MERCEDES-BENZ SLK-Class 2001 R170 Owner's Manual

258 Consumer information
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Consumer information
This has been prepared as required of all manufactures
of passenger cars under Title 49, Code of U.S. Federal
Regulations, Part 575 pursuant to the “National Traffic
and Motor Vehicle Safety Act of 1966”.
Uniform tire quality grading
Quality grades can be found where applicable on the
tire sidewall between tread shoulder and maximum
section width. For example:
All passenger vehicle tires must conform to federal
safety requirements in addition to these grades.Treadwear
The treadwear grade is a comparative rating based on
the wear rate of the tire when tested under controlled
conditions on a specified government test course. For
example, a tire graded 150 would wear one and one-half
(1
1/2) times as well on the government course as a tire
graded 100. The relative performance of tires depends
upon the actual conditions of their use, however, and
may depart significantly from the norm due to
variations in driving habits, service practices and
differences in road characteristics and climate.
Tread wear 200 Traction AA Temperature A

259 Consumer information
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Traction
The traction grades, from highest to lowest are “AA”,
“A”, “B”, and “C”. Those grades represent the tire’s
ability to stop on wet pavement as measured under
controlled conditions on specified government test
surfaces of asphalt and concrete. A tire marked “C” may
have poor traction performance.Te mp e r a t u r e
The temperature grades are “A” (the highest), “B”, and
“C”, representing the tire‘s resistance to the generation
of heat and its ability to dissipate heat when tested
under controlled conditions on a specified indoor
laboratory test wheel. Sustained high temperature can
cause the material of the tire to degenerate and reduce
tire life, and excessive temperature can lead to sudden
tire failure. The grade “C” corresponds to a level of
performance which all passenger vehicle tires must
meet under the Federal Motor Vehicle Safety Standard
No. 109. Grades B and A represent higher levels of
performance on the laboratory test wheel than the
minimum required by law.
Wa r n i n g !
The traction grade assigned to this tire is based on
straightahead braking traction tests, and does not
include acceleration, cornering, hydroplaning, or
peak traction characteristics.
Wa r n i n g !
The temperature grade for this tire is established
for a tire that is properly inflated and not
overloaded. Excessive speed, underinflation, or
excessive loading, either separately or in
combination, can cause excessive heat build up
and possible tire failure.

260 Index
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
Index
A
ABS (Antilock brake system) ....................................... 168
Malfunction indicator lamp ..................................... 182
Adjusting telescoping steering column ........................ 63
Air conditioner refrigerant ...........................................254
Air pump ......................................................................... 196
Airbag deactivation system ............................................ 50
AIRBAG OFF indicator lamp ........................................ 185
Airbags .............................................................................. 52
Alarm system ............................................................. 35, 37
Antenna ...........................................................................232
Anticorrosion / antifreeze .................. 161, 194, 252, 256
Antilock brake system (ABS) ....................................... 168
Malfunction indicator lamp ..................................... 182
Antitheft alarm system ................................................... 35
Aquaplaning ................................................................... 158
Ashtrays ...........................................................................114
Audio system .................................................................... 91
Anti-theft system ........................................................ 93
Button and soft key operation ................................... 94
Cassette mode ............................................................. 99
CD changer ................................................................ 103CD mode ..................................................................... 102
Operating and display elements ...............................92
Operating safety .......................................................... 91
Operation – audio and telephone ............................. 91
Radio mode .................................................................. 97
Telephone operation .................................................106
Automatic central locking .............................................. 31
Automatic transmission ................................................144
Emergency Operation ............................................... 152
Fluid level ................................................................... 192
Program mode selector switch ................................ 151
Selector lever positions ............................................147
Transmission selector lever,
manually unlocking ............................................. 217
BBabySmart
TM airbag deactivation system ..................... 50
Self-test ......................................................................... 51
BAS (Brake assist system) ............................................ 166
Malfunction indicator lamp ..................................... 181
Battery ............................................................................. 210
Charge indicator lamp .............................................. 184
Recycling .................................................................... 211
Block heater .................................................................... 162

