Page 7 of 705
ContentsCOMAND navigation system
(last destinations) .............................. 201
Saving a destination permanently
in the destination memory ........... 201
Saving the vehicle position in
the list of last destinations ........... 201
Saving the crosshair position in
the list of last destinations ........... 201
Deleting one of the last
destinations ................................. 201
COMAND address book ..................... 202
General notes ............................... 202
Address book menu overview ...... 202
Calling up the address book ......... 202
Selecting an entry in the main
address book display.................... 202
Creating a new address book
entry ............................................. 203
Deleting an entry .......................... 204
Searching for an address book
entry ............................................. 204
Displaying a complete address
book entry .................................... 206
Displaying of a complete phone
book entry in the mobile phone.... 207
Changing an entry ........................ 207Calling a number saved in
an entry ........................................ 209
Starting route guidance to
an entry ........................................ 209
Voice entries ................................ 210
Saving a phone book entry from
mobile phone in the COMAND
address book ............................... 211
Importing data from external
Bluetooth devices ........................ 212
COMAND system settings................. 213
Systems settings menu overview . 213
Display settings............................ 213
Time settings................................ 213
Voice Control* settings ................ 215
Setting the system language ........ 216
Assigning the favorite button ....... 216
Bluetooth settings ........................ 217
Reset............................................ 219
COMAND vehicle menu ..................... 220
Setting night security illumination 220
Locator lighting on/off ................. 221
Exterior mirror convenience
settings ........................................ 222
Automatic locking on/off ............. 223Activating easy-entry/exit feature 224
Setting interior ambient lighting .. 225
Setting interior lighting delayed
switch-off ..................................... 226
Extending or retracting rear
window sunshade ........................ 227
Trunk opening-height restriction
on/off .......................................... 227
Switching on/of the tow-away
alarm............................................ 228
COMAND automatic climate control . 229
Setting temperature..................... 230
Adjusting air distribution.............. 230
Adjusting air volume .................... 230
Central climate control menu via
COMAND ..................................... 231
Operating rear climate control*
from the front .............................. 234
COMAND seats ................................. 236
Operating seats via COMAND ...... 236
Lumbar support ........................... 237
Multicontour seats*, front ........... 237
Drive-dynamic multicontour
seats, front*................................. 240
Page 78 of 705
77 Control systems
COMAND operating safety
COMAND introduction
COMAND FM/AM radio
COMAND satellite radio* (USA only)
COMAND
audio CD/audio DVD/MP3
COMAND telephone*
COMAND navigation (introduction)
COMAND navigation system
(entering a destination)
COMAND navigation system
(Point of interest entry)
COMAND navigation system
(route guidance)
COMAND navigation system
(during route guidance)
COMAND navigation system
(destination memory)
COMAND navigation system
(last destinations)COMAND address book
COMAND system settings
COMAND vehicle menu
COMAND automatic climate control
COMAND seats
Instrument cluster control system
Voice Control* operating safety
Voice Control* introduction
Voice Control* telephone
Voice Control* navigation
Voice Control* address book
Voice Control* radio
Voice Control*
CD/DVD changer/MP3
Voice Control* command list
Voice Control* troubleshooting
Voice Control* individualization
Page 81 of 705
80 Control systemsCOMAND introductionCOMAND shortcut buttons
Use the COMAND shortcut buttons to se-
lect main menus directly.
Example:
Switching directly to Radio or CD
menu: Press M once or twice.COMAND display
In the COMAND display, you will find the
function currently selected and the corre-
sponding menus. The COMAND display is
divided into several areas.
1Status line
2Main menus
3Main area
4Submenus
5Climate control settings
A white bar under the main menus 2 indi-
cates the active area.
Once you have selected a main menu 2,
the main area 3 is active.
i
During Dynamic Rear View Monitor* opera-
tion (page 413) it is not possible to operate
the COMAND shortcut buttons.
Function
Page
1
PFavorite button
216
2
MShortcut button for:
radio
CD/DVD
94
111
3
LBack button
87
4
OSeat menu
236
5
NShortcut button for:
telephone*
Navi
115
148
6
oCOMAND on/off
button
79
7
,Volume control
89
8
FMute button
89
Page 230 of 705
229 Control systems
COMAND automatic climate control
COMAND automatic climate control
You can operate the automatic climate
control via COMAND or via the buttons on
the front and rear* automatic climate con-
trol panel (
page 424).
