MERCEDES-BENZ S-Class 2008 W221 Comand Manual
Manufacturer: MERCEDES-BENZ, Model Year: 2008, Model line: S-Class, Model: MERCEDES-BENZ S-Class 2008 W221Pages: 801, PDF Size: 10.23 MB
Page 11 of 801
Contents
Driving abroad .............................. 567
Control and operation of
radio transmitters......................... 567
Catalytic converter ....................... 568
Emission control........................... 568
Coolant temperature .................... 569
At the gas station............................... 570
Refueling ...................................... 570
Check regularly and
before a long trip .......................... 572
Engine compartment.......................... 573
Hood ............................................ 573
Engine oil...................................... 575
Transmission fluid level ................ 578
Active Body Control* (ABC*)
fluid level ...................................... 579
Coolant level ................................ 579
Windshield washer system and
headlamp cleaning system ........... 580
Tires and wheels ................................ 582
Important guidelines .................... 582
Tire care and maintenance ........... 583
Direction of rotation ..................... 585
Loading the vehicle ...................... 585
Recommended tire
inflation pressure ......................... 590Checking tire inflation pressure ... 592
Tire labeling.................................. 598
Load identification ....................... 601
DOT, Tire Identification Number (TIN) ..
602
Maximum tire load ....................... 603
Maximum tire inflation pressure .. 603
Uniform Tire Quality Grading
Standards (U.S. vehicles) ............. 604
Tire ply material ........................... 606
Tire and loading terminology ........ 606
Rotating tires ............................... 609
Winter driving .................................... 610
Winter tires .................................. 610
Snow chains ................................. 611
Maintenance ...................................... 612
Maintenance service
indicator message ........................ 612
Calling up the maintenance
service indicator display............... 613
Resetting the maintenance
service indicator........................... 614
Vehicle care ....................................... 615
Cleaning and care of vehicle ........ 615
Practical hints................................. 627
What to do if …? ................................ 628
Lamps in instrument cluster ........ 628
Air bag off indicator lamp............. 640
Vehicle status messages in the
multifunction display.................... 642
Where will I find ...? ........................... 705
First aid kit ................................... 705
Vehicle jack, vehicle tool kit,
luggage bowl, Minispare wheel .... 705
Unlocking/locking in an emergency .. 708
Unlocking the vehicle................... 708
Locking the vehicle ...................... 709
Resetting activated head restraints ... 710
Head restraints (standard) ........... 710
Luxury head restraints* ............... 711
Replacing SmartKey batteries ........... 712
Replacing bulbs ................................. 714
Bulbs ............................................ 715
Replacing bulbs for front lamps ... 717
Replacing wiper blades ...................... 721
Placing wiper arms in
vertical position ........................... 721
Removing wiper blades ................ 722
Installing wiper blades ................. 722
Page 12 of 801
Contents
Flat tire .............................................. 723
Preparing the vehicle ................... 723
Mounting the spare wheel............ 723
Batteries ............................................ 729
Disconnecting starter battery ...... 731
Removing starter battery ............. 732
Charging battery .......................... 732
Reinstalling starter battery........... 733
Reconnecting starter battery ....... 733
Jump starting ..................................... 734
Towing the vehicle ............................. 737
Towing with front wheels raised ... 738
Towing with all wheels
on the ground............................... 739
Installing towing eye bolt ............. 740
Fuses ................................................. 741
Fuse boxes in
engine compartment .................... 742
Fuse boxes in
passenger compartment .............. 743
Emergency engine shut-down ...... 744
Technical data.................................. 745
Parts service....................................... 746
Warranty coverage ............................. 747
Loss of Service and Warranty
Information Booklet ...................... 747
Identification labels ............................ 748
Layout of poly-V-belt drive .................. 750
S 450 4MATIC, S 550 and
S 550 4MATIC............................... 750
S 63 AMG ..................................... 750
S 600 and S 65 AMG .................... 750
Engine ................................................ 751
Rims and tires .................................... 754
Same size tires ............................. 755
Mixed size tires ............................. 757
Spare wheel .................................. 759
Electrical system ................................ 760
Main dimensions and weights ............ 762
Main dimensions........................... 762
Weights ......................................... 763Fuels, coolants, lubricants, etc. .......... 764
Capacities ..................................... 764
Engine oils .................................... 769
Engine oil additives ....................... 769
Air conditioning refrigerant ........... 769
Brake fluid .................................... 769
Premium unleaded gasoline.......... 770
Fuel requirements......................... 770
Gasoline additives......................... 771
Coolants ....................................... 771
Windshield washer system and
headlamp cleaning system ........... 774
Index................................................. 775
Page 13 of 801
Page 14 of 801
13
Product information
Introduction
Product information
Please observe the following in your own
best interest:
We recommend using Genuine
Mercedes-Benz Parts as well as conversion
parts and accessories explicitly approved
by us for your vehicle model.
