33 At a glance
Quick reference COMAND
Press# or $:
The cursor moves horizontally, adjust-
ing the balance accordingly.
Storing new settings:
Press' or the Back soft key,
or
wait until the display changes.For the following operating modes, differ-
ent settings for bass and treble can be se-
lected:
Radio (FM waveband)
Radio (AM waveband)
Radio (Weather Band)
Single CD
MP3
CD changer*
AUX
Satellite radio*
Navigation*
Bass and treble settings for navigation an-
nouncements are found under “Adjusting
the acoustics for navigation announce-
ments” (
page 113).When adjusting bass or treble, the system
automatically stores the setting for the
currently active operating mode.
Setting bass and treble
Open the main menu of the appropriate
operating mode (
page 29).
Press the Bass or Treble soft key.
The Bass or Treble menu appears.
Bass and treble


34 At a glance
Quick reference COMAND
Press# or $:
The cursor moves horizontally, adjust-
ing bass or treble accordingly.
Storing new settings:
Press' or the Back soft key,
or
wait until the display changes.
If the vehicle is equipped with a sound sys-
tem*, the sound functions are available for
the following operating modes:
Radio
Single CD
MP3
CD changer*
AUX
Satellite radio*The following sound functions are avail-
able:
Default Settings
Resets the sound functions* to the fac-
tory setting.
Standard
Normal stereo playback.
Speech
P l a y b a c k o p t i m i z e d f o r s p e e c h c o m p r e -
hension.
LOGIC7 Surround
7-channel-surround playback (not for
mono-sources like AM waveband or
Weather Band in radio mode).
Different sound functions* can be activat-
ed for each one of the operating modes.
Example:
For CD mode: the
LOGIC7 Surround function,
for Satellite radio* mode: the
Speech func-
tion.Switching sound functions*
Open the main menu of the appropriate
operating mode (
page 29).
Press the Sound soft key.
The Sound menu appears.
Use% or & to select the desired
function.
Press'.
The system switches to the selected
function.
Sound functions*

41 Audio
Radio operation
The following options are available:
Tuning via station search(page 41)
Tuning via station presets (page 42)
Tuning via Autostore presets
(
page 43)
Tuning via scan search (page 43)
Manual tuning (page 44)
Tuning via direct frequency input
(
page 44)
Tuning via station search
On COMAND control unit
Switch to the desired FM or AM wave-
band (
page 40).
Press+ or %.
The next receivable ascending frequen-
cy is tuned in and begins to play;
or
Press, or &.
The next receivable descending fre-
quency is tuned in and begins to play.
On multifunction steering wheel
Switch the multifunction display in the
instrument cluster to the Radio display
(
page 27).
Pressj.
The next receivable ascending frequen-
cy is tuned in and begins to play;
or
Pressk.
The next receivable descending fre-
quency is tuned in and begins to play.
i
The wavebands cover different fre-
quency ranges:
FM broadcast band:
FM (VHF = very high frequency)
87.7 - 107.9 MHz
Tuning increments 0.2 MHz
AM broadcast band:
MW (medium wave)
530 - 1710 kHz
Tuning increments 10 kHz
WB waveband:
WB (Weather Band)
162.400 - 162.550 MHz
Tuning increments = 1 channel
Tuning to a FM/AM station
i
Audio search function Freq. must be
set in the multifunction display
(
page 28).

42 Audio
Radio operation
Tuning via station presets
Ten presets each are available for FM and
AM.
On COMAND control unit
The presets are accessed using the num-
ber keypad, or via the Presets menu.
Accessing via number keypad:
Switch to the desired waveband
(
page 40).
Press one of the number keys
! - ".
The system tunes to the station stored
under this number.
Accessing via Presets menu:
Switch to the desired waveband
(
page 40).
Press the Presets soft key.
The Presets menu appears.
Use $, #, % or & to choose a
preset and press';
or
Press one of the number keys
! - ".
The system tunes to the station stored
under this number.On multifunction steering wheel
Switch the multifunction display in the
instrument cluster to the Radio display
(
page 27).
Pressj.
The system tunes to the next station
stored in the station presets;
or
Pressk.
The system tunes to the previous sta-
tion stored on the station presets.
i
Audio search function Memory must be
set in the multifunction display
(
page 28).

43 Audio
Radio operation
Tuning via Autostore presets
The Autostore function allows placing of
stations into the presets sorted by recep-
tion quality (
page 46).
The system will store the station with the
strongest signal in preset 1.
Ten presets each are available for FM and
AM.
Switch to the desired waveband
(
page 40).
Press the Autost. soft key.
The Autostore preset list appears. It
can take several seconds until all fre-
quencies are displayed.
Use $, #, % or & to choose a
preset and press';
or
Press one of the number keys
! - ".
The system tunes to the station stored
under this number.Tuning via scan search
Scan search is characterized as follows:
Scan search performs two runs.
During the first run, stations with ex-
tremely good reception are played.
During the second run, stations with
weaker reception are played.
Scan search plays each receivable sta-
tion for approx. 8 seconds.
Scan search can be ended manually.
Scan search automatically stops at the
station listened to before the scan
search was started.
Starting scan search
Switch to the desired waveband
(
page 40).
Press the Scan soft key.
Scanning begins.


