service indicator MERCEDES-BENZ SL65AMG 2008 R230 Owner's Manual

Contents
Maximum tire load ....................... 319
Maximum tire inflation pressure .. 319
Uniform Tire Quality Grading
Standards (U.S. vehicles) ............. 320
Tire ply material ........................... 322
Tire and loading terminology ........ 322
Rotating tires ............................... 325
Winter driving .................................... 327
Winter tires .................................. 327
Block heater (Canada only) .......... 328
Snow chains................................. 329
Maintenance ...................................... 330
Maintenance service indicator
message....................................... 330
Calling up the maintenance
service indicator display............... 332
Resetting the maintenance
service indicator........................... 332
Vehicle care ....................................... 333
Cleaning and care of the vehicle .. 333
Practical hints.................................. 341
What to do if … ................................... 342
Lamps in the instrument cluster ... 342
Air bag off indicator lamp.............. 357
Vehicle status messages in the
multifunction display..................... 359
Where will I find ...? ............................ 400
First aid kit .................................... 400
Vehicle tool kit, jack, and
spare wheel .................................. 400
Locking/unlocking in an emergency .. 403
Unlocking the vehicle.................... 403
Locking the vehicle ....................... 405
Lowering the load assist
manually ....................................... 406
Replacing SmartKey batteries ............ 407
Replacing bulbs .................................. 409
Bulbs ............................................. 409
Replacing bulbs for front lamps .... 411
Replacing bulbs for rear lamps ..... 414
Replacing wiper blades....................... 415
Placing wiper arms in vertical
position ......................................... 415
Removing wiper blades ................. 416
Installing wiper blades .................. 416Flat tire............................................... 417
Preparing the vehicle .................... 417
Mounting the spare wheel ............ 417
MOExtended system* ................... 425
Batteries............................................. 427
Disconnecting the batteries.......... 429
Removing the batteries................. 430
Charging and reinstalling
batteries ....................................... 430
Reconnecting the batteries........... 431
Jump starting...................................... 432
Towing the vehicle.............................. 434
Installing towing eye bolt .............. 436
Fuses.................................................. 437
Fuse boxes in engine
compartment ................................ 438
Fuse box in passenger
compartment ................................ 439
Fuse in trunk................................. 439
Emergency engine shut-down ....... 439

75 Safety and Security
Occupant safety
Both driver and the passenger should
always use the 5/ indicator lamp
as an indication of whether or not the
passenger is properly positioned.
iIf the seat, including the trim cover and
cushion needs to be serviced in any way, take
the vehicle to an authorized Mercedes-Benz
Center.
Only use seat accessories approved by
Mercedes-Benz. Warning!G
If the 5/ indicator lamp illuminates
when an adult or someone larger than a
small individual is in the passenger seat,
have the passenger re-position himself or
herself in the seat until the 5/ indi-
cator lamp goes out.
More information about air bag display
messages (
page 368).
In the event of a collision, the air bag control
unit will not allow passenger front air bag
deployment when the OCS classified the
passenger seat occupant as being up to or
less than the weight of a typical
12-month-old child in a standard child
restraint or if the passenger seat is sensed
as being empty.
When the OCS senses that the passenger
seat occupant is classified as being up to or
less than the weight of a typical
12-month-old child in a standard child
restraint, the 5/ indicator lamp will
illuminate when the engine is started and
remain illuminated, indicating that the pas-
senger front air bag is deactivated.
When the OCS senses that the passenger
seat is classified as being empty, the
5/ indicator lamp will illuminate
when the engine is started and remain
illuminated, indicating that the passenger
front air bag is deactivated.


