Page 63 of 329
60 %
*
[LG14800( ALL)01/95]
Speedometer
*
[LG14900( ALL)01/95]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
%*
[LG15000( ALL)01/95]
Odometer
*
[LG15100( ALL)01/95]
The odometer tells you the total number of miles
(kilometers) your vehicle has been driven.
%*
[LG15200( ALL)11/94]
Trip Odometer
*
[LG15300( ALL)03/93]
If you want to track your mileage up to 999.9
miles (kilometers), use the trip odometer. Simply
set the trip odometer to zero by pressing the
reset button firmly when beginning the distance
you wish to measure.
*
[LG15350( ALL)01/95]
Since the trip odometer displays distance
independent of the odometer it will not always
advance to the next mile (kilometer) at the same
time as the odometer.
% [LG16220( ALL)05/94]
Battery Voltage Gauge (If Equipped)
*
[LG16225( ALL)05/94]
This gauge shows you the battery voltage when
the ignition key is in the ON position.
*
[LG16230( ALL)05/94]
If the battery is operating under cold weather
conditions, the pointer may indicate in the upper
range of the NORMAL band while the battery is
charging. If you are running electrical accessories
(when the engine is off, or idling at a low
speed), the pointer may move toward the lower
end of the NORMAL band.
*
[LG16260( ALL)05/94]
If it stays outside the NORMAL band, have your
vehicle's electrical system checked as soon as it
is safely possible.
File:rclgg.ex
Update:Tue Jan 30 08:07:51 1996
Page 76 of 329
73
*
[LG31500( GV)01/95]
A problem is indicated if the fuel gauge bar
graph displays only the top two and bottom two
bars and the message center display for Distance
To Empty or Fuel Remaining functions display
the letters ªCOº or ªCSº. If this happens, contact
your dealer for service as soon as possible.
%*
[LG33600( GV)01/95]
Speedometer
[LG33700( GV)05/95]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving. It
indicates the speed up to 120 mph or up to
195 km/h.
*
[LG34000( GV)01/95]
You can press the E/M (English/Metric) button
located just below the message center display to
show the speed you are going in either miles
per hour or kilometers per hour.
[LG34050( GV)05/95]
quarter page art:0010517-D%*
[LG34100( GV)01/95]
Odometer
*
[LG34200( GV)01/95]
The odometer tells you the total number of miles
or kilometers your vehicle has been driven. If
the cluster is replaced, and the accumulated
mileage on the odometer is unknown, the
replacement cluster will have the circled ªSº
illuminated with zero miles on the odometer. If
the actual vehicle mileage can be verified, then
an authorized service center can program the
actual mileage into the odometer of the
replacement cluster. The actual mileage (if
known) or an estimated mileage (if unknown) is
shown on a label affixed on the door pillar.
File:rclgg.ex
Update:Tue Jan 30 08:07:51 1996
Page 77 of 329
74
*
[LG34410( GV)01/95]
Press the E/M (English/Metric) button located
just below the message center display to show
miles or kilometers.
*
[LG34420( GV)01/95]
If the odometer displays the word ªERRORº
contact your dealer for service.
%
*
[LG46700( GV)04/95]
The Electronic Message Center
(If equipped)
*
[LG46800( GV)01/95]
Along with information the warning lights and
gauges provide, the electronic message center
lets you:
*
[LG47000( GV)01/95]
q
see problems such as Door Ajar, Air
Suspension, Trunk Ajar, Washer Fluid
*
[LG47100( GV)01/95]
q
see how many miles/kilometers you can
drive with the fuel remaining in your tank
[LG47200( GV)05/94]
q
see when overdrive has been turned off
*
[LG47300( GV)01/95]
q
monitor your average fuel economy
*
[LG47400( GV)01/95]
q
monitor your instantaneous fuel economy
*
[LG47600( GV)01/95]
q
check the distance you have travelled during
a trip on either Trip A or Trip B
*
[LG47700( GV)01/95]
q
monitor your average speed
[LG47900( GV)05/95]
one third page art:0010518-H
Message center display showing all segments on
File:rclgg.ex
Update:Tue Jan 30 08:07:51 1996
Page 245 of 329
243 [SV10227( ALL)05/95]
Gasoline and gasoline blends may contain small
amounts of carcinogens, such as benzene.
Long-term exposure to unleaded gasoline vapors
has caused cancer in laboratory animals.
[SV10230( ALL)05/95]
If you are taking the medication ªAntabuseº or
other forms of disulfiram for the treatment of
alcoholism, vapor or skin contact with a
gasoline-methanol blend may cause the same
kind of adverse reaction as drinking an alcoholic
beverage. In sensitive individuals, serious
personal injury or sickness could result. Consult
a physician promptly if you experience an
adverse reaction.
[SV11300( ALL)05/95]
Running Out of Fuel
[SV11350( ALL)05/95]
NOTE: Avoid running out of fuel because this
situation may have an adverse effect on
modern powertrain components.
[SV11500( ALL)05/95]
You may need to crank the engine several times
before the fuel system starts to pump fuel from
the tank to the engine.
[SV11600( ALL)05/95]Calculating Fuel Economy
[SV11700( ALL)05/95]
Fuel economy is an estimate of the efficiency of
your vehicle, and can be calculated as Miles Per
Gallon (MPG) or Liters Per 100 Kilometers
(L/100K).
