MERCEDES-BENZ S-Class 2008 W221 Comand Manual
Manufacturer: MERCEDES-BENZ, Model Year: 2008, Model line: S-Class, Model: MERCEDES-BENZ S-Class 2008 W221Pages: 801, PDF Size: 10.23 MB
Page 541 of 801
540 Controls in detailUseful features
When the mobile phone is inserted in the
cradle, you can operate the telephone us-
ing the following devices:
mobile phone keypad
COMAND telephone keypad
(page 144)
buttonss andt on the multi-
function steering wheel (
page 288)
Voice Control (
page 313)
Bluetooth
® headset (
page 157)
Please note that these functions are only
available with Mercedes-Benz approved
mobile phones. Please contact an autho-
rized Mercedes-Benz Center for informa-
tion on features available for your mobile
phone of choice.
Open telephone compartment
(page 527).Inserting mobile phone in mobile phone
cradle
Once the mobile phone has been inserted
in the mobile phone cradle, you have to
use the hands-free device or Bluetooth
headset to respond during phone calls.
If applicable, remove the cover for the
external antenna connection from the
back of the mobile phone and store it in
a s a f e p l a c e . B e s u r e t o c o m p l y w i t h t h e
mobile phone’s operating instructions,
as well.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.i
Various mobile phone cradles can be in-
stalled in the front center armrest, see separate
installation instructions for the mobile phone
cradle. These mobile phone cradles can be ob-
tained from an authorized Mercedes-Benz Cen-
ter.
The functions and services available to you while
using the mobile phone depend on your service
provider and the type of mobile phone you are
using. See also separate operating manual for in-
structions on how to use your mobile phone.
i
The roof cargo container* may impair mo-
bile phone reception. In an emergency, remove
the mobile phone from the mobile phone cradle
to make a call.
!
Do not try to remove the mobile phone along
with the cradle. You could otherwise damage the
mobile phone cradle.
Page 542 of 801
541 Controls in detail
Useful features
Example illustration1Insert the mobile phone
2Connector contact
3Mobile phone cradle
Slide the lower end of the mobile phone
into connector contact 2 on
cradle3.
Push the top of the mobile phone in di-
rection of arrow 1, until the lug on the
mobile phone release button engages.
The mobile phone is connected to the
network via the external antenna. The mobile phone is linked to the
hands-free device and the multifunc-
tion steering wheel.
The battery is charged depending on its
charge status and the position of the
SmartKey in the starter switch. The
charge procedure will be indicated in
the mobile phone’s display.
You can place or receive phone calls. You
can control other functions of the mobile
phone via the COMAND (
page 141),
instrument cluster control system
(
page 299) or Voice Control
(page 313). Removing mobile phone from mobile
phone cradle
Example illustration1Release catch for mobile phone
2Mobile phone cradle
Press release catch in direction of
arrow1 and take mobile phone out of
mobile phone cradle2.
i
When you take the SmartKey or SmartKey
with KEYLESS-GO* out of the starter switch, the
mobile phone remains switched on for approxi-
mately 10 minutes. If you place or receive a call
during this time, the mobile phone switches off
10 minutes after the call has been completed.
i
When using a flip-style mobile phone, open
flip top before removing from the cradle while a
call is connected. Otherwise, the call will be dis-
connected.
Page 543 of 801
542 Controls in detailUseful featuresChanging mobile phone cradle
If you require a different cradle for your
mobile phone, remove the present cradle
before installing a new one.
Removing an existing mobile phone
cradleExample illustration1To release the mobile phone cradle
2To remove the mobile phone cradle
3Mobile phone cradle
Press release button in direction of
arrow1 and take mobile phone
cradle3 out in direction of arrow2.
Installing a different mobile phone
cradle
Example illustration1Contact plate
2Recesses
3Mobile phone cradle
Insert mobile phone cradle3 into
recesses2 of contact plate1.
Push mobile phone cradle3 forward
until it engages.
Tele Aid
The Tele Aid system
(Tele
matic A
larm I
dentification on D
e-
mand)
The Tele Aid system consists of three
types of response:
automatic and manual emergency
Roadside Assistance, and
information
!
The initial activation of the Tele Aid system
may only be performed by completing the sub-
scriber agreement and placing an acquaintance
call using the Information button¡. Failure
to complete either of these steps will result in a
system that is not activated.
If you have any questions regarding activation,
please call the Response Center at
1-800-756-9018 (in the USA) or
1-888-923-8367 (in Canada).
Page 544 of 801
543 Controls in detail
Useful features
The Tele Aid system is operational provid-
ing that the vehicle’s battery is charged,
properly connected, not damaged and mo-
bile phone and GPS coverage are available.