99 Safety and Security
Anti-theft systems
The alarm system will also be triggered
when

someone attempts to raise the vehicle

unlocking and opening the driver’s
door, the trunk, or the glove box with
the mechanical key

someone opens a door from the inside

someone opens the trunk lid with the
emergency release buttonArming the alarm system
The alarm system indicator lamp is located
in the locking switch in the upper part of
the center console.
1Alarm system indicator lamp
Lock the vehicle with the SmartKey or
KEYLESS-GO*.
The turn signal lamps flash three times
and an acoustic warning sounds three
times to indicate that the alarm system
is armed.
Alarm system indicator lamp 1 starts
flashing.Disarming the alarm system
Unlock the vehicle with the SmartKey
or KEYLESS-GO*.
The turn signal lamps flash once and an
acoustic warning sounds once to
indicate that the alarm system is
disarmed.
Alarm system indicator lamp 1 goes
out.
iIf the alarm stays on for more than
30 seconds, a call to the Response Center is ini-
tiated automatically by the Tele Aid system
(
page 252) provided Tele Aid service was sub-
scribed to and properly activated, and that nec-
essary cellular service and GPS coverage are
available.
iIf the turn signal lamps do not flash three
times and no acoustic warning sounds three
times, a door or the trunk lid may not be properly
closed.
Close the respective element and lock the
vehicle again.
iThe alarm system will rearm automatically
again after approximately 40 seconds if no door
was opened.

147 Controls in detail
Control system
Menus, submenus and functions
Table continued on next page.
Menu 1Menu 2Menu 3Menu 4Menu 5
Standard displayAMG1AUDIO NAVDistronic*
(page 149)(page 150)(page 153)(page 155)(page 156)
Commands/submenus
Calling up digital
speedometer/Outside
temperatureEngine oil temperatureSelecting radio stationShow route guidance
instructions, current
direction traveledCalling up settings
Calling up maintenance
service indicatorVehicle supply voltageSelecting satellite radio
station
Checking tire inflation
pressureRACETIMEROperating CD player
Checking engine oil
level*Overall analysis
Lap analysis
1AMG vehicles only.

149 Controls in detail
Control system
Standard display menu
1Main odometer
2Outside temperature
3Current gear selector lever position
4Trip odometer
5Automatic transmission program mode
Press button è or ÿ repeatedly
until you see the standard display
menu in the multifunction display.You can modify the standard display menu.
Instead of outside temperature 2, you
can choose the digital speedometer to be
displayed in the left multifunction display
by changing the setting in the
Select
Display
function of the Inst. Cluster
submenu (
page 161).
Press button k or jto select
the functions in the standard display
menu.
The following functions are available:Calling up digital speedometer or out-
side temperature
Press button k or juntil the
digital speedometer or, depending on
the chosen setting, the outside temper-
ature appears in the right multifunction
display.
FunctionPage
Calling up digital speedometer or
outside temperature149
Calling up maintenance service
indicator332
Checking tire inflation pressure302
Checking engine oil level*284
iIf you have selected the digital speedometer
for the standard display (
page 161), select the
outside temperature display here.

252 Controls in detail
Useful features
Emergency calls
An emergency call is initiated
automatically following an accident in
which the emergency tensioning devices
(ETDs) or air bags deploy.
An emergency call can also be initiated
manually by opening the cover next to the
interior rear view mirror labeled SOS, then
briefly pressing the button located under
the cover. See (
page 253) for instruc-
tions on initiating an emergency call man-
ually.
Once the emergency call is in progress, the
indicator lamp in the SOS button will begin
to flash. The message
Connecting Call
appears in the multifunction display and
the audio system is muted. When the con-
nection is established, the message
Call Connected appears in the multifunc-
tion display. All information relevant to the
emergency, such as the location of the ve-
hicle (determined by the GPS satellite loca-
tion system), vehicle model, identification
number and color are generated.A voice connection between the Response
Center and the occupants of the vehicle
will be established automatically soon af-
ter the emergency call has been initiated.
The Response Center will attempt to deter-
mine more precisely the nature of the
emergency provided they can speak to an
occupant of the vehicle.
The Tele Aid system is available if

it has been activated and is operational
Activation requires a subscription for
monitoring services, connection and
cellular air time.

the relevant cellular phone network
and GPS signals are available and pass
the information on to the Response
Center
iLocation of the vehicle on a map is only pos-
sible if the vehicle is able to receive signals from
the GPS satellite network and pass the informa-
tion on to the Response Center.
Warning!G
If the indicator lamp in the SOS button is
flashing continuously and there was no
voice connection to the Response Center
established, then the Tele Aid system could
not initiate an emergency call (e.g. the rele-
vant cellular phone network is not available).
The message
Call Failed appears in the
multifunction display for approximately
10 seconds.
Should this occur, assistance must be sum-
moned by other means.

