MERCEDES-BENZ S55AMG 2000 W220 Owner's Manual

388 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Te ch n ica l d a t a
Model S 430 (220.070
1)
S 430 (220.1701)S 500 (220.175
1)
Engine113 113
Mode of operation 4-stroke engine, gasoline injection 4-stroke engine, gasoline injection
No. of cylinders 8 8
Bore 3.54 in (89.90mm) 3.82 in (97.00 mm)
Stroke 3.31 in (84.00 mm) 3.31 in (84.00 mm)
Total piston displacement 260.3 cu. in. (4266 cm
3) 303.5 cu.in. (4966 cm
3)
Compression ratio 10:1 10:1
Output acc. to SAE J 1349 275 hp / 5750 rpm
(205 kW / 5750 rpm)302 hp / 5600 rpm
(225 kW / 5600 rpm)
Maximum torque acc. to SAE J 1349 295 ft-lb (400 Nm) at 3000 rpm 339 ft-lb (460 Nm) at 2700 rpm
Maximum engine speed 6000 rpm 6000 rpm
Firing order 1-5-4-2-6-3-7-8 1-5-4-2-6-3-7-8
Poly-V-belt 2390 mm 2390 mm
1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies
and special equipment.

389 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Model S 55 AMG (220.175)S 600 (220.178
1)
Engine113 13 7
Mode of operation 4-stroke engine, gasoline injection 4-stroke engine, gasoline injection
No. of cylinders 8 12
Bore 3.82 in (97.00 mm) 3.31 in (84.00 mm)
Stroke 3.60 in (92.00 mm) 3.43 in (87.00 mm)
Total piston displacement 335.6 cu.in. (5499 cm
3) 353.6 cu.in. (5786 cm
3)
Compression ratio 10.5:1 10:1
Output acc. to SAE J 1349 349 hp/5500 rpm
(260 kW/5500 rpm)362 hp / 5500 rpm
(270 kW / 5500 rpm)
Maximum torque acc. to SAE J 1349 391 ft.lb/3000 rpm
(530 Nm/3000 rpm)391 ft-lb/4100 rpm
(530 Nm/4100 rpm)
Maximum engine speed 6000 rpm 6000 rpm
Firing order 1-5-4-2-6-3-7-8 1-12-5-8-3-10-6-7-2-11-4-9
Poly-V-belt 2390 mm 2345 mm
1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies
and special equipment.

390 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Rims — Tires
Model S 430, S 500
(except Sport Package)S 600
(except Sport Package)
Rims (light alloy)
Wheel offset:7
1/2Jx16H2
1.81 in (4 6 m m )7
1/2 J x 17 H 2
1. 81 i n ( 46 m m )
All season tires:
Radial-ply tires 225 / 60 R16 98H 225 / 55 R 17 97H
Winter tires:
Radial-ply tires 225 / 60 R16 98H M+S 225 / 55 R17 97H M+S
Spare wheel
Rim (light alloy)
Wheel offset:7
1/2Jx16H2
2.0 in (51 mm)7
1/2Jx17H2
2.0 in (51 mm)
All season tires:
Radial-ply tires 225 / 60 R16 98H 225 / 55 R17 97H

391 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
1 Must not be used with snow chains.Model S 430, S 500
(Sport Package)S 55 AMG
S 600 (Sport Package)
Rims front axle
(AMG light alloy)
Wheel offset8
1/2 J x 18 H 2
1.73 in (44 mm)8
1/2 J x 18 H 2
1.73 in (44 mm)
Rims rear axle
(AMG light alloy)
Wheel offset9
1/2 J x 18 H 2
1.81 in (46 mm)9
1/2 J x 18 H 2
1.81 in (46 mm)
Radial-ply tires
Summer tires, front axle:
Summer tires, rear axle:245 / 45 R 18
275 / 40 R 18
1
245 / 45 R 18
275 / 40 R 18
1
Spare wheel
Rim (light alloy)
Wheel offset:7
1/2Jx16H2
2.0 in (51 mm)7
1/2Jx16H2
2.0 in (51 mm)
All season tires:
Radial-ply tires 225 / 60 R16 98H 225 / 55 R17 97Y

392 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Rims – Winter tires
Electrical system Model S 55 AMG
Rim (light alloy)
Wheel offset7
1/2 J x 17 H 2
1.81 in (46 mm)
Winter tires:
Radial-ply tires 225 / 55 R 17 97 HM+S
Model S 430, S 500 S 55 AMG S 600
Generator (alternator) 14 V / 150 A 14 V / 150 A 14 V / 150 A
Starter motor 12V / 1.7 kW 12V / 1.7 kW 12V / 2.2 kW
Battery 12V / 100 Ah 12V / 100 Ah 12V / 100 Ah
Spark plugs
Electrode gap
Tightening torqueBosch F 8 DPER
Beru 14 FGH 8 DPUR X 2
NGK PFR 5 R-11
0.039 in (1.0 mm)
15 – 22 ft.lb (20 – 30 Nm)Bosch F 8 DPER
0.039 in (1.0 mm)
15 – 22 ft.lb (20 – 30 Nm)Beru 14 F 7-DPUR X 2
0.041 in (1.05 mm)
15 – 22 ft.lb (20 – 30 Nm)

