stop start Mercury Mercury Cougar 1997 s User Guide

218 [MC15700(MBC )12/95]3.8L engine only
[MC15800(MBC )12/95]
q
Open the vent plug.
[MC15900(MBC )12/95]
q
Remove coolant recovery reservoir cap.
[MC16000(MBC )12/95]
q
Remove radiator pressure cap.
[MC16100(MBC )12/95]
q
With the engine off and cool, add a 50/50
mixture of recommended cooling system fluid
and water to the radiator until full, then add
to the reservoir until the reservoir is at the
FULL-HOT level.
[MC16200(MBC )12/95]
q
Close the vent plug.
[MC16300(MBC )12/95]
q
Reinstall the coolant recovery reservoir cap
by installing the cap to the fully installed
position.
[MC16400(MBC )12/95]
q
Reinstall the pressure cap to the pressure
relief position by installing the cap to the
fully installed position, and then backing off
to the first stop.
[MC16500(MBC )12/95]
q
Start and idle engine until the radiator upper
hose is warm (this indicates the thermostat is
open and coolant is flowing through the
entire system).
[MC16600(MBC )12/95]
q
Immediately shut off engine. Cover cap
completely with a thick cloth and cautiously
remove radiator pressure cap and add a
50/50 mixture of recommended coolant and
water until system is full.
[MC16700(MBC )12/95]
q
Reinstall the radiator cap securely.
[MC16800(MBC )12/95]
q
Remove the cap from the engine coolant
recovery reservoir and add a 50/50 mixture
of recommended cooling system fluid and
water to the FULL-HOT mark on the engine
coolant recovery reservoir. Check that
reservoir hose is not kinked.
[MC16900(MBC )12/95]
q
Reinstall the reservoir cap.
File:11rcmcc.ex
Update:Mon Jun 3 09:27:52 1996

226 %
*
[MC23600( ALL)01/96]
Help Us Protect Our Environment
*
[MC23700( ALL)01/96]
Ford Motor Company strongly recommends that
used lead-acid batteries be returned to an
authorized recycling facility for disposal.
*
[MC23800( ALL)01/96]
one inch art:0000983-A
Battery recycling symbol
%*
[MC24000( BCGV)12/95]
Because your vehicle's engine is electronically
controlled by a computer, some control
conditions are maintained by power from the
battery. If you ever disconnect the battery or
install a new battery, you must allow the
computer to ªrelearnº its idle conditions before
your vehicle will drive properly. To let the
engine do this, put the gearshift in P (Park), turn
off all the accessories, and start the vehicle. Let
the engine idle for at least one minute. (Engine
must be warm in order to ªlearn.º) Also, allow
approximately 10 miles (16 km) of stop and go
traffic for your vehicle's engine to completely
ªrelearnº its idle.
%
*
[MC24300( ALL)02/96]
Wiper Blades
*
[MC24400( ALL)01/96]
Check the windshield wiper blades at least twice
a year. Also check them whenever they seem
less effective than usual. Substances such as tree
sap and some hot wax treatments used by
commercial car washes reduce the effectiveness
of wiper blades.
*
[MC24500( ALL)01/96]
If the blades do not wipe properly, clean both
the windshield and the wiper blades. Use
undiluted windshield washer solution or a mild
detergent. Rinse thoroughly with clear water. Do
File:11rcmcc.ex
Update:Mon Jun 3 09:27:52 1996

242 %
*
[MC38200( ALL)01/96]
Information about your vehicle's emission
control system is on the Vehicle Emission
Control Information decal located on or near the
engine. This decal identifies engine displacement
and gives some tune-up specifications.
%*
[MC38300( ALL)03/96]
How to Prepare Your Vehicle for
Inspection/Maintenance (I/M) Testing
*
[MC38400( ALL)05/96]
In some localities it may become a legal
requirement to pass an
Inspection/Maintenance (I/M) test of the
On-Board Diagnostic (OBD) II system. If the
vehicle's powertrain system or its battery has
just been serviced, the OBD II system is reset to
a not ready for I/M testing condition. To
prepare for I/M testing, the law specifies that
additional mixed city and highway driving is
required to complete the check of the OBD II
system.
*
[MC38601( ALL)05/96]
The driving modes required to reach the ready
condition consist of a minimum of 30 minutes of
city and highway driving as described below:
*
[MC38701( ALL)05/96]
q
At least twenty minutes driving in stop and
go, city type traffic with at least four idle
periods.
*
[MC38801( ALL)05/96]
q
At least ten minutes of driving on an
expressway or highway.
[MC38901( ALL)04/96]
Before completing the above driving modes, the
engine must be warmed up and at operating
temperature. Once started, the vehicle must not
be turned off during these driving modes.
File:11rcmcc.ex
Update:Mon Jun 3 09:27:52 1996