254 Controls in detail
Useful features
The message Connecting Call will ap-
pear in the multifunction display and
the audio system is muted.
When the connection is established, the
message
Call Connected appears in the
multifunction display. The Tele Aid system
will transmit data generating the vehicle
identification number, model, color and lo-
cation (subject to availability of cellular
and GPS signals).
A voice connection between the Roadside
Assistance dispatcher and the occupants
of the vehicle will be established.
Describe the nature of the need for as-
sistance.
The Mercedes-Benz Roadside Assistance
dispatcher will either dispatch a qualified
Mercedes-Benz technician or arrange to
tow your vehicle to the nearest authorized
Mercedes-Benz Center. For services such
as labor and/or towing, charges may
apply. Refer to the Roadside Assistance
Manual for more information.The following is only available in the USA:

Sign and Drive services: Services such
as jump start, a few gallons of fuel or
the replacement of a flat tire with the
vehicle spare tire are obtainable.Information button ¡
The Information button¡ is located
below the center armrest cover.
1Information button¡
Open the telephone* compartment
(
page 239).
Press and hold button 1 (for longer
than 2 seconds).
A call to the Customer Assistance Cen-
ter will be initiated. The button will
flash while the call is in progress. The
message
Connecting Call will appear
in the multifunction display and the
audio system is muted.
iThe indicator lamp in the Roadside
Assistance button• remains illuminated in
red for approximately 10 seconds during the
system self-check after switching on the ignition
(together with the SOS button and the Informa-
tion button¡).
See system self-check (
page 251) if the indi-
cator lamp does not come on in red or stays on
longer than approximately 10 seconds.
If the indicator lamp in the Roadside Assistance
button• is flashing continuously and there
was no voice connection to the Response Center
established, then the Tele Aid system could not
initiate a Roadside Assistance call (e.g. the rele-
vant cellular phone network is not available). The
message
Call Failed appears in the multi-
function display.
Roadside Assistance calls can be terminated us-
ing the tbutton on the multifunction steer-
ing wheel or the respective button for ending a
telephone call on the COMAND headunit.


255 Controls in detail
Useful features
When the connection is established, the
message
Call Connected appears in the
multifunction display. The Tele Aid system
will transmit data generating the vehicle
identification number, model, color and lo-
cation (subject to availability of cellular
and GPS signals).
A voice connection between the Customer
Assistance Center representative and the
occupants of the vehicle will be estab-
lished. Information regarding the operation
of your vehicle, the nearest
Mercedes-Benz Center or Mercedes-Benz
USA products and services is available to
you.
For more details concerning the Tele Aid
system, please visit www.mbusa.com and
use your ID and password (sent to you sep-
arately) to learn more (USA only).iThe indicator lamp in the Information
button¡ remains illuminated in red for ap-
proximately 10 seconds during the system
self-check after switching on the ignition (togeth-
er with the SOS button and the Roadside Assis-
tance button•).
See system self-check (
page 251) if the indi-
cator lamp does not come on in red or stays on
longer than approximately 10 seconds.
If the indicator lamp in the Information
button¡ is flashing continuously and no
voice connection to the Response Center was
established, then the Tele Aid system could not
initiate an Information call (e.g. the relevant
cellular phone network is not available). The
message
Call Failed appears in the multi-
function display.
Information calls can be terminated using the
tbutton on the multifunction steering wheel
or the respective button for ending a telephone
call on the COMAND headunit.
!If the indicator lamps do not start flashing
after pressing one of the buttons or remain illu-
minated (in red) at any time, the Tele Aid system
has detected a malfunction or the service is cur-
rently not active, and may not initiate a call. Visit
an authorized Mercedes-Benz Center and have
the system checked or contact the
Response Center at 1-800-756-9018 (in the
USA) or 1-888-923-8367 (in Canada) as soon as
possible.