261 Index
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex Brake assist system (BAS) ............................................ 166
Malfunction indicator lamp ..................................... 181
Brake fluid ......................................................................254
Brake pad wear indicator lamp .................................... 180
Brake warning lamp ...................................................... 179
Brake fluid low .......................................................... 179
Brakes .....................................................155, 166, 168, 170
CCapacities
Fuels, coolants, lubricants etc. ...............................252
Catalytic converter ........................................................ 138
Cellular telephone ..........................................................116
Center console .................................................................. 18
Central locking switch .................................................... 30
Central locking system ................................................... 25
Automatic central locking ......................................... 31
Choosing global or selective mode ........................... 26
Emergency release for trunk lid ............................... 35
General notes ............................................................... 24
Locking and unlocking .............................................. 26
Remote control ............................................ 22, 25, 224
Vehicle keys ................................................................. 22Changing wheels ........................................................... 202
Inflating the collapsible spare tire ........................ 207
Storing spare wheel in wheel well ........................ 208
Charge indicator lamp ................................................... 184
Check engine malfunction indicator lamp .................178
Check regularly and before a long trip ....................... 176
Checking engine oil level
Via engine oil level .....................................................77
Via oil dipstick ........................................................... 193
Child restraint ...............................................44, 50, 51, 61
Cleaning and care of the vehicle ................................ 234
Climate control .................................................................84
Air Recirculation .........................................................89
Basic setting .................................................................86
Defogging windows .....................................................87
Defrosting .....................................................................87
Dust Filter .....................................................................90
Rear window defroster ............................................... 88
Residual Engine Heat Utilization (REST) ................ 89
Special settings ........................................................... 87
Clock, setting .................................................................... 74
Coin Holder ..................................................................... 114
Combination switch ......................................................... 81
Consumer information ................................................. 258
Control and operation of radio transmitters .............. 128

262 Index
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
Coolant level
Adding coolant .......................................................... 194
Checking .................................................................... 194
Coolant temperature gauge ............................................ 73
Coolants ...........................................................................256
Anticorrosion/antifreeze quantity .........................257
Cruise control ................................................................. 163
Cup holder .......................................................................112
DDaytime running lamps .................................................. 80
Deep water
Driving instructions ................................................. 162
Display illumination ........................................................ 72
Doors .................................................................................. 28
Drinking and driving .................................................... 154
Drive sensibly - Save Fuel ............................................ 154
Driving instructions ...................................................... 154
Driving off ....................................................................... 156
EElectronic stability program (ESP) ..............................170
Control switch ........................................................... 172
Malfunction indicator lamp ..................................... 181
Synchronizing ........................................................... 171
Warning lamp ............................................................ 181
Emergency call
See Tele Aid ............................................................... 130
Emergency engine shut-down ..................................... 226
Emergency release for trunk lid ....................................35
Emergency tensioning retractor (ETR) .........................52
SRS indicator lamp ................................................... 180
Emergency unlocking in case of accident ...................32
Emission control ............................................................ 139
Emission control label .................................................. 244
Engine compartment ..................................................... 190
Engine oil additives ...................................................... 254
Engine oil consumption ..................................................78
Engine oil level
Checking ...............................................................77, 193
Warning ...................................................................... 184

263 Index
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex Engine oil level ................................................................. 77
Engine oils ......................................................................254
ESP (Electronic stability program) .............................. 170
Control switch ........................................................... 172
Malfunction indicator lamp ..................................... 181
Synchronizing ........................................................... 171
Warning lamp ............................................................ 181
ETR (Emergency tensioning retractor) ......................... 52
SRS indicator lamp ................................................... 180
Exterior lamp failure indicator .................................... 185
Exterior lamp switch ....................................................... 79
Exterior lamps ................................................................ 218
Additional turn signals on the exterior mirror ....223
Headlamp assembly ................................................. 219
High mounted stop lamp .........................................223
Low and high beam ..................................................220
Parking lamps .................................................. 221, 222
Replacing bulbs ......................................................... 218
Side marker lamp, front ...........................................223
Standing lamps ................................................. 221, 222
Taillamp assemblies .................................................222
Turn signal lamps ............................................ 221, 222
FFirst aid kit ...................................................................... 188
Flexible service system (FSS) ........................................ 75
FSS indicator lamp .............................................. 71, 185
Fuel
Gasoline additives .................................................... 256
Premium unleaded gasoline .................. 174, 253, 255
Fuel cap placement warning ........................................ 181
Fuel filler f lap
Manual release ......................................................... 232
Fuel requirements ........................................................ 255
Fuel reserve warning ..................................................... 181
Fuels, coolants, lubricants etc. - capacities .............. 252
Fuses, electrical .............................................................. 188GGarage door opener ....................................................... 117
Gasoline
Additives .................................................................... 256
Fuel requirements ................................................... 255
Premium unleaded .................................................. 255
General notes on the central locking system .............. 24
Glove box ......................................................................... 112

264 Index
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
HHardtop, retractable ...................................................... 120
Lowering ..................................................................... 121
Raising ........................................................................ 123
Raising manually ......................................................226
Hazard warning flasher switch ..................................... 83
Head restraints
Removal ........................................................................ 40
Headlamp cleaning system ............................................ 80
Headlights ......................................................................... 79
Heated seats ..................................................................... 42
Hood ................................................................................. 190IIdentification labels .......................................................243
Indicator lamps in the instrument cluster .......... 70, 178
Infant and child restraint systems ................................ 61
Inflating the collapsible spare tire .............................207
Information call
See Tele Aid ............................................................... 130Instrument cluster ........................................................... 68
Activating .....................................................................72
Indicator lamps ............................................................70
Malfunction and indicator lamps ...........................178
Instrument lamps ............................................................. 72
Instruments and controls ............................................... 16
Interior
General notes ..............................................................111
Interior lighting .............................................................. 110
JJump starting .................................................................. 212KKeys, vehicle .....................................................................22

