139 Controls in detail
Control system
Standard display menu
You can select the functions in the stan-
dard display menu with button k or
j.
The following functions are available:
Display digital speedometer
Press button j once.
The current vehicle speed is shown in
the right multifunction display.
AUDIO menu
The functions in the
AUDIO
menu operate
the audio equipment which you currently
have turned on.
If no audio equipment is currently turned
on, the message
AUDIO off
is shown in the
right display.
The following functions are available:
iThe headings used in the menus table
are designed to facilitate navigation
within the system and are not neces-
sarily identical to those shown in the
control system displays.
The first function displayed in each
menu will automatically show you
which part of the system you are in.
Function
Page
Calling up digital speedometer
139
Calling up maintenance service
indicator
313
Checking tire inflation pressure
290
Checking engine oil level
272
Function
Page
Selecting radio station
140
Selecting satellite radio
station* (USA only)
140
Operating CD player
141

142 Controls in detailControl systemNAV menu
The
NAV
menu contains the functions need-
ed to operate your navigation system.

Press button è or ÿ repeatedly
until you see the message
NAV
in the
left multifunction display.
The message shown in the multifunction
display depends on the status of the navi-
gation system:


When the navigation system is off, the
message
NAV off
appears in the multi-
function display.


When the navigation system is on, the
message
HEADING
appears in the left
multifunction display and the destina-
tion in the right multifunction display.
Please refer to the COMAND manual for in-
structions on how to activate the route
guidance system.
Distronic* menu
Use the Distronic menu to display the cur-
rent settings for your Distronic system.
What information is shown in the left mul-
tifunction display depends on whether the
Distronic system is active or inactive.
Please refer to the “Driving systems” sec-
tion of this manual (
page 208) for in-
structions on how to activate Distronic.

Press button è or ÿ repeatedly
until you see one of the following two
pictures in the display.Distronic deactivated
When Distronic is deactivated you will see
the standard display in the left multifunc-
tion display.
1Vehicle ahead, if detected
2Actual distance to vehicle ahead
3Preset distance threshold to vehicle
ahead
4Your vehicle
5Symbol for activated distance warning
function

244 Controls in detailUseful features
Remote door unlock
In case you have locked your vehicle unin-
tentionally (e.g. SmartKey inside vehicle),
and the reserve SmartKey is not handy:
Contact the Mercedes-Benz Response
Center at 1-800-756-9018 (in the USA)
or 1-888-923-8367 (in Canada).
You will be asked to provide your pass-
word which you provided when you
completed the subscriber agreement.

Then return to your vehicle and pull the
trunk recessed handle for a minimum
of 20 seconds until the SOS button is
flashing.
The message
Call connected
appears
in the multifunction display.
As an alternative, you may unlock the vehi-
cle via Internet using the ID and password
sent to you shortly after the completion of
your acquaintance call.
iThe indicator lamp in the respective
button flashes until the call is conclud-
ed. Calls can only be terminated by a
Response Center or Customer Assis-
tance Center representative except
Roadside Assistance and Information
calls, which can also be terminated by
pressing button ì on the multifunc-
tion steering wheel or the respective
button for ending a telephone call on
the COMAND headunit.
iWhen a Tele Aid call has been initiated,
the COMAND system audio is muted
and the selected mode (radio or CD)
pauses. The optional cellular phone (if
installed) switches off. If you must use
this phone, the vehicle must be parked.
Disconnect the coiled cord and place
the call. The COMAND navigation sys-
tem (if engaged) will continue to run.
The display in the instrument cluster is
available for use and spoken com-
mands are only available by pressing
the RPT button on the COMAND unit. A
pop-up window will appear in the
COMAND display to indicate that a Tele
Aid call is in progress.

440 Technical termsCAN system
(C
ontroller A
rea N
etwork)
Data bus network serving to control ve-
hicle functions such as door locking or
windshield wiping depending on vehi-
cle settings and/or ambient condi-
tions.
Cockpit
All instruments, switches, buttons and
indicator/warning lamps in the passen-
ger compartment needed for vehicle
operation and monitoring.
Collapsible tire
An especially compact spare tire that
must be inflated with a provided air
pump before using. It should only be
used to bring the vehicle to the nearest
service station.COMAND
(Co
ckpit Man
agement and
D
ata System)
Information and operating center for
vehicle sound and communications
systems, including the radio, CD
changer and navigation system, as well
as other optional equipment (e.g. tele-
phone).
Control system
The control system is used to call up
vehicle information and to change
component settings. Information and
messages appear in the multifunction
display. The driver uses the buttons on
the multifunction steering wheel to
navigate through the system and to ad-
just settings.
Cruise control
Driving convenience system for auto-
matically maintaining the vehicle speed
set by the driver.Distronic*
A driving convenience cruise control
system which helps the driver maintain
a pre-selected speed:


If there is no vehicle directly ahead,
the system operates in the same
way as conventional cruise control.


