Page 13 of 305
10
%*
[IS01700( BCGV)01/96]
The Mechanical Cluster
*
[IS02000( BCGV)01/96]
The following warning lights and gauges are on
the mechanical cluster. All of the warning lights
and gauges alert you to possible problems with
your vehicle. Some of the lights listed are
optional. The following sections detail what each
of these indicators means.
%*
[IS02600( ALL)01/96]
Brake System Warning Light
*
[IS02700( ALL)03/96]
The warning light for the brakes can show two
things Ð that the parking brake is not fully
released, or that the brake fluid level is low in
the master cylinder reservoir. If the fluid level is
low, the brake system should be checked by a
qualified service technician.
[IS03050( GV)05/96]
one inch art:0010681-C
The brake system warning light
[IS03100( ALL)05/96]
This light comes on when the parking brake is
set, or if it is not set, it comes on briefly when
you turn the ignition key to START. It normally
goes off shortly after the engine starts and you
release the parking brake. If the light stays on
after you have fully released the parking brake,
have the hydraulic brake system serviced.
*
[IS03200( ALL)03/96]
RWARNING
The BRAKE light indicates that the brakes
may not be working properly. Have the
brakes checked immediately.
File:03rcisg.ex
Update:Tue Jun 11 13:54:07 1996
Page 17 of 305
14
*
[IS07800( ALL)03/96]
This light illuminates every time you turn the
ignition to the ON or START position (engine
off). The light should go off when the engine
starts and the alternator begins to charge.
*
[IS07900( ALL)03/96]
If the light stays on or illuminates when the
engine is running, have the electrical system
checked as soon as possible.
%*
[IS08400( BCGV)03/96]
Overdrive Off Indicator
[IS08600( ALL)04/96]
one inch art:0010730-B
The overdrive off indicator light
*
[IS08700( ALL)04/96]
This light tells you that the Transmission Control
Switch (TCS) has been pushed. When the light is
on, the transmission will not shift into overdrive.
Depressing the button will return the vehicle to
ªoverdrive onº mode. The transmission will be
in the ªoverdrive onº mode when the vehicle is
started even if the O/D OFF mode was selected
when the vehicle was last shut off.
[IS08900( ALL)05/96]
NOTE: If the light does not come on when the
TCS is depressed or if the light flashes
when you are driving, have your
vehicle serviced at the first
opportunity. If this condition persists,
damage could occur to the
transmission.
File:03rcisg.ex
Update:Tue Jun 11 13:54:07 1996
Page 19 of 305
16 [IS10700( GV)01/96]Normally, the light will glow momentarily as
you turn the ignition key to the ON position. If
it glows continuously:
[IS10800( GV)01/96]
1. Safely pull off the road as soon as possible.
Turn the ignition key from ON to OFF and
ON again.
[IS10900( GV)01/96]
2. If the light still glows, check to see if the air
suspension switch is OFF. If it is OFF, push
the switch ON. If it is ON, push the switch
OFF and have the system checked as soon as
possible.
%*
[IS11000(M GV)03/96]
Check Engine Warning Light
%*
[IS11100( ALL)05/96]
This light illuminates when the engine's
Emission Control System requires service. It will
also illuminate when the ignition key is in the
ON position and the engine is off.
[IS11300(M GV)05/96]
one inch art:0010134-B
The check engine warning light
%*
[IS12300( ALL)03/96]
Turn Signal Indicator Lights
*
[IS12400( ALL)03/96]
The turn signal arrow will flash to indicate the
direction in which you are going to be turning.
[IS12500( ALL)04/96]
one inch art:0010525-A
The turn signal indicator light
File:03rcisg.ex
Update:Tue Jun 11 13:54:07 1996
Page 24 of 305
21 [IS22905( GV)05/96]
4. If the level is low, add oil as necessary
before you start the engine again. Do not
overfill. Do not operate the engine if the
pointer in the oil pressure gauge is below
the normal band, regardless of the oil level.
Contact your nearest dealer for further
service actions.
[IS23000(M GV)04/96]
For more information about adding oil, see
Engine Oil Recommendationsin the Index.