The speaker volume of a Tele Aid call can
be adjusted when using the volume control
on the multifunction steering wheel. To
raise, press buttonæ and to lower,
press buttonç or use the COMAND
volume thumbwheel , on the lower
part of the front center console
(page 98).
To activate, press the SOS button, the
Roadside Assistance button• or
the Information button¡, depend-
ing on the type of response required.Shortly after the completion of your
Tele Aid acquaintance call, you will receive
a user ID and password. By visiting
www.mbusa.com and selecting “Tele Aid”
(USA only), you will have access to account
information, remote door unlock and
more.
System self-check
Initially, after switching on the ignition,
malfunctions are detected and indicated.
If a malfunction is detected, the indicator
lamps in the SOS button, the Roadside As-
sistance button• and the Information
button¡ stay on longer than
10 seconds or do not come on. The mes-
sage “Tele Aid Not Activated” or “Tele Aid
Inoperative” appears in the multifunction
display.
i
The Tele Aid system utilizes the mobile
phone network for communication and the GPS
(Global Positioning System) satellites for vehicle
location. If either of these signals are unavail-
able, the Tele Aid system may not function and if
this occurs, assistance must be summoned by
other means.
i
The SOS button is located above the interior
rear view mirror (
page 545).
The Roadside Assistance button• and the
Information button¡ are located below the
center armrest cover (page 546).
Warning!
G
If the indicator lamps in the SOS button, in
the Roadside Assistance button•
and/or in the Information button¡ do
not come on during the system self-check,
or if any of these indicators remain illuminat-
ed continuously in red and/or the message
“Tele Aid Not Activated” or “Tele Aid Inoper-
ative” is displayed in the multifunction dis-
play after the system self-check, a
malfunction in the system has been detect-
ed.
If a malfunction is indicated as outlined
above, the system may not operate as ex-
pected. Have the system checked at the
nearest Mercedes-Benz Center as soon as
possible.
Page 545 of 801
544 Controls in detailUseful featuresEmergency calls
An emergency call is initiated
automatically following an accident in
which the emergency tensioning devices
(ETDs) or air bags deploy.
An emergency call can also be initiated
manually by opening the cover next to the
interior rear view mirror labeled SOS, then
briefly pressing the button located under
the cover. For instructions on initiating an
emergency call manually (
page 545).
Once the emergency call is in progress, the
indicator lamp in the SOS button will begin
to flash. The message:
“Connecting Call” appears in the multi-
function display
“Emergency Call Activated” appears in
the COMAND display
and the audio system is muted. When the
connection is established, the message:
“Call Connected” appears in the multi-
function display
“Emergency Call Activated” appears in
the COMAND display
All information relevant to the emergency,
such as the location of the vehicle (deter-
mined by the GPS satellite location sys-
tem), vehicle model, identification number
and color are generated.
A voice connection between the Response
Center and the occupants of the vehicle
will be established automatically soon af-
ter the emergency call has been initiated.
The Response Center will attempt to deter-
mine more precisely the nature of the acci-
dent provided they can speak to an
occupant of the vehicle.The Tele Aid system is available if
it has been activated and is operation-
al. Activation requires a subscription
for monitoring services, connection,
and cellular air time
the relevant monitoring service and
GPS coverage are available and pass
the information on to the Response
Center
there is sufficient voltage in the vehicle
batteries
i
During the emergency call message “Emer-
gency Call Activated” is displayed, operation
from COMAND is not possible. The automatic cli-
mate control can be still adjusted using the
switches on the climate control panel.
i
If no vehicle occupant responds, an ambu-
lance will be sent to the vehicle immediately.
i
Location of the vehicle on a map is only pos-
sible if the vehicle is able to receive signals from
the GPS satellite network and pass the informa-
tion on to the Response Center.Warning!
G
If the indicator lamp in the SOS button is
flashing continuously and there was no
voice connection to the Response Center
established, then the Tele Aid system could
not initiate an emergency call (e.g. the rele-
vant mobile phone network is not available).
Page 546 of 801
545 Controls in detail
Useful features
Initiating an emergency call manually
1SOS button
2Cover
Briefly press button on cover2 to
open.
Cover 2 will open.
Press SOS button1 (for longer than
2 seconds).
The indicator lamp in SOS button1
will flash until the emergency call is
concluded.
Wait for a voice connection to the
Response Center.
Close cover2 after the emergency
call is concluded.
The message:
“Call Failed” appears in the multifunc-
tion display for approximately
10 seconds.
A pop-up window with the message:
“Call could not be connected! Please dial
911 directly using the mobile telephone
keypad.” appears in the COMAND dis-
play. Confirm the message pressing
n
(
page 90).
