coolant capacity MERCEDES-BENZ SL600 2000 R129 Owner's Manual

183 Driving insturctions
Technical
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Winter driving
Have your vehicle winterized at your authorized
Mercedes-Benz Center before the onset of winter.
• Change the engine oil if the engine contains an oil
which is not approved for winter operation. For
viscosity (SAE/CCMC class) and filling quantity,
see page 276.
• Check engine coolant anticorrosion/antifreeze
concentration.
• Additive for the windshield washer and headlamp
cleaning system: Add MB Concentrate “S” to a
premixed windshield washer solvent/antifreeze
which is formulated for below freezing
temperatures, see page 88.
• Test battery: Battery capacity drops with decreasing
ambient temperature. A well charged battery helps
to ensure that the engine can be started, even at low
ambient temperatures.
• Tires: We recommend M+S rated radial-ply tires on
all four wheels for the winter season. Observe
permissible maximum speed for M+S rated
radial-ply tires and the legal speed limit.Note:
In winter operation, the maximum effectiveness of the
antilock brake system (ABS) or electronic stability
program (ESP) can only be achieved with M+S rated
radial-ply tires and/or snow chains recommended by
Mercedes-Benz. Snow chains maximize performance.
Block heater (for Canada only)
The engine is equipped with a block heater.
The electrical cable may be installed at your authorized
Mercedes-Benz Center.

225 Coolant level
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hintsCar care Index Windshield and headlamp washer fluid mixing ratio
1Windshield washer/headlamp cleaning system
fluid reservoir
Ve h i c l e s w i t h o u t A D S :
Capacity approx. 5.3 US qt (5.0 l)
Ve h i c l e s w i t h A D S :
Capacity approx. 3.2 US qt (3.0 l)The reservoir should be refilled with MB Windshield
Washer Concentrate and water (or concentrate
commercially available premixed windshield washer
solvent / antifreeze, depending on ambient
temperatures).
For temperatures above freezing:
MB Windshield Washer Concentrate “S” and water.
1 part “S” to 100 parts water
(40 ml “S” to 1 gallon water)
For temperature below freezing:
MB Windshield Washer Concentrate “S” and
commercially available premixed windshield washer
solvent/antifreeze.
1 part “S” to 100 parts solvent
(40 ml “S” to 1 gallon solvent).
1
P82.35-0231-26

276 Fuels, coolants, lubricants etc. - capacities
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Fuels, coolants, lubricants etc. - capacities
Veh icle c omponents and t heir respec tive lub rica nts mu st ma tch . T herefore u se only brands tested and rec omm end ed
by us. Please refer to the Factory Approved Service Products pamphlet, or inquire at your Mercedes-Benz Center.
Model Capacity Fuels, coolants, lubricants etc.
Engine with oil filter SL 500
SL 6008.5 US qt (8.0 l)
10 . 6 U S q t ( 10 . 0 l )Recommended engine oils
Automatic transmission 9.6 US qt (9.1 l) Automatic transmission fluid
Rear axle 1.5 US qt (1.4 l) Hypoid gear oil SAE 90, 85 W 90
Hydraulic system for
adaptive damping
system (ADS)approx. 4.8 US qt (4.5 l) MB Hydraulic fluid
Power steering approx. 1.1 US qt (1.0 l) MB Power steering fluid
Front wheel hubs approx. 2.1 oz (60 g) each High temperature roller bearing grease
Accelerator control
linkageHydraulic fluid
Brake system approx. 0.5 US qt (0.5 l) MB Brake fluid (DOT 4)

277 Fuels, coolants, lubricants etc. - capacities
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Windshield washer
and/headlamp cleaning
systemVehicles without ADS:
approx. 5.3 US qt (5.0 l)
Ve h i c l e s w i t h A D S :
approx. 3.2 US qt (3.0 l)MB Windshield washer concentrate “S”
1
Cooling system SL 500
SL 600approx. 13.2 US qt (12.5 l)
approx. 21.1 US qt (20.0 l)MB Anticorrosion/antifreeze
Fuel tank
including a reserve ofapprox. 21.1 US gal (80.0 l)
approx. 2.6 US gal (10.0 l)Premium unleaded gasoline:
Posted octane 91 (Avg. of 96 RON/86 MON)
Air conditioner system R-134a refrigerant and special PAC lubricant
(Never R-12)1 Use MB Windshield Washer Concentrate “S” and water for temperatures above freezing or MB Windshield Washer Concentrate “S” and
commercially available premixed windshield washer solvent/antifreeze for temperatures below freezing. Follow suggested mixing ratios,
see page 225.
Model Capacity Fuels, coolants, lubricants etc.

286
Technical
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
BBabySmart
TM airbag deactivation system ..................... 58
Self-test ......................................................................... 59
Backrest ............................................................................. 48
BAS (Brake assist system) ............................................ 188
Malfunction indicator lamp .....................................207
Battery .............................................................................236
Charge indicator lamp .............................................. 211
Recycling ....................................................................237
Brake assist system (BAS) ............................................ 188
Brake fluid ......................................................................278
Capacity ...................................................................... 276
Brake pad wear indicator lamp ....................................205
Brake warning lamp ......................................................204
CCatalytic converter ........................................................ 163
Central locking system ................................................... 30
Automatic central locking ......................................... 38
Central locking switch ............................................... 37
General notes ............................................................... 34
Locking and unlocking with remote control .......... 31
Remote control ..................................................... 28, 30Remote control – changing batteries ..................... 251
Vehicle keys .................................................................28
Changing wheels ........................................................... 230
Charge indicator lamp ................................................... 211
Check engine malfunction indicator lamp ................ 204
Check regularly and before a long trip ...................... 202
Checking engine oil level .............................................221
Checking engine oil level indicator .............................. 82
Cleaning and care of the vehicle ................................. 261
Clock .................................................................................. 79
Combination switch .........................................................86
Console storage compartments ....................................127
Consumer information ................................................. 282
Control and operation of radio transmitters .............. 153
Coolant
Adding coolant .......................................................... 224
Anticorrosion/antifreeze quantity .........................281
Checking level .......................................................... 223
Coolants ..................................................................... 280
Low engine coolant level warning lamp ............... 209
Temperature gauge .....................................................78
Cruise control ................................................................. 185
Cup holder .............................................................. 128, 264
