stop start MERCEDES-BENZ SLK-Class 2007 R171 Comand Manual

Contents
Selecting the region . . . . . . . . . . . 119
Entering a city. . . . . . . . . . . . . . . . 119
Narrowing of the destination
after selecting a city . . . . . . . . . . . 121
Entering a city center . . . . . . . . . . 121
Entering a street in the
destination city . . . . . . . . . . . . . . . 122
Narrowing of the destination
after selecting a street . . . . . . . . . 124
Entering an intersection . . . . . . . . 124
Entering a house number . . . . . . . 125
Entering a destination using the
map . . . . . . . . . . . . . . . . . . . . . . . 127
Entering a destination via geo
coordinates. . . . . . . . . . . . . . . . . . 128
Storing map locations. . . . . . . . . . 130
Route guidance . . . . . . . . . . . . . . . . . 131
Starting route guidance menu . . . 131
Route calculation . . . . . . . . . . . . . 131
Route re-calculation . . . . . . . . . . . 131
Navigation announcements . . . . . 132
Navigation displays. . . . . . . . . . . . 132
Destination reached . . . . . . . . . . . 135
Cancelling route guidance . . . . . . 135
Partially digitized areas. . . . . . . . . 135
Off-road and off-map . . . . . . . . . . 137During route guidance . . . . . . . . . . . . 139
Showing soft key displays . . . . . . 139
Info menu . . . . . . . . . . . . . . . . . . . 139
Displaying the route on the map . 140
Displaying the route list . . . . . . . . 141
Detour function. . . . . . . . . . . . . . . 141
Stop-over . . . . . . . . . . . . . . . . . . . 143
Defining route guidance displays . 146
Setting symbols display . . . . . . . . 147
Setting map orientation . . . . . . . . 148
Map display menu. . . . . . . . . . . . . 148
Automatic map toggling . . . . . . . . 149
Scales for full-screen and
split-screen map display . . . . . . . . 150
Last destinations and
destination memory . . . . . . . . . . . . . . 151
Last destinations memory . . . . . . 151
Destination memory . . . . . . . . . . . 152
POIs (Points of Interest) . . . . . . . . . . . 155
Entering POIs . . . . . . . . . . . . . . . . 155
Selecting POI in the local area of
the current position . . . . . . . . . . . 156
Selecting POI for a selected city. . 157
Selecting POI for a long-distance
destination . . . . . . . . . . . . . . . . . . 157
Selecting a POI using the map . . . 159
Service . . . . . . . . . . . . . . . . . . . . . . . 161
Tele Aid*. . . . . . . . . . . . . . . . . . . . . . . 162
Emergency call system . . . . . . . . . 162
Roadside Assistance . . . . . . . . . . . 162
Information . . . . . . . . . . . . . . . . . . 163
System . . . . . . . . . . . . . . . . . . . . . . . 165
System settings . . . . . . . . . . . . . . . . . 166
Calling up the System menu . . . . . 166
Setting the date/time . . . . . . . . . . 166
Setting the language . . . . . . . . . . . 168
Switching confirmation beeps and
acoustic signals ON/OFF . . . . . . . 168
Display settings . . . . . . . . . . . . . . 169
Reset function. . . . . . . . . . . . . . . . 170
Glossary . . . . . . . . . . . . . . . . . . . . . . 173
Index . . . . . . . . . . . . . . . . . . . . . . . . . 177

43 Audio
Radio operation
Tuning via Autostore presets
The Autostore function allows placing of
stations into the presets sorted by recep-
tion quality (
page 46).
The system will store the station with the
strongest signal in preset 1.
Ten presets each are available for FM and
AM.
Switch to the desired waveband
(
page 40).
Press the Autost. soft key.
The Autostore preset list appears. It
can take several seconds until all fre-
quencies are displayed.
Use $, #, % or & to choose a
preset and press';
or
Press one of the number keys
! - ".
The system tunes to the station stored
under this number.Tuning via scan search
Scan search is characterized as follows:
Scan search performs two runs.
During the first run, stations with ex-
tremely good reception are played.
During the second run, stations with
weaker reception are played.
Scan search plays each receivable sta-
tion for approx. 8 seconds.
Scan search can be ended manually.
Scan search automatically stops at the
station listened to before the scan
search was started.
Starting scan search
Switch to the desired waveband
(
page 40).
Press the Scan soft key.
Scanning begins.