256 Controls in detail
Useful features
Call priority
If other service calls such as a Roadside
Assistance call or Information call are
active, an Emergency call is still possible.
In this case, the Emergency call will take
priority and override all other active calls.Remote door unlock
In case you have locked your vehicle unin-
tentionally (e.g. SmartKey inside vehicle),
and the reserve SmartKey is not handy:
Contact the Mercedes-Benz Response
Center at 1-800-756-9018 (in the USA)
or 1-888-923-8367 (in Canada).
You will be asked to provide your pass-
word which you provided when you
completed the subscriber agreement.
Then return to your vehicle and pull the
trunk recessed handle for a minimum
of 20 seconds until the SOS button is
flashing.
The message
Call Connected appears
in the multifunction display.
As an alternative, you may unlock the vehi-
cle via Internet using the ID and password
sent to you shortly after the completion of
your acquaintance call.
iThe indicator lamp in the respective button
flashes until the call is concluded. Calls can only
be terminated by a Response Center or
Customer Assistance Center representative
except Roadside Assistance and Information
calls, which can also be terminated by pressing
button t on the multifunction steering wheel
or the respective button for ending a telephone
call on the COMAND headunit.
!If the indicator lamp continues to flash or
the system does not reset, contact the Response
Center at 1-800-756-9018 (in the USA) or
1-888-923-8367 (in Canada), or Mercedes-Benz
Customer Assistance at 1-800-FOR-MERCedes
(1-800-367-6372) in the USA or Customer
Service at 1-800-387-0100 in Canada.
iWhen a Tele Aid call has been initiated, the
COMAND system audio is muted and the
selected mode (radio or CD) pauses.
The optional cellular phone (if installed) switches
off. If you must use this phone, the vehicle must
be parked. Disconnect the coiled cord and place
the call. The COMAND navigation system (if
engaged) will continue to run. The display in the
instrument cluster is available for use and
spoken commands are only available by pressing
the RPT button on the COMAND unit. A pop-up
window will appear in the COMAND display to
indicate that a Tele Aid call is in progress.

262 Controls in detail
Useful features
Operation of integrated remote control
Switch on the ignition (page 40).
Select and press the appropriate inte-
grated signal transmitter button (2,
3 or4) to activate the remote con-
trolled device.
The integrated remote control trans-
mitter continues to send the signal as
long as the button is pressed – up to
20 seconds.
Erasing the integrated remote control
memory
Switch on the ignition (page 40).
Simultaneously press and hold outer
signal transmitter buttons2 and 4,
for approximately 20 seconds, until the
indicator lamp1 flashes rapidly. Do
not hold for longer than 30 seconds.
The codes of all three channels are
erased.Programming tips
If you are having difficulty programming
the integrated remote control, here are
some helpful tips:

Check the frequency of hand-held re-
mote control5 (typically located on
the reverse side of the remote). The in-
tegrated remote control is compatible
with radio-frequency devices operating
between 280-390 MHz.

Put a new battery in hand-held remote
control5. This will increase the likeli-
hood of the hand-held remote control
sending a faster and more accurate sig-
nal to the integrated remote control.

While performing step 3, hold
hand-held remote control5 at
different lengths and angles from the
signal transmitter button (2, 3 or4)
you are programming. Attempt varying
angles at the distance of
2 to 5 in (5 to 12 cm) away or the
same angle at varying distances.

If another hand-held remote control is
available for the same device, try the
programming steps again using that
other hand-held remote control. Make
sure new batteries are in the hand-held
remote control before beginning the
procedure.

Straighten the antenna wire from the
garage door opener assembly. This
may help improve transmitting and/or
receiving signals.
iIf you sell your vehicle, erase the codes of all
three channels.
iCertain types of garage door openers are in-
compatible with the integrated remote control. If
you should experience further difficulties with
programming the integrated remote control,
contact an authorized Mercedes-Benz Center, or
call Mercedes-Benz Customer Assistance
Center (in the USA only) at
1-800-FOR-MERCedes, or Customer Service (in
Canada) at 1-800-387-0100.