393 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index We i g h t s
Main dimensions Roof load max. 220 lb (100 kg)
Trunk load max. 220 lb (100 kg)
Model S 430 (220.070)S 430 (220.170),
S 500 (220.175)S 55 AMG (220.173)S 600 (220.178)
Overall vehicle length 198.3 in (5038 mm) 203.1 in (5158 mm) 203.1 in (5158 mm) 203.1 in (5158 mm)
Overall vehicle width 73.0 in (1855 mm) 73.0 in (1855 mm) 73.0 in (1855 mm) 73.0 in (1855 mm)
Overall vehicle height 56.9 in (1444 mm) 56.9 in (1444 mm) 56.9 in (1444 mm) 56.9 in (1444 mm)
Wheel base 116.7 in (2965 mm)121. 5 i n ( 3 08 5 m m ) 121. 5 in ( 3085 mm) 121.5 in (3085 mm)
Track, front 62.0 in (1574 mm) 62.0 in (1574 mm) 62.0 in (1574 mm) 62.0 in (1574 mm)
Track, rear 62.0 in (1574 mm) 62.0 in (1574 mm) 61.8 in (1570 mm) 62.0 in (1574 mm)

394 Fuels, coolants, lubricants etc. - capacities
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Fuels, coolants, lubricants etc. - capacities
Vehicle components and their respective lubricants must match. Therefore use only brands tested and recommended
by us. Please refer to the Factory Approved Service Products pamphlet, or inquire at your Mercedes-Benz Center.
Model Capacity Fuels, coolants, lubricants etc.
Engine with oil filter S 430, S 500
S 55 AMG
S 6008.5 US qt (8.0 l)
8.0 US qt (7.5 l)
10.0 US qt (9.5 l)Recommended engine oils
Automatic
transmission9.6 US qt (9.1 l) Automatic transmission fluid
Rear axle 1.7 US qt (1.6 l) Hypoid gear oil SAE 85 W 90
Hydraulic system for
adaptive damping
system (ADS) or active
body control (ABC)approx. 5.3 US qt (5.0 l) MB Hydraulic f luid
Power steering approx. 1.1 US qt (1.0 l) MB Power steering fluid
Front wheel hubs approx. 2.1 oz (60 g) each High temperature roller bearing grease
Brake system 0.7 US qt (0.7 l) MB Brake fluid (DOT 4+)
Cooling system S 430, S 500
S 55 AMG
S 600approx. 12.1 US qt (11.5 l)
approx. 12.1 US qt (11.5 l)
approx. 12.7 US qt (12.0 l)MB Anticorrosion / antifreeze

395 Fuels, coolants, lubricants etc. - capacities
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Fuel tank
including a reserve of23.2 US gal (88.0 l)
2.9 US gal (11.0 l)Premium unleaded gasoline: Posted
Octane 91
(Avg. of 96 RON / 86 MON)
Air conditioner system R-134a refrigerant and special PAG
lubricant
Windshield washer
and headlamp
cleaning system7.1 US qt (6.7 l) MB Windshield washer concentrate
1
1 Use MB Windshield Washer Concentrate “S” and water for temperatures above freezing or MB Windshield Washer Concentrate “S” and
commercially available premixed windshield washer solvent / antifreeze for temperatures below freezing. Follow suggested mixing ratios, see
page 337.
Model Capacity Fuels, coolants, lubricants etc.

396 Fuels, coolants, lubricants etc. - capacities
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Engine oils
Engine oils are specifically tested for their suitability in
our engines. Therefore, use only engine oils
recommended by Mercedes-Benz. Information on
recommended brands is available at your authorized
Mercedes-Benz Center.
Please follow Service Booklet recommendations for
scheduled oil changes. Failure to do so could result in
engine damage not covered by the Mercedes-Benz
Limited Warranty.
Engine oil additives
Do not blend oil additives with engine oil. They may be
harmful to the engine operation.
Damage or malfunctions resulting from blending oil
additives are not covered by the Mercedes-Benz Limited
War ra nt y.Air conditioner refrigerant
R-134a (HFC) refrigerant and special PAG lubricating oil
is used in the air conditioner system.
Never use R-12 (CFC) or mineral-based lubricating oil,
otherwise damage to the system will occur.
Brake fluid
During vehicle operation, the boiling point of the brake
fluid is continuously reduced through the absorption of
moisture from the atmosphere. Under extremely hard
operating conditions, this moisture content can lead to
the formation of bubbles in the system thus reducing
the system’s efficiency.
The brake fluid must therefore be replaced every two
years, preferably in the spring.
It is recommended to use only brake fluid approved by
Mercedes-Benz. Your authorized Mercedes-Benz Center
will provide you with additional information.

397 Fuels, coolants, lubricants etc. - capacities
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Premium unleaded gasoline
Caution!
To maintain the engine’s durability and performance,
premium unleaded gasoline must be used. If premium
unleaded is not available and low octane fuel is used,
follow these precautions:
•have the fuel tank filled only partially with unleaded
regular and fill up with premium unleaded as soon
as possible,
•avoid full throttle driving and abrupt acceleration,
•do not exceed an engine speed of 3000 rpm, if the
vehicle is loaded with a light load such as two
persons and no luggage,
•do not exceed
2/3 of maximum accelerator pedal
position, if the vehicle is fully loaded or operating in
mountainous terrain.Fuel requirements
Use only Premium unleaded meeting ASTM
standard D 439:
The octane number (posted at the pump) must be
91 min. It is an average of both the Research (R) octane
number and the Motor (M) octane number: (R+M) / 2).
This is also known as ANTI-KNOCK INDEX.
Unleaded gasoline containing oxygenates such as
Ethanol, IPA, IBA and TBA can be used provided the
ratio of any one of these oxygenates to gasoline does not
exceed 10%, MTBE not to exceed 15%.
The ratio of Methanol to gasoline must not exceed 3%
plus additional cosolvents.
Using mixtures of Ethanol and Methanol is not allowed.
Gasohol, which contains 10% Ethanol and 90% unleaded
gasoline, can be used.
These blends must also meet all other fuel requirements
such as resistance to spark knock, boiling range, vapor
pressure etc..
