If the leather cannot be completely cleaned using a mild soap and water
solution, the leather may be cleaned using a commercially available
cleaning product ªTanners Preserve Leather Cleanerº and a 3M ªType T'
scrubbing pad by using the following steps;
The type of scrubbing pad is very critical because the common 3M
ªScotch Briteº green pad is too aggressive and will damage the
leather surface
²Spray a small amount of the leather cleaner on the pad and rub the
area to be cleaned with the pad using a circular motion. Only clean 1/4
of the area at a time. For heavily soiled areas, spray the cleaner
directly onto the leather (two squirts should be adequate) and rub
with the pad. Repeat if necessary.
²Use a soft, damp cloth to remove the loosened dirt and foam.
²Dry with a soft cloth.
Do not use household cleaners, glass cleaner, alcohol solutions or
cleaner intended for vinyl, rubber or plastics. These products can
damage the leather.
In some instances, color or dye transfer can occur when wet
clothing (wool, denim, leathers or other non-colorfast garments)
comes in contact with leather upholstery. If this occurs, the
leather should be cleaned immediately to avoid permanent
staining.
ªTanners Preserve Leather Cleanerº (product number AS-300) is
available from ªFirst Brandsº by calling 1±800±726±1001. This product
may also be available at many local automotive after market stores.
3M ªType Tº Clean And Finish Scrubbing Pads (UPC 04011±01276) are
available through your local 3M distributor. Call 1±800±742±9649 for the
nearest distributor in your area.
PART NUMBER PART NAME
(Obtain Locally) Tanners Preserve Leather Cleaner
(Obtain Locally) 3M9Type T9Clean and Finish Scrubbing Pads
Inside windows
Use glass cleaner for the inside windows if they become fogged.
Maintenance and care
141

MOTORCRAFT PART NUMBERS
Component 4.6L SOHC V8 engine
Air filter FA-1032
Fuel filter FG-800A
Battery (standard) BXT-59
Battery (optional) BXT-65-650
Oil filter FL-820-S
PCV valve EV-98
Spark plugs* AWSF-32PP
* Refer to Vehicle Emissions Control Information (VECI) decal for
spark plug gap information. If a spark plug is removed for inspection, it
must be reinstalled in the same cylinder. Cylinders No. 1, 2, 3 and 4
have a9PG9suffix and Cylinders No. 5, 6, 7 and 8 have a9P9suffix. If a
spark plug needs to be replaced, use only spark plugs with the service
number suffix letter as shown on the engine decal.
Capacities and specifications
142

REFILL CAPACITIES
Fluid Ford Part Name Capacity
Engine oil (includes
filter change)Motorcraft 5W30 Super
Premium Motor Oil4.7L (5.0 quarts)
Brake fluid High Performance DOT 3
Motor Vehicle Brake
FluidFill to line on
reservoir
Power steering fluid Motorcraft MERCONt
AT FFill to line on
reservoir
Transmission fluid Motorcraft MERCONtV
AT F13.1L (13.9 quarts)
Engine coolant
213.3L (14.1 quarts)
Fuel tank N/A 71.9L (19.0 gallons)
Rear axle fluid
1Motorcraft SAE 80W90
Rear Axle Lubricant1.8-1.9L (3.75-4.0
pints)
Windshield washer
fluidUltra-Clear Windshield
Washer ConcentrateFill to line on
reservoir
1Add 118 ml (4 oz.) of additive friction modifier C8AZ-19B546±A, Ford
specification EST-M2C118±A for complete refill of Traction-Lok axles.
Service refill capacities are determined by filling the rear axle 6 mm to
14 mm (1/4 inch to 9/16 inch) below the bottom of the filler hole.
Rear axles are considered lubricated for life when the vehicle is used for
normal service. See your ªService Guideº for Severe Duty requirements.
2If your engine coolant is green, use Ford Premium Cooling System
Fluid; if your coolant is orange, use Ford Extended Life Coolant. Refer to
Lubricant Specificationsfor part numbers and specification numbers.
Capacities and specifications
143