Should this occur, assistance must be sum-
moned by other means.
i
During the emergency call the mobile phone
is switched off automatically and must be
switched back on to make a call.
i
The roof cargo container* may impair mo-
bile phone reception. In an emergency, remove
the mobile phone from the mobile phone cradle
(
page 539) to make a call.
i
The “911” emergency call system is a public
service. Using it without due cause is a criminal
offense.
Warning!
G
If you feel at any way in jeopardy when in the
vehicle (e.g. smoke or fire in the vehicle, ve-
hicle in a dangerous road location), please
do not wait for voice contact after you have
pressed the emergency button. Carefully
leave the vehicle and move to a safe loca-
tion. The Response Center will automatically
contact local emergency officials with the
vehicle’s approximate location if they
receive an automatic SOS signal and cannot
make voice contact with the vehicle occu-
pants.
Page 547 of 801
546 Controls in detailUseful featuresRoadside Assistance button• and
Information button¡
The Roadside Assistance button• and
the Information button¡ are located in
the storage compartment below the front
armrest (
page 527).
1Information button¡
2Roadside Assistance button•Roadside Assistance button•
Press and hold Roadside Assistance
button • (for longer than
2 seconds).
A call to a Mercedes-Benz Roadside As-
sistance dispatcher will be initiated.
The button will flash while the call is in
progress. The message:
“Connecting Call” appears in the
multifunction display
“Roadside Assistance Activated”
appears in the COMAND display
and the audio system is muted.
When the connection is established, the
message:
“Call Connected” appears in the multi-
function display
“Roadside Assistance Activated”
appears in the COMAND display The Tele Aid system will transmit data gen-
erating the vehicle identification number,
model, color and location (subject to avail-
ability of cellular and GPS signals).
A voice connection between the Roadside
Assistance dispatcher and the occupants
of the vehicle will be established.
Describe the nature of the need for as-
sistance.
The Mercedes-Benz Roadside Assistance
dispatcher will either dispatch a qualified
Mercedes-Benz technician or arrange to
tow your vehicle to the nearest authorized
Mercedes-Benz Center. For services such
as labor and/or towing, charges may ap-
ply. Refer to the Roadside Assistance Man-
ual for more information.
These programs are only available in the
USA:
Sign and Drive services: Services such
as jump start, a few gallons of fuel or
the replacement of a flat tire with the
vehicle spare tire are obtainable.
Page 548 of 801
547 Controls in detail
Useful features
Information button¡
Press and hold Information button
¡ (for longer than 2 seconds).
A call to the Customer Assistance Cen-
ter will be initiated. The button will
flash while the call is in progress. The
message:
“Connecting Call” appears in the
multifunction display
“Information Call Activated” ap-
pears in the COMAND display
and the audio system is muted.
When the connection is established, the
message:
“Call Connected” appears in the multi-
function display
“Information Call Activated” appears in
the COMAND display
The Tele Aid system will transmit data gen-
erating the vehicle identification number,
model, color and location (subject to avail-
ability of cellular and GPS signals).A voice connection between the Customer
Assistance Center representative and the
occupants of the vehicle will be estab-
lished. Information regarding the operation
of your vehicle, the nearest authorized
Mercedes-Benz Center or Mercedes-Benz
USA products and services is available to
you.
For more details concerning the Tele Aid
system, please visit www.mbusa.com and
use your ID and password (sent to you sep-
arately) to learn more (USA only).
i
The indicator lamp in the Roadside Assis-
tance button• remains illuminated in red for
approximately 10 seconds during the system
self-check after switching on the ignition (togeth-
er with the SOS button and the Information
button¡).
See system self-check (
page 543) if the indi-
cator lamp does not come on in red or stays on
longer than approximately 10 seconds.
If the indicator lamp in the Roadside Assistance
button• is flashing continuously and no
voice connection to the Response Center was
established, the Tele Aid system could not ini-
tiate a Roadside Assistance call (e.g. the relevant
mobile phone network is not available). The mes-
sage:
“Call Failed” appears in the multifunction
display for approximately 10 seconds
“Call could not be connected!” appears in
the COMAND display. Confirm the message
pressing
n
(page 90).
Roadside Assistance calls can be terminated us-
ing button t on the multifunction steering
wheel or COMAND (page 141).
i
The indicator lamp on the Information
button¡ remains illuminated in red for ap-
proximately 10 seconds during the system
self-check after switching on the ignition (togeth-
er with the SOS button and the Roadside Assis-
tance button•).
See system self-check (
page 543) if the indi-
cator lamp does not come on in red or stays on
longer than approximately 10 seconds.