52 Audio
Single CD operation
Selecting via manual entry of the track
number
Open the Single CD main menu
(
page 50).
Press..
The Manual track input display ap-
pears.
1Number of tracks on the CD (12 tracks)
Entry example: Track 1
Press!.Entry example: Track 12
Press! and A in quick succession.
Wait approx. 3 seconds after entering
the number.
The selected track is played. The CD
main menu appears.
Selecting via scan search
Scan search is characterized as follows:
Scan search plays each track on the
current CD for approx. 8 seconds.
Scan search can be ended manually.
Scan search automatically stops at the
track listened to before the scan
search was started.Starting scan search
Press the Scan soft key.
Ending scan search manually
Press the Scan soft key.
The track playing at the time the scan
is ended remains playing.
Open the Single CD main menu
(
page 50).
Press and hold+ or,.
To stop release+ or,.
i
Entries beyond the number of available
tracks on the CD are not possible.
i
When you start the scan search, play-
back option
Normal Sequence
(page 53) is activated automatically.
Fast forward/reverse

61 Audio
MP3 operation
1Current track
Open the MP3 main menu (page 58);
Press% or & to select a different
track.
Th e c u r r e n t t r a c k r e m a i n s p l a y i n g w h i l e
selecting.
Press', or wait approx. 3 seconds
without changing the selection.
The selected track is played.Selecting via direct entry of the track
number
Open the MP3 main menu (page 58).
Press..
The Manual track input display ap-
pears.
1Number of tracks in the current folder
(10 tracks)
Example entry: Track 1
Press!.Example entry: Track 10
Press! and " in quick succession.
Wait approx. 3 seconds after entering
the number.
The selected track is played.
Selecting via scan search
Scan search is characterized as follows:
Scan search plays each track in the
current folder for approx. 8 seconds.
Scan search can be ended manually.
Scan search automatically stops at the
track listened to before the scan
search was started.
i
It is not possible to enter a number
greater than the number of tracks in
the current folder.

62 Audio
MP3 operation
Starting scan search
In the MP3 main menu (page 58)
press the
Scan soft key.
The scan search starts.
Ending scan search manually
Press the Scan soft key.
The track playing when scan search is
ended remains selected.
Open the MP3 main menu (page 58).
Press and hold+ or,.
To stop release+ or,.
The following options are available:
Normal sequence
The COMAND plays tracks in a folder in
succession.
Once all the tracks in a folder have
been played, COMAND begins playing
the track(s) in the next folder on the
CD.
Repeat track
The COMAND will repeat the current
track until this function is canceled.
Repeat folder
The COMAND will repeat the tracks in
the current folder until this function is
canceled.
The track sequence is the same as the
Normal sequence option.
Track Random
This option is restricted to the tracks in
the current folder. The tracks are
played in random order.
Folder Random
All tracks on the CD are played in ran-
dom order.
Changing the playback option
In the MP3 main menu (page 58),
press the
Setting soft key.
The Settings menu is displayed.
The solid circle indicates which op-
tion is currently selected.
i
The scan search will not function if the
current folder only contains one track.
When you start scan search, playback
option
Normal sequence (page 62) is
activated automatically.
Therein scan search is restricted to the
current folder.
Fast forward/reverse
Playback options

67 Audio
CD changer* operation
Loading options:
Loading a single magazine compart-
ment
Loading all six magazine compart-
ments
Loading a single magazine compart-
ment
Open the glove box
(
Vehicle owner's manual).
Briefly press the button 2 of the emp-
ty magazine compartment to be load-
ed.
Wait until the LED in the button 2
flashes green.
This indicates that the CD changer re-
quests a CD.
Insert an audio CD into the CD slot 1
within approx. 15 seconds. Insert the
CD face up.
The CD is pulled in. The red LED in the
corresponding magazine compartment
button 2 lights up continuously. The
system starts playing the CD.
The loading procedure is completed.
Loading all six magazine compart-
ments
Initial situation: all magazine compart-
ments are empty.
The CD changer loads all magazine com-
partments beginning with compartment 1.
Open the glove box
(
Vehicle owner's manual).1CD slot
2Magazine compartment buttons
Press and hold the button of an empty
magazine compartment 2 for more
than 2 seconds.
The LEDs of all magazine compartment
buttons 2 briefly light up green sever-
al times.
Wait until the LED in the first magazine
compartment button 2 flashes green.
This indicates that the CD changer re-
quests a CD.
i
Loading a magazine slot will stop the
playback of a CD in the changer.


