buttons Mercury Grand Marquis 1996 Owner's Manuals

75 % [LG48000( GV)10/90]
All of the message center functions are
controlled by the three switches located just
below the message center display:
[LG48030( GV)02/94]
q
E/M Ð Changes the electronic instrument
cluster display to read in either English or
Metric units.
*
[LG48060( GV)01/95]
q
ResetÐ Sets the selected function to zero
(if resettable).
*
[LG48100( GV)01/95]
q
SelectÐ Selects the function. This is a dual
action switch, the right side advances function
to the right, the left side advances function to
the left.
[LG48130( GV)03/94]
one inch art:0010520-C
Buttons for the message center
*
[LG48160( GV)01/95]
How to use the message center
*
[LG48200( GV)01/95]
To reset any function:
*
[LG48260( GV)01/95]
1. Push either the right or left side of the
SELECT button to choose the function you
would like to set.
*
[LG48300( GV)01/95]
2. Push the RESET button and the selected
message center function will be reset to zero.
(The only functions which can be reset to
zero are: AVG ECON, TRIP A or TRIP B,
and AVG SPEED.)
File:rclgg.ex
Update:Tue Jan 30 08:07:51 1996

90 [IP12600( GV)03/94]Fan speed can be reduced, after a comfortable
temperature has been reached, to provide quieter
system operation.
[IP12800( GV)05/94]
To cool your vehicle using outside air, move the
SELECT knob to NORM A/C, move the TEMP
knob to the end of the blue range (full
counterclockwise) and set the fan to the desired
speed. Cooling your vehicle in this way provides
quieter operation, but it is not as economical as
MAX A/C.
[IP13000( GV)03/92]
The instrument panel registers may be adjusted
to control the quantity and direction of air being
discharged. The thumbwheel controls the volume
of air and the knob in the center of the register
directs the air up and down or side to side.
[IP13200( GV)05/94]
When the SELECT knob is moved to OFF, the
system is off and the fan will not operate.
% [IP13300( BCGV)01/89]
Adjusting the panel register airflow
[IP13400( BCGV)03/92]
The instrument panel registers may be adjusted
to your comfort needs. The thumbwheel controls
the volume of air and the knob in the center of
the register controls direction up or down or
side to side.
%*
[IP15900( GV)04/95]
Electronic Automatic Temperature Control
System
*
[IP16000( GV)05/95]
The control for your Electronic Automatic
Temperature Control (EATC) is located at the
center of the instrument panel and operates only
when the key is in the ON position.
*
[IP16100( GV)05/95]
The EATC feature maintains the temperature
you select and automatically controls the airflow
for your comfort. It also allows you to override
the automatic operation with manual override
buttons.
File:rcipg.ex
Update:Tue Jan 30 08:05:49 1996

91 [IP16200( GV)03/95]
half page art:0011299-D
The controls for the electronic automatic temperature
control
*
[IP16300( GV)02/95]
To turn your EATC on, push the AUTOMATIC
button or any of the six override buttons along
the bottom of the control.
*
[IP16400( GV)02/95]
To turn your EATC off, press the OFF button.
When the system is off, the display window will
be blank (dark) except when OUTSIDE TEMP
has been selected. Then, OUTSIDE TEMP and
the temperature will appear in the window.
*
[IP16500( GV)01/95]
If you select AUTOMATIC, the system will
automatically determine fan speed and airflow
location. If an override button is selected, your
selection determines airflow location only. Fan
speed remains automatic unless you override it
by rotating the vertical thumbwheel located at
the extreme right of the control panel.
File:rcipg.ex
Update:Tue Jan 30 08:05:49 1996

