MERCEDES-BENZ S550 2007 W221 Owner's Manual

450 Controls in detailLoading and storingStorage compartments in rear passen-
ger compartment
Armrest with integrated storage com-
partmentVehicles without control panel* in rear arm-
rest
Opening: Pull release catch1 and
swing the cover upward.
Vehicles with control panel* in rear armrest
Opening: Press button1 and swing
the cover upward.Storage compartment between rear
seats
Vehicles without rear center seat*
Opening: Pull handle1 backward in
direction of arrow.
!
Before storing the armrest in the backrest,
close the storage compartment cover.
!
Do not sit on or lean your body weight
against the armrest when it is folded down, as
you could otherwise damage it.

451 Controls in detail
Loading and storing
Rear storage box
Opening: Fold down rear center arm-
rest and swing down cover1.Ruffled storage pockets
Ruffled storage pockets 1 are located on
the back of the front seats.
!
Do not sit on or lean your body weight
against the armrest when it is folded down, as
you could otherwise damage it.
i
When the rear seats are in their basic posi-
tion, you can open the cover more easily.
Warning!
G
Do not place objects with a combined
weight of more than 4.4 lbs (2 kg) into the
ruffled storage pocket. Otherwise, the Occu-
pant Classification System OCS (
page 50)
may not be able to properly approximate the
occupant weight category.
The ruffled storage pocket is intended for
storing light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
ruffled storage pocket. In an accident, dur-
i n g h a r d b r a k i n g , o r s u d d e n m a n e u v e r s , t h e y
could be thrown around inside the vehicle
and cause injury to vehicle occupants.
The ruffled storage pocket cannot protect
transported goods in the event of an acci-
dent.

452 Controls in detailLoading and storingCup holders
Cup holder in front center console
1Mark
2Handle

Opening: Press mark1 on the front.

Closing: Fold cover in until it engages.

Removing: Pull cup holder out by pull-
ing silver handle2 upward in direction
of arrow.

Inserting: Press downward until it en-
gages. While doing so, make sure that
the word “Front” is in the proper instal-
lation position.
Cup holder in rear
Vehicles without control panel* in rear arm-
rest1Compartment for cup holder
Opening: Press mark1 on the front.
Warning!
G
In order to help prevent spilling liquids on
vehicle occupants and/or vehicle equip-
ment, only use containers that fit into the
cup holder. Use lids on open containers and
do not fill containers to a height where the
contents, especially hot liquids, could spill
during braking, vehicle maneuvers, or in an
accident. Liquids spilled on vehicle occu-
pants may cause serious personal injury.
Liquids spilled on vehicle equipment may
cause damage not covered by the
Mercedes-Benz Limited Warranty.
When not in use, keep the cup holders
closed. An open cup holder may cause injury
to you or others when contacted during
braking, vehicle maneuvers, or in an acci-
dent.
Keep in mind that objects placed in the cup
holder may come loose during braking, vehi-
cle maneuvers, or in an accident and be
thrown around in the vehicle interior.
Objects thrown around in the vehicle interi-
or may cause an accident and/or serious
personal injury.
i
You can remove the cup holder to clean it.
Only clean it using clear, lukewarm water.

453 Controls in detail
Loading and storing
Vehicles with control panel* in rear armrest1Compartment for cup holder
Opening: Press front of cup holder1.
Trunk
Storage spaces under trunk floor
You can fold back the front and rear parts
of the trunk floor.1Trunk floor
2Storage spaces
1Storage space
2Trunk floorCargo tie-down hooks
4 hooks are located in the trunk.

Carefully secure cargo by applying
even load on all hooks with rope of suf-
ficient strength to hold down the cargo.

454 Controls in detailLoading and storingRetaining hooks
Two hooks are located on the upper edge
of the trunk and can be used to attach car-
go items such as bags.
Pull tab1 of retaining hook2 down.
Parcel net in trunk
There is a pocket net on each side of the
right and left trunk side walls to secure
loads.Retainer for Operator’s Manual pouch
Use Velcro strap1 to fasten Operator’s
Manual pouch2 in place.
Umbrella holder
You can attach an umbrella to the trunk lid.1Umbrella holder
2Umbrella

Swing down holder1 in direction of
arrow.

Take umbrella2 out of holder 1.
!
Do not use the retaining hooks to tie down
cargo.
Warning!
G
Do not pull on the umbrella holder when you
are closing the trunk lid. You could other-
wise injure yourself on the trunk lid.i
You can purchase a suitable umbrella at any
authorized Mercedes-Benz Center.

455 Controls in detail
Useful features
Useful features
Sun visors
1Sun visor
2Vanity mirror cover
3Vanity mirror lamp
4Document holderGlare from front

Swing sun visor1 down.
Glare from front and sides

Disengage sun visor1 from the
mounting.

Pivot sun visor1 to the side.
Vanity mirror in sun visor

To use vanity mirror, lift up cover2.
Vanity mirror lamp3 comes on.
Document holder
You can use the plastic tab of document
holder4 to hold admission tickets, park-
ing passes, or similar items in place.
Vanity mirror in rear
Opening: Press mark1.
The vanity mirror swings down in the di-
rection of the arrow.

Closing: Swing vanity mirror up until it
engages.
Warning!
G
Do not use the vanity mirror while driving.
Keep the vanity mirrors in the sun visors
closed while vehicle is in motion. Reflected
glare can endanger you and others.
!
Close vanity mirror cover2 (if open) before
you disengage sun visor1 from the mounting
and pivot it to the side.
i
If you disengage sun visor1 from the
mounting, vanity mirror lamp2 will switch off.