73 Audio
CD changer* operation
Use% or & to select another track
from the list.
Th e c u r r e n t t r a c k r e m a i n s p l a y i n g w h i l e
selecting.
Press', or wait approx. 3 seconds
without changing the selection.
The track is changed. The newly select-
ed track is played.
Selecting via manual entry of the track
number
Open the CD changer main menu
(
page 69).
Press..
The Manual track input display ap-
pears.
1Number of tracks on the current CD
(12 tracks)
Entry example: Track 1
Press!.
Entry example: Track 12
Press! and A in quick succession.
Wait approx. 3 seconds after entering
the number.
The selected track is played. The CD
main menu appears.
Selecting via scan search
Scan search is characterized as follows:
Scan search plays each track on the
current CD for approx. 8 seconds.
Scan search can be ended manually.
Scan search automatically stops at the
track listened to before the scan
search was started.
i
Entries beyond the number of available
tracks on the CD are not possible.

74 Audio
CD changer* operation
Starting scan search
Press the Scan soft key.
Ending scan search manually
Press the Scan soft key.
The track playing at the time the scan
is terminated remains playing.
Open the CD changer main menu
(
page 69).
Press and hold+ or ,.
To stop release+ or ,.The following options are available:
Normal sequence
Repeat track
Repeat CD
Track Random
CD Random
Explanation of the playback options
Normal sequence
The tracks are played in the normal se-
quence (e.g. track 1, 2, 3 etc.).
If only one CD is loaded, the last track
is followed by the first track.
If several CDs are loaded in the CD
changer, the last track on a CD will be
followed by the first track of the next
CD in the changer. The CDs are changed in their normal
sequence (e.g. CD 1, 2, 3 etc.).
The last track of the last CD in the
changer will be followed by the first
track of the first CD.
Repeat track
The current track will be repeated until
this function is deactivated.
Repeat CD
The current CD will be repeated until
this function is deactivated.
i
When you start scan search, playback
option
Normal sequence (page 74) is
activated automatically.
Therein scan search is restricted to the
current CD.
Fast forward/reverse
Playback options
i
It is only possible to select this function
if at least two audio CDs are loaded in
the CD changer.

80 Satellite radio*
Satellite radio operation
Station information is displayed on the
main area and in the center of the status
bar.
Main area, in this example:
ROCK = selected category (page 81)
Vault = name of the selected station
Status bar, in this example:
SAT (on the left) = the selected mode
SAT5 = location in the program
memory, if the current channel is pre-
stored
Ch16 = number of the current channel
Selectable soft keys
Presets
shows channels pre-stored in the pro-
gram memory (up to 10 channels). You
can store stations (
page 84) and re-
quest stored stations (
page 80).
Info
shows additional text information relat-
ed to the current channel.
Scan
is used to start and stop the scan
search (
page 83).
Service
displays a screen showing the tele-
phone number of the Sirius Service
Center and electronic serial number
(ESN) of the receiver in your vehicle.
You can also adjust the following:
Balance (page 32)
Bass and treble (page 33)
Sound functions (page 34)
Volume (not on soft keys)
(
page 31)
The following options are available:
Tuning via station presets (page 81)
Tuning via manual channel input
(
page 81)
Tuning via the program category list
(
page 81)
Tuning a station within the selected
category (
page 82)
Tuning via scan search (page 83)
SAT main menu
Selecting a station

83 Satellite radio*
Satellite radio operation
Tuning using the multifunction steering
wheel
Switch the multifunction display in the
instrument cluster to Satellite radio
display (
page 27).
Pressk.
The search proceeds in ascending or-
der;
or
Pressj.
The search proceeds in descending or-
der.
The search stops at the first receivable
station. Tuning via scan search
Scan search is characterized as follows:
Scan search plays a channel for
approx. 8 seconds and then skips to
the next channel within the current
category.
Scan search can be ended manually.
Scan search stops automatically at the
station that was playing when scan
search was started.
Press the Scan soft key.
The scan search starts.
Press the Scan soft key again.
The scan search stops.Additional text information (artist and
track title) related to the current broadcast
can be displayed.
Press the Info soft key.
i
Using% o r&7i s f o l l o w e d b y a s h o r t
delay before the change occurs. Using
+ a n d, changes the channel
immediately.
Obtaining additional text
information