LUBRICANT SPECIFICATIONS
Item Ford part name Ford part
numberFord
specification
Brake fluid High Performance
DOT 3 Motor Vehicle
Brake FluidC6AZ-
19542-ABESA-M6C25-A
and DOT 3
Door
weatherstripsSilicone Lubricant
C0AZ-19553-
AA and D7AZ-
19553-AAESR-M13P4-A
Engine coolant
222
Engine oil Motorcraft 5W-30
Super Premium
Motor OilXO-5W30-
QSPWSS-M2C153-
G with API
Certification
Mark
Hinges, latches,
striker plates,
fuel filler door
hinge and seat
tracksMulti-Purpose
GreaseDOAZ-19584-
AA or F5AZ-
19G209-AAESB-M1C93-B
or ESR-
M1C159-A
Lock cylinders Penetrating
LubricantE8AZ-
19501-Bnone
Power steering
fluidMotorcraft
MERCONtAT FXT-2-QDX MERCONt
Automatic trans-
mission (4R70W)Motorcraft
MERCONtVATFXT-5-QM
MERCONtV
Rear axle
1Motorcraft Premium
Rear Axle LubricantXY-80W90-QL WSL-
M2C197-A
Windshield
washer fluidUltra-Clear
Windshield Washer
ConcentrateC9AZ-
19550-ABESR-M17P5-A
1Add 118 ml (4 oz.) of additive friction modifier C8AZ-19B546±A, Ford
specification EST-M2C118±A for complete refill of Traction-Lok axles.
2If your coolant is green, use Ford Premium Cooling System Fluid, part number
E2FZ-19659±AA, specification number ESE-M97B44±A; if your coolant is orange,
use Ford Extended Life Coolant, part number F6AZ-19544±AA, specification
number WSS-M97B44±B or DEX-COOL equivalent.
Capacities and specifications
144

ENGINE DATA
Engine 4.6L SOHC V8 engine
Cubic inches 281
Horsepower-single exhaust 200 @ 4250 rpm
Horsepower-dual exhaust 215 @ 4500 rpm
Torque-single exhaust 265 lb. ft. @ 3000 rpm
Torque-dual exhaust 275 lb. ft. @ 3000 rpm
Required fuel grade 87 octane
Firing order 1-3-7-2-6-5-4-8
Spark plug gap 1.3-1.4 mm (0.052-.056 inch)
Ignition system Coil on plug
Compression ratio 9.0:1
VEHICLE DIMENSIONS
Vehicle dimensions mm (in)
(1) Overall length 5 382 (211.9)
(2) Overall width 1 987 (78.2)
(3) Overall height 1 443 (56.8)
(4) Wheelbase 2 913 (114.4)
(5) Track - Front 1 611 (63.4)
(5) Track - Rear 1 659 (65.3)
Capacities and specifications
145

3
5
2
4
1
Capacities and specifications
146

IDENTIFYING YOUR VEHICLE
Safety compliance label
The National Highway Traffic Safety
Administration Regulations require
that a Safety Compliance
Certification Label be affixed to a
vehicle and prescribe where the
Safety Compliance Certification
Label may be located. The Safety
Compliance Certification Label is
located on the front door latch pillar
on the driver's side.
Vehicle identification number
The vehicle identification number is
attached to a metal tag and is
located on the driver side
instrument panel.
Engine number
The engine number (the last eight numbers of the vehicle identification
number) is stamped on the engine block, transmission, frame and
transfer case (if equipped).
MFD. BY FORD MOTOR CO. IN U.S.A.
EXT PNT: XXXXXX XXXXXX RC: XX DSO: XXXX F0000
BAR INT TR TP/PS R AXLE TR SPR T0000
X XX XXX X XX X XXXX
UTC
ÑFOHT-15294A10-GA
MAXIMUM LOAD=OCCUPANTS + LUGGAGE=XXXKG/XXXXLB
OCCUPANTS: X TOTAL X FR X 2ND X RR OCCUPANTS LUGGAGE
XX XXXKG/XXXXLB
TIRE: XXXX/XXXXX XXX X XXXKG/XXXXLB
PRESSURE (FR) XXX kPa/33 PSI COLD
PRESSURE (RR) XXX kPa/33 PSI COLD
TRAILER TOWING - SEE OWNER GUIDE
DATE: XXXXX GVWR:XXXXX LB/ XXXXX KG
VIN: XXXXXXXXXXXXXXXXX TYPE: XXXXXXXXXXXXXXX FGAWR: XXXXXX/XXXXXXX RGAWR: XXXXXXX/XXXXXXX
THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL
MOTOR VEHICLE SAFETY STANDARDS IN EFFECT ON THE
DATE OF MANUFACTURE SHOWN ABOVE.
XXXXXXXXXXXXXXXXX
AIR BAG
Capacities and specifications
147

REPORTING SAFETY DEFECTS (U.S. ONLY)
If you believe that your vehicle has
a defect that could cause a crash, or
could cause injury or death, you
should immediately inform the
National Highway Traffic Safety
Administration (NHTSA) in addition
to notifying Ford Motor Company.
If NHTSA receives similar complaints, it may open an investigation, and
if it finds that a safety defect exists in a group of vehicles, it may order a
recall and remedy campaign. However, NHTSA cannot become involved
in individual problems between you, your dealer or Ford Motor Company.
To contact NHTSA, you may either call the Auto Safety Hotline toll-free
at 1±800±424±9393 (202±366±0123 in the Washington D.C. area) or write
to:
NHTSA
U.S. Department of Transportation
400 Seventh Street
Washington D.C. 20590
You can also obtain other information about motor vehicle safety from
the Hotline.
Reporting safety defects
148