92
*
[IP16600( GV)02/95]
To change the temperature in the display
window, select any temperature between65ÊF
(18ÊC) and 85ÊF (29ÊC)using the BLUE (cooler)
or RED (warmer) buttons. The Electronic
Automatic Temperature Control will do the rest.
*
[IP16700( GV)02/95]
If you want continuous maximum cooling, push
the BLUE button until60ÊF (16ÊC) isshown in
the display window. Your EATC will cool at
maximum and disregard the60ÊF (16ÊC)setting
until you select a warmer temperature with the
RED button. If you want continuous maximum
heating, push the RED button until90ÊF (32ÊC)
is shown in the display window. Your EATC
will provide maximum heat regardless of the
90ÊF (32ÊC)setting until you select a cooler
temperature with the BLUE button.
[IP16800( GV)05/94]
one third page art:0011300-B*
[IP16900( GV)03/95]
The display window tells you how the system is
operating. It will indicate the selected
temperature and the operating function you
have chosen; AUTO or one of the six manual
overrides. It will also indicate manual
(thumbwheel) control of the fan speed with the
Hsymbol. The display window with all possible
displays and their positions are shown here.
Normally not all are shown at the same time but
are included here to familiarize you with the
names and symbols.
File:rcipg.ex
Update:Tue Jan 30 08:05:49 1996

93
*
[IP17000( GV)01/95]
Automatic operation
*
[IP17100( GV)02/95]
Push the AUTOMATIC button and select the
desired temperature. The selected temperature
and AUTO will be shown in the display
window. The EATC will automatically heat or
cool to achieve the set temperature. Under
normal conditions, your EATC will need no
additional attention.
[IP17200( GV)05/95]
quarter page art:0011301-C*
[IP17300( GV)02/95]
When in AUTOMATIC and weather conditions
require heat, air will be sent to the floor. But, a
feature is included in your EATC to prevent
blowing cold air to the floor if the engine
coolant is not warm enough to allow heating.
For a short time the fan will be at low speed
and air directed to the windshield. In 3-1/2
minutes or less, the fan speed will start to
increase and the airflow will change to the floor
area.
*
[IP17400( GV)02/95]
If unusual conditions exist (i.e., window fogging,
etc.), the six manual override buttons allow you
to select special air discharge locations. A
thumbwheel allows you to adjust the fan speed
to suit your needs.
File:rcipg.ex
Update:Tue Jan 30 08:05:49 1996

94
*
[IP17500( GV)03/95]
Temperature selection
*
[IP17600( GV)05/95]
The RED and BLUE buttons at the upper left of
the Control are for temperature selection. The
RED button will increase the set temperature
and the BLUE button will lower the set
temperature. Pressing a button and releasing it
will change the set temperature one degree.
Holding either button in will rapidly change the
temperature setting in one degree increments to
either65ÊF (18ÊC)(BLUE) or85ÊF(29ÊC)(RED).
Then, the set temperature will jump 5Ê and stop
at either60ÊF (16ÊC)which is maximum cooling
or 90ÊF (32ÊC)which is maximum heating.
[IP17700( GV)03/95]
one third page art:0011302-C*
[IP17800( GV)06/94]
The average temperature range used is between
68ÊF (20ÊC) and 78ÊF (26ÊC).Changing the
temperature setting by several degrees outside
this range will not speed up the heating or
cooling process.
File:rcipg.ex
Update:Tue Jan 30 08:05:49 1996

95
*
[IP17900( GV)01/95]
Temperature display
*
[IP18000( GV)01/95]
The selected temperature displayed in the
window can be set for either 0ÊF or0ÊC.Your
car may have an English/Metric (E/M) Button
to change your speedometer from miles to
kilometers. When pressed, this button also
changes the temperature display. With or
without an E/M Button, the temperature display
can also be changed to 0ÊF or 0ÊC using the
MAX A/C and DEFrost override buttons.
[IP18100( GV)05/95]
one third page art:0011303-D*
[IP18201( GV)01/95]
To change the temperature display to 0ÊF or0ÊC,
press and hold the MAX A/C and DEF Buttons
at the same time for 3/4 second. The display
will change. If you continue to press the two
buttons, the display will continuously switch
between 0ÊF and0ÊC. If thetemperature display
does not agree with the speedometer on vehicles
with an E/M button, pressing the E/M button
will make them agree.
File:rcipg.ex
Update:Tue Jan 30 08:05:49 1996

