail
Power tilt/sliding sunroof
Power tilt/sliding sunroof
Opening and closing power tilt/sliding sunroofWarning!
G
When closing the tilt/sliding sunroof, make
sure that there is no danger of anyone being
harmed by the closing procedure.
If the tilt/sliding sunroof encounters an ob-
struction that blocks its path in a circum-
stance where you are closing the tilt/sliding
sunroof by moving the tilt/sliding sunroof
switch past the resistance point, or by
pressing and holding button‹on the
SmartKey, by pressing and holding the sen-
sor surface (vehicles with KEYLESS-GO*) on
the outside door handle, the automatic re-
versal function will not operate.
The opening/closing procedure of the
tilt/sliding sunroof can be immediately halt-
ed by releasing the switch or, if the switch
was moved past the resistance point and re-
leased, by moving the switch in any direc-
tion.
The tilt/sliding sunroof is made out of glass.
In the event of an accident, the glass may
shatter. This may result in an opening in the
roof.
In a vehicle rollover, occupants not wearing
their seat belts or not wearing them properly
may be thrown out of the opening. Such an
opening also presents a potential for injury
for occupants wearing their seat belts
properly as entire body parts or portions of
them may protrude from the passenger
compartment.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment can cause an accident
and/or serious personal injury.!
To avoid damaging the seals, do not trans-
port any objects with sharp edges which can
stick out of the tilt/sliding sunroof.Do not open the tilt/sliding sunroof if there is
snow or ice on the roof, as this could result in
malfunctions.
The tilt/sliding sunroof can be opened or closed
manually should an electrical malfunction occur
(
page 617).
i
When the tilt/sliding sunroof is open, reso-
nance noises may result in addition to the usual
wind noises. They are caused by minimal pres-
sure changes in the passenger compartment. To
reduce or eliminate these noises, change the po-
sition of the tilt/sliding sunroof or open a side
window slightly.
i
You can also open or close the tilt/sliding
sunroof using the SmartKey, see “Summer open-
ing feature” (
page 355) and “Convenience
closing feature” (page 356). Depending on
current position, the tilt/sliding sunroof may
also open or close when the air recirculation
button, (
page 426) is pressed and held
for 2 seconds.
i
If PRE-SAFE
® has been activated, the
tilt/sliding sunroof closes automatically until
only a small gap remains.

442 Controls in detailPower tilt/sliding sunroof1Push back to slide sunroof open
2Push forward to slide sunroof closed
3Push up to raise sunroof at rear
4Pull down to lower sunroof at rear
With the sunroof closed or tilted open, a
screen can be slid into the roof opening to
help provide shade. When sliding the sun-
roof open, the screen will also retract.
Switch on the ignition (
page 315).

To open, close, raise or lower, move the
switch to resistance point in the re-
quired direction1to4 until the
tilt/sliding sunroof has reached the de-
sired position.

Express-operation: To open, close,
raise or lower, move the switch past
the resistance point in the required
direction1to4 and release.
The tilt/sliding sunroof opens or closes
completely.

Stopping during Express-opening/
closing: Move the switch in any direc-
tion.
Synchronizing
The tilt/sliding sunroof must be synchro-
nized

after the tilt/sliding sunroof has been
closed manually (
page 617)


if the tilt/sliding sunroof can only be
opened with a jerking motion


after a malfunction

Switch on the ignition (
page 315).

Press and hold the sunroof switch in
the direction of arrow3 until the
tilt/sliding sunroof is fully raised at the
rear.
Keep holding the sunroof switch in the
direction of arrow3 for approximately
1 second.

Check the Express-operation feature
(page 442).
If the tilt/sliding sunroof opens com-
pletely, the sunroof is synchronized.
Otherwise repeat the above steps.
i
With the SmartKey in starter switch
position0 or removed from the starter switch,
the tilt/sliding sunroof can be operated


until you open the driver’s or passenger door


for up to approximately 5 minutes
i
If the movement of the tilt/sliding sunroof is
blocked during the closing procedure, the sun-
roof will stop and reopen slightly.
!
Do not open the tilt/sliding sunroof com-
pletely if it is not aligned. Otherwise you could
damage the tilt/sliding sunroof.

443 Controls in detail
Panorama roof with power tilt/sliding panel*
Panorama roof with power tilt/sliding panel*
Roller sunblinds
The roller sunblinds are designed to pro-
tect you from excessive sunlight streaming
in through the panorama roof with power
tilt/sliding panel.
The front roller sunblind only operates with
the tilt/sliding panel closed. The front and
rear roller sunblind cannot be operated in-
dividually.
Switch on the ignition (
page 315).Operating front roller sunblind
Roof panel switch1Extend front roller sunblind
2Retract front roller sunblind
Extending or retracting: Move the
roof panel switch to the resistance
point in the required direction of
arrow1 or2 until the front roller
sunblind has reached the desired posi-
tion.

