MOTORCRAFT PART NUMBERS
Component 4.6L SOHC V8 engine
Air filter element FA-1668
Fuel filter FG-986B
Battery (standard) BXT-59
Battery (optional) BXT-65-650
Oil filter FL-820-S
PCV valve EV-98
Spark plugs* AWSF-32P
* Refer to Vehicle Emissions Control Information (VECI) decal for spark
plug gap information.
REFILL CAPACITIES
Fluid Ford Part Name Capacity
Engine oil (includes
filter change)Motorcraft 5W-30 Super
Premium Motor Oil4.7L
(5.0 quarts)
Brake fluid High Performance DOT 3
Motor Vehicle Brake FluidFill to line on
reservoir
Power steering fluid Motorcraft MERCONtATF Fill to line on
reservoir
Transmission fluid Motorcraft MERCONtV ATF 13.1L
(13.9 quarts)
Engine coolant
1Premium Engine Coolant 15.0L
(15.8 quarts)
Fuel tank N/A 71.9L
(19.0 gallons)
Rear axle lubricant
2Motorcraft SAE 80W90
Premium Rear Axle Lubricant1.8-1.9L
(3.75-4.0 pints)
Windshield washer
fluidUltra-Clear Windshield
Washer ConcentrateFill to line on
reservoir
1Use Ford Premium Engine Coolant (green in color). DO NOT USE Ford
Extended Life Engine Coolant (orange in color). Refer toAdding engine
coolant, in the Maintenance and Care chapter.
2Rear axles are considered lubricated for life when the vehicle is used
for normal service. See your Scheduled Maintenance Guide for Severe
Duty requirements. Traction-Lok axles use 2.2±2.4L (4.75±5.0 pints) of
Capacities and specifications
175
Page 195 of 200
Radio ..............35,36,37,38,39,40,42
43,44,45,46,47,48,49,50,51
Relays .................................121,126
Remote entry system ............70,73
illuminated entry ......................74
locking/unlocking doors ...........71
replacement/additional
transmitters ...............................75
replacing the batteries .............74
Safety Compliance
Certification Label ....................179
Safety defects, reporting ..........192
Safety restraints ...........84,85,86,87
cleaning the safety belts ...89,174
extension assembly ..................88
for children ...............................94
lap belt ......................................87
warning light and chime .....88,89
Seat belts (see Safety
restraints) ....................................84
Seats ............................................80
child safety seats ......................95
cleaning ...................................174
Servicing your vehicle ..............136
Spark plugs, specifications .......175
Specification chart, lubricants .176
Speed control ..............................58
Starting your vehicle .........101,103
jump starting ............130,131,133
preparing to start your
vehicle .......................................75
Steering wheel
tilting .........................................57Tires ....................................153,154
changing ...........................126,127
checking the pressure ............154
replacing ..................................156
rotating ....................................154
snow tires and chains ............157
tire grades ...............................154
treadwear ................................153
Towing .........................117,118,119
wrecker ....................................135
Traction control ........................109
Transmission .............................112
fluid, checking and adding
(automatic) ...............147,148,149
Trunk ...........................................73
remote release ..........................67
Vehicle dimensions ...................177
Vehicle Identification Number
(VIN) ..........................................179
Vehicle loading ..........................115
Ventilating your vehicle ...........105
Warning chimes ......................11,22
Washer fluid ..............................142
Water, Driving through .............119
Wheels
anti-theft lug nuts ...........129,130
Windows .................................67,68
Windshield washer fluid and
wipers
checking and cleaning ............152
operation ...................................56
replacing wiper blades ...........152
Index
195