If a slower moving vehicle is ahead,
Distronic* will reduce your vehicle
speed to the extent permitted by re-
duced throttle and up to 20% brak-
ing power to maintain the preset
minimum following distance.
DTR
(->Distr
onic*)
Engine number
The number set by the manufacturer
and placed on the cylinder block to
uniquely identify each engine pro-
duced.

441 Technical terms
ESP
(E
lectronic S
tability P
rogram)
Improves vehicle handling and direc-
tional stability.
ETD
(E
mergency Tensioning D
evice)
Device which deploys in certain frontal
and rear collisions exceeding the sys-
tem's threshold to tighten the seat
belts.
->SRS
FSS (Canada vehicles)
(F
lexible S
ervice S
ystem)
Service indicator in the multifunction
display that informs the driver when
the next vehicle maintenance service is
due.
Gear range
Number of gears which are available to
the automatic transmission for shifting.
The automatic gear shifting process
can be adapted to specific operating
conditions using the gear selector le-
ver.GPS
(G
lobal P
ositioning S
ystem)
Satellite-based system for relaying
geographic location information to and
from vehicles equipped with special re-
ceivers. Employs CD digital maps for
navigation.
Head-thorax airbag
Installed in the doors, these airbags
protect occupants during side impact
collisions exceeding a preset thresh-
old. Unlike normal side airbags,
head-thorax airbags are also designed
to provide protection for the head area.
Instrument cluster
The displays and indicator/warning
lamps in the driver’s field of vision, in-
cluding the tachometer, speedometer,
engine temperature and fuel gauge.
KEYLESS-GO*
System for entering and operating the
vehicle without the use of a key. Kickdown
Depressing the accelerator past the
point of resistance shifts the transmis-
sion down to the lowest possible gear.
This very quickly accelerates the vehi-
cle and should not be used for normal
acceleration needs.
Lock button
Button on the door which indicates
whether the door is locked or un-
locked. Pushing the lock button down
on an individual door from inside will
lock that door.
Maintenance System (U.S. vehicles)
Maintenance service indicator in the
multifunction display that informs the
driver when the next vehicle mainte-
nance service is due. The Maintenance
system tracks distance driven and teh
time elapsed since the last mainte-
nance service, calculates other mainte-
nance service work required, and calls
for the next service accordingly.

457 Index
Multifunction display messages
ABC 337
ABS 338
Battery 345, 346
Brake pads 346
Brake system 350
CHECK ENGINE 351
Coolant 352
Coolant level 351, 353
Display malfunction 354
Doors 354
Easy-entry/exit feature 354
Fuel reserve tank 357
Hood 357
Luggage cover 371
Retractable hardtop 357
Roll bar 364
SBC brake system 347, 348
Seat belts 364
SmartKey 357
SmartKey with KEYLESS-GO* 359
Tele Aid 364
Telephone* 364Tires 365
Trunk 371
Washer fluid 371
Multifunction steering wheel 28, 135,
442
Buttons 135
N
Navigation system
Operating 142
Night security illumination 154
Normal occupant weight 306
O
Occupant distribution 306
Octane number 443
Odometer, main 25
Oil
Adding 274
Consumption 272
Filler neck 274
Oil level
Checking 269One-touch gearshifting 166
Canceling gear range limit 166
Downshifting 166
Upshifting 166
Opening
Doors from the inside 106
Fuel filler flap 267
Hood 270
Luggage cover 197
Retractable hardtop (SmartKey) 200
Retractable hardtop (switch) 197
Side windows 194
Storage compartment in the
armrest 230
Storage compartment in the center
console 230
Sunshade 204
Trunk from inside vehicle 108
Trunk lid 107
Windows 193

458 IndexOperating
CD player 141
Navigation system 142
Radio 140
Telephone* 161
Overhead control panel 31
Overspeed range 132, 442
P
Panic alarm 78
Panic button on SmartKey 78
Panorama roof*
Sunshade 203
Sunshade closing 204
Sunshade opening 204
Parcel net in passenger footwell 231
Parcel net in trunk 231
Parktronic* deactivation switch 30
Parking 259
Parking assistance (Parktronic*) 223
Parking brake
Engaging 57
Releasing 50
Parking brake pedal 23Parking lamps 381
Replacing the bulbs 384
Switching on 123
Parking position
Exterior rear view mirrors 121, 158,
179
Parktronic* 30, 223, 442
Activating 226
Cleaning system sensors 318
Deactivating 226
Malfunctioning 227
Minimum distance 225
Range 224
Rear sensors 225
System sensors 318
Warning indicators 23, 225
Parts service 416
Passenger side
Front airbag 68
Head-thorax airbag 69
Parcel net in footwell 231Pedals 255
Phone book* 162
Loading 163
Quick search 163
Phone number*
Dialing 162
Redialing 163
Plastic and rubber parts
Cleaning 321
Poly-V-belt drive 442
Layout 419
Potential problems associated with under-
inflated and overinflated tires 294
Power assistance 256
Power seat
Adjusting backrest tilt 41
Adjusting head restraint height 41
Adjusting head restraint tilt 41
Adjusting seat cushion depth 41
Adjusting seat cushion tilt 41
Adjusting seat height 41
