668 Practical hints
Where will I find ...?
First aid kit
The first aid kit is located in the storage
compartment under the front passenger
seat.
1Tab
2Cover
Pull tab1 upward.
Fold the covering forward in the direc-
tion of arrow.
Remove the first aid kit.
Vehicle jack, vehicle tool kit, luggage
bowl, Minispare wheel
The vehicle jack, Minispare wheel, the ve-
hicle tools, and the luggage bowl are
stored in the compartment underneath the
trunk floor.
Lift up trunk floor cover and engage
trunk floor handle in upper edge of
trunk.
You can now remove the tools and ac-
cessories.The vehicle tool kit includes:

Towing eye bolt

Wheel wrench with socket wrench

Alignment bolt

Pair of gloves

Fuse extractor1


Fuse chart for the main fuse box

Spare fuses1


Collapsible wheel chock

Release tool for mechanically releasing
the electronic parking brake
The spare wheel bolts are fixed at the
Minispare wheel.
!Always keep the storage compartment un-
der the front passenger seat closed while the ve-
hicle is in motion.
iCheck expiration dates and contents for
completeness at least once a year and replace
missing/expired items.
!To prevent damage, always disengage trunk
floor handle from trunk lid and lower trunk floor
before closing the trunk.
1Depending on vehicle production date.

689 Practical hints
Flat tire
Removing the wheel
1Alignment bolt
Unscrew upper-most wheel bolt and
remove.
Replace this wheel bolt with alignment
bolt1 supplied in the tool kit.
Remove the remaining bolts.
Remove the wheel.Attaching the spare wheel
1Wheel bolt for light alloy rims and
Minispare wheel with light alloy rim
2Wheel bolt for Minispare wheel with
steel rim (located in trunk with spare
wheel)
!Do not place wheel bolts in sand or dirt. This
could result in damage to the bolt and wheel hub
threads.
Warning!G
Always replace wheel bolts that are dam-
aged or rusted.
Never apply oil or grease to wheel bolts.
Damaged wheel hub threads should be re-
paired immediately. Do not continue to drive
under these circumstances! Contact an au-
thorized Mercedes-Benz Center or call
Roadside Assistance.
Incorrect wheel bolts or improperly tight-
ened wheel bolts can cause the wheel to
come off. This could cause an accident.
Make sure you are using the correct wheel
bolts.
Warning!G
Only use Genuine Mercedes-Benz wheel
bolts. Other wheel bolts may come loose.
Do not tighten the wheel bolts when the ve-
hicle is raised. Otherwise the vehicle could
fall off the jack.

690 Practical hints
Flat tire
Clean contact surfaces of wheel and
wheel hub.
Guide the spare wheel onto the align-
ment bolt and push it on.
Insert wheel bolts and tighten them
slightly.
Unscrew the alignment bolt, install the
last wheel bolt and tighten slightly.Lowering the vehicle
Lower vehicle by turning crank coun-
terclockwise until vehicle is resting ful-
ly on its own weight.
Remove the jack.
1 - 5 Wheel bolts
!Wheel bolts2 must be used when mount-
ing a Minispare wheel with steel rim. The use of
any wheel bolts other than wheel bolts2 for a
Minispare wheel with steel rim will physically
damage the vehicle’s brakes.
Wheel bolts1 must be used when mounting a
Minispare wheel with light alloy rim. The use of
any wheel bolts other than wheel bolts1 for
a Minispare wheel with light alloy rim will physi-
cally damage the vehicle’s brakes.
Warning!G
Make sure to use the original length wheel
bolts when remounting the original wheel
after it has been repaired.!To avoid paint damage, place wheel flat
against hub and hold it there while installing first
wheel bolt.