265 Index
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
LLamps, exterior
Fog lamps ............................................................ 79, 222
Headlamps ......................................... 79, 185, 219, 237
Parking lamps ............................................ 79, 219, 221
Replacing bulbs ......................................................... 218
Side marker lamp, front .................................... 79, 223
Standing lamps ........................................... 79, 219, 221
Taillamps ............................................79, 185, 222, 237
Layout of poly-V-belt drive ............................................245
Lighter ..............................................................................115
Limp Home Mode (Automatic transmission) ............ 152
Locking and unlocking ................................................... 26
Low engine coolant level warning .............................. 183
Luggage cover ................................................................. 126MMaintenance ................................................................... 129
Malfunction and indicator lamps
in the instrument cluster ......................................... 178
Manual transmission .................................................... 143
Mirror, exterior, adjusting .............................................. 65
Mirror, exterior, rear view .............................................. 65
Mirror, inside, rear view ................................................. 64
NNight security illumination .......................................... 110OOn-board diagnostic system .........................................178
Operator’s manual ............................................................. 6
Outside temperature indicator .......................................73
Overhead control panel ................................................... 19PPanic button ......................................................................27
Parcel net in passenger footwell .................................. 116
Parking ............................................................................ 156
Parking brake ............................... 153, 155, 156, 171, 179
Power assistance ............................................................ 155
Power seats ....................................................................... 38
Power windows ...............................................................109
Express opening ........................................................109
Operate with hard top switch ..................................120
Problems with your vehicle ............................................ 12
Product information .......................................................... 5

266 Index
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
RRadio and telephone ...................................................... 128
Radio transmitters ......................................................... 128
Rear view mirrors ............................................................ 64
Exterior ......................................................................... 65
Inside ............................................................................ 64
Rear window defroster .................................................... 88
Remote control ................................................................. 22
Battery replacement .................................................224
Synchronizing ...........................................................225
Replacing bulbs .............................................................. 218
Replacing wiper blade insert ....................................... 231
Reporting safety defects ................................................. 13
Residual Engine Heat Utilization (REST) ..................... 89
Retractable hardtop ....................................................... 120
Roadside assistance ........................................................... 8
Roadside assistance call
See Tele Aid ............................................................... 130
SSafety guidelines for the seat belt, emergency
tensioning retractor and airbag ................................59
Seat belts ........................................................................... 44
Fastening ......................................................................46
Seat belt nonusage warning system .........................45
Unfastening .................................................................. 48
Warning lamp ............................................................ 180
Seat belts and integrated restraint system .................. 44
Seats ...................................................................................38
Power seats .................................................................. 38
Seat heater ...................................................................42
Service indicator
See Flexible service system (FSS) ............................ 75
Setting the audio volume ................................................95
Shelf behind roll bars .................................................... 116
Side marker lamp .......................................................... 223
Snow chains .................................................................... 160
SOS-call
See Tele Aid ............................................................... 130
Spare parts service ....................................................... 242
Spare wheel ........................................................... 196, 200
Special settings (Climate control) ................................. 87

267 Index
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex SRS (Supplemental restraint system) ........................... 51
Indicator lamp ........................................................... 180
SRS malfunction ......................................................... 54
Start lock-out .................................................................... 24
Malfunction lamp ...................................................... 185
Starting and turning off the engine ............................ 142
Steering column, telescopic
Adjusting ...................................................................... 63
Warning lamp ............................................................ 182
Steering lock ................................................................... 140
Storage compartments ...................................................113
Armrest ........................................................................113
Center console ............................................................113
Glove box .....................................................................112
Trunk floor ................................................................. 196
Stowing things in the vehicle ...................................... 188
Sun visors ........................................................................ 111
Supplemental restraint system (SRS) ........................... 51
Indicator lamp ........................................................... 180
SRS malfunction ......................................................... 54
Synchronizing remote control .....................................225
TTachometer ........................................................................ 74
Technical data ................................................................ 248
Electrical system .......................................................251
Main Dimensions ...................................................... 251
Rims – Tires .............................................................. 249
Weights ....................................................................... 251
Tele Aid ............................................................................ 130
Emergency calls ........................................................ 131
Information ................................................................ 134
Initiating an emergency call manually .................. 132
Roadside Assistance ................................................. 133
Telephones and two-way radio .....................................128
Telescoping steering column
Adjusting ......................................................................63
Warning lamp ............................................................ 182
The first 1 000 miles (1 500 km) ................................129
Tires
Consumer information ............................................ 258
Driving instructions ................................................. 157
Rims and tires .......................................................... 249
Rotating wheels ......................................................... 199
Tire inflation pressure ............................................ 209
Tire replacement ....................................................... 198
Tire speed rating ....................................................... 159