%
*
[IS25102( GV)03/96]
The Electronic Cluster
*
[IS25104( GV)03/96]
The electronic cluster works only when your
ignition is in the ON position. Each time you
start your vehicle, the displays go through a
self-test by flashing on and off once before the
actual readings are displayed. (Neither the turn
signals nor the high beam indicator light will
flash like the other indicators do for the
self-test.) Some of the warning lights will flash
on and remain on (will not immediately flash
off) until the normal cluster display is lit. This
self-test is used to indicate that all of the
warning/indicator lights are working properly.
*
[IS25106( GV)03/96]
Your electronic cluster tells you about the
condition of your vehicle by using two types of
equipment:
*
[IS25108( GV)03/96]
q
warning lights and gauges
*
[IS25109( GV)03/96]
q
message center
File:03rcisg.ex
Update:Tue Jun 11 13:54:07 1996
Page 41 of 305
38
*
[IS32500( GV)05/96]
If the light is displayed while driving and the
air suspension switch is not turned off, safely
pull off the road as soon as possible. Turn the
ignition switch from ON to OFF and to ON
again. If the light continues to be displayed turn
the air suspension switch (located in the trunk
on the right side) off and take your vehicle to a
dealership for service as soon as possible.
[IS32600( GV)05/96]
one inch art:0010522-A
The check air suspension light
%*
[IS32700( GV)03/96]
Overdrive Off Indicator
[IS32800( GV)05/96]
one inch art:0010733-B
The overdrive off indicator light
*
[IS32900( GV)04/96]
This light tells you that the Transmission Control
Switch (TCS) has been pushed. When the light is
on, the transmission will not shift into overdrive.
Depressing the button will return the vehicle to
ªoverdrive onº mode. The transmission will be
in the ªoverdrive onº mode when the vehicle is
started even if the O/D OFF mode was selected
when the vehicle was last shut off.
File:03rcisg.ex
Update:Tue Jun 11 13:54:07 1996
Page 167 of 305
167 %
*
[GF08800( ALL)05/96]
R (Reverse)
*
[GF08900( ALL)05/96]
With the gearshift in the R (Reverse) position,
the vehicle will move backward. You should
always come to a complete stop before shifting
into or out of R (Reverse).
*
[GF09000( ALL)01/96]
N (Neutral)
[GF09100( ALL)12/95]
As in P (Park), there is no power transferred
through the transmission. However, the final
drive is not locked so the wheels are free to
rotate. The vehicle may be started in the N
position, but the ignition key cannot be
removed.
%*
[GF09200( ALL)05/96]
Driving
[GF09300( GV)12/95]
Your vehicle's gearshift is on the steering
column. The Transmission Control Switch (TCS)
is located on the end of the gearshift lever. The
Transmission Control Indicator Light (O/D OFF)
is located on the instrument panel. You can put
the gearshift lever in any of the several
positions.
[GF09600( GV)12/95]
The O/D OFF light is off (not illuminated)
during normal vehicle operation. This allows the
transmission to upshift and downshift from 1st
through 4th gears. When the TCS is pressed, the
Transmission Control Indicator Light will
illuminate (O/D OFF) on the instrument panel.
When this O/D OFF is illuminated the
transmission will upshift and downshift from 1st
through 3rd gears.
[GF09800( ALL)12/95]
If the O/D OFF light does not come ªonº when
the TCS is depressed or if the light ªFLASHESº
when you are driving, have your vehicle
serviced at the first opportunity. If this condition
persists, damage could occur to the transmission.
File:09rcgfg.ex
Update:Thu Sep 19 12:26:42 1996
Page 284 of 305
Index 295
Index
A
ABS warning light (see Anti-lock
brake system)........... 11,41
Accessory position on the ignition..... 87
Additives, engine oil.......... 211
Air bag supplemental
restraint system............ 133
and child safety seats......... 139
description.............. 133
driver air bag............ 133
indicator light........... 13,25
operation.............. 135
passenger air bag........... 135
service and information labels..... 135
tone generator............ 137
Air cleaner filter
location............... 209
specifications............. 253
Air conditioning
electronic automatic temperature control
system............... 69
manual heating and air
conditioning system......... 67
Air suspension
description.............. 163
see also Rear air suspension system . . 163
Alarm, activating remote personal.... 115
Aluminum wheels............ 196
Antenna, radio (see Electronic
sound system)............. 50
Antifreeze (see Engine coolant)...... 217
Anti-lock brake system (ABS)
description.............. 157
see also Brake............ 157
warning light............ 11,41
