94 Telephone*
Telephone operation
The ringing tone is audible in the event of
an incoming call. The call screen pops up
on the current display.If the multifunction display in the instru-
ment cluster is set to telephone mode, the
call screen also appears in the multifunc-
tion display.
Answering calls
On the COMAND control unit
Press2.On the multifunction steering wheel
Presss .
In both cases the call is active. Commu-
nica ti on is con ducted via the ha nds-f ree
system. The call volume can be adjusted
(
page 31).
For other user functions, see
“Active call” (
page 99).
Ending or refusing a call
On the COMAND control unit
Press3.
On the multifunction steering wheel
Presst .
i
If a list is empty, the corresponding soft
key ( ,
Recvd.#, Dialed # or SMS) is
without function and appears shaded
out.
Answering an incoming call
i
The caller’s number appears only if it is
transmitted.
The caller’s name only appears if the
number and the name are stored in the
phone book (
page 101).
i
It is also possible to accept, refuse or
end a call from the cell phone
(
Telephone Operation Guide).

116 Navigation*
Destination entry
You can see which characters can be
entered when using the keys.
Each additional depression moves you
to the next available character.
The selected character appears black.
Wait until the character display disap-
pears, or press'.
The character is entered.
Deleting a character
Press the Delete soft key if necessary.
The character last accepted by the sys-
tem is deleted.Confirming the data entry
After entering all the characters the data
entry must be confirmed.
Press and hold' for approx. 2 sec-
onds;
or
Use$ or & to select the sym-
bol and press'.
.
One frequently used destination address
can be established as the home address.
Open the Navigation main menu
(
page 112).
Press the Home soft key.
A message
No home address stored ap-
pears;or
If a home address has already been es-
tablished, the home address appears.
i
Do not confuse the Delete soft key (de-
letion of the last character) with the
Back soft key (deletion of the complete
entry).
i
The symbol can only be selected if
the system has recognized the entry.
Entering a home address
ok
ok

120 Navigation*
Destination entry
Enter city (USA) appears in the status bar.
The characters in parenthesis indicate the
selected region (
page 119).
Accepting the displayed destination
Press and hold ' for approx. 2 sec-
onds.
Entering a different city
Use the keypad menu or the 12 button
keypad to enter the data of the city
(
page 115).
After entering the city a selection list of
cities appears indicated by
Select city
displayed in the status bar. Now contin-
ue with selecting a city.
Switching to a selection list is possible at
any time while entering a city.
Press the List soft key.
A selection list appears indicated by
Se-
lect city
displayed in the status bar.
Now continue with selecting a city.
Selecting a city
Use% or & to select the destina-
tion city.
The
Page soft keys allow scrolling
through the list page by page.
Press'.
After selecting the desired city, one of
the following menus appears:
For larger cities with more than 15
streets:
Enter Street menu (
page 122).
For smaller cities with up to
15 streets:
Select Street menu (
page 123).
If no streets are registered for the
selected city:
Select City Center menu
(
page 121).
The appropriate menu can be identified
from the display in the status bar.
i
Do not confuse the '7button with the
symbol in the main screen.
ok
i
The selection is cancelled if the Back
soft key is pressed.

126 Navigation*
Destination entry
Enter house number menu

Use #, $, %, &, 6 or 8 to
select the numbers. Press ' after
each selection;
or
Press! - " to enter the numbers.
Press the Delete soft key if necessary.
The number last accepted by the sys-
tem is deleted.
Press and hold ' for approx. 2 sec-
onds to confirm the input;
or
Use$ or & to select the sym-
bol and press'.
The house number list appears. Now a
house number range can be selected.Selecting a house number range

Use % or &7to select the desired
range of house numbers.
The
Page soft keys allow scrolling
through the list page by page.
Press '.
The Start Route Guidance menu
(
page 131) appears.
i
Do not confuse the Delete soft key (de-
letion of the last number) with the
Back
soft key (deletion of the complete en-
try).
i
The symbol can only be selected if
the system has recognized the house
number.
ok
ok

154 Navigation*
Last destinations and destination memory
To select lower or upper case or to select
special characters, the following shift
fields on the display are available:
= upper case
= lower case
= special characters
Use&, # or $7to select one of
the shift fields.
Press'.
Use#, $, %, &, 6 or 8 to
select the characters. Press ' after
each selection.
If necessary, press the Delete soft key
to delete the character last entered.
Upon completion of the name entry
press and hold ' for approx. 2 sec-
onds;
or
Use$ or & to select the sym-
bol and press '.
The system will save the entry.
ABC
abc
...
i
Do not confuse the Delete soft key (de-
letion of the last character) with the
Back soft key (deletion of the complete
entry).
ok
