173 Navigation
Route guidance

While the map or symbol display is ac-
tive, press b.
A query will appear.

Press the right-hand rotary/push-
button v and confirm “Yes”.
The main destination input menu will
appear.Continuing route guidance

Press *.
or

Turn the right-hand rotary/push-
button v to highlight “No” and press
to confirm.
The map or the symbol display will ap-
pear.
Canceling route guidance

174 NavigationDestination memory

Destination memoryYou can save frequently used destinations
in the destination memory.Main destination memory menu1Info/status line
2Retrieves destination from the destina-
tion memory for destination input
3Sorts destination memory
4Deletes destination in the destination
memory
5Saves the current destination
6Saves current vehicle location with a
name

Turn the right-hand rotary/push-
button v to highlight “Destination me-
mory” in the main destination input
menu and press to confirm.
The main destination memory menu
will appear.

Press the right-hand rotary/push-
button v to confirm “Display destina-
tions...” in the main destination memo-
ry menu.
After the message “Compiling sorted
destination list”, the destination me-
mory will appear.
P82.85-9235-311
56
2
3
4
Retrieving a destination from the
destination memory
P82.85-9236-31

175 Navigation
Destination memory

Turn the right-hand rotary/push-
button v to highlight the desired entry
and press to confirm.

Then calculate the route (
page 141).When you have entered or reached the cur-
rent destination, you can save the destina-
tion in the destination memory.
Input menu1Name entered
2Saves the destination without entering
a name In the selection menu “Destination Entry”
(
page 128)

Turn the right-hand rotary/push-
button v until “Save” is highlighted
and press to confirm.
In the main destination memory menu

Turn the right-hand rotary/push-
button v until “Save current destinati-
on...” is highlighted and press to con-
firm.
An input menu will appear.
iDisplaying longer entries (
page 165).
Saving the current destination
iIf all memory locations are used, the
message “Destination memory is full”
will appear. Press the right-hand rotary/
push-button v to remove the message.
The main destination memory menu will
appear.
Deleting a destination in destination
memory (
page 179).

176 NavigationDestination memorySaving with a name
You can enter a name for the current des-
tination.
Turn the right-hand rotary/push-
button v to highlight the desired cha-
racter and press to confirm.
The letter you have selected appears in
the input line.

Enter the other letters until the name is
complete.

Press the right-hand rotary/push-
button v longer than 2 seconds.
The destination memory will activate.
The current destination has been saved
with a name and appears in red.

Turn the right-hand rotary/push-
button v to move the entry to the
desired point in the list and press to
confirm.
Saving after destination has been ente-
red:
The main destination entry menu will
appear, “Start Guidance...” is highligh-
ted.
Saving on arrival at destination:
The main destination entry menu will
appear.3Starting route guidance

Press the right-hand rotary/push-
button v to confirm 3.
Route guidance begins.
P82.85-9238-31
P82.85-9239-31
3

177 Navigation
Destination memory
Saving without a name
If you do not wish to enter a name,
COMAND will save the destination with
city and street name.
While you are in the input menu, turn
the right-hand rotary/push-
button v to highlight “Save without
names” and press to confirm.
The destination memory will appear.With this function, you can save the cur-
rent vehicle location in the destination me-
mory. Enter a name so you will be able to
retrieve it at a later date.

Turn the right-hand rotary/push-
button v to highlight “Save current lo-
cation...” in the main destination me-
mory menu and press to confirm.
The input menu “Save Location” will
appear.

Enter a name.

Then activate the destination memory
and save the position in the desired
memory location, see “Saving with a
name”.
The main destination input menu will
appear.
Saving the current vehicle location

178 NavigationDestination memory
Turn the right-hand rotary/push-
button v to highlight “Sort destinati-
ons...” in the main destination memory
menu and press to confirm.
After the message “Compiling sorted
destination list”, the destination me-
mory will appear.

Turn the right-hand rotary/push-
button v to highlight the desired entry
and press to confirm.
The entry is now red.

Turn the right-hand rotary/push-
button v to move the entry to the
desired position and press to confirm.
The entry is saved at that location.
The entry is black again. The main des-
tination memory menu is reactivated
automatically.
Sorting destination memory
P82.85-9158-31
P82.85-9157-31

179 Navigation
Destination memory

Turn the right-hand rotary/push-
button v to highlight “Delete Destina-
tion in Memory” in the main destination
memory menu and press to confirm.
After the message “Compiling sorted
destination list”, the destination me-
mory will appear.

Turn the right-hand rotary/push-
button v to highlight the entry you
wish to delete and press to confirm.
The inquiry “Do you really want to dele-
te the destination?” will appear.

Turn the right-hand rotary/push-
button v to highlight “Yes” and press
to confirm.
The entry has been deleted from the
list. The following entries will each
move up one position. The delete func-
tion is still active.If you do not want to delete the destination

Turn the right-hand rotary/push-
button v to highlight “No” and press
to confirm.
The destination memory will appear.
Activating the main destination memory
menu

Press *.
Deleting a destination
P82.85-9156-31
P82.85-9155-31

180 NavigationSettings

SettingsCOMAND normally determines the vehicle
location automatically with the GPS. In ex-
ceptional cases, this may not be possible.
You can then enter the current vehicle lo-
cation manually in connection with a
crossroad.
Turn the right-hand rotary/push-
button v to highlight “Settings” in the
main destination input menu and press
to confirm.

Turn the right-hand rotary/push-
button v to highlight “Location...” and
press to confirm.
The input menu to enter the city will ap-
pear.

Enter the city/suburb and then the
street and select the required entries
from the corresponding list. See “Ente-
ring destination address”
(page 123).
After you have selected the street, you will
see a prompt for the intersection.

Turn the right-hand rotary/push-
button v to highlight the appropriate
cross street and press to confirm.
The input menu “Location/Intersec-
tion” will appear.
Location is ahead or behind an intersection
Turn the right-hand rotary/push-
button v to the right (location is
ahead) or to the left (location is behind)
and press to confirm.
The message “Chosen location accep-
ted” will appear.

Press the right-hand rotary/push-
button v to confirm.
Entering the vehicle location

181 Navigation
Settings
In order to ensure an exact fix on position,
you have to calibrate COMAND to new ti-
res every time tires are changed.
Turn the right-hand rotary/push-
button v to highlight “Settings” in the
main destination input menu and press
to confirm.
A menu of options will appear.
Menu “Settings”1Activate menu “Calibration”
Turn the right-hand rotary/push-
button v to highlight 1 and press to
confirm.
The menu “Calibration” will appear.2Enter the tread depth and the tire type
3Return to the main destination input
menu

Press the right-hand rotary/push-
button v to start calibration.
A menu of options will appear.
CalibrationiMercedes-Benz recommends that you
have tires changed by an authorized
Mercedes-Benz Center.

182 NavigationSettings4Tread depth
≥ 4 mm (3/16 in.)
5Tread depth < 4 mm (3/16 in.)

Turn the right-hand rotary/push-
button v to highlight the desired
menu field and press to confirm.
An input menu will appear.Enter the new tire type

Turn the right-hand rotary/push-
button v to highlight the apropriate di-
gits one by one and press to confirm.

Press the right-hand rotary/push-
button v longer than 2 seconds to
confirm the entry.
The main destination input menu will
appear.
iEnter the front axle tire parameters.