The following automatic climate control
functions can be operated via COMAND:The automatic climate control menu is
called up via the climate control settings.
Climate control settings with functions
(submenus)1Temperature, left
2Air distribution, left
3Air volume, left
4Central menu, climate control
5Air volume, right
6Air distribution, right
7Temperature, right
i
The components and operating principles of
COMAND can be found on (
page 79).
Warning!
G
When operating the automatic climate con-
trol, the air that enters the passenger com-
partment through the air vents can be very
hot or very cold (depending on the set tem-
perature). This may cause burns or frostbite
to unprotected skin in the immediate area of
the air vents.
Always keep sufficient distance between un-
protected parts of the body and the air
vents. If necessary, use the air distribution
adjustment (
page 230) to direct the air to
air vents in the vehicle interior that are not
in the immediate area of unprotected skin.
Warning!
G
Follow the recommended settings for heat-
ing and cooling given on the following pages
and pages in the “Controls in detail” part
(page 424) Otherwise the windows could
fog up, impairing visibility and endangering
you and others.
Function
Page
Temperature
230
Air distribution
230
Air volume
230
Switching off cooling (“AC
OFF”)
231
Central climate control (“Mono”)
232
Footwell temperature
232
Air flow from air vents
233
Rear climate control*
234
Page 231 of 705
230 Control systemsCOMAND automatic climate controlSetting temperature
Use the temperature controls %$
(page 426) in the center console or
COMAND climate control settings to sepa-
rately adjust the air temperature on each
side of the passenger compartment.
Select climate control settings Tem-
perature, left or right and then
pressn.
Changing temperature: Slide qmr or
rotate ymz.
Exiting menu: Press n, back
buttonL in the center console
(page 80) or slideomp.
The setting is saved.
Adjusting air distribution
You can adjust the air distribution sepa-
rately for the driver’s and front passenger’s
side.
Select climate control settings Air
distribution, left or right.
Changing air distribution:
Rotateymz.
The symbol for air distribution changes.
The direction and size of the arrows
represent the air distribution.
Exiting menu: Press n, back
buttonL in the center console
(page 80) or slideomp.
The setting is saved.
Adjusting air volume
Use buttonsQ (
page 426) in the cen-
ter console or COMAND climate control
settings to separately adjust the air vol-
ume on each side of the passenger com-
partment.
Select climate control settings Air
volume, left or right.
i
When you change the air distribution, the au-
tomatic function of the climate control system is
switched off.
i
When you change the air volume, the auto-
matic function of the climate control system is
switched off.
Page 232 of 705
231 Control systems
COMAND automatic climate control
Changing air volume: Slide qmr or
rotate ymz.
Exiting menu: Press n, back
buttonL in the center console
(page 80) or slideomp.
The setting is saved.
Central climate control menu via
COMAND
The central climate control menu is in the
center of the climate control settings.
When the automatic climate control is
switched on, you will see “on” in the cen-tral menu. The following functions can only
be operated in the central climate control
menu via COMAND:
Select climate control settings Cen-
tral menu.Switching cooling on or off
The cooling function, only operational
when the engine is running, cools the vehi-
cle interior down to the selected tempera-
ture. The cooling function also
dehumidifies the air in the vehicle interior,
thus preventing the windows from fogging
up.
The “AC
OFF” function is used to permanent-
ly switch off the cooling function of the au-
tomatic climate control system.
Function
Page
Switching off cooling (“AC
OFF”)
231
Central climate control (“Mono”)
232
Footwell temperature
232
Air flow from air vents
233
Rear climate control
234
i
Condensation may drip out from underneath
the vehicle. This is normal and not an indication
of a malfunction.Warning!
G
If you turn off the cooling function, the
vehicle will not be cooled when weather
conditions are warm. The windows can fog
up more quickly. Window fogging may
impair visibility and endanger you and
others.
Page 233 of 705
232 Control systemsCOMAND automatic climate control
Select climate control settings Cen-
tral climate control menu.
Selecting “AC
OFF”: Slide qmr or
rotateymz.
Confirming selection: Press n.
A checkmark appears when the cooling
is switched off.
“AC
OFF” appears in the central menu of
the climate control settings.Selecting “Mono” mode
“Mono” is used to adjust the climate zones
for the entire vehicle at the same time.
