clock Mercury Grand Marquis 1997 Owner's Manuals

49
*
[AS10378( GV)03/96]
Adjusting the tone balance of your radio
*
[AS10379( GV)03/96]
q
Increasing or decreasing bass and treble
response
*
[AS10380( GV)03/96]
Push the ªBASS/TREBº popout knob to gain
access to the bass and treble controls. Bass
control allows you to adjust the lower, bass
frequencies to your preference. The outer ring
of the ªBASS/TREBº knob adjusts the bass
(turn clockwise to increase bass;
counterclockwise to decrease bass).
*
[AS10381( GV)03/96]
Treble control allows you to adjust the
higher, treble frequencies of your radio to
your preference. The inner ring of the
ªBASS/TREBº knob adjusts the treble (turn
clockwise to increase treble; counterclockwise
to decrease treble).
*
[AS10382( GV)03/96]
q
Adjusting speaker balance and speaker fader
*
[AS10383( GV)03/96]
Push the ªBAL/FADEº popout knob to gain
access to the speaker balance and fader
controls. Balance control allows you to adjust
the sound distribution between the right and
left speakers. The outer ring of ªBAL/FADEº
knob adjusts the speaker balance control.
(Turn clockwise to shift the sound to the
right speakers, and turn counterclockwise to
shift the sound to the left speakers.)
*
[AS10384( GV)03/96]
Fade control allows you to adjust the sound
distribution between the front and rear
speakers. The inner ring of the ªBAL/FADEº
knob adjusts the speaker fader. (Turn
clockwise to shift the sound to the rear
speakers, and turn counterclockwise to shift
the sound to the front speakers.)
File:04rcasg.ex
Update:Mon Sep 23 08:30:54 1996

67
Controls and Features
%*
[CF00200( ALL)01/96]
The main controls for the climate control system,
clock, and radio are on the instrument panel.
%*
[CF00300( ALL)03/96]
NOTE: Any cleaner or polish that increases the
gloss (shine) of the upper part of the
instrument panel should be avoided.
The dull finish in this area is to help
protect the driver from undesirable
windshield reflection.
*
[CF00400( ALL)03/96]
Your vehicle has a variety of features designed
for your comfort, convenience and safety. Read
this chapter to find out about standard and
optional features.
%
*
[CF00500( ALL)03/96]
The Climate Control Systems
[CF00600( ALL)12/95]
Your vehicle has one of two different climate
control systems. The two systems are:
[CF00900( BCGV)12/95]
q
a manual heating and air conditioning system
[CF01100( GV)12/95]
q
an electronic automatic temperature control
system
*
[CF01200( ALL)12/95]
If you are not sure which system your vehicle
has, see the diagrams on the following pages.
% [CF03500( BCGV)12/95]
The Manual Heating and Air Conditioning
System
[CF03600( BCGV)04/96]
You can heat the inside of your vehicle, defrost
the windshield, and turn on the air conditioning
with the three controls in the center of the
instrument panel:
[CF03700( BCGV)12/95]
q
FAN
[CF03800( BCGV)12/95]
q
TEMP
[CF03900( BCGV)12/95]
q
SELECT
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

68 [CF04000( GV)12/95]
one third page art:0010621-EThe controls for the manual heating and air conditioning
system
[CF04200( GV)12/95]
For maximum heating, move the SELECT knob
to FLOOR, move the TEMP knob to the end of
the red range (full clockwise) and move the fan
speed to HI.
% [CF04400( GV)12/95]
To heat the interior of your vehicle and defrost
the windshield at the same time, move the
SELECT knob to MIX and select the temperature
and fan speed desired.
[CF04600( GV)12/95]
For maximum defrosting, move the SELECT
knob to DEFROSTV, move the temperature to
the end of the red range (full clockwise) and
operate the fan as necessary to provide the
volume of air required.
% [CF04800( GV)12/95]
For ventilation, move the SELECT knob to VENT
and select the temperature and blower speed
desired.
[CF05000( GV)12/95]
To cool the inside of your vehicle quickly, in
warm weather, move the SELECT knob to MAX
A/C, move the TEMP knob to the end of the
blue range (full counterclockwise) and move the
fan to HI.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

