mirror controls Mercury Grand Marquis 2001 Owner's Manuals

AUTOMATIC DIMMING INSIDE REAR VIEW MIRROR (IF EQUIPPED)
Your vehicle is equipped with an
inside rear view mirror which has an
auto-dimming function. The
electronic day/night mirror will
change from the normal state to the
non-glare state when bright lights
(glare) reach the mirror. When the
mirror detects bright light from
front or behind, it will automatically
adjust (darken) to minimize glare.
Do not block the sensor on the backside of the mirror since this may
impair proper mirror performance.
Press the control to turn the mirror on or off.
ELECTRONIC COMPASS (IF EQUIPPED)
The compass reading will remain accurate during most driving
conditions. Unknown to the driver, the compass is continuously
recalibrating due to magnetic fields and subtle, slow changes in vehicle
magnetics which can occur over the life of the vehicle.
The compass reading will remain fixed when significant levels are
experienced (such as steel bridges). The compass will return to normal
operation upon leaving the magnetized area.
If highly magnetized items (such as magnetic mount antennas) are
placed very near the compass the display will change to ªCº for 15
seconds, then display all segments until the magnetized item is removed.
If a ªCº is displayed, refer toCompass calibration adjustment.
Most geographic areas (zones) have a magnetic north compass point that
varies slightly from the northerly direction on maps. This variation is four
degrees between adjacent zones and will become noticeable as the
vehicle crosses multiple zones. A correct zone setting will eliminate this
error. Refer toCompass zone adjustment.
COMP MIRROR
Controls and features
78

Compass zone adjustment
1. Determine which compass zone
you are in by referring to the zone
map.
2. With the compass display turned
on, press and hold the COMP side of
the control for no more than six
seconds until the zone selection
number appears in the mirror
display window. If a ªCº appears
repeat this step.
3. Release the COMP side of the
control, then press it down again.
4. Continue to press until your zone number is shown in the mirror
display, then release.
5. The display will show all segments, then return to normal compass
mode within ten seconds.
Compass calibration adjustment
Perform this adjustment in an open area free from steel structures and
high voltage lines.
1. Start the vehicle.
1
2
3
4
5
6
7891011121314 15
COMP MIRROR
NW
Controls and features
79

2. Press and hold the COMP side of
the control for approximately six
seconds until ªCº appears in the
mirror display.
3. Drive the vehicle slowly (less
than 5 km/h [3 mph]) in circles or
on your everyday routine until the
display reads a direction.
4. The compass is now calibrated.
FUEL DOOR RELEASE
Your vehicle is equipped with a
locking fuel door. To open the door,
press the control located on the
door.
Fuel filler door override release
If the remote release is inoperative,
open the trunk, then pull the
override release handle located
inside the trunk to open the fuel
filler door.
COMP MIRROR
NW
FUEL TRUNK
Controls and features
80

POWER SIDE VIEW MIRRORS
To adjust your mirrors:
1. Select
to adjust the
left mirror or
to adjust the right
mirror.
2. Move the control in the direction
you wish to tilt the mirror.
3. Return to the center position to
lock mirrors in place.
CHILDPROOF DOOR LOCKS
When these locks are set, the rear
doors cannot be opened from the
inside. The rear doors can be
opened from the outside when the
doors are unlocked.
The childproof locks are located on
rear edge of each rear door and
must be set separately for each
door. Setting the lock for one door will not automatically set the lock for
both doors.
Move lock control up to engage the childproof lock. Move control down
to disengage childproof locks.
CENTER CONSOLE (IF EQUIPPED)
Your vehicle may be equipped with a variety of console features. These
include:
²Utility compartment
²Power point (rear of console)
²Cupholders
²Air vents to the rear seating positions (heat only)
Controls and features
83

engine compartment ..............213
exterior ............................211±212
exterior lamps .........................212
instrument cluster lens ..........215
instrument panel ....................214
interior .....................................215
mirrors .....................................212
plastic parts ............................212
safety belts ..............................215
washing ....................................211
waxing .....................................211
wheels ......................................212
windows ..................................215
wiper blades ............................213
woodtone trim ........................215
Climate control (see Air
conditioning or Heating) ............29
Clock ............................................64
Compass, electronic ....................78
calibration .................................79
set zone adjustment .................79
Console ........................................83
Controls
power seat .......................100±101
steering column ........................73
Coolant
checking and adding ..............175
coolant temperature light ........11
refill capacities ................179, 216
specifications ..................218±219
Cruise control (see Speed
control) ........................................69
Customer Assistance ................149
Ford accessories for your
vehicle .....................................229
Ford Extended
Service Plan ............................222
Getting assistance outside the
U.S. and Canada .....................228Getting roadside assistance ...149
Getting the service
you need .................................222
Ordering additional owner's
literature .................................231
The Dispute Settlement
Board .......................................224
Utilizing the
Mediation/Arbitration
Program ...................................227
D
Daytime running lamps
(see Lamps) ................................27
Defrost
rear window ..............................38
Dipstick
automatic transmission
fluid ..........................................183
engine oil .................................171
Doors
lubricant specifications ..........218
Driving under special conditions
through water .........................148
E
Electronic message center .........22
Emergencies, roadside
jump-starting ..........................162
Emission control system ..........203
Engine ................................219±220
check engine/service engine
soon light ....................................9
cleaning ...................................213
coolant .....................................175
fail-safe coolant ......................180
idle speed control ...................186
Index
235
