450 Technical dataFuels, coolants, lubricants, etc.To provide important corrosion protection,
the solution must be at least 45% anticor-
rosion/antifreeze (equivalent to freeze
protection to approx. - 22°F [-30°C]). If
you use a solution that is more than 55%
anticorrosion/antifreeze (freeze protec-
tion to approx. - 49°F [-45°C]), the engine
temperature will increase due to the lower
heat transfer capability of the solution.
Therefore, do not use more than this
amount of anticorrosion/antifreeze.If the coolant level is low, water and
MB 325.0 Anticorrosion/Antifreeze
should be used to bring it up to the proper
level (have cooling system checked for
signs of leakage). Please make sure the
mixture is in accordance with label instruc-
tions.
The water in the cooling system must meet
minimum requirements, which are usually
satisfied by normal drinking water. If you
are not sure about the water quality, con-
sult an authorized Mercedes-Benz Center.

451 Technical data
Fuels, coolants, lubricants, etc.
Anticorrosion/antifreeze
Your vehicle contains a number of alumi-
num parts. The use of aluminum compo-
nents in motor vehicle engines
necessitates that anticorrosion/antifreeze
coolant used in such engines be specifical-
ly formulated to protect the aluminum parts. (Failure to use such anticorro-
sion/antifreeze coolant will result in a sig-
nificantly shortened service life.)
Therefore, the following product is strongly
recommended for use in your vehicle:
Mercedes-Benz 325.0 anticorrosion/anti-
freeze agent.Before the start of the winter season (or
once a year in hot southern regions), you
should have the anticorrosion/antifreeze
concentration checked. The coolant is also
regularly checked each time you bring your
vehicle to an authorized Mercedes-Benz
Center for service.
Anticorrosion/antifreeze quantityModel
Approx. freeze protection
– 35°F (– 37°C)
– 49°F (– 45°C)
SL 550
6.1 US qt (5.8 l)
6.8 US qt (6.4 l)
SL 600 (main cooling system)
6.9 US qt (6.5 l)
7.5 US qt (7.1 l)
SL 600 (low temperature cooling system)
1.2 US qt (1.1 l)
1.3 US qt (1.2 l)
SL 55 AMG
6.3 US qt (6.0 l)
7.0 US qt (6.6 l)
SL 65 AMG (main cooling system)
8.2 US qt (7.75 l)
9.0 US qt (8.5 l)
SL 65 AMG (low temperature cooling system)
1.5 US qt (1.45 l)
1.7 US qt (1.6 l)

452 Technical dataFuels, coolants, lubricants, etc.Windshield and headlamp washer system
Both the windshield and headlamp washer
systems are supplied from the windshield
washer fluid reservoir.
The windshield and headlamp washer fluid
reservoir has a capacity of approx.
7.4 US qt (7 l).
Refill the reservoir with MB Windshield
Washer Concentrate and water (or con-
centrate and commercially available
premixed windshield washer
solvent/antifreeze, depending on am-
bient temperatures).Windshield and headlamp washer fluid
mixing ratio
For temperatures above freezing point, use
MB Windshield Washer Concentrate
“MB SummerFit” and water:


1 part “MB SummerFit” to 100 parts
water
(1.34 fl oz [40 ml] “MB SummerFit” to
1gal [4.0l] water)
For temperatures below freezing point, use
MB Windshield Washer Concentrate
“MB SummerFit” and commercially avail-
able premixed windshield washer
solvent/antifreeze:


1 part “MB SummerFit” to 100 parts
solvent
(1.34 fl oz [40 ml] “MB SummerFit” to
1 gal [4.0 l] solvent)
Warning!
G
Washer solvent/antifreeze is highly flamma-
ble. Do not spill washer solvent/antifreeze
on hot engine parts because it may ignite
and burn. You could be seriously burned.