69 [CF05200( GV)12/95]
If the inside of the vehicle is very warm, drive
for the first few minutes with the windows open
to force the hot, stale air out of the vehicle.
[CF05400( GV)12/95]
Fan speed can be reduced, after a comfortable
temperature has been reached, to provide quieter
system operation.
[CF05600( GV)12/95]
To cool your vehicle using outside air, move the
SELECT knob to NORM A/C, move the TEMP
knob to the end of the blue range (full
counterclockwise) and set the fan to the desired
speed. Cooling your vehicle in this way provides
quieter operation, but it is not as economical as
MAX A/C.
[CF05800( GV)12/95]
The instrument panel registers may be adjusted
to control the quantity and direction of air being
discharged. The thumbwheel controls the volume
of air and the knob in the center of the register
directs the air up and down or side to side.
[CF06000( GV)12/95]
When the SELECT knob is moved to OFF, the
system is off and the fan will not operate.
% [CF06100( BCGV)12/95]
Adjusting the panel register airflow
[CF06200( BCGV)04/96]
The instrument panel registers may be adjusted
to your comfort needs. The thumbwheel controls
the volume of air and the control in the center
of the register controls direction up or down or
side to side.
%*
[CF08700( GV)12/95]
Electronic Automatic Temperature Control
System
*
[CF08800( GV)05/96]
The Electronic Automatic Temperature Control
(EATC) module is located at the center of the
instrument panel and operates only when the
key is in the ON position.
*
[CF08900( GV)12/95]
The EATC feature maintains the temperature
you select and automatically controls the airflow
for your comfort. It also allows you to override
the automatic operation with manual override
buttons.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

83 [CF17700( BCGV)12/95]
Chime for headlamps on
*
[CF17800( ALL)12/95]
This chime sounds if the driver or any passenger
door is open when the parking lamps or
headlamps are on. The chime sounds until you
close the door, turn off the lamps or turn the
ignition to the ON position.
%*
[CF17900( GV)05/96]
Setting the Autolamp On/Off Delay
System
*
[CF18100( BCGV)01/96]
The autolamp sets the headlamps to turn on and
off automatically. You can use the autolamp to:
*
[CF18200( BCGV)01/96]
q
turn on the lamps automatically at night
*
[CF18300( BCGV)01/96]
q
turn off the lamps automatically during
daylight
*
[CF18400( BCGV)01/96]
q
keep the lamps on for up to three minutes
after you turn the key to OFF.
[CF18500( GV)12/95]
one third page art:0010198-F
The autolamp system on the left side of the instrument
panel
[CF18800( GV)12/95]
To activate the autolamp feature, simply turn the
headlamp knob counterclockwise towards the
autolamp delay area. The autolamp
automatically turns the lamps on and off for
you.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

84
*
[CF19400( BCGV)10/95]
Do not put any articles on top of the photocell
that is located in the top right corner of the
instrument panel. This photocell controls the
autolamp. If you cover it, the photocell reacts as
if it is nighttime, and the lamps turn on.
[CF19600( GV)12/95]
You can adjust the autolamp to keep the lamps
on after you leave your vehicle. The further you
move the headlamp knob to the left
(counterclockwise), the longer the lamps stay on.
*
[CF19700( BCGV)01/96]
You can set the autolamp so the lamps stay on
for up to three minutes after you turn your
vehicle off.
%*
[CF20000( ALL)01/96]
Lighting Up the Interior and Instrument
Panel
[CF20400( GV)12/95]
With the parking lamps or headlamps
illuminated, you can brighten or dim the lights
in the instrument panel. To do this, locate the
switch above the headlight control knob and
press it up (to brighten the lights) or down (to
dim the lights). To turn the interior lights on
and off, push the headlamp knob in.
[CF20700( GV)12/95]
one third page art:0011308-B
The knob controls the light on the instrument panel and
the interior light (autolamp feature shown Ð other models
similar)
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

