Locking with keyless go MERCEDES-BENZ SL550 2007 R230 Owner's Manual

Contents
Introduction.......................................... 9
Product information ................................ 9
Operator’s Manual ............................... 10
Service and warranty information .. 10
Important notice for California
retail buyers and lessees of
Mercedes-Benz automobiles .......... 11
Maintenance .................................. 12
Roadside Assistance ...................... 12
Change of address or ownership.... 12
Operating your vehicle outside the
USA or Canada............................... 13
Where to find it .................................... 14
Symbols ............................................... 15
Operating safety .................................. 16
Proper use of the vehicle ............... 16
Problems with your vehicle .................. 17
Reporting safety defects...................... 18
Reporting safety defects ................ 18
Vehicle data recording ......................... 19
Information regarding electronic
recording devices ........................... 19
At a glance.......................................... 21
Exterior view ......................................... 22
Cockpit ................................................. 24
Instrument cluster ................................ 26
Multifunction steering wheel ................ 30
Center console ..................................... 31
Upper part ...................................... 31
Lower part ...................................... 32
Overhead control panel ........................ 33
Storage compartments ......................... 34
Door control panel................................ 36
Getting started................................... 37
Unlocking ............................................. 38
Unlocking with the SmartKey ......... 38
Unlocking with KEYLESS-GO*......... 39
Starter switch positions .................. 39
Adjusting .............................................. 42
Seats .............................................. 42
Steering wheel ................................ 45
Mirrors ............................................ 47
Driving .................................................. 49
Fastening the seat belts ................. 49
Starting the engine ......................... 52
Parking brake ................................. 54
Driving off ....................................... 54
Switching on headlamps ................. 55
Turn signals .................................... 56
Windshield wipers ........................... 57
Problems while driving.................... 59
Parking and locking .............................. 60
Parking brake ................................. 61
Switching off headlamps................. 61
Turning off the engine..................... 62
Releasing seat belts........................ 62
Locking ........................................... 63

ContentsSafety and Security........................... 65
Occupant safety................................... 66
Air bags .......................................... 68
Occupant Classification System ..... 72
Seat belts ....................................... 77
Roll bar ........................................... 81
Children in the vehicle .................... 83
Panic alarm .......................................... 86
Activating ....................................... 86
Deactivating ................................... 86
Driving safety systems ......................... 87
ABS ................................................ 87
BAS ................................................ 89
ESP
®............................................... 89
Electro-hydraulic brake system ...... 92
Anti-theft systems................................ 96
Immobilizer..................................... 96
Anti-theft alarm system .................. 96
Tow-away alarm ............................. 98
Controls in detail............................. 101
Locking and unlocking ....................... 102
SmartKey ..................................... 102
SmartKey with KEYLESS-GO* ...... 105
Opening the doors from the
inside ........................................... 111
Opening the trunk ........................ 111
Closing the trunk.......................... 113
Valet locking ................................ 117
Trunk lid emergency release ........ 117
Power closing assist for trunk lid . 118
Automatic central locking ............ 119
Locking and unlocking from the
inside ........................................... 119
Seats ................................................. 121
Moving the seats forward and
backward ..................................... 121
Lumbar support............................ 121
Multicontour backrest* ................ 122
Seat heating ................................. 123
Seat ventilation* .......................... 125
Memory function ............................... 126
Storing positions into memory ..... 127
Recalling positions from memory . 127 Lighting ............................................ 128
Exterior lamp switch .................... 128
Corner-illuminating front fog
lamps ........................................... 132
Combination switch ..................... 133
Hazard warning flasher ................ 133
Interior lighting ............................ 134
Courtesy lighting .......................... 135
Trunk lamp ................................... 135
Instrument cluster ............................. 136
Adjusting instrument cluster
illumination .................................. 136
Coolant temperature gauge ......... 137
Trip odometer .............................. 137
Tachometer.................................. 138
Outside temperature indicator ..... 138
Control system .................................. 139
Multifunction display.................... 139
Multifunction steering wheel........ 140
Menus .......................................... 142
Standard display menu ................ 145
AMG menu ................................... 146
AUDIO menu ................................ 149
NAV menu .................................... 151
Distronic* menu .......................... 151

39 Getting started
Unlocking
Unlocking with KEYLESS-GO*
With the KEYLESS-GO function, you can
lock and unlock the vehicle without using
the remote control buttons on the
SmartKey and start the engine without in-
serting the SmartKey in the starter switch.
The function of the SmartKey overrules the
KEYLESS-GO function.