453 Index
A
ABC 225
Messages in display 349
Oil level 279
ABS 87
Indicator lamp 29, 334
Messages in the multifunction
display 351, 352
Warning lamp 27, 332
Accelerator position, automatic
transmission 171
Accessory weight 312
Accident 59
Active Body Control see ABC
Air bags 68
Children in the vehicle 83
Front 71
Front passenger front air bag off
indicator lamp 76
Head-thorax 72
Knee bag 72
Occupant Classification System
(OCS) 72
Passenger 72
Air conditioning system see Automatic cli-
mate control systemAir distribution 188, 189
Air pressure 312
Tire inflation pressure 291
Air pump 410
Air recirculation mode 191
Air vents 185
Air volume 188, 190
Alarm system see Anti-theft systems
Alignment bolt (vehicle tool kit) 409
Anticorrosion/antifreeze 445, 451
Antiglare, Interior rear view mirror 180
Antilock Brake System see ABS
Anti-theft systems
Anti-theft alarm system 96
Immobilizer 96
Tow-away alarm 98
Aquaplaning see Hydroplaning
Armrest 234
Ashtray 31, 239
Aspect ratio 312
ATF 279
Auto-dimming, Rear view mirrors 180
Automatic central locking 119
Control system 162Automatic climate control system 184
Air conditioning, Cooling 193
Air conditioning refrigerant 446
Air distribution 188, 189
Air recirculation mode 191
Air vents 185
Air volume 188, 190
Control panel 185
Deactivating system 187
Defrosting 183, 190
Residual heat utilization 194
Temperature 188
Temperature sensor 33
Ventilated glove box 195
Automatic lighting control, Interior
lighting 135
Automatic locking when driving 119
Automatic shift program 173
Automatic transmission 168
Accelerator position 171
Comfort program mode 173
Emergency operation
(Limp-Home Mode) 179
Gear ranges 172
Gear selector lever 32, 168
Gear selector lever position 168, 170

454 Index
Gear shifting malfunctions 179
Kickdown 171
Manual shifting 174
One-touch gearshifting 174
Program mode selector switch 32,
173
Starting the engine 52
Transmission fluid level 279
Automatic Transmission Fluid see ATF
B
Backrest
Lumbar support 122
Multicontour seat* 122
Power seat 44
Shoulder region support 122
Backup lamp
Messages in the multifunction
display 382
Replacing bulb 398, 402
Bar 312
BAS 89
Batteries, SmartKey
Checking battery condition 105
Replacing 395Batteries, SmartKey with KEYLESS-GO*
Checking battery condition 110
Replacing 395
Batteries, Vehicle 281
Charging 417
Consumer battery 281, 389, 414
Jump starting 419
Messages in the multifunction
display 366
Starter battery 281, 414
Bead 312
Bi-Xenon headlamps* 398
Block heater (Canada only) 317
Brake Assist System see BAS
Brake lamps 398
High mounted 398
Messages in the multifunction
display 380
Brake pads
Messages in the multifunction
display 366
Brake system
Messages in the multifunction
display 370Brakes 260
BAS 89
Brake fluid 272, 445, 447
Electro-hydraulic brake system 92
High-performance brake system (AMG
vehicles only) 262
Warning lamp 335
Break-in period 258
Bulbs
Messages in the multifunction
display 380
Replacing 397
C
California retail buyers and lessees,
important notice for 11
Call priority, Tele Aid 249
Capacities and recommended
fuel/lubricants 444
Cargo area see Trunk
Carpets, cleaning 329
Catalytic converter 269
CD changer 150
CD player 150
Operating 151