85
%*
[CF20800( ALL)03/96]
Clock
[CF20900( GV)12/95]
quarter page art:0011295-B
The digital clock
[CF21200( ALL)12/95]
1. To set the hour, press and hold the H
button. When the desired hour appears,
release the button.
[CF21300( ALL)12/95]
2. To set the minutes, press and hold the M
button. When the desired minute appears,
release the button.
%
*
[CF21400( GV)12/95]
Ashtray and Cupholder
[CF21500( GV)12/95]
Your vehicle is equipped with an
ashtray/cupholder mounted to the lower center
of the instrument panel.
*
[CF21600( GV)12/95]
To open the ashtray, pull out the bottom edge of
the drawer until it stops.
*
[CF21700( GV)12/95]
To close, remove cup(s) and push drawer
forward until closed.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

165 %
*
[GF06800( ALL)05/96]
Putting Your Vehicle in Gear
*
[GF06900( ALL)05/96]
RWARNING
Hold the brake pedal down while you
move the gearshift lever from position to
position. If you do not hold the brake
pedal down, your vehicle may move
unexpectedly and injure someone.
*
[GF07000( GV)03/96]
To move the shifter out of P (Park), the ignition
key must be turned to the ON position. This
vehicle is also equipped with the brake shift
interlock safety feature which prevents shifting
the transmission out of the P (Park) position
without the brake pedal being depressed if the
key is in the ON position.
*
[GF07200( ALL)12/95]
To operate:
*
[GF07300( ALL)12/95]
1. Start the engine.
*
[GF07400( ALL)12/95]
2. Depress and hold the brake pedal.
*
[GF07500( ALL)12/95]
3. Move the gearshift lever out of P (Park).
%*
[GF07600( ALL)12/95]
Your vehicle is equipped with a Brake Shift
Interlock safety feature. This feature prevents the
gearshift from being moved from the P (Park)
position until the brake pedal is depressed. This
feature is active when the ignition is in the ON
position. If the gearshift lever CANNOT be
moved from P (Park) with the brake pedal
depressed:
*
[GF07700( ALL)12/95]
1. Turn the engine off and remove the ignition
key.
*
[GF07800( ALL)12/95]
2. Apply parking brake.
*
[GF07900( ALL)04/96]
3. Reinsert the ignition key and turn clockwise
to the first position.
*
[GF08000( ALL)01/96]
4. Depress the brake pedal, move the gearshift
lever to N (Neutral) and start the engine.
File:09rcgfg.ex
Update:Thu Sep 19 12:26:42 1996

191 [ER13500( GV)12/95]
quarter page art:0010573-A
The air suspension switch Ð located in the trunk
*
[ER13600( ALL)05/96]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
*
[ER13700( ALL)01/96]
2. Get out the spare tire and jack.
*
[ER13800( GV)01/96]
RWARNING
On vehicles equipped with Air
Suspension, turn OFF the Air Suspension
switch prior to jacking, hoisting or towing
your vehicle.
[ER14100( GV)12/95]
3. Remove any optional wheel covers or wheel
ornaments with the tapered end of a wheel
nut wrench. Insert the handle of the wrench
and twist it against the inner wheel cover
flange. For more about removing wheel
covers, see the information later in this
section.
[ER14300( GV)12/95]
4. Loosen each wheel lug nut one-half turn
counterclockwise, but do not remove them
until the tire is raised off the ground. You
should pull up on the handle rather than
push to develop maximum force to loosen
wheel lug nuts.
File:10rcerg.ex
Update:Wed Jun 19 09:54:58 1996

192 %
*
[ER14400( ALL)01/96]
Removing and Replacing the Tire
[ER14700( GV)12/95]
1. Find the jacking location notches (a
depression on plastic moulding) near the tire
that you are changing. Align the two tabs on
jack with rectangular notch on sheet metal.
Slowly push jack straight until the tabs are
against the side of the frame. MAKE SURE
THE JACK IS PROPERLY POSITIONED
UNDER THE FRAME. Turn the handle of
the jack clockwise until the wheel is
completely off the ground.
*
[ER14800( ALL)01/96]
RWARNING
To lessen the risk of personal injury, do
not put any part of your body under the
vehicle while changing a tire. Do not start
the engine when your vehicle is on the
jack. The jack is only meant for changing
the tire.
[ER15000( ALL)12/95]
half page art:0010759-A
The improper lift point
File:10rcerg.ex
Update:Wed Jun 19 09:54:58 1996