Grasp an outside door handle.
All turn signal lamps flash once. The
locking knobs on the doors move up.
The anti-theft alarm system is dis-
armed.
The electro-hydraulic brake system is
activated.
If the SmartKey with KEYLESS-GO is inside
the vehicle, pressing the KEYLESS-GO
start/stop button on the gear selector le-
ver corresponds to turning the SmartKey
to the various starter switch positions
(
page 40).
For more information, see “SmartKey with
KEYLESS-GO*” (
page 105).
Starter switch positions
Warning!
G
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO* with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.i
To unlock the vehicle, the SmartKey with
KEYLESS-GO must be outside the vehicle, no
further than approx. 3 feet (1 meter) away from
the door.
i
If the vehicle has been parked for more than
72 hours, you must pull an outside door handle
in order to activate the KEYLESS-GO function.
i
Opening a door causes the windows on that
side of the car to open slightly. They will return to
the up-position when the door is closed.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or the SmartKey with
KEYLESS-GO* from the starter switch, take
it with you, and lock the vehicle. Do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment may
cause an accident and/or serious personal
injury.

40 Getting startedUnlockingSmartKeyStarter switch0For removing SmartKey
1Power supply for some electrical con-
sumers, such as seat adjustment
2Ignition (power supply for all electrical
consumers) and driving position
All lamps (except high beam headlamp
indicator lamp and turn signal indicator
lamps unless activated) in the instru-
ment cluster come on. If a lamp in the
instrument cluster fails to come on
when the ignition is switched on, have
it checked and replaced if necessary.If a lamp in the instrument cluster re-
mains on after starting the engine or
comes on while driving, refer to “Lamps
in the instrument cluster”
(
page 332).
3Starting position
SmartKey with KEYLESS-GO*
KEYLESS-GO start/stop button1USA only
2Canada only
i
When you switch on the ignition, the indica-
tor and warning lamps (except high beam head-
lamp indicator lamp and turn signal indicator
lamps unless activated) in the instrument cluster
come on. The indicator and warning lamps (ex-
cept high beam headlamp indicator lamp and
turn signal indicator lamps if activated) should go
out when the engine is running. This indicates
that the respective systems are operational.
i
The SmartKey can only be removed from the
starter switch with the gear selector lever in
position P.
!
If the SmartKey cannot be turned in the
starter switch, the starter battery may not be
sufficiently charged.


Check the starter battery and charge it if
necessary (
page 414).


Get a jump start (
page 419).
To prevent accelerated battery discharge or a
completely discharged battery, always remove
the SmartKey from the starter switch when the
engine is not in operation.

41 Getting started
Unlocking
The SmartKey with KEYLESS-GO must be
located in the vehicle.
Make sure the gear selector lever is set
toP.

Do not depress the brake pedal.
Position 0
Before you press the KEYLESS-GO
start/stop button, the vehicle’s on-board
electronics have the status0 (as with
SmartKey removed).
Position 1

Press the KEYLESS-GO start/stop
button once.
This supplies power for some electrical
consumers, such as seat adjustment.Ignition (or Position 2)

Press the KEYLESS-GO start/stop but-
ton twice.
This supplies power for all electrical
consumers. All lamps (except high
beam headlamp indicator lamp and
turn signal indicator lamps unless acti-
vated) in the instrument cluster come
on.For more information, see “SmartKey with
KEYLESS-GO*” (
page 105).
For information on starting the engine us-
ing the KEYLESS-GO start/stop button,
see “Starting with KEYLESS-GO*”
(
page 53).
i
If you now press the KEYLESS-GO
start/stop button


once again, the ignition (position2) is
switched on


twice, the power supply is again switched off
i
If you now press the KEYLESS-GO
start/stop button once, the power supply is
again switched off.
i
When you switch on the ignition, the indica-
tor and warning lamps (except high beam head-
lamp indicator lamp and turn signal indicator
lamps unless activated) in the instrument cluster
come on. The indicator and warning lamps
(except high beam headlamp indicator lamp and
turn signal indicator lamps if activated) should go
out when the engine is running. This indicates
that the respective systems are operational.

60 Getting startedParking and lockingYou have now completed your first drive.
You have properly stopped and parked
your vehicle. End your drive as follows.Warning!
G
With the engine not running, there is no
power assistance for the brake and steering
systems. In this case, it is important to keep
in mind that a considerably higher degree of
effort is necessary to brake and steer the ve-
hicle.
Warning!
G
Do not park this vehicle in areas where com-
bustible materials such as grass, hay or
leaves can come into contact with the hot
exhaust system, as these materials could be
ignited and cause a vehicle fire.
To reduce the risk of personal injury as a re-
sult of vehicle movement, before
turning off
the engine and leaving the vehicle always:


Keep right foot on brake pedal.


Firmly depress parking brake pedal.


Move the gear selector lever to
positionP.


Slowly release brake pedal.


When parked on an incline, turn front
wheels towards the road curb.