455 Index
Center console
Lower part 32
Upper part 31
Central locking
Automatic 119, 162
Central locking/unlocking switch 31,
119
Locking/unlocking from inside 119
Certification label 430
Check engine see Lamps, indicator and
warning
Checking tire pressure electronically with
the Advanced Tire Pressure Monitoring
System (Advanced TPMS)*,
(Canada only) 298
Children in the vehicle
Air bags 83
Front passenger front air bag off indica-
tor lamp 76, 345
Infant and child restraint systems 83
Occupant Classification System
(OCS) 72
Cigarette lighter 239
Clock 25, 157
Cockpit 24
Cold tire inflation pressure 312COMAND system 31
Driving instructions 268
Combination switch
High beam 56, 133
Turn signals 56
Windshield wipers 57
Consumer battery 281
Control and operation of radio
transmitters 268
Control system 139, 142
Control system menus
AMG Menu 146
AUDIO 149
NAV 151
Settings 153
Standard display 145
TEL* 165
Trip computer 163
Vehicle status message memory 152
Control system submenus 143
Convenience 162
Instrument cluster 156
Lighting 159
Time 157
Vehicle 162
Convenience feature 201Coolant 449
Anticorrosion/antifreeze mixing ratio
and quantity 451
Checking coolant level 280
Coolant warning lamp 337
Messages in the multifunction
display 371, 373
Temperature 270
Temperature gauge 137
Corner-illuminating front fog lamps 132
Corner-illuminating front fog lamps*
Replacing bulbs 397
Courtesy lighting 135
Cruise control 209
Messages in the multifunction
display 352, 353
Cup holder 238
Curb weight 312
D
Daytime running lamp mode 130
Setting 159
Deep water see Standing water
Defogging, Windshield 191
Defrosting, Front 190
Defrosting, Rear 183

456 IndexDelayed switch-off
Exterior lamps 160
Interior lighting 161
Department of Transportation see DOT
Difficulties
While driving 59
With starting the engine 53
Digital clock see Clock
Digital speedometer 145
Dimensions, Vehicle 442
Dipstick see Oil dipstick
Direction of rotation (tires) 286
Displays
Digital speedometer 145
Distronic* 215
Maintenance service indicator 319
Multifunction display 139
Outside temperature 138, 145
Symbol messages 365
Text messages 349
Vehicle status message memory 152
Vehicle status messages 347
Distance to empty (range), Trip
computer 165Distance warning function* 224
Activating 225
Deactivating 225
Intermittent warning sound 224
Symbol 217
Distronic indicator lamp* 27
Distronic* 213
“Resume” function 220
Activating 218
Cleaning system sensor cover 325
Control system 151, 217
Distance warning function 224
Driving hints 222
System sensor cover 325
Warning and indicator lamps 215,
216, 224, 339
Door
Control panel 36
Handle, Inside 36
Locking/unlocking,
KEYLESS-GO* 39, 64
Locking/unlocking, Mechanical
key 391, 393
Locking/unlocking, SmartKey 38, 63
Messages in the multifunction
display 374Opening from inside 111
Storage compartment 233
Door control panel 36
Door handle 36
DOT 312
Drinking and driving 259
Driving
Abroad 268
Driving off 262
Electro-hydraulic brake system 95
Hydroplaning 264
In winter 266, 316
Instructions 54, 259
Problems 59
Safety systems 87
Systems 209
Through standing water 267
With Distronic* 222
Driving safety systems 87
ABS 87
BAS 87, 89
Electro-hydraulic brake system 87,
92
Electronic traction system 91
ESP
®
87, 89

457 Index
Driving systems 209
ABC 225
Cruise control 209
Distronic* 213
Parktronic* 228
DTR see Distronic*
E
Easy-entry/exit feature 46, 162
Messages in the multifunction
display 375
Electric air pump 389, 410
Electrical outlet see Power outlet
Electro-hydraulic brake system 87, 92
Activation 93
Deactivation 94
Driving hints 95
Messages in the multifunction
display 367, 368
Self-check 94
Warning lamp 92
Electronic Stability Program see ESP
®
Emergency calls
Tele Aid 244, 245
Emergency engine shut-down 426
Emergency operation (Limp-Home
Mode) 179Emergency operations
Automatic transmission (Limp-Home
Mode) 179
Glove box, Unlocking 392
Load assist, Lowering 394
Locking/unlocking the vehicle 391,
393
Remote door unlock, Tele Aid 250
Trunk lid, Releasing from the
inside 117
Trunk lid, Unlocking 392
Emergency Tensioning Device see ETD
Emission control 269
Information label 431
System warranties 10
Vacuum line routing diagram
label 431
Engine
Block heater (Canada only) 317
Break-in recommendations 258
Cleaning 324
Compartment 274
Malfunction indicator lamp 29, 336
Number 431
Poly-V-belt layout 432
Starting 52Tachometer 29
Technical data 433
Turning off 62
Engine coolant see Coolant
Engine oil 275, 446
Adding 278, 444
Additives 446
Checking level, With control
system 276
Checking level, With oil dipstick 278
Consumption 275
Filler neck 278, 279
Messages in the multifunction
display 277, 375
Oil dipstick 278
ESP
®
87, 89
Switch 32
Switching off 91
Switching on 92
Synchronizing 355
Warning lamp 27, 332
ETD 81
Safety guidelines 70
Warning and indictor lamps 342
Exterior lamp switch 128
Exterior rear view mirrors 48, 180