Express-extending: Move the roof
panel switch past the resistance point
in direction of arrow1 and release.
The front roller sunblind extends com-
pletely.

Stopping during Express-extending:
Move the roof panel switch in any di-
rection.
Operating rear roller sunblind from
front
1Extending and retracting

Extending or retracting: Press
button1 until the rear roller sunblind
has reached the desired position.
Warning!
G
When extending/retracting the roller sun-
blinds, make sure that no one is in danger of
being injured by the closing procedure. The
extending/retracting of the roller sunblinds
can be immediately halted by releasing the
switch or, if the switch was pressed past the
resistance point and released, by pressing
the switch in any direction.
i
To change directions, you must first extend
or retract the rear roller sunblind completely.

444 Controls in detailPanorama roof with power tilt/sliding panel*Operating rear roller sunblind from rearRear door control panel1Retracting
2Extending
Extending: Press button2 on the
rocker switch until the rear roller sun-
blind has reached the desired position.

Retracting: Press button1 on the
rocker switch until the rear roller sun-
blind has reached the desired position.Opening and closing panorama roof
with power tilt/sliding panelWarning!
G
When opening or closing the tilt/sliding pan-
el, make sure that there is no danger of any-
one being harmed by the opening or closing
procedure.
The opening procedure of the tilt/sliding
panel can be immediately halted by releas-
ing the switch or, if the switch was moved
past the resistance point and released, by
moving the switch in any direction.
The closing procedure of the tilt/sliding
panel can be immediately halted by releas-
ing the switch.
The panorama roof with power tilt/sliding
panel is made out of glass. In the event of an
accident, the glass may shatter. This may re-
sult in an opening in the roof.
In a vehicle rollover, occupants not wearing
their seat belts or not wearing them properly
may be thrown out of the opening.
Such an opening also presents a potential
for injury for occupants wearing their seat
belts properly as entire body parts or por-
tions of them may protrude from the pas-
senger compartment.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children
unattended in the vehicle, or with access to
an unlocked vehicle. Unsupervised use of
vehicle equipment can cause an accident
and/or serious personal injury.!
To avoid damaging the seals, do not trans-
port any objects with sharp edges which can
stick out of the tilt/sliding panel.
Do not open the tilt/sliding panel if there is snow
or ice on the roof, as this could result in malfunc-
tions.
The tilt/sliding panel can be opened or closed
manually should an electrical malfunction occur
(
page 617).

445 Controls in detail
Panorama roof with power tilt/sliding panel*
The tilt/sliding panel only operates with
the roller sunblinds extended.
Roof panel switch1Push back to slide roof panel open
2Push forward to slide roof panel closed
3Push up to raise roof panel
4Pull down to lower roof panel
Switch on the ignition (
page 315).

To open, close, raise, or lower the
tilt/sliding panel, move the roof panel
switch to resistance point in the re-
quired direction of arrows1 to4.
Release the roof panel switch when the
tilt/sliding panel has reached the de-
sired position.

Express-opening: Move the roof panel
switch past the resistance point in di-
rection of arrow1 and release.
The tilt/sliding panel opens
completely.

Express-raising: Move the roof panel
switch past the resistance point in di-
rection of arrow3 and release.
The tilt/sliding panel raises
completely.

Stopping during Express-operation:
Move the roof panel switch in any di-
rection.
i
When the panorama roof with power
tilt/sliding panel is open, resonance noises may
result in addition to the usual wind noises. They
are caused by minimal pressure changes in the
passenger compartment. To reduce or eliminate
these noises, change the position of the panora-
ma roof with power tilt/sliding panel or open a
side window slightly.
i
You can also open or close the tilt/sliding
panel using the SmartKey, see “Summer open-
ing feature” (
page 355) and “Convenience
closing feature” (page 356).
Depending on current position, the tilt/sliding
panel may also open or close when the air recir-
culation button, in the control panel of the
climate control (
page 424), is pressed and
held for 2 seconds.
i
If the front roller sunblind is retracted while
being raised, it will extend first.
i
You cannot automatically close and lower
the panorama roof with power tilt/sliding panel.

446 Controls in detailPanorama roof with power tilt/sliding panel*Synchronizing
The tilt/sliding panel and front roller sun-
blinds must be synchronized

after the tilt/sliding panel has been
closed manually (
page 617)


after a malfunction


if the panorama roof with power
tilt/sliding panel can only be opened
with a jerking motion
Tilt/sliding panel and front roller sun-
blind

Switch on the ignition (
page 315).