97
*
[IP18801( GV)02/95]
You can override the fan speed at any time. If
you use the thumbwheel to override the fan
speed, the EATC will continue to control the
temperature but you control the fan speed. To
return to auto fan control, press the
AUTOMATIC button. If you are operating in
one of the override functions (FLOOR, MAX
A/C, etc.), automatic fan control will continue
unless you rotate the fan thumbwheel. To return
to automatic fan control, press the AUTOMATIC
button. The EATC will return to Automatic
operation. If you want to return to any override
function, press the button for that function. The
fan speed will continue to be automatically
controlled.
*
[IP18901( GV)01/95]
Manual override buttons
*
[IP19001( GV)02/95]
Your EATC has six buttons which allow you to
make special selections. The buttons are located
along the bottom edge of the EATC control and
allow you to determine where the air will be
discharged. Pressing any override button
changes the air discharge location only. It does
not affect the ability of the system to control
temperature or the fan speed. Return to fully
Automatic operation by pushing the
AUTOMATIC button.
*
[IP19101( GV)01/95]
MAX A/C button
[IP19201( GV)05/94]
The MAX A/C feature allows for faster cooling
because air is drawn from inside the car. Using
inside air causes the fan to sound louder which
is normal for this selection. The Display window
will indicate MAX A/C under the selected
temperature. The airflow will be from the
instrument panel registers.
File:rcipg.ex
Update:Tue Jan 30 08:05:49 1996

125 %
*
[FV02600( BCGV)01/95]
Using the Illuminated Entry System
(If equipped)
[FV02700( CGV)05/95]
The interior lights will illuminate for
approximately 25 seconds when either front door
handle is lifted, any button on the keyless entry
pad is pressed, or the remote entry system
UNLOCK button is pushed. If the amount of
light outside your vehicle is below a
predetermined level, the exterior lights will also
illuminate.
[FV03200( BCGV)02/95]
These lights automatically turn off after 25
seconds or when you turn the ignition key to
ON or ACC. The inside lights will not turn off if
you have turned them on manually or if a door
is open.
%*
[FV03598( BCGV)05/95]
Using the Keyless Entry System
(If equipped)
[FV03600( BCGV)06/92]
If your vehicle has the keyless entry system, you
can lock or unlock the vehicle doors and trunk
without using a key. The buttons for the system
are above the outside door handle on the
driver's side.
[FV03850( GV)05/94]
one third page art:0010477-B
The keyless entry buttons
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

126
*
[FV03900( BCGV)04/95]
When you bought your vehicle, you were given
a computer code that operates the system for
your vehicle. For your convenience, we have
duplicated this code in three places.
*
[FV04000( BCGV)02/95]
The code is:
*
[FV04100( BCGV)02/95]
q
on your owner's wallet card found in the
glove compartment
[FV04400( BCGV)02/95]
q
taped to the underside of the trunk lid
[FV04800( GV)10/94]
q
taped to the computer module behind the
driver's door trim panel.
[FV04925( BCGV)05/95]
When you use this entry system, the illuminated
entry system turns on the interior lights for 25
seconds and the buttons on the keypad light up.
Do not push the buttons with a key, ballpoint
pen, pencil, or any other hard object. These
objects could damage the buttons.
%*
[FV04950( BCGV)02/95]
Unlocking the doors with the keyless entry
system
[FV05000( BCGV)02/95]
You must unlock the driver's door before you
unlock any of the other doors or trunk. If you
let more than five seconds pass between pressing
numbers, the system shuts down, and you have
to enter the code again. The system has shut
down if the keypad light is out. If the keyless
entry system does not work properly, use the
key or transmitter(s) to lock and unlock the
doors or unlock the trunk.
*
[FV05100( BCGV)02/95]
1. To unlock the driver's door, enter the factory
code or your personal code. All codes have
five numbers. After you press the fifth
number, the driver's door unlocks.
[FV05140( GV)03/92]
2. To unlock the passenger's doors, press the
3/4 button within five seconds of unlocking
the driver's door or trunk, or re-enter the
code to open the driver's door, then press
3/4.
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996
