MERCEDES-BENZ SL-Class 2001 R129 Owner's Manual

267 Cleaning and care of the vehicle
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hintsCar careIndex In general, regular spraying or cleansing with clear
water is sufficient to keep the top clean.
Wash the top only when heavily soiled.
Light colored soft tops should be cleaned frequently to
prevent spots and dirt from setting in, which could stain
and discolor the soft top material permanently.
Caution!
Never use any gasoline, thinner, tar and stain removers,
glass cleaner, or similar organic solvents to clean the
soft top, plastic window or wind screen. They will cause
damage which is not covered by the Mercedes-Benz
Limited Warranty.
Headliner
Soft top:
Clean with soft bristle brush, or use a dry-shampoo
cleaner in case of excessive dirt.Wind screen
Use only water or mild detergent to clean the wind
screen.
Automatic antenna
For trouble-free operation of the automatic antenna, we
recommend that you clean the antenna mast
periodically.
Wiper blade
Clean the wiper blade rubber with a clean cloth and
detergent solution.
Note:
For safety reasons, remove key from steering lock before
cleaning the wiper blade, otherwise the wiper motor
can suddenly turn on and cause injury.
Headlamp cleaning system
The condition of the wiper blades is important for
satisfactory cleaning of the headlamp lenses. We
therefore recommend that the blades be inspected
regularly.

268 Cleaning and care of the vehicle
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hintsCar careIndex
Leather upholstery
Using aftermarket seat covers or wearing clothing that
have the tendency to give off coloring (e.g. when wet
etc.) may cause the upholstery to become permanently
discolored. By lining the seats with a proper
intermediate cover, contact-discoloration will be
prevented.
Wipe leather upholstery with a damp cloth and dry
thoroughly or clean with Mercedes-Benz approved
Leather Care. Exercise particular care when cleaning
perforated leather as its underside should not become
wet.Plastic and rubber parts
Do not use oil or wax on these parts.
Illuminated door sill panels
Use a gentle dish-washing detergent or mild detergent
for delicate fabrics as a washing solution. Wipe with a
cloth moistened in lukewarm solution. Do not use
scouring agents.

269 Contents - Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Technical data Spare parts service ........................270
Warranty coverage .........................270
Identification labels ....................... 271
Layout of poly-V-belt drive ............272
Engine ..............................................273
Rims - Tires ..................................... 274
Weights ............................................ 276
Main Dimensions ........................... 276Fuels, coolants, lubricants etc. -
capacities ................................... 277
Engine oils ...................................... 279
Engine oil additives ...................... 279
Air conditioner refrigerant .......... 279
Brake fluid ...................................... 279
Premium unleaded gasoline ........ 280
Fuel requirements ........................ 280
Gasoline additives ......................... 281
Coolants .......................................... 281
Consumer information ................. 283

270 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Spare parts service
All authorized Mercedes-Benz Centers maintain a stock
of original spare parts required for maintenance and
repair work. In addition, strategically located parts
distribution centers provide quick and reliable parts
service.
More than 300 000 different spare parts, for
Mercedes-Benz models, are available.
Mercedes-Benz original spare parts are subjected to
stringent quality inspections. Each part has been
specifically developed, manufactured or selected for and
adapted to Mercedes-Benz vehicles.
Therefore, Mercedes-Benz original spare parts should
be installed.
Important!
The use of non-genuine parts and accessories not
authorized by Mercedes-Benz could damage the vehicle
which damage is not covered by the Mercedes-Benz
Limited Warranty or compromise its durability or safety.Warranty coverage
Your vehicle is covered under the terms of the
“warranties” printed in the Service and Warranty
Information booklet and your authorized
Mercedes-Benz Center will exchange or repair any
defective parts originally installed on the vehicle in
accordance with the terms of the following warranties:
1. New vehicle limited warranty
2. Emission system warranty
3. Emission performance warranty
4. California, Massachusetts, and Vermont emission
control systems warranty
Replacement parts and accessories are covered by the
Mercedes-Benz Spare Parts and Accessories warranties,
copies of which are available at any Mercedes-Benz
Center.
Loss of Service and
Warranty Information Booklet
Should you lose your Service and Warranty Information
booklet, have your authorized Mercedes-Benz Center
arrange for a replacement. It will be mailed to you.

