maintenance reset MERCEDES-BENZ SL600 2008 R230 Owner's Manual

Contents
Maximum tire load ....................... 319
Maximum tire inflation pressure .. 319
Uniform Tire Quality Grading
Standards (U.S. vehicles) ............. 320
Tire ply material ........................... 322
Tire and loading terminology ........ 322
Rotating tires ............................... 325
Winter driving .................................... 327
Winter tires .................................. 327
Block heater (Canada only) .......... 328
Snow chains................................. 329
Maintenance ...................................... 330
Maintenance service indicator
message....................................... 330
Calling up the maintenance
service indicator display............... 332
Resetting the maintenance
service indicator........................... 332
Vehicle care ....................................... 333
Cleaning and care of the vehicle .. 333
Practical hints.................................. 341
What to do if … ................................... 342
Lamps in the instrument cluster ... 342
Air bag off indicator lamp.............. 357
Vehicle status messages in the
multifunction display..................... 359
Where will I find ...? ............................ 400
First aid kit .................................... 400
Vehicle tool kit, jack, and
spare wheel .................................. 400
Locking/unlocking in an emergency .. 403
Unlocking the vehicle.................... 403
Locking the vehicle ....................... 405
Lowering the load assist
manually ....................................... 406
Replacing SmartKey batteries ............ 407
Replacing bulbs .................................. 409
Bulbs ............................................. 409
Replacing bulbs for front lamps .... 411
Replacing bulbs for rear lamps ..... 414
Replacing wiper blades....................... 415
Placing wiper arms in vertical
position ......................................... 415
Removing wiper blades ................. 416
Installing wiper blades .................. 416Flat tire............................................... 417
Preparing the vehicle .................... 417
Mounting the spare wheel ............ 417
MOExtended system* ................... 425
Batteries............................................. 427
Disconnecting the batteries.......... 429
Removing the batteries................. 430
Charging and reinstalling
batteries ....................................... 430
Reconnecting the batteries........... 431
Jump starting...................................... 432
Towing the vehicle.............................. 434
Installing towing eye bolt .............. 436
Fuses.................................................. 437
Fuse boxes in engine
compartment ................................ 438
Fuse box in passenger
compartment ................................ 439
Fuse in trunk................................. 439
Emergency engine shut-down ....... 439

331 Operation
Maintenance
Clearing the maintenance service indi-
cator message
The maintenance service indicator mes-
sage is automatically cleared after approx-
imately 30 seconds

after you have switched on the ignition

after you have reached the mainte-
nance service threshold while driving
You can also clear the maintenance ser-
vice indicator message yourself.
1Reset button
Press reset button1 on the instru-
ment cluster.
The maintenance service indicator
message is cleared and the standard
display appears in the multifunction
display (
page 149).Maintenance service term exceeded
If you have exceeded the suggested main-
tenance service term, you will see the fol-
lowing message in the right multifunction
display:Service A Exceeded By XXXX Miles (Km)
Service A Exceeded By XXX Days
In addition, a signal sounds when the mes-
sage appears.
Any authorized Mercedes-Benz Center will
reset the maintenance service indicator
following a completed maintenance ser-
vice.

332 Operation
Maintenance
Calling up the maintenance service
indicator display
You can call up the maintenance service in-
dicator display at any time to check when
the next maintenance service is due.
Switch on the ignition (page 40).
Press button è or ÿ on the mul-
tifunction steering wheel repeatedly
until the standard display appears in
the multifunction display (
page 149).
Press button k or j on the
multifunction steering wheel until the
maintenance service indicator display
with the maintenance service symbol
9 or ½ appears in the left multi-
function display and the maintenance
service deadline appears in the right
multifunction display.Resetting the maintenance service
indicator
In the event that the maintenance service
on your vehicle is not carried out by an au-
thorized Mercedes-Benz Center, you can
have the maintenance service indicator
reset. The automotive maintenance facility
carrying out the maintenance service will
find the information for resetting the
maintenance service indicator in the main-
tenance-relevant information for your vehi-
cle. Such information is available from an
authorized Mercedes-Benz Center or
directly from Mercedes-Benz.
iThe menu overview can be found on
(
page 146).
iIf the battery supplying the vehicle’s electri-
cal consumers is disconnected, the days of dis-
connection will not be included in the count
shown by the maintenance service indicator. To
arrive at the true maintenance service deadline,
you will need to subtract these days from the
days shown in the maintenance service indicator
message or maintenance service indicator dis-
play.
Do not confuse the maintenance service indica-
tor with the engine oil level indicator N.
!If the maintenance service indicator was in-
advertently reset, have an authorized
Mercedes-Benz Center correct it.
Only reset if the proper maintenance service has
been performed. Resetting the system without
performing proper maintenance service as
called for by the maintenance service indicator
will result in engine damage and/or other vehicle
damage not covered by the Mercedes-Benz
Limited Warranty.