[SV11750( ALL)05/95]
Do not calculate fuel economy during your
vehicle's break-in period. This would not be an
accurate estimate of how much fuel your vehicle
will normally use.
[SV11800( ALL)05/95]
To calculate fuel economy:
[SV11900( ALL)05/95]
1. Fill the fuel tank completely and record the
initial odometer reading.
[SV12000( ALL)05/95]
2. Every time you buy fuel, record the
amount (in gallons or liters) purchased.
File:rcsvg.ex
Update:Wed Jun 28 16:19:38 1995
Page 246 of 329
244 [SV12100( ALL)05/95]3. After at least 3-5 tankfuls, fill the fuel tank
and record the final odometer reading.
[SV12200( ALL)05/95]
4. Use these equations to calculate your fuel
economy:
[SV12250( ALL)05/95]
q
English: MPG = (total miles driven)V
(gallons used)
[SV12275( ALL)05/95]
q
Metric: L/100k = (liters used)V
(100 kilometers)
[SV12300( ALL)05/95]
Comparisons With EPA Estimates
[SV12400( ALL)05/95]
EPA fuel economy figures are obtained from
laboratory tests under simulated road conditions
and may not reflect the actual conditions you
experience or your style of driving. The EPA
fuel economy estimate is not a guarantee that
you will achieve the fuel economy shown.
[SV12650( ALL)05/95]
The following decrease fuel economy:
[SV12700( ALL)05/95]
q
Lack of regular, scheduled maintenance
[SV12800( ALL)05/95]
q
Rapid acceleration and excessive speed
[SV12850( ALL)05/95]
q
Driving with your foot on the brake
[SV12900( ALL)05/95]
q
Sudden stops
[SV12950( ALL)05/95]
q
Extended engine idling
[SV13000( ALL)05/95]
q
Using speed control in hilly terrain
[SV13100( ALL)05/95]
q
Extended use of the A/C, defroster, rear
window defroster and other accessories
[SV13200( ALL)05/95]
q
Underinflated tires
[SV13300( ALL)05/95]
q
Heavy loads
[SV13400( ALL)05/95]
q
Aftermarket add-ons such as bike, ski or
luggage racks, bug deflectors, etc.
File:rcsvg.ex
Update:Wed Jun 28 16:19:38 1995
Page 317 of 329
320 Index
Fuel and distance computer (continued)
select button.............. 75
to empty indicator........... 76
trip distance.............. 79
trip/reset button............ 79
Fuel cap, removing........... 239
Fuel filter, specifications......... 292
Fuel gauge.............. 58,71
Fuel pump shut-off switch, starting
after a collision............. 45
Fuse panels
engine compartment.......... 275
high current fuse panel........ 276
instrument panel........... 271
Fuses
charts................ 273
checking and replacing........ 278
circuit breakers............ 279
G
Gas cap (see Fuel cap).......... 239
Gasoline (see Fuel)............ 239
Gauges, Electronic
engine coolant temperature gauge.... 64
fuel gauge............... 71
odometer................ 73
speedometer.............. 73
Gauges, Mechanical
battery voltage gauge.......... 60
engine coolant temperature gauge.... 58
engine oil pressure gauge........ 61
fuel gauge............... 58
odometer................ 60
speedometer.............. 60
trip odometer.............. 60
GAWR (Gross Axle Weight Rating)
calculating.............. 186
definition............... 186
location............... 186
File:rcixg.ex
Update:Wed Jan 31 09:58:27 1996
Page 322 of 329
Index 325
O
Odometer
description............. 60,73
trip odometer............. 60
Oil filter................ 292
Oil (see Engine oil)........... 245
Oil viscosity.............. 246
On-board diagnostic (OBD II) system . . . 288
Overdrive............... 175
P
Panic alarm feature, remote
entry system............. 132
Parking brake
operation.............. 180
warning light............ 49,85
Parts (see Motorcraft Parts)....... 292
PCV valve, specifications........ 292
Power distribution box (see Fuses).... 271
Power door locks............ 124
Power features
antenna............... 154
door locks.............. 124
lumbar support............ 138
mirrors............... 141
seats................. 138
windows............... 134
Power point electrical outlet....... 145
Power steering
driving with power steering...... 178
fluid, checking and adding...... 270
fluid, refill capacity.......... 291
fluid, specifications.......... 293
servicing............... 178
File:rcixg.ex
Update:Wed Jan 31 09:58:27 1996
Page 326 of 329
Index 329
Towing a trailer (see Trailer towing) . . . 188
Towing your vehicle,
with a tow truck........... 211
Traction assist............. 177
Traction-lok rear axle.......... 176
Trailer towing
calculating maximum trailer weight . . 189
safety chains............. 192
tips................. 194
trailer brakes............. 192
trailer lamps............. 193
Transmission
automatic operation.......... 171
fluid, checking and adding
(automatic)............ 266
fluid, refill capacities......... 291
lubricant specifications........ 293
Transmission control switch....... 174
Transmitter (see Remote entry)...... 130
Trip odometer.............. 60
Trunk
remote release lever.......... 147
trunk ajar warning light......... 82
using the keys to open........ 146
using the remote entry
system to open........... 131
Tune-up specifications (VECI)...... 288
Turn signal
indicator lights........... 57,70
lever................ 111
U
Used engine oil, disposal........ 248
File:rcixg.ex
Update:Wed Jan 31 09:58:27 1996