458 IndexF
Filler neck, Engine oil 278, 279
First aid kit 388
Flat tire 405
Preparing the vehicle 405
Spare wheel 388, 405
Flexible Service System see FSS
Fluids
Automatic climate control
system 444
Automatic transmission 279, 444
Brake system 272, 444, 447
Capacities 444
Engine coolant 280, 444, 449
Engine oil 275, 444, 446
Power steering 444
Retractable hardtop, Hydraulics 444
Windshield washer and headlamp
cleaning system 444
Fog lamps 131
Messages in the multifunction
display 380, 382
Replacing bulbs 398
Front air bags 71
Front lamps see HeadlampsFront passenger front air bag
Messages in the multifunction
display 356–359
Front passenger front air bag off indicator
lamp 76, 345
FSS (Canada only) 319
Fuel 271
Additives 448
Capacity, Fuel tank 444
Consumption statistics 163
Filler flap 271
Fuel reserve warning lamp 29, 339
Gasoline additives 448
Gauge 29
Premium unleaded gasoline 272,
445, 447
Refueling 271
Requirements 448
Fuel filler flap
Opening 271
Fuels, coolants, lubricants etc.
Capacities 444
Functions (control system) 141
Fuse chart see Vehicle tool kit
Fuses 424G
Garage door opener 251
Gasoline see Fuel
GAWR 312
Gear range
Automatic transmission 172
Canceling limit 175
Indicator 29
Limiting 172
Shifting into optimal 175
Gear selector lever 32, 168
Cleaning 328
Lock 52
Position 168, 170
Global locking/unlocking see Key
Glove box 233
Good visibility 180
Gross Axle Weight Rating see GAWR
Gross Vehicle Weight Rating see GVWR
Gross Vehicle Weight see GVW
GVW 312
GVWR 313

459 Index
H
Hard plastic trim items, cleaning 328
Hardtop see Retractable hardtop
Hazard warning flasher 133
Head restraints 44
Headlamp switch-off delay see Delayed
switch-off, exterior lamps
Headlamps
Automatic mode 129
Cleaning lenses 325
Cleaning system 180
Manual mode 129
Messages in the multifunction
display 380
Replacing bulbs 397
Switch 55, 128
Headliner, cleaning 329
Head-thorax air bag 72
Heated steering wheel* 240
High beam flasher 56, 133
High beam headlamps 56, 128, 398
Indicator lamp 29
Messages in the multifunction
display 380
Replacing bulbs 397, 400
Switching on 133High mounted brake lamp 398
High-performance brake system
(AMG vehicles only) 262
Hood 274
Messages in display 377
Opening 274
Horn 25
HVAC see Automatic climate control
Hydroplaning 264
I
Identification labels 430
Identification number, Vehicle (VIN) 431
Ignition 40
Immobilizer 96
Indicator lamps see Lamps, indicator and
warning
Infant and child restraint systems 83
Infant and child restraint systems see
Children in the vehicle
Inflation pressure see
Tires, Inflation pressure
Inside door handle 111Instrument cluster 26, 136
Illumination brightness 136
Lamps 332
Language 156
Messages in the multifunction
display 26, 347
Multifunction display 139
Instrument lighting see Instrument cluster,
Illumination brightness
Instrument panel see Instrument cluster
Instruments and controls see Cockpit
Interior lighting 134
Delayed switch-off 161
Interior rear view mirror 48
Antiglare position 180
Auto-dimming 180
J
Jack 389
Jacking up the vehicle 406
Jump starting 419