We have tested these parts to determine
their reliability, safety and special suitabili-
ty for Mercedes-Benz vehicles.We are unable to make an assessment for
other products and therefore cannot be
held responsible for them, even if in indi-
vidual cases an official approval or authori-
zation by governmental or other agencies
should exist. Use of such parts and acces-
sories could adversely affect the safety,
performance or reliability of your vehicle.
Please do not use them.Genuine Mercedes-Benz Parts as well as
conversion parts and accessories ap-
proved by us are available at any autho-
rized Mercedes-Benz Center where you will
receive comprehensive information, also
on permissible technical modifications,
and where proper installation will be per-
formed.
Page 15 of 801
14 IntroductionOperator’s ManualThis Operator’s Manual contains a great
deal of useful information. We urge you to
read it carefully and familiarize yourself
with the vehicle before driving.
For your own safety and longer service life
of the vehicle, we urge you to follow the in-
structions and warnings contained in this
manual. Ignoring them could result in dam-
age to the vehicle or personal injury to you
or others. Vehicle damage caused by fail-
ure to follow instructions is not covered by
the Mercedes-Benz Limited Warranty.
Your vehicle may have some or all of the
equipment described in this manual.
Therefore, you may find explanations for
optional equipment not installed in your
vehicle. If you have any questions about
the operation of any equipment, any autho-
rized Mercedes-Benz Center will be glad to
demonstrate the proper procedures.We continuously strive to improve our
product, and ask for your understanding
that we reserve the right to make changes
in design and equipment. Therefore, infor-
mation, illustrations and descriptions in
this Operator’s Manual might differ from
your vehicle.
Optional equipment is also described in
this manual, including operating instruc-
tions wherever necessary. Since they are
special-order items, the descriptions and
illustrations herein may vary slightly from
the actual equipment of your vehicle.
If there are any equipment details that are
not shown or described in this Operator’s
Manual, any authorized Mercedes-Benz
C e n t e r w i l l b e g l a d t o i n f o r m y o u o f c o r r e c t
care and operating procedures. The Oper-
ator’s Manual and Maintenance Booklet
are important documents and should be
kept with the vehicle.
Service and warranty information
The Service and Warranty Information
Booklet contains detailed information
about the warranties covering your
Mercedes-Benz, including:
New Vehicle Limited Warranty
Emission System Warranty
Emission Performance Warranty
California, Maine, Massachusetts, and
Vermont Emission Control System
Warranty
(California, Maine, Massachusetts, and
Vermont only)
State Warranty Enforcement Laws
(Lemon Laws)
Page 16 of 801
15 Introduction
Operator’s Manual
Important notice for California retail
buyers and lessees of Mercedes-Benz automobiles
Under California law you may be entitled to
a replacement of your vehicle or a refund
of the purchase price or lease price, if
Mercedes-Benz USA, LLC and/or its au-
thorized repair or service facilities fail to fix
one or more substantial defects or mal-
functions in the vehicle that are covered by
its express warranty after a reasonable
number of repair attempts. During the pe-
riod of 18 months from original delivery of
the vehicle or the accumulation of
18 000 miles (approximately 29 000 km)
on the odometer of the vehicle, whichever
occurs first, a reasonable number of repair
attempts is presumed for a retail buyer or
lessee if one or more of the following oc-
curs: (1) the same substantial defect or mal-
function results in a condition that is
likely to cause death or serious bodily
injury if the vehicle is driven, that de-
fect or malfunction has been subject to
repair two or more times, and you have
directly notified Mercedes-Benz USA,
LLC in writing of the need for its repair,
(2) the same substantial defect or mal-
function of a less serious nature than
category (1) has been subject to repair
four or more times and you have direct-
ly notified us in writing of the need for
its repair, or
(3) the vehicle is out of service by reason
of repair of the same or different sub-
stantial defects or malfunctions for a
cumulative total of more than
30 calendar days.