476 Index
Light sensor 392
Lighter see Cigarette lighter
Lighting
Instruments 140
Interior 138
Settings (control system) 163
Trunk 139
Limp-home mode 184
Load assist 245
Lowering manually 406
Loading terminology 322
Loading the vehicle 294
Lock buttons 38
Door handle (KEYLESS-GO*) 66
Locking the vehicle 62
In an emergency 405
Low beam headlamps 57, 131, 410
Replacing bulbs 412
Lowering
Load assist manually 406
Roll bar 84
Luggage compartment, rear 242
Luggage cover 210
Messages in the multifunction
display 399
Lumbar support adjustment 124M
Main fuse box 438
Maintenance
Calling up maintenance service
indicator display 332
Clearing maintenance service
indicator message 331
Maintenance service indicator
message 330
Maintenance service term
exceeded 331
Resetting maintenance service
indicator 332
Maintenance service
When due 330
Maintenance service indicator 330
Maintenance System 330
Malfunction memory 156
Calling up 157
Clearing 157
Manual operation
Interior lighting control 139
Locking the vehicle 405
Lowering load assist 406
Unlocking storage
compartments 404Unlocking the driver’s door 403
Unlocking the trunk 404
Manual shift program SL 55 AMG and
SL 65 AMG 182
Deactivating 184
Massage function 125
Maximum cooling MAXCOOL 195
Maximum inflation pressure 324
Maximum load rating 323
Maximum loaded vehicle weight 323
Mechanical key
Loss of 113
Menus 145
AMG 150
AUDIO 153
Distronic* 156, 222
NAV 155
Standard display 149
TEL* 169
Trip computer 167
Vehicle status message memory 156
Menus see Control system menus
Miles/kilometers in speedometer 160
Minimum distance (Parktronic*) 235

480 Index
Retractable hardtop
Closing (SmartKey) 206
Closing (switch) 205
Convenience feature 206
Locking after raising/lowering 207
Opening (SmartKey) 206
Opening (switch) 205
Problems when operating 208
Summer opening feature 206
Reverse gear position, Automatic
transmission 172, 174
Rim 324
Roll bar 83
Buttons 32
Lowering 84
Messages in display 396
Raising 84
Warning lamp 29
RON 280
Rubber parts, cleaning 339
Run Flat Indicator (Canada only) 303S
Satellite radio 154
Seat belt force limiter 82
Seat belts 50, 68, 79
Cleaning 340
Messages in the multifunction
display 373
Telltale 352
Warning lamp 352–353
Seat heating
Switching on 126
Seat ventilation* 128
Switching on 128
Seating capacity 295
Seats
Adjusting height 45
Adjusting lumbar support 125
Adjusting shoulder support 125
Heating 126
Massage function 125
Moving 124
Selector lever see Gear selector lever
Self-test
OCS 78Service
Basic service (Service A) 330
Batteries 427
Extended service (Service B) 330
Types 330
Service life (tires) 292
Service System see Maintenance
Settings
Clock 161
Convenience functions 166
Cruise control 217
Daytime running lamp mode 163
Interior lighting delayed
switch-off 165
Lamps and lighting (control
system) 163
Language, multifunction display 161
Locator lighting 164
Miles/kilometers in
speedometer 160
Night security illumination 164
Resetting all (control system) 158
Selective (SmartKey with
KEYLESS-GO*) 112
