609 Operation
Tires and wheels
Uniform Tire Quality Grading Standards
A tire information system that provides
consumers with ratings for a tire’s traction,
temperature and treadwear. Ratings are
determined by tire manufacturers using
government testing procedures. The
ratings are molded into the sidewall of the
tire.
Vehicle maximum load on the tire
Load on an individual tire that is
determined by distributing to each axle its
share of the maximum loaded vehicle
weight and dividing it by two.Rotating tiresTire rotation can be performed on vehicles
with tires of the same dimension all
around. If your vehicle is equipped with
tires of the same dimension all around,
tires can be rotated, observing a
front-to-rear rotation pattern that will
maintain the intended rotation (spinning)
direction of the tire (
page 585).
In some cases, such as when your vehicle
is equipped with mixed-size tires (different
tire dimension front vs. rear), tire rotation
is not possible.
If applicable to your vehicle’s tire configu-
ration, tires can be rotated according to
the tire manufacturer’s recommended in-
tervals in the tire manufacturer’s warranty
pamphlet located in your vehicle literature
portfolio. If none is available, tires should
be rotated every 3 000 to 6 000 miles
(5 000 to 10 000 km), or sooner if neces-
sary, according to the degree of tire wear.
The same rotation (spinning) direction
must be maintained (page 585). Rotate tires before the characteristic tire
wear pattern becomes visible (shoulder
wear on front tires and tread center wear
on rear tires).
Thoroughly clean the mounting face of
wheels and brake disks, i.e. the inner side
of the wheels/tires, during each rotation.
Check for and ensure proper tire inflation
pressure.
For information on wheel change, see the
“Practical hints” section (
page 723).
Warning!
G
Rotate front and rear wheels only if the tires
are of the same dimension.
If your vehicle is equipped with mixed-size
tires (different tire dimensions front vs.
rear), tire rotation is not possible.
Warning!
G
Have the tightening torque checked after
changing a wheel. Wheels could become
loose if not tightened with a torque of
110 lb-ft (150 Nm).
Only use Genuine Mercedes-Benz wheel
bolts specified for your vehicle’s rims.

795 Index
Tilt/sliding sunroof see Power tilt/sliding
sunroof
Time
Setting (COMAND) 259
TIN 608
Tire and Loading Information
Placard 586
Tire Identification Number see TIN
Tires 582
Advanced Tire Pressure Monitoring
System (Advanced TPMS)* 593
And Rims 754
And Wheels 582
Care and maintenance 583
Chains 611
Checking inflation pressure electroni-
cally with Advanced Tire Pressure
Monitoring System (Advanced
TPMS) 593
Cleaning 584
Cold tire inflation pressure 606
Combination low tire pressure
malfunction telltale 29, 638
Direction of rotation 585
Driving instructions 563Important notes on tire inflation
pressure 591
Inflation pressure 590
Information placard 586
Inspection 583
Load rating 599, 608
Load rating, Maximum 603, 607
Minispare wheel 707
Ply composition and
material used 608
Problems under-/overinflation 590
Retreads 582
Rotating 609
Service life 583
Sizes 754
Snow 610
Spare wheel 759
Speed rating 564, 600, 608
Storing 584
Temperature 591, 605
Terminology 606
Total load limit 608
TPMS malfunction telltale 638
TPMS* malfunction telltale 29
Traction 564, 608Tread depth 584
Tread depth, Winter 610
Treadwear indicators 608
Vehicle maximum load on 609
Wear pattern 609
Winter 610
Tools 705
Top tether
Children in the vehicle 62
Towing eye bolt (vehicle tool kit) 705,
740
Towing the vehicle 737
Tow-start 734, 737
Traction 564, 605, 608
Transmission see Automatic transmission
Traveling abroad 567
Tread 608
Tread depth, Tires 584
Tread depth, Winter tires 610
Treadwear indicators 608
Trip odometer 291
Resetting 292
Troubleshooting
Voice Control 352
