MERCEDES-BENZ SLK320 2000 R170 Owner's Manual
Manufacturer: MERCEDES-BENZ, Model Year: 2000, Model line: SLK320, Model: MERCEDES-BENZ SLK320 2000 R170Pages: 273
Page 151 of 273
148 Automatic transmission
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Dependent on the program mode selector switch
position “S” or “W” the maximum speed in the
reverse gear is different. However, it is not
possible to change the program mode while in
reverse.
Neutral
No power is transmitted from the engine to the
drive axle. When the brakes are released, the
vehicle can be moved freely (pushed or towed). Do
not engage “N” while driving except to coast
when the vehicle is in danger of skidding (e.g. on
icy roads, see page 160 for winter driving
instructions).
Important!
Coasting the vehicle, or driving for any other
reason with selector lever in “N” can result in
transmission damage that is not covered by the
Mercedes-Benz Limited Warranty.
Drive
The transmission automatically upshifts through
5th gear. Position “D” provides optimum driving
characteristics under all normal operating
conditions.Gear selection for special circumstances
The transmission gear ranges for special circumstances
can be selected by pressing the selector lever to the
right or the left with the selector lever in position “D”.
The gear range currently selected is indicated in the
instrum ent clu ster disp lay.
Briefly press selector lever in the ç direction:
The transmission downshifts, one gear at a time, in the
order “4”, “3”, “2”, “1”.
Press and hold selector lever in the ç direction:
The selector lever position display will switch to the
gear range currently selected by the automatic
transmission.
The transmission will only shift down one gear if the
gear range currently selected has already shifted to its
highest possible gear.
Briefly press selector lever in the æ direction:
The transmission will shift from the current gear range
to the next higher gear range. If the transmission is
already in gear range “D”, an additional upshift of one
gear is possible.
Page 152 of 273
149 Automatic transmission
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Press and hold selector lever in the æ direction:
The transmission will shift from the current gear
directly to gear range “D”.
Important!
With transmission in gear range “D”, “4” or “3”,
upshifting from 1st to 2nd to 3rd gear is delayed
depending on vehicle speed and engine temperature.
This allows the catalytic converter to heat up more
q uickly to operating temperatures.
During the brief warm-up period this delayed upshift
and increased engine noise might be perceived as a
malfunction. However, neither the engine nor
transmission are negatively affected by this mode of
operation.The delayed upshift is effective with vehicle speeds
below 31 mph (50 km / h) at partial throttle and engine
temperatures below 95°F (35°C).
To avoid overrevving the engine when the selector lever
is moved to a lower gear range, the transmission will not
shift to a lower gear, if the engine’s revolutions per
minute limit would be exceeded. In this case there will
be no downshift, even when the vehicle speed reaches
RPM limit of that gear, e.g. by applying the service
brakes.
To prevent the engine from laboring at low RPM when
driving uphill gradients or with your vehicle heavily
loaded, the automatic transmission will downshift when
necessary to maintain engine RPM within the best
torque range.
Wa r n i n g !
On slippery road surfaces, never downshift in order
to obtain braking action. This could result in drive
wheel slip and reduced vehicle control. Your
vehicle’s ABS will not prevent this type of loss of
control.
Page 153 of 273
150 Automatic transmission
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Gear ranges:
Upshift through 4th gear only. Suitable for
performance driving.
Upshift through 3rd gear only. Suitable for
moderately steep hills. Since the transmission
does not shift higher than 3rd gear, this gear
selection will allow use of the engine’s braking
power downhill.Upshift through 2nd gear only. For driving in
mountainous regions or under extreme operating
conditions. This gear selection will allow use of
the engine’s braking power when descending
steep grades.
Use this position, which makes maximum use of
the engine’s braking effect, while descending
very steep or lengthy downgrades and only at
speeds below 40 mph (60 km / h).