271 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Identification labels
1Certification label
(left door pillar)
Note:
When ordering spare parts, please specify vehicle
identification and engine numbers.2VIN, visible (lower edge of windshield)
3Vehicle Identification No. (VIN)
4Engine number
5Body number and paintwork number
6Emission control label
7Information label
California version
Vacuum line routing for emission control system

272 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Layout of poly-V-belt drive
SL 500
1Automatic belt tensioner
2Crankshaft
3Air conditioner compressor
4SL 500: Coolant pump
SL 600: FanSL 600
5Generator (alternator)
6Idler pulley
7Power steering pump
8Air pump
9Coolant pump
For dimensions of the poly-V-belts, see page 273.

273 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Technical data
Model SL 500 (129.068)
1
SL 600 (129.076)
1
Engine113 1 2 0
Mode of operation 4-stroke engine,
gasoline injection4-stroke engine,
gasoline injection
No. of cylinders 8 12
Bore 3.82 in (97.00 mm) 3.50 in (89.00 mm)
Stroke 3.30 in (84.00 mm) 3.16 in (80.20 mm)
Total piston displacement 303 cu.in. (4966 cm
3) 365.4 cu.in. (5987 cm
3)
Compression ratio 8.8:1 10:1
Output acc.
to SAE J 1349302 hp/5600 rpm
(225 kW/5600 rpm)389 hp/5200 rpm
(290 kW/5200 rpm)
Maximum torque acc.
to SAE J 1349339ft.lb/2750 rpm
(460 Nm/2750 rpm)420ft.lb/3800 rpm
(570 Nm/3800 rpm)
Maximum engine speed 6000 rpm 6000 rpm
Firing order 1-5-4-2-6-3-7-8 1-12-5-8-3-10-6-7-2-11-4-9
Poly-V-belts length 2390 mm 2585 mm
1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies
and special equipment.

274 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Rims – Tires
2 Must only be used with special MB authorized snow chains.Rims and summer tires
(except Sport Package)
Rims (light alloy)
Wheel offset:8
1/4 J x 17 H 2
1.33 in (34 mm)
All season tires:
Radial-ply tires 245/45 R17 95 W
Winter tires:
Radial-ply tires 245/45 R 17 45 H M+S
2
Spare wheel
Rim (light alloy)
Wheel offset:8
1/4 J x 17 H 2
1.33 in (34 mm)
All season tires:
Radial-ply tires 245/45 R 17 95 W
2

275 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
2 Must only be used with special MB authorized snow chains.
3 Must not be used with snow chains.Rims and summer tires
(Sport package)
Model SL 500 SL 600
Rims front axle
AMG light alloy rims
Wheel offset:8
1/2 J x 18 H 2
1.0 in (25 mm)8
1/2 J x 18 H 2
1.0 in (25 mm)
Rims rear axle
AMG light alloy rims
Wheel offset:9
1/2 J x 18 H 2
0.9 in (23 mm)10 J x 18 H 2
1.0 in (25 mm)
Radial-ply tires
front axle
rear axle245/40 ZR 18
275/35 ZR 18
3
245/40 ZR 18
275/35 ZR 18
3
Spare wheel
Rim (light alloy)
Wheel offset:8
1/4 J x 17 H 2
1.33 in (34 mm)8
1/4 J x 17 H 2
1.33 in (34 mm)
All season tire:
Radial-ply tire 245/45 R 17 95W
2
245/45 R 17 95W
2

276 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Electrical system Weights
(see certification tag)
Main dimensions Generator (alternator) 14 V/150 A
Battery 12V/100 Ah
Starter motor
SL 500:
SL 600:12 V / 1. 7 k W
12V/2.2 kW
Spark plugs
SL 500:
SL 600:
Electrode gap
Tightening torqueBosch F 8 DPER
Beru 14 FGH 8 DPUR X 2
Beru 14 FGH 8 DPUR X 2
0.039 in (1.0 mm)
15 – 22 ft.lb (20 – 30 Nm)Hardtop load max. 66 lb (30 kg)
Trunk load max. 220 lb (100 kg)
Overall vehicle length 177.1 in (4499 mm)
O ve r a l l v e h i c l e w i d t h 71.3 in ( 1812 m m )
Overall height 51.3 in (1303 mm)
Wheel base 99.0 in (2515 mm)
Track, front 60.4 in (1535 mm)
Track, rear 60.0 in (1523 mm)