456 Controls in detailUseful featuresRear window sunshade
The switches are on the rear doors.
1Opening
2Closing
You can also operate the rear window sun-
shade via COMAND (
page 227) or via
the favorite button (
page 216).

Switch on the ignition (
page 315).

Press upper part 1 of the rocker
switch briefly to extend the sunshade.

Press lower part 2 of the rocker
switch briefly to retract the sunshade.
Ashtrays
Center console ashtray
1Button for disengaging ashtray
2Cover plate
i
Operating the rear window sunshade from
the rear is not possible if you activate the over-
ride switch (
page 67).
i
If you operate the rear window sunshade via
COMAND or via the favorite button, this takes
precedence over the rear window sunshade but-
tons on the rear doors.
i
The rear window sunshade is switched off at
temperatures below -4°F (-20°C).
Warning!
G
Remove ashtray only with vehicle standing
still. Set the parking brake to secure vehicle
from movement. Set automatic transmis-
sion toP. With the automatic transmission
set toP, turn off the engine.

457 Controls in detail
Useful features
Opening ashtray
Press mark on cover plate2 forward.
Removing ashtray insert

Push sliding button1 to the left.
The ashtray is disengaged and slides
out a short way.

Remove the insert from the ashtray
frame.
Reinstalling ashtray insert

Install the insert by pushing it back into
the frame until it engages.
Closing ashtray

Briefly press mark on cover plate2
forward.
Rear door ashtray
Opening ashtray

Lift up the cover.Removing ashtray insert
1Insert

Press the open cover outwards beyond
the stop.
Ashtray insert1 pops out of the hold-
er.

Remove insert by pulling it upward.
Reinstalling ashtray insert

Install the insert by pushing it back into
the frame until it engages.
Cigarette lightersWarning!
G
Never touch the heating element or sides of
the lighter; they are extremely hot. Hold the
knob only.
Make sure that any children traveling with
you do not injure themselves or start a fire
with the hot cigarette lighter.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.
To avoid possible injury to children sitting in
the rear seat, activate the override switch
(page 67). Activation of the override
switch deactivates the rear center console
lighter.

458 Controls in detailUseful features1Center console cigarette lighter
1Rear center console lighter
Switch on the ignition (
page 315).

Push in cigarette lighter1.The lighter will pop out automatically
when hot.
Power outlet
The power outlet is located in the rear cen-
ter console.
Switch on the ignition (
page 315).

Flip up cover1 and insert electrical
plug (cigarette lighter type).
!
The lighter socket can be used to accommo-
date 12V DC electrical accessories (up to a max-
imum of 85 W) designed for use with the
standard “cigarette lighter” plug type. Keep in
mind, however, that connecting accessories to
the lighter socket (for example extensive con-
necting and disconnecting, or using plugs that do
not fit properly) can damage the lighter socket.
With the socket damaged, the lighter may no
longer be able to be placed in the heating
(pushed-in) position, or the lighter may pop out
too early with the lighter not hot enough.
To help avoid damaging the cigarette lighter
socket, we recommend connecting 12V DC elec-
trical accessories designed for use with a stan-
dard “cigarette lighter” plug type to the 12V
power outlets (
page 458) in your vehicle
whenever possible.
i
Operation of the rear door lighters is only
possible, if the override switch (
page 67) is de-
activated.
i
If the engine is off and the cigarette lighter is
being used extensively, the vehicle battery may
become discharged.
i
The power outlet can be used to
accommodate 12V DC electrical accessories
(e.g. air pump, auxiliary lamps) up to a maximum
of 180 W.
If the engine is off and the outlet is being used
extensively, the vehicle battery may become dis-
charged.

459 Controls in detail
Useful features
Telephone*
Radio transmitters, such as a portable tele-
phone or a citizens band unit, should only
be used inside the vehicle if they are con-
nected to an antenna that is installed on
the outside of the vehicle.
The external antenna must be approved by
Mercedes-Benz. Please contact an autho-
rized Mercedes-Benz Center for informa-
tion on the installation of an approved
external antenna. Refer to the radio trans-
mitter operation instructions regarding use
of an external antenna.When the mobile phone is inserted in the
cradle, you can operate the telephone us-
ing the following devices:


mobile phone keypad


COMAND telephone keypad
(page 115)


buttonss andt on the steering
wheel (
page 249)


Voice Control* (
page 262)


Bluetooth headset (
page 217)
See also separate operating manual for in-
structions on how to use the mobile phone.
Warning!
G
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system, pos-
sibly resulting in an accident and/or serious
personal injury.
Warning!
G
Please do not forget that your primary re-
sponsibility is to drive the vehicle. A driver’s
attention to the road must always be
his/her primary focus when driving. For
your safety and the safety of others, we rec-
ommend that you pull over to a safe location
and stop before placing or taking a tele-
phone call.
If you choose to use the telephone
1 while
driving, please use the hands-free device
and only use the telephone when road,
weather and traffic conditions permit. Some
jurisdictions prohibit the driver from using a
mobile telephone while driving a vehicle.
Only operate the COMAND (Cockpit Man-
agement and Data System)
1 if road, weather
and traffic conditions permit.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.
1Observe all legal requirements.
i
Various mobile phone cradles can be in-
stalled in the cockpit. These mobile phone cra-
dles can be obtained from an authorized
Mercedes-Benz Center.
The functions and services available to you while
using the mobile phone depend on your service
provider and the type of mobile phone you are
using.