Written notification should not be sent to a
dealer, it should be addressed to:
Mercedes-Benz USA, LLC
Customer Assistance Center
One Mercedes Drive
Montvale, NJ 07645-0350
Maintenance
The Maintenance Booklet describes all the
necessary maintenance work which should
be performed at regular intervals.
Always have the Maintenance Booklet with
you when you take the vehicle to an autho-
rized Mercedes-Benz Center for service.
The service advisor will record each ser-
vice in the booklet for you.Roadside Assistance
The Mercedes-Benz Roadside Assistance
Program provides factory trained technical
help in the event of a breakdown. Calls to
the toll-free Roadside Assistance number
1-800-FOR-MERCedes (in the USA)
1-800-387-0100 (in Canada)
will be answered by Mercedes-Benz
Customer Assistance Representatives
24 hours a day, 365 days a year.
Page 17 of 801
16 IntroductionOperator’s ManualFor additional information refer to the
Mercedes-Benz Roadside Assistance Pro-
gram brochure (in the USA) or the Road-
side Assistance section of the Service &
Warranty Information booklet (in Canada)
in your vehicle literature portfolio.Change of address or ownership
If you change your address, be sure to
send in the “Change of Address Notice”
found in the Service and Warranty Informa-
tion Booklet, or simply call the
Mercedes-Benz Customer Assistance
Center (in the USA) at
1-800-FOR-MERCedes, or Customer
Service (in Canada) at 1-800-387-0100.
This will assist us in contacting you in a
timely manner should the need arise.
If you sell your Mercedes, please leave all
literature with the vehicle to make it avail-
able to the next operator.If you bought this vehicle used, be sure to
send in the “Notice of Purchase of Used
Car” found in the Service and Warranty In-
formation Booklet, or call the
Mercedes-Benz Customer Assistance Cen-
ter (in the USA) at 1-800-FOR-MERCedes,
or Customer Service (in Canada) at
1-800-387-0100.
Operating your vehicle outside the USA
or Canada
If you plan to operate your vehicle in for-
eign countries, please be aware that:
service facilities or replacement parts
may not be readily available,
unleaded gasoline for vehicles with cat-
alytic converters may not be available;
the use of leaded fuels will damage the
catalysts,
gasoline may have a considerably low-
er octane rating, and improper fuel can
cause engine damage.Certain Mercedes-Benz models are avail-
able for delivery in Europe under our Euro-
pean Delivery Program. For details, consult
an authorized Mercedes-Benz Center or
write to:
In the USA:
Mercedes-Benz USA, LLC
European Delivery Department
One Mercedes Drive
Montvale, NJ 07645-0350
In Canada:
Mercedes-Benz Canada, Inc.
European Delivery Department
98 Vanderhoof Avenue
Toronto, Ontario M4G 4C9
Page 18 of 801
17 Introduction
Where to find it
Where to find it
This Operator’s Manual is designed to pro-
vide comprehensive support information
for you, the vehicle operator. Each section
has its own reference color.At a glance
Here you will find an overview of your vehi-
cle’s interior and exterior main features.Safety and Security
Here you will find descriptions of the safety
and security features of your vehicle.Control systems
Here you will find detailed information
about the operation of the COMAND sys-
tem, instrument cluster control system
and Voice Control.