Turn the SmartKey in the starter switch
to position0 and remove the SmartKey
from the starter switch, or press the
start/stop button (vehicles with
KEYLESS-GO*).


Take the SmartKey or the SmartKey with
KEYLESS-GO* and lock vehicle when
leaving.

61 Getting started
Parking and locking
Parking brake
1Release handle
2Parking brake pedal
Step firmly on parking brake pedal2.
When the engine is running, the indica-
tor lamp;(USA only) or3
(Canada only) in the instrument cluster
will be illuminated.
Switching off headlamps
Turn the exterior lamp switch to posi-
tion M (
page 55).
For more information, see “Exterior lamp
switch” (
page 128).
Warning!
G
When leaving the vehicle, always remove the
SmartKey or the SmartKey with
KEYLESS-GO* from the starter switch, take
it with you, and lock the vehicle. Do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. Children
could release the parking brake and/or
move the gear selector lever from
positionP, either of which could result in an
accident and/or serious injury.
Warning!
G
Getting out of your vehicle with the gear se-
lector lever not fully engaged in positionP is
dangerous. Also, when parked on an incline,
positionP alone may not prevent your vehi-
cle from moving, possibly hitting people or
objects.
Always set the parking brake in addition to
shifting to positionP (
page 170).
When parked on an incline, also turn front
wheels towards the road curb.

62 Getting startedParking and lockingTurning off the engine
Place the gear selector lever in
positionP.

Apply the parking brake (
page 61).
Turning off with the SmartKey

Turn the SmartKey in the starter switch
to position0 (
page 40).

Remove the SmartKey from the starter
switch.
The immobilizer is activated.Turning off with KEYLESS-GO*

Place the gear selector lever in
positionP.

Press the KEYLESS-GO start/stop but-
ton (
page 40) to turn off the engine.
With the driver’s door closed, the start-
er switch is now in position1. With the
driver’s door opened, the starter switch
is set to position0, same as SmartKey
removed from starter switch
(
page 40).
Releasing seat belts
Press the seat belt release button
(page 50).
Allow the retractor to completely re-
wind the seat belt by guiding the latch
plate.
i
Always set the parking brake in addition to
shifting to positionP.
On slopes, turn the front wheels towards the
road curb.
i
The SmartKey can only be removed from the
starter switch with the gear selector lever in
positionP.
i
With the SmartKey removed and the driver’s
door open, a warning sounds if the vehicle’s
exterior lamps are not switched off.
i
If you hear a warning signal you have tried to
turn off the engine while the gear selector lever
was not inP.
In addition, the message
Gear selector
lever to P
appears in the multifunction dis-
play.
Place the gear selector lever in positionP.
!
M a k e s u r e t h e s e a t b e l t r e t r a c t s f u l l y s o t h a t
the seat belt and/or latch plate cannot get
caught or pinched in the door or in the seat
mechanism. This can damage the seat belt and
impair the effectiveness of the seat belt, and/or
cause damage to the door and/or door trim
panel. Such damage is not covered by the
Mercedes-Benz Limited Warranty.
Damaged seat belts must be replaced. Contact
an authorized Mercedes-Benz Center.

63 Getting started
Parking and locking
Locking

Exit the vehicle and close the doors and
the trunk.Locking with the SmartKey

Press the lock button‹on the
SmartKey (
page 38).
With the trunk and all doors closed, all
turn signal lamps flash three times. The
locking knobs on the doors move
down. The anti-theft alarm system is
armed.
For more information, see “Locking and
unlocking” (
page 102).
Warning!
G
To prevent possible personal injury, always
keep hands and fingers away from the door
openings when closing the doors. Be espe-
cially careful when small children are
around.
Before closing doors, make sure that there
is no possibility of someone getting caught
in a door during closing.Warning!
G
When leaving the vehicle, always remove the
SmartKey or the SmartKey with
KEYLESS-GO* from the starter switch, take
it with you, and lock the vehicle. Do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment may
cause an accident and/or serious personal
injury.
i
If you hear a warning signal you have forgot-
ten to turn off the headlamps.
In addition the message
Turn off lights
ap-
pears in the multifunction display.
Switch off the headlamps.
i
Vehicles with KEYLESS-GO*: A warning sig-
nal and the message
Don’t forget your key

remind you not to leave the SmartKey with
KEYLESS-GO* in the vehicle.
i
Opening a door causes the windows on that
side of the car to open slightly. They will return to
the closed position when the door is closed.

64 Getting startedParking and lockingLocking with KEYLESS-GO*
1Lock button
Press lock button1 on a door handle
or the lock button on the trunk lid
(page 110).
With the trunk and all doors closed, the
turn signal lamps flash three times. The
locking knobs on the doors move
down. The anti-theft alarm system is
armed.
For more information, see “Locking and
unlocking” (
page 102).