Aiming headlamps ....................135
Air bag supplemental
restraint system ..........................67
and child safety seats ..............68
description ................................67
disposal ......................................71
indicator light ...........................70
passenger air bag .....................69
Air conditioning
manual heating and air
conditioning system ............25,26
Air suspension
description ................................86
Anti-lock brake system
(ABS)#$description
Battery .......................................120
voltage gauge ............................16
Brake fluid
checking and adding ..............112
Brakes ..........................................82
anti-lock .....................................82
anti-lock brake system
(ABS) warning light .................83
fluid, checking and adding ....112
traction control .........................84
Brake-shift interlock ...................87
Break-in period .............................2
Bulbs, replacing ........................133
specifications ..........................136
Changing a tire .........................100
Child safety seats ........................72
Childproof locks ..........................48
Chime
headlamps on ............................11
Cleaning your vehicle ...............137
engine compartment .......138,139
exterior ....................................140
headlamps ...............................139
plastic parts ............................139
washing ....................................137
waxing .....................................137
wheels ......................................138windows ..................................141
wiper blades ............................139
Climate control system
automatic temperature
control ...................27,28,29,30,32
Clock ............................................33
Compass, electronic ....................43
calibration .................................44
set zone adjustment .................44
Coolant (see Engine coolant)
temperature gauge ...................15
Defrost
rear window ..............................24
Emission control system ..........131
Engine
service points ..........................109
Engine block heater ...................80
Engine coolant
checking and adding ..............114
disposal ....................................115
refill capacities ........................115
Engine oil ...........................110,111
changing oil and oil filter .......112
checking and adding .......110,111
Exhaust fumes ............................81
Floor mats ...................................49
Fuel
calculating fuel economy .......130
improving fuel economy ..........93
octane rating ...........................129
quality ......................................130
running out of fuel .................130
safety information relating
to automotive fuels ................127
Fuel pump shut-off switch .........94
Fuse panels
instrument panel ......................96
power distribution box .............98
Fuses .......................................95,96
Gauges, Mechanical ....................12
fuel gauge ..................................12
Hazard flashers ...........................94
Index
149

Headlamps ...................................23
autolamp system .......................24
daytime running lights .............24
flashing ......................................23
high beam .................................23
Heating ........................................25
High beams
indicator light .............................9
Hood
release lever ............................108
Ignition
positions of the ignition ...........35
Instrument panel
cleaning ...................................140
lighting up panel and interior .23
Keyless entry system
autolock .....................................50
keypad .......................................55
programming entry code ....55,56
Keys
key in ignition chime ...............11
Lamps
headlamps ...............................133
high-mount brakelamp ...........135
interior lamps .........................136
parking lamps .........................134
tail lamps .................................135
License plate lamps ..................135
Lights, warning and indicator
air bag ..........................................8
air suspension ...........................10
anti-lock brakes (ABS) .........8,22
brake .......................................8,22
charging system ..........................9
check engine ............................6,7
fuel reset .....................................6
low coolant ................................10
oil pressure .................................9
overdrive off ..............................10
safety belt ...................................8
turn signal indicator ...................9
Lubricant specifications ...........144Message center ...........................17
reset button .........................17,18
select button .............................18
Mirrors
automatic dimming
rearview mirror .........................42
side view mirrors (power) .......47
Motorcraft parts ........................142
Odometer .....................................14
Panic alarm feature,
remote entry system ..................51
Parking brake ..............................83
Power door locks ........................47
Power steering
fluid, checking and adding ....118
Radio ............................................33
Refill capacities for fluids ........143
Relays ...................................95,100
Remote entry system .................49
illuminated entry ......................51
locking/unlocking doors ...........49
replacement/additional
transmitters ...............................53
replacing the batteries .............52
Reporting safety defects ..........148
Safety restraints
cleaning the safety belts ........140
extension assembly ..................65
for children ...............................71
lap and shoulder belts ...61,62,63
maintenance ..............................66
proper use .................................60
warning light
and chime ........................11,65,66
Safety seats for children
attaching with tether straps ....76
in rear seat ................................76
tether anchorage hardware .....76
Seats ............................................57
adjusting the seat, manual ..57,58
adjusting the seat, power ...58,60
cleaning upholstery ................140
Index
150