When the “Mono” function is switched on
and you change the climate on the driver’s
side, these changes will be carried out in
the same manner for all climate zones.
Select climate control settings Cen-
tral climate control menu.
Selecting “Mono”: Slide qmr or
rotateymz.
Confirming selection: Press n.
A checkmark appears when the func-
tion has been selected.
Exiting menu: Press back button L
in the center console (
page 80) or
slideomp.The “Mono” function is automatically
switched off when you:
change an automatic climate control
setting for the front passenger’s side
using COMAND
operate a button from the automatic
climate control for the front passen-
ger’s side
operate one of the buttons for the rear
climate control system.
Adjusting footwell temperature
The “Footwell Temperature” function is
used to adjust the temperature difference
between the footwell and the rest of the
passenger compartment.
The higher the selected value, the higher
the temperature in the footwell will be.
Select climate control settings Cen-
tral climate control menu.
!
If the air conditioning cannot be turned on
again, this indicates that the air conditioning is
losing refrigerant. The compressor has turned it-
self off.
Have the air conditioning checked at the nearest
authorized Mercedes-Benz Center.
i
In automatic mode, this setting optimizes
the footwell temperature when outside tempera-
tures are low.
Page 234 of 705
233 Control systems
COMAND automatic climate control
Selecting “Footwell Temperature”:
Slide qmr or rotate ymz and then
pressn.
Changing temperature difference:
Slide qmr or rotate ymz.
Exiting menu: Press n, back
buttonL in the center console
(page 80) or slideomp.
The setting is saved.Adjusting air flow from air vents
The “Airflow” setting defines air distribu-
tion and air volume in automatic mode:
“Focused” (default setting, increased
air flow)
“Medium” (reduced air flow)
“Diffuse” (minimal air flow)
Select climate control settings Cen-
tral climate control menu “Airflow”.
A selection list appears.
The current setting is indicated by a
dotR.
Changing air flow: Slide qmr or
rotateymz.
Confirming selection: Press n.
i
In automatic mode, this setting optimizes
the air flow when outside temperatures are high.
i
When the interior ambient temperature of
the vehicle is very hot and the automatic climate
control is cooling the interior, the setting for air
flow is temporarily overridden.
Page 235 of 705
234 Control systemsCOMAND automatic climate controlOperating rear climate control* from the front
The “Rear)” function is used to oper-
ate the rear climate control via COMAND
and the buttons on the center console con-
trol unit (
page 434).
Switching on rear climate control oper-
ation from the front
Select climate control settings Cen-
tral climate control menu.
Selecting “Rear)”: Slide qmr or
rotate ymz.
Confirming selection: Press n.In the climate control settings, “)”
appears in the central menu. The rear
climate control can be operated from
the front.
Climate control settings, rear climate con-
trol1Rear temperature, left
2Rear air distribution, left
3Rear air volume
4Central menu for rear climate control
5Rear air distribution, right
6Rear temperature, right
The rear climate control is operated in the
same manner as the climate control sys-
tem for the driver’s and front passenger’s
side (
page 229).Central menu for rear climate control
In the central menu for the rear climate
control, you can:
switch back to operating the front cli-
mate control system
switch off the rear climate control
switch the automatic function of the
rear climate control from automatic to
manual
Select climate control settings Cen-
tral climate control menu.
Page 236 of 705
235 Control systems
COMAND automatic climate control
Switching off rear climate control oper-
ation from the front
Select climate control settings Cen-
tral climate control menu.
The current setting is indicated by a
dotR.
Selecting “Front Climate Control”:
Slide qmr or rotate ymz.
Confirming selection: Press n.
The climate control settings shows the
climate control settings for the driver
and front passenger.Switching off rear climate control
Select climate control settings Cen-
tral climate control menu.
The current setting is indicated by a
dotR.
Selecting “Rear Climate Control
OFF”: Slide qmr or rotate ymz.
Confirming selection: Press n.
The rear climate control is switched off.Switching on the automatic function of
the rear climate control
Select climate control settings Cen-
tral climate control menu.
The current setting is indicated by a
dotR.
Selecting “Rear Automatic”:
Slideqmr or rotate ymz.
Confirming selection: Press n.
The automatic function of the rear cli-
mate control is switched on.