44 Audio
Radio operation
Ending Scan search manually
Press the Scan soft key again.
Manual tuning
Switch to the desired waveband
(
page 40).
Press+ or, for at least 2
seconds to scroll up or down.
Manual tuning is activated.
Keep the button pressed or release it
and keep tapping+ or, in
quick succession.
The frequency will change by the tuning
increments for the respective wave-
band each time one of the buttons is
pressed or for as long as a button is
pressed and held.
Manual tuning is deactivated if no but-
ton is pressed for approx. 3 seconds. Tuning via direct frequency input
Entry example:
98.5 MHz in FM waveband
Switch to the FM waveband
(
page 40).
Press..
The frequency input display appears.
The frequency range of the FM wave-
band is shown.
i
Manual tuning is also possible in all
wavebands by pressing#or$.
The frequency will change by the tuning
increments for the respective wave-
band each time one of the buttons is
pressed.
Frequency increments for manual
tuning:
FM 0.2 MHz
AM 10 kHz

45 Audio
Radio operation
Press the number buttons in
succession:=, >, and ?.
Each number entered appears in the
display.
The system tunes to the frequency en-
tered (in this example: 98.5 Mhz) and
switches back to the FM menu.
Seven channels are available on the
Weather Band. Switch to the WB waveband by press-
ing the
WB soft key in the Radio main
menu (
page 40).
Each time you press the
WB soft key the
system will tune to the strongest re-
ceivable station.
Tuning via station search
On the COMAND control unit
Switch to the WB waveband by press-
ing the
WB soft key in the Radio main
menu (
page 40).
The system will tune to the strongest
receivable station.
Press+ or,.
The search begins descending or as-
cending.
The search stops at the next receivable
station.On the multifunction steering wheel
Switch the multifunction display in the
instrument cluster to Audio display
(
page 27).
Pressj ork.
The search stops at the next receivable
station.
Tuning via station presets
The seven strongest channels are sort-
ed in preset 1 to 7 each time you press
the WB soft key. They are accessed us-
ing the number keypad.
Press one of the number keys
! - @.
The system tunes to the station stored
under this number.
i
Entries outside the frequency range are
not possible.
Within the AM waveband, the input is
restricted to frequencies within the re-
spective frequency increment, which
is10 kHz.
The system will select the nearest valid
frequency if a frequency outside the
frequency increment is entered.
Tuning to a station on Weather Band

49 Audio
Single CD operation
aa
The COMAND CD drive holds one CD. The
slot for inserting a CD is located above the
display (
page 15).
Loading a CD
WarningG
In order to avoid distraction which could
lead to an accident, the driver should insert
CDs with the vehicle at a standstill and oper-
ate the audio system only when road, weath-
er and traffic conditions permit.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.
!
Do not attach labels of any type to the
CD. They may become detached and
damage the drive.
Your CD drive has been designed to
play CDs which correspond to the IEC
60908 standard. Therefore only CDs
not exceeding a thickness of 1.3 mm
can be used.
If you insert thicker data carriers, e.g.
ones that have data on both sides (one
side with DVD data, the other side with
audio data), they will become stuck and
damage the drive.
Data carriers which contain data on
both sides can cause play-back prob-
lems because the storage layers are
thinner than one-sided data carriers.
!
Do not play single-CDs (80 mm) with an
adapter. An adapter could become
stuck and damage the drive. Only use
12 cm diameter CDs.
i
Th e C O M A N D C D d r i v e m a y n o t b e a b l e
to play audio CDs with copy protection.
!
If a CD is already loaded, it must be
ejected before inserting the new CD.
Inserting a second CD in the slot with
another CD still loaded will cause dam-
age to the CD drive not covered by the
Mercedes-Benz Limited Warranty.

50 Audio
Single CD operation
Insert a CD into the CD slot while
COMAND is switched ON. Insert the
CD face up.
COMAND pulls in the CD. If the CD is
an audio CD, the system switches to
Single CD mode and starts playing the
first track.
Press/.
COMAND ejects the CD.
Remove the CD from the slot.
If you do not remove the CD from the
slot within approx. 7 seconds, the CD is
pulled back into the CD drive.
Open the Audio main menu
(
page 38).
Press the CD soft key.
The system switches to Single CD
mode and starts playing the first track.
The center of the status bar shows:
The track number and total number
of tracks
The elapsed playing time of the
track1Track title or track number
2Elapsed track playing time
3Track number/total tracks
The Single CD main menu shows the track
title in the center if the CD contains corre-
sponding text data.
If the CD does not contain any CD text da-
ta, the track number is displayed instead of
the track title.
i
If the CD is an MP3 CD, the system
switches to MP3 mode (
page 57).
Ejecting a CD
Single CD main menu
i
The CD soft key is shaded out if no CD
is loaded. The system will not switch to
Single CD mode.
Load an audio CD into the
COMAND CD drive (
page 49)
The
MP3 soft key instead of the CD soft
key is visible when a MP3 CD has been
inserted.

51 Audio
Single CD operation
The following options are available:
Selecting via track skip
Selecting via track list (page 51)
Selecting via manual entry of the track
number (
page 52)
Selecting via scan search (page 52)
Selecting via track skipOn the COMAND control unit
Open the Single CD main menu
(
page 50).
Press+7for forward skipping;
or
Press, for backward skipping.
The tracks skip immediately after
pressing one of the buttons.
On the multifunction steering wheel
Switch the multifunction display in the
instrument cluster to the Single CD dis-
play (
page 27).
Pressj for forward skipping;
or
Pressk for backward skipping.
The tracks skip immediately after
pressing one of the buttons.Selecting via track list
The track list contains all tracks of the cur-
rent CD. Only one list entry is visible at a
time, it is the number of the track currently
playing.
Use% or & to select another track
from the list.
The current track remains playing while
selecting.
Press' or wait approx. 3 seconds
without changing the selection.
The newly selected track is played.
Selecting a track
i
Forward skipping:
The next track is played.
Backward skipping:
If the track has been playing longer
than approx. 10 seconds, the system
skips back to the beginning of the
track.
If less than 10 seconds have played,
the system skips back to the beginning
of the previous track.