Move and hold the roof panel switch in
direction of arrow2 until the front
roller sunblind is fully retracted.

Keep holding the roof panel switch in
direction of arrow2 for approximately
1 second.

Move and hold the roof panel switch in
direction of arrow1 until the front
roller sunblind is fully extended.

Move and hold the roof panel switch in
direction of arrow1 until the tilt/slid-
ing panel is slightly opened.

Move and hold the roof panel switch in
direction of arrow2 until the tilt/slid-
ing panel is fully closed.

Keep holding the roof panel switch in
direction of arrow2 for approximately
1 second.

Check the Express-open feature of the
tilt/sliding panel (
page 445).
If the tilt/sliding panel opens com-
pletely, the roof is synchronized. Other-
wise repeat the above steps.Rear roller sunblind

Switch on the ignition (
page 315).

Press button1 until the rear roller
sunblind is fully retracted.

Keep holding button1 for approxi-
mately 1 second.

447 Controls in detail
Loading and storing
Loading and storing
Roof rack*

Flip the covers upward.

Only attach the roof-rack system to the
anchorage points under the covers.
Observe manufacturer’s instructions
for installation.
Loading instructions
The total load weight including vehicle oc-
cupants and luggage/cargo should not ex-
ceed the load limit or vehicle capacity
weight as indicated on the corresponding
placard located on the driver’s door B-pillar
(page 503).
Warning!
G
Only use roof racks approved by
Mercedes-Benz for your vehicle model to
avoid damage to the vehicle.
Follow the manufacturer’s installation
instructions. Otherwise, an improperly
attached roof rack system or its load could
become detached from the vehicle.
Do not exceed the maximum roof load of
220 lb (100 kg).
Take into consideration that when the roof
rack is loaded, the handling characteristics
are different from those when operating the
vehicles without the roof rack loaded.
!
Load the roof rack in such a way that the ve-
hicle cannot be damaged while driving.
Make sure


you can fully raise tilt/sliding sunroof or the
panorama roof with tilt/sliding panel*


you can fully open the trunk
Warning!
G
Always fasten items being carried as secure-
ly as possible using cargo tie-down hooks
and fastening materials appropriate for the
weight and size of the load.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle and can cause in-
jury to vehicle occupants unless the items
are securely fastened in the vehicle.
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when transporting cargo. Put luggage or car-
go in the trunk if possible.


448 Controls in detailLoading and storingStorage compartmentsStorage compartments in the front pas-
senger compartment
Glove box
1Glove box lid release
2Unlocking glove box
3Locking glove box
The glove box can be unlocked and locked
with the mechanical key (
page 614).

Opening: Press glove box lid
release1.

Closing: Push the lid up.

Locking: Insert the mechanical key
into the glove box lock and turn it
clockwise to position3.

Unlocking: Insert the mechanical key
into the glove box lock and turn it coun-
terclockwise to position2.
Storage compartments in the front arm-
rest
1Storage tray/telephone compartment
2Storage compartment (not with rear
climate control system*)
Do not pile luggage or cargo higher than the
seat backs. Do not place anything on the
rear-window shelf.
Never drive vehicle with trunk open. Deadly
carbon monoxide (CO) gases may enter ve-
hicle interior resulting in unconsciousness
and death.Warning!
G
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when storing objects in the vehicle. Put lug-
gage or cargo in the trunk if possible. Do not
pile luggage or cargo higher than the seat
backs.
Parcel nets cannot secure hard or heavy ob-
jects.
Keep compartment lids closed. This will help
to prevent stored objects from being thrown
about and injuring vehicle occupants during

braking


vehicle maneuvers or


an accident.


449 Controls in detail
Loading and storing

Opening storage tray/telephone
compartment: Press button1 and
swing armrest to left or right side.

Opening storage compartment:
Press button2 and swing center arm-
rest upward.
Storage compartments below the front
seats

Opening: Pull tab1 upward and fold
cover2 forward.Eyeglasses compartment

Opening: Press mark1.

Closing: Swing eyeglasses compart-
ment upward until it engages.
Parcel net in front passenger footwellA small convenience parcel net is located
in the front passenger footwell. It is for
small and light items, such as road maps,
mail, etc.Warning!
G
The parcel net is intended for storing
light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
parcel net. In an accident, during hard
braking, or sudden maneuvers, they could
be injury to vehicle occupants.
The parcel net cannot protect transported
goods in the event of an accident.