If the indicator lamp in the Information
button¡ is flashing continuously and no
voice connection to the Response Center was
established, then the Tele Aid system could not
initiate an Information call (e.g. the relevant
Page 549 of 801
548 Controls in detailUseful features
Destination Download to the COMAND
System
Destination Download allows you access
to a database of over 10,000,000 points of
interest (POIs) that can be downloaded to
your vehicle’s navigation system. If you
know the destination the address can be
downloaded. Or if you are unsure of your
destination you can be provided with
points of interests near your location.
The Response Center can transmit desti-
nation data to the COMAND during the
connection with the Roadside Assistance
or Customer Assistance Center.
The transmitted data can contain address
details for a Mercedes-Benz Center or POIs
(points of interest).Route guidance
A prompt appears for confirmation if route
guidance to the address is to be started.
Slide rmq or rotate ymz to select
“Yes” menu item and confirm by
pressingn.
The system starts the route calculation
and subsequently the route guidance
to the defined address (
page 188).
Call priority
If other service calls such as a Roadside
Assistance call or Information call are ac-
tive, an emergency call is still possible. In
this case, the emergency call will take pri-
ority and override all other active calls.
mobile phone network is not available). The mes-
sage:
“Call Failed” appears in the multifunction
display for approximately 10 seconds
“Call could not be connected!” appears in
the COMAND display. Confirm the message
pressing n (
page 90).
Information calls can be terminated using button
t on the multifunction steering wheel or
COMAND (
page 141).
!
If the indicator lamps do not start flashing
after you press one of the buttons or remain illu-
minated (in red) at any time, the Tele Aid system
has detected a fault or the service is not current-
ly activated, and may not initiate a call. Contact
an authorized Mercedes-Benz Center and have
the system checked or contact the Response
Center at 1-800-756-9018 (in the USA) or
1-888-923-8367 (in Canada) as soon as possi-
ble.
i
The components and operating principles of
COMAND can be found on (
page 87).
i
If you select “No”, you can save the address
in your address book (
page 167).
i
The destination download feature is avail-
able if the relevant mobile phone network is
available and data connection is possible.
Page 550 of 801
549 Controls in detail
Useful features
Remote door unlock
In case you have locked your vehicle unin-
tentionally (e.g. SmartKey inside vehicle),
and the reserve SmartKey is not handy:
Contact the Mercedes-Benz Response
Center at 1-800-756-9018 (in the USA)
or 1-888-923-8367 (in Canada).
You will be asked to provide your pass-
word which you provided when you
completed the subscriber agreement.
or
Contact the Tele Aid web page via In-
ternet using the ID and password sent
to you shortly after the completion of
your acquaintance call.
Then return to your vehicle and pull the
trunk lid handle for a minimum of
20 seconds until the SOS button be-
gins to flash.
The message: “Connecting Call” ap-
pears in the multifunction display and
the SOS button is flashing.
The Response Center will then unlock
your vehicle with the remote door un-
locking feature.
i
The indicator lamp in the respective button
flashes until the call is concluded. Calls can only
be terminated by a Response Center or Custom-
er Assistance Center representative except
Roadside Assistance and Information calls,
which can also be terminated by pressing
buttont on the multifunction steering wheel
or COMAND (
page 141).
!
If the indicator lamp continues to flash or
the system does not terminate the call at all,
contact the Response Center at
1-800-756-9018 (in the USA) or
1-888-923-8367 (in Canada), or Mercedes-Benz
Customer Assistance at 1-800-FOR-MERCedes
(1-800-367-6372) in the USA or Customer Ser-
vice at 1-800-387-0100 in Canada.
i
When a Tele Aid call has been initiated, the
audio system is muted. The optional mobile
phone (if installed) switches off. If you must use
this phone, the vehicle must be parked. Unplug
the telephone, switch it on and place the call.
The COMAND navigation system (if engaged) will
continue to run. The multifunction display in the
instrument cluster is available for use, but spo-
ken commands are not available.
i
You can exit Roadside Assistance and/ or
the information display during an active connec-
tion and call up the COMAND application last se-
lected. To do so, select “Back”. Meanwhile,
mute remains active (
page 87).
i
The remote door unlock feature is available
if the relevant mobile phone network is available
and data connection is possible.
The SOS button will flash and the message:
“Connecting Call” appears in the multifunction
display to indicate receipt of the door unlock
command.
Once the vehicle is unlocked, a Response Center
specialist might attempt to establish voice con-
tact with the vehicle occupants.
If the trunk lid handle was pulled for more than
20 seconds before door unlock authorization
was received by the Response Center, you must
wait 15 minutes before pulling the trunk lid han-
dle again.