Controls in detail
Here you will find detailed information
about the equipment installed in your vehi-
cle. This section also describes technical
innovations.Operation
Here you will find all the information you
need for the proper operation of your vehi-
cle.Practical hints
This section provides fast assistance for
dealing with problems you may encounter.
Technical data
All important technical data for your vehi-
cle can be found in this section.Indexes
The table of contents and the index are de-
signed to help you find information quickly
and easily.
The following publications are part of your
vehicle documentation:
this Operator’s Manual
the Maintenance Booklet
Separate operating instructions will be
provided as required depending on the
equipment options installed in your vehi-
cle.
Page 19 of 801
18 IntroductionSymbolsTrademarks:
Bluetooth
® is a registered trademark of
of Bluetooth SIG Inc.
ESP
® and PRE-SAFE
® are registered
trademark of DaimlerChrysler.
HomeLink
® is a registered trademark
of Prince, a Johnson Controls
Company.
LOGIC7
® is a registered trademark of
Harman International Industries, Incor-
porated.
SIRIUS and related marks are trade-
marks of SIRIUS Satellite Radio Inc.The following symbols are found in this
Operator’s Manual:
* Optional equipment is identified
with an asterisk. Since standard
equipment varies between models,
the descriptions and illustrations in
this manual may differ slightly from
the actual equipment of your vehi-
cle.
This symbol points to instructions for
you to follow.
A number of these symbols appearing
in succession indicates a multiple-step
procedure.
page This symbol tells you where to
look for further information on a
topic.
This continuation symbol marks
a warning which is continued on
the next page.
This continuation symbol marks
a procedure which is continued
on the next page.
-> This symbol is used to indicate
cross-references to term defini-
tions.
DisplayWords appearing in the multi-
function display and COMAND
display are printed in the type
shown here.
Warning!
G
Warning notices draw your attention to haz-
ards that may endanger your health or life,
or the health or life of others.!
Highlights hazards that may result in dam-
age to your vehicle.
i
Helpful hints or further information you may
find useful.
Page 20 of 801
19 Introduction
Operating safety
Operating safety
Proper use of the vehicle
Proper use of the vehicle requires that you
are familiar with the following information
and rules:
the safety precautions in this manual
the “Technical data” section in this
manual
traffic rules and regulations
motor vehicle laws and safety stan-
dards
Warning!
G
Work improperly carried out on electronic
components and associated software could
cause them to cease functioning. Because
the vehicle’s electronic components are in-
terconnected, any modifications made may
produce an undesired effect on other sys-
tems. Electronic malfunctions could seri-
ously impair the operating safety of your
vehicle.
Contact an authorized Mercedes-Benz Cen-
ter for repairs or modifications to electronic
components.
Other improper work or modifications on the
vehicle could also have a negative impact on
the operating safety of the vehicle.
Some safety systems only function while the
engine is running. You should therefore nev-
er turn off the engine while driving.
Warning!
G
Heavy blows against the vehicle underbody
or tires/wheels, for example when running
over an obstacle, road debris or a pothole,
may cause serious damage and impair the
o per at i ng s a fet y of yo ur veh ic l e. I f y ou f ee l a
sudden significant vibration or ride distur-
bance, or you suspect that damage to your
vehicle has occurred, you should turn on
your hazard warning flashers, carefully slow
down, and drive with caution to an area
which is a safe distance from the road.
Inspect the vehicle underbody and
tires/wheels for possible damage. If the ve-
hicle appears unsafe, have it towed to the
nearest authorized Mercedes-Benz Center
or other qualified maintenance or repair fa-
cility for further inspection or repairs.
Warning!
G
Various warning labels are attached to your
vehicle. These warning labels are intended
to make you and others aware of various
risks. You should not remove any of these
warning labels unless explicitly instructed to
do so by information on the label itself. Re-
moval of any of these labels may cause you
and others to be unaware of certain risks
which may result in an accident and/or per-
sonal injury.