Page 154 of 273
151 Automatic transmission
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Program mode selector switch
The transmission is provided with a selector switch for
Standard “S” and Winter / Wet (snow and ice) “W”
program modes.SStandard mode
Press switch on symbol “S”. Use this mode for all
regular driving.
The vehicle starts out in 1st gear.
Accelerator Operation:
Fa st o n = d e p re s s i ng t h e a c c e l e r a to r p e d a l q u i ck ly
(not into kickdown position) while driving
continuously, rather than depressing the
accelerator pedal in the usual manner, will cause
the automatic transmission to shift down into a
lower gear. This gear shifting process is
dependent on the current vehicle speed.
Fast off = there will be no upshift when releasing
the accelerator pedal quickly, e.g. using the
engine’s braking power during performance
driving.
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
@@
€€
ÀÀ
yy
P27.60-2102-26
Page 155 of 273
152 Automatic transmission
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
WWinter / Wet (snow and ice) mode
Press switch on symbol “W”. The vehicle starts
out in 2nd gear, except with selector lever in 1st
gear, or with accelerator pedal in kick-down
position.
The “W” mode helps to improve traction and
driving stability of the vehicle.
The gear shifting process occurs at lower vehicle
and engine speeds than in the “S” program mode.
Caution!
Never change the program mode when the selector lever
is out of position “P”. It could result in a change of
driving characteristics for which you may not be
prepared.
Important!
Always be certain of the program mode selected since
the vehicle driving characteristics change with the
selection of the program mode.
Dependent on the program mode selector switch
position “S” or “W” and the gear selector lever in
position “R”, the ratio of power transmission changes.Emergency Operation
(Limp Home Mode)
If vehicle acceleration worsens, or the transmission no
longer shifts, the transmission is most likely operating
in Limp Home Mode which engages when there is a
malfunction of the transmission. This condition may be
accompanied by the “CHECK ENGINE” malfunction
indicator lamp in the instrument cluster coming on.
In this mode only the 2nd gear or reverse gear can be
activated.
To engage 2nd gear or reverse:
1.Stop the vehicle.
2.Move selector lever to position “P”.
3.Turn off the engine.
4.Wait approximately 10 seconds.
5.Restart the engine.
6.Move sel ector lever to position “D” (for 2nd gear), or
move selector lever to position “R” (for reverse gear).
Have the transmission checked at your authorized
Mercedes-Benz Center as soon as possible.
Page 156 of 273
153 Parking brake
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Parking brakeTo engage, firmly pull up brake handle (1). When the
key is in steering lock position 2, the brake warning
lamp in the instrument cluster should come on brightly.
To release, slightly pull up handle while pushing lock
button (2), and guide lever downward to its stop. The
brake warning lamp in the instrument cluster should go
out.
A warning sounds, if you start to drive without having
released the parking brake.
Also see brake warning lamp on page 179.
P42.20-2052-27
2
1
Wa r n i n g !
When leaving the vehicle always remove the
electronic key from the steering lock, and lock the
vehicle. Do not leave children unattended in the
vehicle, or with access to an unlocked vehicle.
Children could release the parking brake, which
could result in an accident or serious injury.
Page 157 of 273
154 Driving instructions
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Driving instructions
Drive sensibly – Save Fuel
Fue l consumption, to a g rea t ex tent, depends on driv ing
habits and operating conditions.
To save fuel you should:
•keep tires at the recommended inflation pressures,
•remove unnecessary loads,
•allow engine to warm up under low load use,
•avoid frequent acceleration and deceleration,
•have all maintenance work performed at regular
intervals by an authorized Mercedes-Benz Center.
Fuel consumption is also increased by driving in cold
weather, in stop-and-go traffic, on short trips and in hilly
country.Drinking and driving
Pedals
Wa r n i n g !
Drinking or taking drugs and driving can be a very
dangerous combination. Even a small amount of
alcohol or drugs can affect your reflexes,
perceptions and judgement.The possibility of a serious or even fatal accident is
sharply increased when you drink or take drugs
and drive.Please don‘t drink or take drugs and drive or allow
anyone to drive after drinking or taking drugs.Wa r n i n g !
