EXCEPTIONS
In addition, there are several exceptions to the Normal Schedule. They
are listed below:
Normal vehicle axle maintenance
❑Rear axles and power take-off (PTO) units containing synthetic lubricant and light duty trucks equipped with Ford-design
axles are lubricated for life. These lubricants are not to be checked or changed unless a leak is suspected, service is re-
quired or the axle assembly has been submerged in water. The axle and PTO lubricant should be changed anytime the axle
and PTO have been submerged in water. During extended trailer tow operation above 70°F (21°C) ambient and wide open
throttle for extended periods above 45 mph (72 km/h), non-synthetic rear axle lubricants should be replaced every
3,000 miles (4,800 km) or three months, whichever occurs first. The 3,000 mile (4,800 km) lubricant change interval
may be waived if the axle was filled with 75W140 synthetic gear lubricant meeting Ford specification WSL-M2C192-A, part
number F1TZ-19580-B or equivalent. Add friction modifier XL-3 (EST-M2C118-A) or equivalent for complete refill of Traction-
Lok rear axles (refer to
Maintenance product and specificationsin theMaintenance and Specificationschapter for details).
The axle lubricant should be changed anytime an axle has been submerged in water.
Police/Taxi/Livery vehicle axle maintenance
❑Replace rear axle lubricant every 100,000 miles (160,000 km). Rear axle lubricant change may be waived if the axle
was filled with 75W140 synthetic gear lubricant meeting Ford specification WSL-M2C192-A, part number FITZ-19580-B or
equivalent. Add four ounces (118 mL) of friction modifier XL-3 (EST-M2C118-A) or equivalent for complete refill of Traction-
Lok rear axles. The axle lubricant should be changed anytime the axle has been submerged in water.
California fuel filter replacement
❑If vehicle is registered in California, the California Air Resources Board has determined that the failure to perform this main-
tenance item will not nullify the emission warranty or limit recall liability prior to the completion of the vehicle’s useful life.
Ford Motor Company, however, urges you to have all recommended maintenance services performed at the specified inter-
vals and to record all vehicle service.
Hot climate oil change intervals
❑If operating conditions are normal and you drive your Ford, Lincoln or Mercury vehicle under typical, everyday conditions
andyou are using an API performance category oil of SL or later (for example SM, etc.) then you can follow the
7,500 mile (12,000 km) normal service oil change intervals schedule. Vehicles operating in the Middle East, North Africa,
Sub-Saharan Africa or locations with similar climates must follow the oil change interval of 3,000 mile (5,000 km) if the
owner is using oils defined by the American Petroleum Institute (API) performance category of API SK or earlier (for ex-
ample SJ, etc.).
Engine air filter & cabin air filter replacement
❑Engine air filter and cabin air filter life is dependent on exposure to dusty and dirty conditions. Vehicles operated in these
conditions will require frequent inspection and replacement of the engine air filter and cabin air filter.
Scheduled Maintenance Guide
353
2011 Mariner(mrn)
Owners Guide, 1st Printing
USA(fus)

A
Accessory delay ..........................70
Active Park Assist .....................229
AdvanceTrac ..............................214
Air cleaner filter .......316, 318, 320
Air conditioning
automatic temperature
control system ..........................47
manual heating and air
conditioning system .................44
Airbag supplemental restraint
system ........................136, 145, 148
and child safety seats ............138
description ..............136, 145, 148
disposal ....................................151
driver airbag ............138, 146, 149
indicator light .........144, 147, 150
operation .................138, 146, 149
passenger airbag .....138, 146, 149
side airbag ...............................145
All Wheel Drive (AWD),
driving off road .........................234
Ambient mood/lighting ...............57
Ambulance packages ....................6
AM/FM .........................................26
Antifreeze (see Engine
coolant) .....................................295
Anti-lock brake system
(see Brakes) ......................212–213
Anti-theft system ......................105
Audio system (see Radio) .........26
Automatic transmission
driving an automatic
overdrive .................................222
fluid, refill capacities ..............321
fluid, specification ..................321Auxiliary input jack (Line in) ....34
Auxiliary power point .................69
Axle
lubricant specifications ..........321
refill capacities ........................321
B
Battery .......................................293
acid, treating emergencies .....293
jumping a disabled battery ....263
maintenance-free ....................293
replacement, specifications ...320
servicing ..................................293
Belt-Minder.............................131
Blind spot mirror ......................233
Booster seats .............................165
Brakes ........................................212
anti-lock ...........................212–213
anti-lock brake system (ABS)
warning light ...........................213
fluid, checking and adding ....314
fluid, refill capacities ..............321
fluid, specifications .................321
lubricant specifications ..........321
parking ....................................213
shift interlock ..........................221
Bulbs ............................................57
C
Capacities for refilling fluids ....321
Car2UHome Automation
System .........................................78
Cargo area shade ........................85
Cargo management system ........85
CD ................................................26
Cell phone use ..............................9
Index
356
2011 Mariner(mrn)
Owners Guide, 1st Printing
USA(fus)

lubrication specifications .......321
refill capacities ........................321
service points ..................285–286
starting after a collision .........243
Engine block heater .................210
Engine oil ..................................289
checking and adding ..............289
dipstick ....................................289
filter, specifications ........292, 320
recommendations ...................292
refill capacities ........................321
specifications ..........................321
Event data recording ....................7
Exhaust fumes ..........................210
F
Fail safe cooling ........................299
Fleet MyKey programming ........90
Flexible Fuel Vehicle (FFV) ....301
Floor mats .............................83–84
Fluid capacities .........................321
Fog lamps ....................................52
Four-Wheel Drive vehicles
driving off road .......................235
preparing to drive your
vehicle .....................................220
Fuel ............................................301
calculating fuel
economy ............................20, 308
cap ...........................................304
capacity ...................................321
choosing the right fuel ...........305
detergent in fuel .....................306
filler funnel .............................307
filling your vehicle
with fuel ..................301, 304, 308
filter, specifications ........300, 320fuel pump shut-off switch .....243
improving fuel economy ........308
octane rating ...................305, 324
quality ......................................306
running out of fuel .........262, 307
safety information relating to
automotive fuels .....................301
Fuel - flex fuel vehicle
(FFV) .................................301, 305
Fuses ..................................244–245
G
Garage door opener ....................77
Gas cap (see Fuel cap) ............304
Gas mileage (see Fuel
economy) ...................................308
Gauges .........................................16
H
Hazard flashers .........................243
Headlamps ...................................51
aiming ........................................54
bulb specifications ....................58
daytime running lights .............53
flash to pass ..............................53
high beam .................................52
replacing bulbs .........................59
turning on and off ....................51
Heating
heating and air conditioning
system .......................................47
manual heating and air
conditioning system .................44
Hood ..........................................285
I
Ignition ...............................206, 324
Index
358
2011 Mariner(mrn)
Owners Guide, 1st Printing
USA(fus)