Keep driver‘s foot area clear at all times. Objects
stored in this area may impair pedal movement.
Page 158 of 273
155 Driving instructions
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Power assistance
BrakesThe condition of the parking brake system is checked
each time the vehicle is in the shop for the required
maintenance service.
If the parking brake is released and the brake warning
lamp in the instrument cluster stays on, the brake f luid
level in the reservoir is too low.
Brake pad wear or a leak in the system may be the
reason for low brake f luid in the reservoir.
Have the brake system inspected at an authorized
Mercedes-Benz Center immediately.
Al l checks and service work on the brake system shoul d
be carried out by an authorized Mercedes-Benz Center.
Install only brake pads and brake fluid recommended by
Mercedes-Benz.
Wa r n i n g !
When the engine is not running, the brake and
steering systems are without power assistance.
Under these circumstances, a much greater effort is
necessary to stop or steer the vehicle.Wa r n i n g !
After driving in heavy rain for some time without
applying the brakes or through water deep enough
to wet brake components, the first braking action
may be somewhat reduced and increased pedal
pressure may be necessary to obtain expected
braking effect. Be sure to maintain a safe distance
from vehicles in front.Resting your foot on the brake pedal will cause
excessive and premature wear of the brake pads.It can also result in the brakes overheating thereby
significantly reducing their effectiveness. It may
not be possible to stop the vehicle in sufficient time
to avoid an accident.
Wa r n i n g !
If other than recommended brake pads are
installed, or other than recommended brake fluid
is used, t he braking properties of th e vehic le can be
degraded to an extent that safe braking is
substantially impaired. This could result in an
accident.
Page 159 of 273
156 Driving instructions
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Caution!
When driving down long and steep grades, relieve the
load on the brakes by shifting into a lower gear to use
the engine’s braking power. This helps prevent
overheating of the brakes and reduces brake pad wear.
After hard braking, it is advisable to drive on for some
time, rather than immediately parking, so the air stream
will cool down the brakes faster.
Driving off
Apply the service brakes to test them briefly after
driving off. Perform this procedure only when the road
is clear of other traffic.
Warm up the engine smoothly. Do not place full load on
the engine until the operating temperature has been
reached.
W hen sta rting of f on a sl ippery surfa ce, d o not al low one
drive wheel to spin for an extended period with the ESP
switched off. Doing so may cause serious damage to the
drive train which is not covered by the Mercedes-Benz
Limited Warranty.Parking
Wa r n i n g !
To reduce the risk of personal injury as a result of
vehicle movement, before
turning off the engine
and leaving the vehicle, always:
1. Keep right foot on the service brake pedal.
2. Firmly engage parking brake.
3. Move the selector lever to position “P”
(manual transmission: first or reverse gear).
4. Slowly release the service brake pedal.
5. Turn front wheels towards the road curb.
6. Turn the key to steering lock position 0 and
remove.
7. Take the key and lock vehicle when leaving.
Page 160 of 273
157 Driving instructions
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Important!
It is advisable to set the parking brake whenever
parking or leaving the vehicle. In addition, move
selector lever to position “P” (manual transmission:
first or reverse gear).
When parking on hills, always set the parking brake.Tires
Tread wear indicators (TWI) are required by law. These
indicators are located in six places on the tread
circumference and become visible at a tread depth of
approximately
1/16 in (1.5 mm), at w hich point t he tire is
considered worn and should be replaced.
The tread wear indicator appears as a solid band across
the tread.
Wa r n i n g !
If you feel a sudden significant vibration or ride
disturbance, or you suspect that possible damage to
your vehicle has occurred, you should turn on the
hazard warning flashers, carefully slow down, and
drive with caution to an area which is a safe
distance from the roadway.Inspect the tires and under the vehicle for possible
damage. If the vehicle or tires appear unsafe, have
it towed to the nearest Mercedes-Benz Center or
tire dealer for repairs.
